[OMRON] — S3D2 Sensor Controller (High-speed 0.1 ms, Relay/Transistor Output)
Sensor Controllers Omron

[OMRON] — S3D2 Sensor Controller (High-speed 0.1 ms, Relay/Transistor Output)

Family ID: OMRON-S3D2

Offers High-speed Input Response of 0.1 ms and Equipped with Built-in Timer.

18 product codes available in this family

RFQ Cart (0)

Product Codes & Specifications

Product Code Description Brand Spec
S3D2-DK S3D2 100 to 240 VAC, Relay output, NPN, Single-function, 1 input/output (2 circuits) OMRON Power Supply: 100 to 240 VAC | Output: Relay | Timer Function: No | Function: Single-function, 1 input/output (2 circuits) | Connection: NPN | Input Response: 0.1 ms | UL: —
S3D2-EK S3D2 100 to 240 VAC, Relay output, NPN, Single-function, 1 input/output (2 circuits) OMRON Power Supply: 100 to 240 VAC | Output: Relay | Timer Function: Yes | Function: Single-function, 1 input/output (2 circuits) | Connection: NPN | Input Response: 0.1 ms | UL: —
S3D2-AK S3D2 100 to 240 VAC, Relay output, NPN, Single-function, 2 inputs/1 output (AND/OR) OMRON Power Supply: 100 to 240 VAC | Output: Relay | Timer Function: No | Function: Single-function, 2 inputs/1 output (AND/OR) | Connection: NPN | Input Response: 0.1 ms | UL: —
S3D2-BK S3D2 100 to 240 VAC, Relay output, NPN, Flip-flop function, 2 inputs/1 output OMRON Power Supply: 100 to 240 VAC | Output: Relay | Timer Function: No | Function: Flip-flop function, 2 inputs/1 output | Connection: NPN | Input Response: 0.1 ms | UL: —
S3D2-CK S3D2 100 to 240 VAC, Relay output, NPN, Multi-function, 2 inputs/1 output OMRON Power Supply: 100 to 240 VAC | Output: Relay | Timer Function: Yes | Function: Multi-function, 2 inputs/1 output | Connection: NPN | Input Response: 0.1 ms | UL: —
S3D2-CC S3D2 100 to 240 VAC, Transistor output, NPN, Multi-function, 2 inputs/1 output OMRON Power Supply: 100 to 240 VAC | Output: Transistor | Timer Function: Yes | Function: Multi-function, 2 inputs/1 output | Connection: NPN | Input Response: 0.1 ms | UL: —
S3D2-AKD S3D2 24 VDC, Relay output, NPN, Single-function, 2 inputs/1 output OMRON Power Supply: 24 VDC | Output: Relay | Timer Function: No | Function: Single-function, 2 inputs/1 output | Connection: NPN | Input Response: 0.1 ms | UL: —
S3D2-CKD S3D2 24 VDC, Relay output, NPN, Multi-function, 2 inputs/1 output OMRON Power Supply: 24 VDC | Output: Relay | Timer Function: Yes | Function: Multi-function, 2 inputs/1 output | Connection: NPN | Input Response: 0.1 ms | UL: —
S3D2-CCD S3D2 24 VDC, Transistor output, NPN, Multi-function, 2 inputs/1 output OMRON Power Supply: 24 VDC | Output: Transistor | Timer Function: Yes | Function: Multi-function, 2 inputs/1 output | Connection: NPN | Input Response: 0.1 ms | UL: —
S3D2-AKB S3D2 100 to 240 VAC, Relay output, PNP, Single-function, 2 inputs/1 output (AND/OR) OMRON Power Supply: 100 to 240 VAC | Output: Relay | Timer Function: No | Function: Single-function, 2 inputs/1 output (AND/OR) | Connection: PNP | Input Response: 0.1 ms | UL: —
S3D2-CKB S3D2 100 to 240 VAC, Relay output, PNP, Multi-function, 2 inputs/1 output OMRON Power Supply: 100 to 240 VAC | Output: Relay | Timer Function: Yes | Function: Multi-function, 2 inputs/1 output | Connection: PNP | Input Response: 0.1 ms | UL: —
S3D2-CCB S3D2 100 to 240 VAC, Transistor output, PNP, Multi-function, 2 inputs/1 output OMRON Power Supply: 100 to 240 VAC | Output: Transistor | Timer Function: Yes | Function: Multi-function, 2 inputs/1 output | Connection: PNP | Input Response: 0.1 ms | UL: —
S3D2-AK-US S3D2 100 to 240 VAC, Relay output, NPN, Single-function, 2 inputs/1 output (AND/OR) OMRON Power Supply: 100 to 240 VAC | Output: Relay | Timer Function: No | Function: Single-function, 2 inputs/1 output (AND/OR) | Connection: NPN | Input Response: 0.1 ms | UL: UL certified
S3D2-CK-US S3D2 100 to 240 VAC, Relay output, NPN, Multi-function, 2 inputs/1 output OMRON Power Supply: 100 to 240 VAC | Output: Relay | Timer Function: Yes | Function: Multi-function, 2 inputs/1 output | Connection: NPN | Input Response: 0.1 ms | UL: UL certified
S3D2-CC-US S3D2 100 to 240 VAC, Transistor output, NPN, Multi-function, 2 inputs/1 output OMRON Power Supply: 100 to 240 VAC | Output: Transistor | Timer Function: Yes | Function: Multi-function, 2 inputs/1 output | Connection: NPN | Input Response: 0.1 ms | UL: UL certified
S3D2-AKB-US S3D2 100 to 240 VAC, Relay output, PNP, Single-function, 2 inputs/1 output (AND/OR) OMRON Power Supply: 100 to 240 VAC | Output: Relay | Timer Function: No | Function: Single-function, 2 inputs/1 output (AND/OR) | Connection: PNP | Input Response: 0.1 ms | UL: UL certified
S3D2-CKB-US S3D2 100 to 240 VAC, Relay output, PNP, Multi-function, 2 inputs/1 output OMRON Power Supply: 100 to 240 VAC | Output: Relay | Timer Function: Yes | Function: Multi-function, 2 inputs/1 output | Connection: PNP | Input Response: 0.1 ms | UL: UL certified
S3D2-CCB-US S3D2 100 to 240 VAC, Transistor output, PNP, Multi-function, 2 inputs/1 output OMRON Power Supply: 100 to 240 VAC | Output: Transistor | Timer Function: Yes | Function: Multi-function, 2 inputs/1 output | Connection: PNP | Input Response: 0.1 ms | UL: UL certified
