Geared Motors
MITSUBISHI ELECTRIC
[MITSUBISHI ELECTRIC] — GM-PJPB Parallel Shaft Geared Motor with Brake (3.7-22kW, Leg Mount, SF1.0-2.0)
Family ID: MEL-GM-PJP-LEG-B
Mitsubishi Electric GM-PJPB large-capacity parallel shaft geared motor with built-in brake, 3.7 to 22kW, leg-mounted horizontal, service factor 1.0 to 2.0. High-reduction range 1/40 to 1/240, output speeds 7.5 to 45 r/min at 60Hz. Integrated electromagnetic brake for low-speed load holding. Oil-lubricated, 3-phase, 4-pole; made-to-order. Brake unavailable on 30kW and above. Vertical and flange mounts on request. Ships without oil; fill recommended lubricant before use.
15 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| GM-PJPB 3.7kW 1/240 | GM-PJPB 3.7kW 1/240, leg mount, gear size 74240, brake | MITSUBISHI ELECTRIC | Series: GM-PJP · Type: Parallel Shaft · Service Factor: 1.0-2.0 (varies by capacity/ratio selection) · Mount: Leg (horizontal); vertical/flange on request · Brake: Built-in electromagnetic · Output: 3.7kW · Reduction Ratio: 1/240 · Output Speed: 7.5 r/min (60Hz) / 6.3 r/min (50Hz) · Poles: 4P · Phase: 3-phase · Gear Size: 74240 · Lubrication: Oil (ships without oil; fill recommended lubricant) · Availability: Made-to-order | ||
| GM-PJPB 5.5kW 1/180 | GM-PJPB 5.5kW 1/180, leg mount, gear size 74180, brake | MITSUBISHI ELECTRIC | Series: GM-PJP · Type: Parallel Shaft · Service Factor: 1.0-2.0 (varies by capacity/ratio selection) · Mount: Leg (horizontal); vertical/flange on request · Brake: Built-in electromagnetic · Output: 5.5kW · Reduction Ratio: 1/180 · Output Speed: 10 r/min (60Hz) / 8.3 r/min (50Hz) · Poles: 4P · Phase: 3-phase · Gear Size: 74180 · Lubrication: Oil (ships without oil; fill recommended lubricant) · Availability: Made-to-order | ||
| GM-PJPB 5.5kW 1/240 | GM-PJPB 5.5kW 1/240, leg mount, gear size 74240, brake | MITSUBISHI ELECTRIC | Series: GM-PJP · Type: Parallel Shaft · Service Factor: 1.0-2.0 (varies by capacity/ratio selection) · Mount: Leg (horizontal); vertical/flange on request · Brake: Built-in electromagnetic · Output: 5.5kW · Reduction Ratio: 1/240 · Output Speed: 7.5 r/min (60Hz) / 6.3 r/min (50Hz) · Poles: 4P · Phase: 3-phase · Gear Size: 74240 · Lubrication: Oil (ships without oil; fill recommended lubricant) · Availability: Made-to-order | ||
| GM-PJPB 7.5kW 1/130 | GM-PJPB 7.5kW 1/130, leg mount, gear size 74130, brake | MITSUBISHI ELECTRIC | Series: GM-PJP · Type: Parallel Shaft · Service Factor: 1.0-2.0 (varies by capacity/ratio selection) · Mount: Leg (horizontal); vertical/flange on request · Brake: Built-in electromagnetic · Output: 7.5kW · Reduction Ratio: 1/130 · Output Speed: 13.8 r/min (60Hz) / 11.5 r/min (50Hz) · Poles: 4P · Phase: 3-phase · Gear Size: 74130 · Lubrication: Oil (ships without oil; fill recommended lubricant) · Availability: Made-to-order | ||
| GM-PJPB 7.5kW 1/180 | GM-PJPB 7.5kW 1/180, leg mount, gear size 74180, brake | MITSUBISHI ELECTRIC | Series: GM-PJP · Type: Parallel Shaft · Service Factor: 1.0-2.0 (varies by capacity/ratio selection) · Mount: Leg (horizontal); vertical/flange on request · Brake: Built-in electromagnetic · Output: 7.5kW · Reduction Ratio: 1/180 · Output Speed: 10 r/min (60Hz) / 8.3 r/min (50Hz) · Poles: 4P · Phase: 3-phase · Gear Size: 74180 · Lubrication: Oil (ships without oil; fill recommended lubricant) · Availability: Made-to-order | ||
| GM-PJPB 7.5kW 1/240 | GM-PJPB 7.5kW 1/240, leg mount, gear size 84240, brake | MITSUBISHI ELECTRIC | Series: GM-PJP · Type: Parallel Shaft · Service Factor: 1.0-2.0 (varies by capacity/ratio selection) · Mount: Leg (horizontal); vertical/flange on request · Brake: Built-in electromagnetic · Output: 7.5kW · Reduction Ratio: 1/240 · Output Speed: 7.5 r/min (60Hz) / 6.3 r/min (50Hz) · Poles: 4P · Phase: 3-phase · Gear Size: 84240 · Lubrication: Oil (ships without oil; fill recommended lubricant) · Availability: Made-to-order | ||
| GM-PJPB 11kW 1/90 | GM-PJPB 11kW 1/90, leg mount, gear size 7490, brake | MITSUBISHI ELECTRIC | Series: GM-PJP · Type: Parallel Shaft · Service Factor: 1.0-2.0 (varies by capacity/ratio selection) · Mount: Leg (horizontal); vertical/flange on request · Brake: Built-in electromagnetic · Output: 11kW · Reduction Ratio: 1/90 · Output Speed: 20 r/min (60Hz) / 16.7 r/min (50Hz) · Poles: 4P · Phase: 3-phase · Gear Size: 7490 · Lubrication: Oil (ships without oil; fill recommended lubricant) · Availability: Made-to-order | ||
| GM-PJPB 11kW 1/130 | GM-PJPB 11kW 1/130, leg mount, gear size 84130, brake | MITSUBISHI ELECTRIC | Series: GM-PJP · Type: Parallel Shaft · Service Factor: 1.0-2.0 (varies by capacity/ratio selection) · Mount: Leg (horizontal); vertical/flange on request · Brake: Built-in electromagnetic · Output: 11kW · Reduction Ratio: 1/130 · Output Speed: 13.8 r/min (60Hz) / 11.5 r/min (50Hz) · Poles: 4P · Phase: 3-phase · Gear Size: 84130 · Lubrication: Oil (ships without oil; fill recommended lubricant) · Availability: Made-to-order | ||
| GM-PJPB 11kW 1/180 | GM-PJPB 11kW 1/180, leg mount, gear size 84180, brake | MITSUBISHI ELECTRIC | Series: GM-PJP · Type: Parallel Shaft · Service Factor: 1.0-2.0 (varies by capacity/ratio selection) · Mount: Leg (horizontal); vertical/flange on request · Brake: Built-in electromagnetic · Output: 11kW · Reduction Ratio: 1/180 · Output Speed: 10 r/min (60Hz) / 8.3 r/min (50Hz) · Poles: 4P · Phase: 3-phase · Gear Size: 84180 · Lubrication: Oil (ships without oil; fill recommended lubricant) · Availability: Made-to-order | ||
| GM-PJPB 15kW 1/50 | GM-PJPB 15kW 1/50, leg mount, gear size 6450, brake | MITSUBISHI ELECTRIC | Series: GM-PJP · Type: Parallel Shaft · Service Factor: 1.0-2.0 (varies by capacity/ratio selection) · Mount: Leg (horizontal); vertical/flange on request · Brake: Built-in electromagnetic · Output: 15kW · Reduction Ratio: 1/50 · Output Speed: 36 r/min (60Hz) / 30 r/min (50Hz) · Poles: 4P · Phase: 3-phase · Gear Size: 6450 · Lubrication: Oil (ships without oil; fill recommended lubricant) · Availability: Made-to-order | ||
| GM-PJPB 15kW 1/90 | GM-PJPB 15kW 1/90, leg mount, gear size 8490, brake | MITSUBISHI ELECTRIC | Series: GM-PJP · Type: Parallel Shaft · Service Factor: 1.0-2.0 (varies by capacity/ratio selection) · Mount: Leg (horizontal); vertical/flange on request · Brake: Built-in electromagnetic · Output: 15kW · Reduction Ratio: 1/90 · Output Speed: 20 r/min (60Hz) / 16.7 r/min (50Hz) · Poles: 4P · Phase: 3-phase · Gear Size: 8490 · Lubrication: Oil (ships without oil; fill recommended lubricant) · Availability: Made-to-order | ||
| GM-PJPB 15kW 1/130 | GM-PJPB 15kW 1/130, leg mount, gear size 84130, brake | MITSUBISHI ELECTRIC | Series: GM-PJP · Type: Parallel Shaft · Service Factor: 1.0-2.0 (varies by capacity/ratio selection) · Mount: Leg (horizontal); vertical/flange on request · Brake: Built-in electromagnetic · Output: 15kW · Reduction Ratio: 1/130 · Output Speed: 13.8 r/min (60Hz) / 11.5 r/min (50Hz) · Poles: 4P · Phase: 3-phase · Gear Size: 84130 · Lubrication: Oil (ships without oil; fill recommended lubricant) · Availability: Made-to-order | ||
| GM-PJPB 22kW 1/40 | GM-PJPB 22kW 1/40, leg mount, gear size 7440, brake | MITSUBISHI ELECTRIC | Series: GM-PJP · Type: Parallel Shaft · Service Factor: 1.0-2.0 (varies by capacity/ratio selection) · Mount: Leg (horizontal); vertical/flange on request · Brake: Built-in electromagnetic · Output: 22kW · Reduction Ratio: 1/40 · Output Speed: 45 r/min (60Hz) / 37.5 r/min (50Hz) · Poles: 4P · Phase: 3-phase · Gear Size: 7440 · Lubrication: Oil (ships without oil; fill recommended lubricant) · Availability: Made-to-order | ||
| GM-PJPB 22kW 1/50 | GM-PJPB 22kW 1/50, leg mount, gear size 7450, brake | MITSUBISHI ELECTRIC | Series: GM-PJP · Type: Parallel Shaft · Service Factor: 1.0-2.0 (varies by capacity/ratio selection) · Mount: Leg (horizontal); vertical/flange on request · Brake: Built-in electromagnetic · Output: 22kW · Reduction Ratio: 1/50 · Output Speed: 36 r/min (60Hz) / 30 r/min (50Hz) · Poles: 4P · Phase: 3-phase · Gear Size: 7450 · Lubrication: Oil (ships without oil; fill recommended lubricant) · Availability: Made-to-order | ||
| GM-PJPB 22kW 1/90 | GM-PJPB 22kW 1/90, leg mount, gear size 9490, brake | MITSUBISHI ELECTRIC | Series: GM-PJP · Type: Parallel Shaft · Service Factor: 1.0-2.0 (varies by capacity/ratio selection) · Mount: Leg (horizontal); vertical/flange on request · Brake: Built-in electromagnetic · Output: 22kW · Reduction Ratio: 1/90 · Output Speed: 20 r/min (60Hz) / 16.7 r/min (50Hz) · Poles: 4P · Phase: 3-phase · Gear Size: 9490 · Lubrication: Oil (ships without oil; fill recommended lubricant) · Availability: Made-to-order |
