Measuring Instruments
Mitutoyo
[Mitutoyo] — 468-163 Hole Tester (Digimatic)
Family ID: 402-7184
Mitutoyo 468-163 Digimatic Hole Tester is a precision digital bore-measuring instrument sourced direct from Korea. Hole testers of this type are widely used in machining and quality control environments to verify the internal diameter of bored, reamed, or honed workpieces with repeatable accuracy. Request a quote today for export-ready supply at competitive pricing through a KITA-registered Korean exporter.
8 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| 402-7184 | 468-163 | Mitutoyo | 468-163 | Measurement Range: 10~12 | Minimum Scale: 0.001 | Extension Rod: 100 (952322) | ||
| 402-7193 | 468-164 | Mitutoyo | 468-164 | Measurement Range: 12~16 | Minimum Division: 0.001 | Extension Rod: 150 (952621) | ||
| 402-7209 | 468-165 | Mitutoyo | 468-165 | Measurement Range: 16~20 | Minimum Division: 0.001 | Extension Rod: 150 (952621) | ||
| 402-7218 | 468-166 | Mitutoyo | 468-166 | Measurement Range: 20~25 | Minimum Scale: 0.001 | Extension Rod: 150 (952622) | ||
| 402-7227 | 468-167 | Mitutoyo | 468-167 | Measurement Range: 25~30 | Minimum Division: 0.001 | Extension Rod: 150 (952622) | ||
| 402-7236 | 468-168 | Mitutoyo | 468-168 | Measurement Range: 30~40 | Minimum Scale: 0.001 | Extension Rod: 150 (952622) | ||
| 402-7245 | 468-169 | Mitutoyo | 468-169 | Measurement Range: 40~50 | Minimum Scale: 0.001 | Extension Rod: 150 (952622) | ||
| 402-7254 | 468-170 | Mitutoyo | 468-170 | Measurement Range: 50~63 | Minimum Division: 0.001 | Extension Rod: 150 (952623) |
