Standard Gauges
Fuji
[Fuji] — 178MA R Gauge
Family ID: 431-0011
The Fuji 178MA R Gauge is a precision measuring instrument designed to check radius dimensions on workpiece profiles, sourced direct from Korea. R gauges of this type are commonly used by machinists, toolmakers, and quality control personnel to verify concave and convex radii on turned, milled, or formed parts during production and inspection. Request a quote today for export-ready supply of this Fuji gauging tool at competitive pricing, fulfilled by a KITA-registered Korean exporter.
6 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| 431-0011 | 178MA | Fuji | 178MA (1~7mm) | Interval: 0.25/0.5 | Measurement Range: 1.0~7.0 | Set Quantity: 34 | ||
| 431-0020 | 178MB | Fuji | 178MB (7.5-15mm) | Pitch: 0.5 | Measuring Range: 7.5~15.0 | Set Quantity: 32 | ||
| 431-0039 | 178MC(MR) | Fuji | 178MC(MR) (15.5-25.0mm) | Graduation: 0.5/1.0 | Measurement Range: 15.5~25.0 | Set Quantity: 30 | ||
| 431-0048 | 178MD | Fuji | 178MD (24-30mm) | Pitch: 1.0 | Measurement Range: 24.0~30.0 | Set Quantity: 14 | ||
| 431-0057 | 178ME | Fuji | 178ME (31-40mm) | Class Interval: 1.0 | Measurement Range: 31.0~40.0 | Set Quantity: 20 | ||
| 431-2611 | 178MAA | Fuji | 178MAA | Graduation: 0.1 | Measurement Range: 0.1~1.0 | Set Quantity: 20 |
