[GGM] — KGC-3657-U2 Spur Geared DC Motor (ø36, DC 24V, 6000rpm base, 32 ratios 1/2-1/2430)
Family ID: GGM-KGC3657-U2
GGM KGC-3657-U2 spur geared DC motor, ø36 frame, DC 24V (6000 rpm base motor). 32 gear ratios 1/2-1/2430, output torque up to 6 kgf·cm, ø6 output shaft on 3-M3 PCD ø31 flange. Stall 5 A / 1.6 kgf·cm.
32 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| KGC-0002-KD3657U2 | KGC-3657-U2 spur geared, 1/2, 2500rpm, 0.3kgf·cm | GGM | Gear Ratio: 1/2 | Output Speed: 2500 rpm | Output Torque: 0.3 kgf·cm | Gearhead Length L: 21 mm | ||
| KGC-0003-KD3657U2 | KGC-3657-U2 spur geared, 1/3, 1666rpm, 0.5kgf·cm | GGM | Gear Ratio: 1/3 | Output Speed: 1666 rpm | Output Torque: 0.5 kgf·cm | Gearhead Length L: 21 mm | ||
| KGC-0005-KD3657U2 | KGC-3657-U2 spur geared, 1/5, 1000rpm, 0.8kgf·cm | GGM | Gear Ratio: 1/5 | Output Speed: 1000 rpm | Output Torque: 0.8 kgf·cm | Gearhead Length L: 21 mm | ||
| KGC-0010-KD3657U2 | KGC-3657-U2 spur geared, 1/10, 500rpm, 1.6kgf·cm | GGM | Gear Ratio: 1/10 | Output Speed: 500 rpm | Output Torque: 1.6 kgf·cm | Gearhead Length L: 21 mm | ||
| KGC-0015-KD3657U2 | KGC-3657-U2 spur geared, 1/15, 333rpm, 2.1kgf·cm | GGM | Gear Ratio: 1/15 | Output Speed: 333 rpm | Output Torque: 2.1 kgf·cm | Gearhead Length L: 21 mm | ||
| KGC-0020-KD3657U2 | KGC-3657-U2 spur geared, 1/20, 250rpm, 2.9kgf·cm | GGM | Gear Ratio: 1/20 | Output Speed: 250 rpm | Output Torque: 2.9 kgf·cm | Gearhead Length L: 21 mm | ||
| KGC-0025-KD3657U2 | KGC-3657-U2 spur geared, 1/25, 200rpm, 3.6kgf·cm | GGM | Gear Ratio: 1/25 | Output Speed: 200 rpm | Output Torque: 3.6 kgf·cm | Gearhead Length L: 21 mm | ||
| KGC-0030-KD3657U2 | KGC-3657-U2 spur geared, 1/30, 166rpm, 4.3kgf·cm | GGM | Gear Ratio: 1/30 | Output Speed: 166 rpm | Output Torque: 4.3 kgf·cm | Gearhead Length L: 21 mm | ||
| KGC-0040-KD3657U2 | KGC-3657-U2 spur geared, 1/40, 125rpm, 5.2kgf·cm | GGM | Gear Ratio: 1/40 | Output Speed: 125 rpm | Output Torque: 5.2 kgf·cm | Gearhead Length L: 29 mm | ||
| KGC-0050-KD3657U2 | KGC-3657-U2 spur geared, 1/50, 100rpm, 6kgf·cm | GGM | Gear Ratio: 1/50 | Output Speed: 100 rpm | Output Torque: 6 kgf·cm | Gearhead Length L: 29 mm | ||
| KGC-0060-KD3657U2 | KGC-3657-U2 spur geared, 1/60, 83rpm, 6kgf·cm | GGM | Gear Ratio: 1/60 | Output Speed: 83 rpm | Output Torque: 6 kgf·cm | Gearhead Length L: 29 mm | ||
| KGC-0070-KD3657U2 | KGC-3657-U2 spur geared, 1/70, 71rpm, 6kgf·cm | GGM | Gear Ratio: 1/70 | Output Speed: 71 rpm | Output Torque: 6 kgf·cm | Gearhead Length L: 29 mm | ||
| KGC-0083-KD3657U2 | KGC-3657-U2 spur geared, 1/83, 60rpm, 6kgf·cm | GGM | Gear Ratio: 1/83 | Output Speed: 60 rpm | Output Torque: 6 kgf·cm | Gearhead Length L: 29 mm | ||
| KGC-0090-KD3657U2 | KGC-3657-U2 spur geared, 1/90, 55rpm, 6kgf·cm | GGM | Gear Ratio: 1/90 | Output Speed: 55 rpm | Output Torque: 6 kgf·cm | Gearhead Length L: 29 mm | ||
| KGC-0100-KD3657U2 | KGC-3657-U2 spur geared, 1/100, 50rpm, 6kgf·cm | GGM | Gear Ratio: 1/100 | Output Speed: 50 rpm | Output Torque: 6 kgf·cm | Gearhead Length L: 29 mm | ||
| KGC-0120-KD3657U2 | KGC-3657-U2 spur geared, 1/120, 41rpm, 6kgf·cm | GGM | Gear Ratio: 1/120 | Output Speed: 41 rpm | Output Torque: 6 kgf·cm | Gearhead Length L: 29 mm | ||
| KGC-0150-KD3657U2 | KGC-3657-U2 spur geared, 1/150, 33rpm, 6kgf·cm | GGM | Gear Ratio: 1/150 | Output Speed: 33 rpm | Output Torque: 6 kgf·cm | Gearhead Length L: 29 mm | ||
| KGC-0180-KD3657U2 | KGC-3657-U2 spur geared, 1/180, 27.7rpm, 6kgf·cm | GGM | Gear Ratio: 1/180 | Output Speed: 27.7 rpm | Output Torque: 6 kgf·cm | Gearhead Length L: 29 mm | ||
| KGC-0200-KD3657U2 | KGC-3657-U2 spur geared, 1/200, 25rpm, 6kgf·cm | GGM | Gear Ratio: 1/200 | Output Speed: 25 rpm | Output Torque: 6 kgf·cm | Gearhead Length L: 33.7 mm | ||
| KGC-0210-KD3657U2 | KGC-3657-U2 spur geared, 1/210, 23.8rpm, 6kgf·cm | GGM | Gear Ratio: 1/210 | Output Speed: 23.8 rpm | Output Torque: 6 kgf·cm | Gearhead Length L: 33.7 mm | ||
| KGC-0240-KD3657U2 | KGC-3657-U2 spur geared, 1/240, 20.8rpm, 6kgf·cm | GGM | Gear Ratio: 1/240 | Output Speed: 20.8 rpm | Output Torque: 6 kgf·cm | Gearhead Length L: 33.7 mm | ||
| KGC-0300-KD3657U2 | KGC-3657-U2 spur geared, 1/300, 16.6rpm, 6kgf·cm | GGM | Gear Ratio: 1/300 | Output Speed: 16.6 rpm | Output Torque: 6 kgf·cm | Gearhead Length L: 33.7 mm | ||
| KGC-0360-KD3657U2 | KGC-3657-U2 spur geared, 1/360, 13.8rpm, 6kgf·cm | GGM | Gear Ratio: 1/360 | Output Speed: 13.8 rpm | Output Torque: 6 kgf·cm | Gearhead Length L: 33.7 mm | ||
| KGC-0400-KD3657U2 | KGC-3657-U2 spur geared, 1/400, 12.5rpm, 6kgf·cm | GGM | Gear Ratio: 1/400 | Output Speed: 12.5 rpm | Output Torque: 6 kgf·cm | Gearhead Length L: 33.7 mm | ||
| KGC-0500-KD3657U2 | KGC-3657-U2 spur geared, 1/500, 10rpm, 6kgf·cm | GGM | Gear Ratio: 1/500 | Output Speed: 10 rpm | Output Torque: 6 kgf·cm | Gearhead Length L: 33.7 mm | ||
| KGC-0600-KD3657U2 | KGC-3657-U2 spur geared, 1/600, 8.3rpm, 6kgf·cm | GGM | Gear Ratio: 1/600 | Output Speed: 8.3 rpm | Output Torque: 6 kgf·cm | Gearhead Length L: 33.7 mm | ||
| KGC-0750-KD3657U2 | KGC-3657-U2 spur geared, 1/750, 6.6rpm, 6kgf·cm | GGM | Gear Ratio: 1/750 | Output Speed: 6.6 rpm | Output Torque: 6 kgf·cm | Gearhead Length L: 33.7 mm | ||
| KGC-0900-KD3657U2 | KGC-3657-U2 spur geared, 1/900, 5.5rpm, 6kgf·cm | GGM | Gear Ratio: 1/900 | Output Speed: 5.5 rpm | Output Torque: 6 kgf·cm | Gearhead Length L: 33.7 mm | ||
| KGC-1080-KD3657U2 | KGC-3657-U2 spur geared, 1/1080, 4.6rpm, 6kgf·cm | GGM | Gear Ratio: 1/1080 | Output Speed: 4.6 rpm | Output Torque: 6 kgf·cm | Gearhead Length L: 33.7 mm | ||
| KGC-1350-KD3657U2 | KGC-3657-U2 spur geared, 1/1350, 3.7rpm, 6kgf·cm | GGM | Gear Ratio: 1/1350 | Output Speed: 3.7 rpm | Output Torque: 6 kgf·cm | Gearhead Length L: 33.7 mm | ||
| KGC-1620-KD3657U2 | KGC-3657-U2 spur geared, 1/1620, 3rpm, 6kgf·cm | GGM | Gear Ratio: 1/1620 | Output Speed: 3 rpm | Output Torque: 6 kgf·cm | Gearhead Length L: 33.7 mm | ||
| KGC-2430-KD3657U2 | KGC-3657-U2 spur geared, 1/2430, 2rpm, 6kgf·cm | GGM | Gear Ratio: 1/2430 | Output Speed: 2 rpm | Output Torque: 6 kgf·cm | Gearhead Length L: 33.7 mm |
