Temperature Controller
Omron
[OMRON] — NX-HTC Advanced Temperature Control Unit (NX Series, 4Ch/8Ch, Universal Input, Heating/Cooling or Standard Control)
Family ID: OMRON-NX-HTC
Combining Space-Saving Design and Advanced Temperature Controllability. NX Series Advanced Temperature Control Units. 4Ch type with Heating and Cooling Control (50ms conversion, Free-Run refreshing). 8Ch type with Standard Control. Universal inputs: thermocouple, platinum resistance thermometer, analog voltage, analog current.
3 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| NX-HTC3510-5 | Advanced Temperature Control Unit, 4Ch, Universal input, Voltage+Linear current output, Heating/Cooling Control | OMRON | Type: Advanced Temperature Control Unit | Channels: 4 | Input: Universal (TC/RTD/Analog voltage/Analog current) | Output: Voltage (for driving SSR) + Linear current | Output Points: 4 | CT Input: 4 points | Control Type: Heating and Cooling Control | Conversion Time: 50ms | I/O Refresh: Free-Run | ||
| NX-HTC4505-5 | Advanced Temperature Control Unit, 8Ch, Universal input, Voltage output, Standard Control | OMRON | Type: Advanced Temperature Control Unit | Channels: 8 | Input: Universal (TC/RTD/Analog voltage/Analog current) | Output: Voltage (for driving SSR) | Output Points: 8 | CT Input: 8 points | Control Type: Standard Control | Conversion Time: 50ms | I/O Refresh: Free-Run | ||
| NX-AUX03 | Cold Junction Sensor for NX-HTC (replacement/spare, 1 included with unit) | OMRON | Type: Cold Junction Sensor | Compatible: NX-HTC only | Note: One sensor included with each NX-HTC unit. Purchase only when damaged or lost. |
