Limit Switches
Omron
[OMRON] — D5B Mechanical Touch Switch (Multi-direction, M5/M8/M10, Hemispheric/Cone/Wobble)
Family ID: OMRON-D5B
Detects Objects in Multiple Directions with High Sensitivity, Ideal for Robotics
30 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| D5B-5011 | D5B Hemispheric M5 1 m | OMRON | Type: Mechanical Touch Switch | Actuator: Hemispheric actuator | Body Size: M5 | Cable Length: 1 m | Detection: Multi-direction | ||
| D5B-5013 | D5B Hemispheric M5 3 m | OMRON | Type: Mechanical Touch Switch | Actuator: Hemispheric actuator | Body Size: M5 | Cable Length: 3 m | Detection: Multi-direction | ||
| D5B-5015 | D5B Hemispheric M5 5 m | OMRON | Type: Mechanical Touch Switch | Actuator: Hemispheric actuator | Body Size: M5 | Cable Length: 5 m | Detection: Multi-direction | ||
| D5B-8011 | D5B Hemispheric M8 1 m | OMRON | Type: Mechanical Touch Switch | Actuator: Hemispheric actuator | Body Size: M8 | Cable Length: 1 m | Detection: Multi-direction | ||
| D5B-8013 | D5B Hemispheric M8 3 m | OMRON | Type: Mechanical Touch Switch | Actuator: Hemispheric actuator | Body Size: M8 | Cable Length: 3 m | Detection: Multi-direction | ||
| D5B-8015 | D5B Hemispheric M8 5 m | OMRON | Type: Mechanical Touch Switch | Actuator: Hemispheric actuator | Body Size: M8 | Cable Length: 5 m | Detection: Multi-direction | ||
| D5B-1011 | D5B Hemispheric M10 1 m | OMRON | Type: Mechanical Touch Switch | Actuator: Hemispheric actuator | Body Size: M10 | Cable Length: 1 m | Detection: Multi-direction | ||
| D5B-1013 | D5B Hemispheric M10 3 m | OMRON | Type: Mechanical Touch Switch | Actuator: Hemispheric actuator | Body Size: M10 | Cable Length: 3 m | Detection: Multi-direction | ||
| D5B-1015 | D5B Hemispheric M10 5 m | OMRON | Type: Mechanical Touch Switch | Actuator: Hemispheric actuator | Body Size: M10 | Cable Length: 5 m | Detection: Multi-direction | ||
| D5B-5021 | D5B Cone-shaped M5 1 m | OMRON | Type: Mechanical Touch Switch | Actuator: Cone-shaped actuator | Body Size: M5 | Cable Length: 1 m | Detection: Multi-direction | ||
| D5B-5023 | D5B Cone-shaped M5 3 m | OMRON | Type: Mechanical Touch Switch | Actuator: Cone-shaped actuator | Body Size: M5 | Cable Length: 3 m | Detection: Multi-direction | ||
| D5B-5025 | D5B Cone-shaped M5 5 m | OMRON | Type: Mechanical Touch Switch | Actuator: Cone-shaped actuator | Body Size: M5 | Cable Length: 5 m | Detection: Multi-direction | ||
| D5B-8021 | D5B Cone-shaped M8 1 m | OMRON | Type: Mechanical Touch Switch | Actuator: Cone-shaped actuator | Body Size: M8 | Cable Length: 1 m | Detection: Multi-direction | ||
| D5B-8023 | D5B Cone-shaped M8 3 m | OMRON | Type: Mechanical Touch Switch | Actuator: Cone-shaped actuator | Body Size: M8 | Cable Length: 3 m | Detection: Multi-direction | ||
| D5B-8025 | D5B Cone-shaped M8 5 m | OMRON | Type: Mechanical Touch Switch | Actuator: Cone-shaped actuator | Body Size: M8 | Cable Length: 5 m | Detection: Multi-direction | ||
| D5B-1021 | D5B Cone-shaped M10 1 m | OMRON | Type: Mechanical Touch Switch | Actuator: Cone-shaped actuator | Body Size: M10 | Cable Length: 1 m | Detection: Multi-direction | ||
| D5B-1023 | D5B Cone-shaped M10 3 m | OMRON | Type: Mechanical Touch Switch | Actuator: Cone-shaped actuator | Body Size: M10 | Cable Length: 3 m | Detection: Multi-direction | ||
| D5B-1025 | D5B Cone-shaped M10 5 m | OMRON | Type: Mechanical Touch Switch | Actuator: Cone-shaped actuator | Body Size: M10 | Cable Length: 5 m | Detection: Multi-direction | ||
| D5B-5511 | D5B Wobble short spring M5 1 m | OMRON | Type: Mechanical Touch Switch | Actuator: Wobble stick actuator (short spring) | Body Size: M5 | Cable Length: 1 m | Detection: Multi-direction | ||
| D5B-5513 | D5B Wobble short spring M5 3 m | OMRON | Type: Mechanical Touch Switch | Actuator: Wobble stick actuator (short spring) | Body Size: M5 | Cable Length: 3 m | Detection: Multi-direction | ||
| D5B-5515 | D5B Wobble short spring M5 5 m | OMRON | Type: Mechanical Touch Switch | Actuator: Wobble stick actuator (short spring) | Body Size: M5 | Cable Length: 5 m | Detection: Multi-direction | ||
| D5B-8511 | D5B Wobble short spring M8 1 m | OMRON | Type: Mechanical Touch Switch | Actuator: Wobble stick actuator (short spring) | Body Size: M8 | Cable Length: 1 m | Detection: Multi-direction | ||
| D5B-8513 | D5B Wobble short spring M8 3 m | OMRON | Type: Mechanical Touch Switch | Actuator: Wobble stick actuator (short spring) | Body Size: M8 | Cable Length: 3 m | Detection: Multi-direction | ||
| D5B-8515 | D5B Wobble short spring M8 5 m | OMRON | Type: Mechanical Touch Switch | Actuator: Wobble stick actuator (short spring) | Body Size: M8 | Cable Length: 5 m | Detection: Multi-direction | ||
| D5B-1511 | D5B Wobble short spring M10 1 m | OMRON | Type: Mechanical Touch Switch | Actuator: Wobble stick actuator (short spring) | Body Size: M10 | Cable Length: 1 m | Detection: Multi-direction | ||
| D5B-1513 | D5B Wobble short spring M10 3 m | OMRON | Type: Mechanical Touch Switch | Actuator: Wobble stick actuator (short spring) | Body Size: M10 | Cable Length: 3 m | Detection: Multi-direction | ||
| D5B-1515 | D5B Wobble short spring M10 5 m | OMRON | Type: Mechanical Touch Switch | Actuator: Wobble stick actuator (short spring) | Body Size: M10 | Cable Length: 5 m | Detection: Multi-direction | ||
| D5B-1531 | D5B Wobble long spring M10 1 m | OMRON | Type: Mechanical Touch Switch | Actuator: Wobble stick actuator (long spring) | Body Size: M10 | Cable Length: 1 m | Detection: Multi-direction | Note: Long spring available for M10 only | ||
| D5B-1533 | D5B Wobble long spring M10 3 m | OMRON | Type: Mechanical Touch Switch | Actuator: Wobble stick actuator (long spring) | Body Size: M10 | Cable Length: 3 m | Detection: Multi-direction | Note: Long spring available for M10 only | ||
| D5B-1535 | D5B Wobble long spring M10 5 m | OMRON | Type: Mechanical Touch Switch | Actuator: Wobble stick actuator (long spring) | Body Size: M10 | Cable Length: 5 m | Detection: Multi-direction | Note: Long spring available for M10 only |
