KNIPEX — High Leverage Diagonal Cutter 74 02 Series
Family ID: 217-2295
KNIPEX 74 02 series high leverage diagonal cutter. Chrome vanadium steel. Hardness: 64 HRC. Available: 74 02 160 / 74 02 160 SB / 74 02 180 SB / 74 02 200 SB / 74 02 250 SB. Soft wire: 3.1–4.6mm / copper wire: 2.0–3.5mm. Origin: Germany.
5 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| 217-2295 | High leverage diagonal cutter. Chrome vanadium. Blade: 64 HRC. | KNIPEX | Model: 74 02 160 | Length: 160mm | Soft wire: 3.1mm | Copper wire: 2.0mm | Piano wire: 1.5mm | Weight: 157g | ||
| 217-3966 | High leverage diagonal cutter. Chrome vanadium. Blade: 64 HRC. | KNIPEX | Model: 74 02 160 SB | Length: 160mm | Soft wire: 3.8mm | Copper wire: 2.7mm | Piano wire: 2.2mm | Weight: 209g | ||
| 217-2301 | High leverage diagonal cutter. Chrome vanadium. Blade: 64 HRC. | KNIPEX | Model: 74 02 180 SB | Length: 180mm | Soft wire: 3.8mm | Copper wire: 2.7mm | Piano wire: 2.2mm | Weight: 157g | ||
| 215-9203 | High leverage diagonal cutter. Chrome vanadium. Blade: 64 HRC. | KNIPEX | Model: 74 02 200 SB | Length: 200mm | Soft wire: 4.4mm | Copper wire: 3.2mm | Piano wire: 2.5mm | Weight: 215g | ||
| 217-2310 | High leverage diagonal cutter. Chrome vanadium. Blade: 64 HRC. | KNIPEX | Model: 74 02 250 SB | Length: 250mm | Soft wire: 4.6mm | Copper wire: 3.5mm | Piano wire: 3.0mm | Weight: 437g |
