[OMRON] — S8BA-SBF Separated Battery DC-DC UPS, 24VDC Input/Output, DIN Rail Mount

Family ID: OMRON-S8BA-SBF

S8BA-SBF Separated battery type DC-DC UPS. Control unit and battery unit sold separately. DIN rail mount.

4 product codes available in this family

Product Codes & Specifications

	Product Code	Description	Brand	Spec
	S8BA-24D24D480SBF	UPS SBF control unit 24V 20A/480W	OMRON	Type: UPS Control Unit \| Input: 24 VDC \| Output: 24 VDC / 20 A / 480 W \| Battery: Separated (sold separately) \| Mount: DIN rail \| Series: S8BA-SBF
	S8BA-24D24D960SBF	UPS SBF control unit 24V 40A/960W	OMRON	Type: UPS Control Unit \| Input: 24 VDC \| Output: 24 VDC / 40 A / 960 W \| Battery: Separated (sold separately) \| Mount: DIN rail \| Series: S8BA-SBF
	S8BA-S480L	Battery Unit 25.2V 3900mAh for S8BA-24D24D480SBF	OMRON	Type: UPS Battery Unit \| Rated Voltage: 25.2 VDC \| Rated Capacity: 3900 mAh \| Weight: 1.5 kg \| Compatible: S8BA-24D24D480SBF \| Note: 960W control unit incompatible
	S8BA-S960L	Battery Unit 25.2V 7800mAh for S8BA-24D24D480SBF or 960SBF	OMRON	Type: UPS Battery Unit \| Rated Voltage: 25.2 VDC \| Rated Capacity: 7800 mAh \| Weight: 2.5 kg \| Compatible: S8BA-24D24D480SBF / S8BA-24D24D960SBF
