![[OMRON] — WL-N/WLG Spatter-prevention Limit Switch (Sealed Top-roller Plunger)](https://prosourcemro.com/wp-content/uploads/2026/05/001-467-1024x683.png)
Limit Switches
Omron
[OMRON] — WL-N/WLG Spatter-prevention Limit Switch (Sealed Top-roller Plunger)
Family ID: OMRON-WL-SPATTER-PLUNGER
Two-circuit limit switches that can be selected to match the operating environment and application WL-N/Basic models, WLG/High-sensitivity and High-precision models
6 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| WLD28-LDS-N | Sealed top-roller plunger Spatter screw LED | OMRON | Type: Two-circuit Limit Switch | Actuator: Sealed top-roller plunger | Terminal: Screw (G1/2) | Pretravel: 1.7mm max. | Indicator: LED | Built-in Switch: Spatter-prevention | ||
| WLD28-LES-N | Sealed top-roller plunger Spatter screw Neon | OMRON | Type: Two-circuit Limit Switch | Actuator: Sealed top-roller plunger | Terminal: Screw (G1/2) | Pretravel: 1.7mm max. | Indicator: Neon | Built-in Switch: Spatter-prevention | ||
| WLD28-LDS-M1J-1-N | WL Spatter Plunger PWC NO only M12 | OMRON | Type: Two-circuit Limit Switch | Actuator: Sealed top-roller plunger | Terminal: Pre-wired connector M12 | Pretravel: 1.7mm max. | Indicator: LED | Built-in Switch: Spatter-prevention | Wiring: NO only | ||
| WLD28-LDS-M1GJ-1-N | WL Spatter Plunger PWC NO only M12 | OMRON | Type: Two-circuit Limit Switch | Actuator: Sealed top-roller plunger | Terminal: Pre-wired connector M12 | Pretravel: 1.7mm max. | Indicator: LED | Built-in Switch: Spatter-prevention | Wiring: NO only | ||
| WLD28-LDS-DGJS-N | WL Spatter Plunger PWC NC+NO M12 | OMRON | Type: Two-circuit Limit Switch | Actuator: Sealed top-roller plunger | Terminal: Pre-wired connector M12 | Pretravel: 1.7mm max. | Indicator: LED | Built-in Switch: Spatter-prevention | Wiring: NC+NO | ||
| WLD28-LDS-DTGJS-N | WL Spatter Plunger PWC NC+NO Smartclick | OMRON | Type: Two-circuit Limit Switch | Actuator: Sealed top-roller plunger | Terminal: Pre-wired connector Smartclick | Pretravel: 1.7mm max. | Indicator: LED | Built-in Switch: Spatter-prevention | Wiring: NC+NO |
