Geared Motors
MITSUBISHI ELECTRIC
[MITSUBISHI ELECTRIC] — GM-LJPB Parallel Shaft Geared Motor with Brake (11-22kW, Leg Mount, SF1.4)
Family ID: MEL-GM-LJP-LEG-B
Mitsubishi Electric GM-LJPB parallel shaft geared motor with built-in brake, 11 to 22kW, leg-mounted horizontal, service factor 1.4. Reduction ratios 1/3 to 1/60, output speeds 30 to 600 r/min at 60Hz. Integrated electromagnetic brake for load holding on inclined conveyors and hoist-type drives. Oil-lubricated, 3-phase, 4-pole. Flange mount (F-type) and vertical/horizontal orientations available on request. Brake unavailable on 22kW 1/45 and 30kW and above. Ships without oil; fill with recommended lubricant.
21 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| GM-LJPB 11kW 1/3 | GM-LJPB 11kW 1/3, leg (horizontal), gear size SM, brake | MITSUBISHI ELECTRIC | Series: GM-LJP · Type: Parallel Shaft · Service Factor: 1.4 · Mount: Leg (horizontal) · Brake: Built-in electromagnetic · Output: 11kW · Reduction Ratio: 1/3 · Output Speed: 600 r/min (60Hz) / 500 r/min (50Hz) · Poles: 4P · Phase: 3-phase · Gear Size: SM · Lubrication: Oil (ships without oil; fill recommended lubricant) · Availability: Made-to-order | ||
| GM-LJPB 11kW 1/5 | GM-LJPB 11kW 1/5, leg (horizontal), gear size SM, brake | MITSUBISHI ELECTRIC | Series: GM-LJP · Type: Parallel Shaft · Service Factor: 1.4 · Mount: Leg (horizontal) · Brake: Built-in electromagnetic · Output: 11kW · Reduction Ratio: 1/5 · Output Speed: 360 r/min (60Hz) / 300 r/min (50Hz) · Poles: 4P · Phase: 3-phase · Gear Size: SM · Lubrication: Oil (ships without oil; fill recommended lubricant) · Availability: Made-to-order | ||
| GM-LJPB 11kW 1/10 | GM-LJPB 11kW 1/10, leg (horizontal), gear size L, brake | MITSUBISHI ELECTRIC | Series: GM-LJP · Type: Parallel Shaft · Service Factor: 1.4 · Mount: Leg (horizontal) · Brake: Built-in electromagnetic · Output: 11kW · Reduction Ratio: 1/10 · Output Speed: 180 r/min (60Hz) / 150 r/min (50Hz) · Poles: 4P · Phase: 3-phase · Gear Size: L · Lubrication: Oil (ships without oil; fill recommended lubricant) · Availability: Made-to-order | ||
| GM-LJPB 11kW 1/15 | GM-LJPB 11kW 1/15, leg (horizontal), gear size L, brake | MITSUBISHI ELECTRIC | Series: GM-LJP · Type: Parallel Shaft · Service Factor: 1.4 · Mount: Leg (horizontal) · Brake: Built-in electromagnetic · Output: 11kW · Reduction Ratio: 1/15 · Output Speed: 120 r/min (60Hz) / 100 r/min (50Hz) · Poles: 4P · Phase: 3-phase · Gear Size: L · Lubrication: Oil (ships without oil; fill recommended lubricant) · Availability: Made-to-order | ||
| GM-LJPB 11kW 1/20 | GM-LJPB 11kW 1/20, leg (horizontal), gear size L, brake | MITSUBISHI ELECTRIC | Series: GM-LJP · Type: Parallel Shaft · Service Factor: 1.4 · Mount: Leg (horizontal) · Brake: Built-in electromagnetic · Output: 11kW · Reduction Ratio: 1/20 · Output Speed: 90 r/min (60Hz) / 75 r/min (50Hz) · Poles: 4P · Phase: 3-phase · Gear Size: L · Lubrication: Oil (ships without oil; fill recommended lubricant) · Availability: Made-to-order | ||
| GM-LJPB 11kW 1/30 | GM-LJPB 11kW 1/30, leg (horizontal), gear size M, brake | MITSUBISHI ELECTRIC | Series: GM-LJP · Type: Parallel Shaft · Service Factor: 1.4 · Mount: Leg (horizontal) · Brake: Built-in electromagnetic · Output: 11kW · Reduction Ratio: 1/30 · Output Speed: 60 r/min (60Hz) / 50 r/min (50Hz) · Poles: 4P · Phase: 3-phase · Gear Size: M · Lubrication: Oil (ships without oil; fill recommended lubricant) · Availability: Made-to-order | ||
| GM-LJPB 11kW 1/45 | GM-LJPB 11kW 1/45, leg (horizontal), gear size TN, brake | MITSUBISHI ELECTRIC | Series: GM-LJP · Type: Parallel Shaft · Service Factor: 1.4 · Mount: Leg (horizontal) · Brake: Built-in electromagnetic · Output: 11kW · Reduction Ratio: 1/45 · Output Speed: 40 r/min (60Hz) / 33 r/min (50Hz) · Poles: 4P · Phase: 3-phase · Gear Size: TN · Lubrication: Oil (ships without oil; fill recommended lubricant) · Availability: Made-to-order | ||
| GM-LJPB 11kW 1/60 | GM-LJPB 11kW 1/60, leg (horizontal), gear size TP, brake | MITSUBISHI ELECTRIC | Series: GM-LJP · Type: Parallel Shaft · Service Factor: 1.4 · Mount: Leg (horizontal) · Brake: Built-in electromagnetic · Output: 11kW · Reduction Ratio: 1/60 · Output Speed: 30 r/min (60Hz) / 25 r/min (50Hz) · Poles: 4P · Phase: 3-phase · Gear Size: TP · Lubrication: Oil (ships without oil; fill recommended lubricant) · Availability: Made-to-order | ||
| GM-LJPB 15kW 1/3 | GM-LJPB 15kW 1/3, leg (horizontal), gear size SN, brake | MITSUBISHI ELECTRIC | Series: GM-LJP · Type: Parallel Shaft · Service Factor: 1.4 · Mount: Leg (horizontal) · Brake: Built-in electromagnetic · Output: 15kW · Reduction Ratio: 1/3 · Output Speed: 600 r/min (60Hz) / 500 r/min (50Hz) · Poles: 4P · Phase: 3-phase · Gear Size: SN · Lubrication: Oil (ships without oil; fill recommended lubricant) · Availability: Made-to-order | ||
| GM-LJPB 15kW 1/5 | GM-LJPB 15kW 1/5, leg (horizontal), gear size SN, brake | MITSUBISHI ELECTRIC | Series: GM-LJP · Type: Parallel Shaft · Service Factor: 1.4 · Mount: Leg (horizontal) · Brake: Built-in electromagnetic · Output: 15kW · Reduction Ratio: 1/5 · Output Speed: 360 r/min (60Hz) / 300 r/min (50Hz) · Poles: 4P · Phase: 3-phase · Gear Size: SN · Lubrication: Oil (ships without oil; fill recommended lubricant) · Availability: Made-to-order | ||
| GM-LJPB 15kW 1/10 | GM-LJPB 15kW 1/10, leg (horizontal), gear size L, brake | MITSUBISHI ELECTRIC | Series: GM-LJP · Type: Parallel Shaft · Service Factor: 1.4 · Mount: Leg (horizontal) · Brake: Built-in electromagnetic · Output: 15kW · Reduction Ratio: 1/10 · Output Speed: 180 r/min (60Hz) / 150 r/min (50Hz) · Poles: 4P · Phase: 3-phase · Gear Size: L · Lubrication: Oil (ships without oil; fill recommended lubricant) · Availability: Made-to-order | ||
| GM-LJPB 15kW 1/15 | GM-LJPB 15kW 1/15, leg (horizontal), gear size M, brake | MITSUBISHI ELECTRIC | Series: GM-LJP · Type: Parallel Shaft · Service Factor: 1.4 · Mount: Leg (horizontal) · Brake: Built-in electromagnetic · Output: 15kW · Reduction Ratio: 1/15 · Output Speed: 120 r/min (60Hz) / 100 r/min (50Hz) · Poles: 4P · Phase: 3-phase · Gear Size: M · Lubrication: Oil (ships without oil; fill recommended lubricant) · Availability: Made-to-order | ||
| GM-LJPB 15kW 1/20 | GM-LJPB 15kW 1/20, leg (horizontal), gear size M, brake | MITSUBISHI ELECTRIC | Series: GM-LJP · Type: Parallel Shaft · Service Factor: 1.4 · Mount: Leg (horizontal) · Brake: Built-in electromagnetic · Output: 15kW · Reduction Ratio: 1/20 · Output Speed: 90 r/min (60Hz) / 75 r/min (50Hz) · Poles: 4P · Phase: 3-phase · Gear Size: M · Lubrication: Oil (ships without oil; fill recommended lubricant) · Availability: Made-to-order | ||
| GM-LJPB 15kW 1/30 | GM-LJPB 15kW 1/30, leg (horizontal), gear size N, brake | MITSUBISHI ELECTRIC | Series: GM-LJP · Type: Parallel Shaft · Service Factor: 1.4 · Mount: Leg (horizontal) · Brake: Built-in electromagnetic · Output: 15kW · Reduction Ratio: 1/30 · Output Speed: 60 r/min (60Hz) / 50 r/min (50Hz) · Poles: 4P · Phase: 3-phase · Gear Size: N · Lubrication: Oil (ships without oil; fill recommended lubricant) · Availability: Made-to-order | ||
| GM-LJPB 15kW 1/45 | GM-LJPB 15kW 1/45, leg (horizontal), gear size TP, brake | MITSUBISHI ELECTRIC | Series: GM-LJP · Type: Parallel Shaft · Service Factor: 1.4 · Mount: Leg (horizontal) · Brake: Built-in electromagnetic · Output: 15kW · Reduction Ratio: 1/45 · Output Speed: 40 r/min (60Hz) / 33 r/min (50Hz) · Poles: 4P · Phase: 3-phase · Gear Size: TP · Lubrication: Oil (ships without oil; fill recommended lubricant) · Availability: Made-to-order | ||
| GM-LJPB 22kW 1/3 | GM-LJPB 22kW 1/3, leg (horizontal), gear size SP, brake | MITSUBISHI ELECTRIC | Series: GM-LJP · Type: Parallel Shaft · Service Factor: 1.4 · Mount: Leg (horizontal) · Brake: Built-in electromagnetic · Output: 22kW · Reduction Ratio: 1/3 · Output Speed: 600 r/min (60Hz) / 500 r/min (50Hz) · Poles: 4P · Phase: 3-phase · Gear Size: SP · Lubrication: Oil (ships without oil; fill recommended lubricant) · Availability: Made-to-order | ||
| GM-LJPB 22kW 1/5 | GM-LJPB 22kW 1/5, leg (horizontal), gear size SP, brake | MITSUBISHI ELECTRIC | Series: GM-LJP · Type: Parallel Shaft · Service Factor: 1.4 · Mount: Leg (horizontal) · Brake: Built-in electromagnetic · Output: 22kW · Reduction Ratio: 1/5 · Output Speed: 360 r/min (60Hz) / 300 r/min (50Hz) · Poles: 4P · Phase: 3-phase · Gear Size: SP · Lubrication: Oil (ships without oil; fill recommended lubricant) · Availability: Made-to-order | ||
| GM-LJPB 22kW 1/10 | GM-LJPB 22kW 1/10, leg (horizontal), gear size N, brake | MITSUBISHI ELECTRIC | Series: GM-LJP · Type: Parallel Shaft · Service Factor: 1.4 · Mount: Leg (horizontal) · Brake: Built-in electromagnetic · Output: 22kW · Reduction Ratio: 1/10 · Output Speed: 180 r/min (60Hz) / 150 r/min (50Hz) · Poles: 4P · Phase: 3-phase · Gear Size: N · Lubrication: Oil (ships without oil; fill recommended lubricant) · Availability: Made-to-order | ||
| GM-LJPB 22kW 1/15 | GM-LJPB 22kW 1/15, leg (horizontal), gear size N, brake | MITSUBISHI ELECTRIC | Series: GM-LJP · Type: Parallel Shaft · Service Factor: 1.4 · Mount: Leg (horizontal) · Brake: Built-in electromagnetic · Output: 22kW · Reduction Ratio: 1/15 · Output Speed: 120 r/min (60Hz) / 100 r/min (50Hz) · Poles: 4P · Phase: 3-phase · Gear Size: N · Lubrication: Oil (ships without oil; fill recommended lubricant) · Availability: Made-to-order | ||
| GM-LJPB 22kW 1/20 | GM-LJPB 22kW 1/20, leg (horizontal), gear size N, brake | MITSUBISHI ELECTRIC | Series: GM-LJP · Type: Parallel Shaft · Service Factor: 1.4 · Mount: Leg (horizontal) · Brake: Built-in electromagnetic · Output: 22kW · Reduction Ratio: 1/20 · Output Speed: 90 r/min (60Hz) / 75 r/min (50Hz) · Poles: 4P · Phase: 3-phase · Gear Size: N · Lubrication: Oil (ships without oil; fill recommended lubricant) · Availability: Made-to-order | ||
| GM-LJPB 22kW 1/30 | GM-LJPB 22kW 1/30, leg (horizontal), gear size P, brake | MITSUBISHI ELECTRIC | Series: GM-LJP · Type: Parallel Shaft · Service Factor: 1.4 · Mount: Leg (horizontal) · Brake: Built-in electromagnetic · Output: 22kW · Reduction Ratio: 1/30 · Output Speed: 60 r/min (60Hz) / 50 r/min (50Hz) · Poles: 4P · Phase: 3-phase · Gear Size: P · Lubrication: Oil (ships without oil; fill recommended lubricant) · Availability: Made-to-order |
