Servo Cables
Omron
[OMRON] — Control Cables for G5 Series R88D-KT Servo Drive CN1 (PCU / Motion / General-purpose)
Family ID: OMRON-R88KT-CTRL-CABLES
Control cables for G5 Series R88D-KT Servo Drive CN1 connection to Position Control Units and Motion Control Units.
26 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| XW2Z-100J-G9 | Connection cable for CJ1W-NC234/434, 1-axis, 1.0m | OMRON | Type: Connection cable for CN1 | Controller: CJ1W-NC234/434 | Axes: 1 | Length: 1.0 m | ||
| XW2Z-500J-G9 | Connection cable for CJ1W-NC234/434, 1-axis, 5.0m | OMRON | Type: Connection cable for CN1 | Controller: CJ1W-NC234/434 | Axes: 1 | Length: 5.0 m | ||
| XW2Z-10MJ-G9 | Connection cable for CJ1W-NC234/434, 1-axis, 10.0m | OMRON | Type: Connection cable for CN1 | Controller: CJ1W-NC234/434 | Axes: 1 | Length: 10.0 m | ||
| XW2Z-100J-G1 | Connection cable for CJ1W-NC234/434, 2-axis, 1.0m | OMRON | Type: Connection cable for CN1 | Controller: CJ1W-NC234/434 | Axes: 2 | Length: 1.0 m | ||
| XW2Z-500J-G1 | Connection cable for CJ1W-NC234/434, 2-axis, 5.0m | OMRON | Type: Connection cable for CN1 | Controller: CJ1W-NC234/434 | Axes: 2 | Length: 5.0 m | ||
| XW2Z-10MJ-G1 | Connection cable for CJ1W-NC234/434, 2-axis, 10.0m | OMRON | Type: Connection cable for CN1 | Controller: CJ1W-NC234/434 | Axes: 2 | Length: 10.0 m | ||
| XW2Z-100J-G13 | Connection cable for CJ1W-NC214/NC414, 1-axis, 1.0m | OMRON | Type: Connection cable for CN1 | Controller: CJ1W-NC214/NC414 | Axes: 1 | Length: 1.0 m | ||
| XW2Z-300J-G13 | Connection cable for CJ1W-NC214/NC414, 1-axis, 3.0m | OMRON | Type: Connection cable for CN1 | Controller: CJ1W-NC214/NC414 | Axes: 1 | Length: 3.0 m | ||
| XW2Z-100J-G5 | Connection cable for CJ1W-NC214/NC414, 2-axis, 1.0m | OMRON | Type: Connection cable for CN1 | Controller: CJ1W-NC214/NC414 | Axes: 2 | Length: 1.0 m | ||
| XW2Z-300J-G5 | Connection cable for CJ1W-NC214/NC414, 2-axis, 3.0m | OMRON | Type: Connection cable for CN1 | Controller: CJ1W-NC214/NC414 | Axes: 2 | Length: 3.0 m | ||
| R88A-CPG001M1 | Control cable for CS1W-MC221/MC421, 1-axis, 1.0m | OMRON | Type: Control cable for CN1 | Controller: CS1W-MC221/MC421 | Axes: 1 | Length: 1.0 m | ||
| R88A-CPG002M1 | Control cable for CS1W-MC221/MC421, 1-axis, 2.0m | OMRON | Type: Control cable for CN1 | Controller: CS1W-MC221/MC421 | Axes: 1 | Length: 2.0 m | ||
| R88A-CPG003M1 | Control cable for CS1W-MC221/MC421, 1-axis, 3.0m | OMRON | Type: Control cable for CN1 | Controller: CS1W-MC221/MC421 | Axes: 1 | Length: 3.0 m | ||
| R88A-CPG005M1 | Control cable for CS1W-MC221/MC421, 1-axis, 5.0m | OMRON | Type: Control cable for CN1 | Controller: CS1W-MC221/MC421 | Axes: 1 | Length: 5.0 m | ||
| R88A-CPG001M2 | Control cable for CS1W-MC221/MC421, 2-axis, 1.0m | OMRON | Type: Control cable for CN1 | Controller: CS1W-MC221/MC421 | Axes: 2 | Length: 1.0 m | ||
| R88A-CPG002M2 | Control cable for CS1W-MC221/MC421, 2-axis, 2.0m | OMRON | Type: Control cable for CN1 | Controller: CS1W-MC221/MC421 | Axes: 2 | Length: 2.0 m | ||
| R88A-CPG003M2 | Control cable for CS1W-MC221/MC421, 2-axis, 3.0m | OMRON | Type: Control cable for CN1 | Controller: CS1W-MC221/MC421 | Axes: 2 | Length: 3.0 m | ||
| R88A-CPG005M2 | Control cable for CS1W-MC221/MC421, 2-axis, 5.0m | OMRON | Type: Control cable for CN1 | Controller: CS1W-MC221/MC421 | Axes: 2 | Length: 5.0 m | ||
| R88A-CPG001S | General-purpose control cable with connector one end, 1.0m | OMRON | Type: General-purpose control cable for CN1 | Length: 1.0 m | ||
| R88A-CPG002S | General-purpose control cable with connector one end, 2.0m | OMRON | Type: General-purpose control cable for CN1 | Length: 2.0 m | ||
| XW2Z-C50X | Connector terminal block cable 0.5m | OMRON | Type: Connector terminal block cable | Controller: CJ1W-NC[][]4 | Length: 0.5 m | ||
| XW2Z-100X | Connector terminal block cable 1.0m | OMRON | Type: Connector terminal block cable | Controller: CJ1W-NC[][]4 | Length: 1.0 m | ||
| XW2Z-200X | Connector terminal block cable 2.0m | OMRON | Type: Connector terminal block cable | Controller: CJ1W-NC[][]4 | Length: 2.0 m | ||
| XW2Z-300X | Connector terminal block cable 3.0m | OMRON | Type: Connector terminal block cable | Controller: CJ1W-NC[][]4 | Length: 3.0 m | ||
| XW2Z-500X | Connector terminal block cable 5.0m | OMRON | Type: Connector terminal block cable | Controller: CJ1W-NC[][]4 | Length: 5.0 m | ||
| XW2Z-010X | Connector terminal block cable 10.0m | OMRON | Type: Connector terminal block cable | Controller: CJ1W-NC[][]4 | Length: 10.0 m |
