[OMRON] — XW6T Common Terminal Block with Visible Indicators (1.5 mm², 8/12/16/20/40 Pins)
Family ID: OMRON-XW6T-COM1.5
Common Terminal Blocks with Visible Indicators. Our Value Design Products Increase the Value of Your Control Panels. Contributing to downsize control panels and save work. It can proper wiring without skillful operators, because of indicators make wiring completion simply visible.
15 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| XW6T-COM1.5X8RD | XW6T 1.5 mm², 8-pin, Red short bar | OMRON | Max Conductor Cross Section: 1.5 mm² (fine stranded) | Number of Pins: 8 | Short Bar Color: Red | Weight: Approx. 16 g | Mounting: DIN Rail | Set Contents: Terminal block units + short bar + end cover | ||
| XW6T-COM1.5X8BL | XW6T 1.5 mm², 8-pin, Blue short bar | OMRON | Max Conductor Cross Section: 1.5 mm² (fine stranded) | Number of Pins: 8 | Short Bar Color: Blue | Weight: Approx. 16 g | Mounting: DIN Rail | Set Contents: Terminal block units + short bar + end cover | ||
| XW6T-COM1.5X8YL | XW6T 1.5 mm², 8-pin, Yellow short bar | OMRON | Max Conductor Cross Section: 1.5 mm² (fine stranded) | Number of Pins: 8 | Short Bar Color: Yellow | Weight: Approx. 16 g | Mounting: DIN Rail | Set Contents: Terminal block units + short bar + end cover | ||
| XW6T-COM1.5X12RD | XW6T 1.5 mm², 12-pin, Red short bar | OMRON | Max Conductor Cross Section: 1.5 mm² (fine stranded) | Number of Pins: 12 | Short Bar Color: Red | Weight: Approx. 23 g | Mounting: DIN Rail | Set Contents: Terminal block units + short bar + end cover | ||
| XW6T-COM1.5X12BL | XW6T 1.5 mm², 12-pin, Blue short bar | OMRON | Max Conductor Cross Section: 1.5 mm² (fine stranded) | Number of Pins: 12 | Short Bar Color: Blue | Weight: Approx. 23 g | Mounting: DIN Rail | Set Contents: Terminal block units + short bar + end cover | ||
| XW6T-COM1.5X12YL | XW6T 1.5 mm², 12-pin, Yellow short bar | OMRON | Max Conductor Cross Section: 1.5 mm² (fine stranded) | Number of Pins: 12 | Short Bar Color: Yellow | Weight: Approx. 23 g | Mounting: DIN Rail | Set Contents: Terminal block units + short bar + end cover | ||
| XW6T-COM1.5X16RD | XW6T 1.5 mm², 16-pin, Red short bar | OMRON | Max Conductor Cross Section: 1.5 mm² (fine stranded) | Number of Pins: 16 | Short Bar Color: Red | Weight: Approx. 29 g | Mounting: DIN Rail | Set Contents: Terminal block units + short bar + end cover | ||
| XW6T-COM1.5X16BL | XW6T 1.5 mm², 16-pin, Blue short bar | OMRON | Max Conductor Cross Section: 1.5 mm² (fine stranded) | Number of Pins: 16 | Short Bar Color: Blue | Weight: Approx. 29 g | Mounting: DIN Rail | Set Contents: Terminal block units + short bar + end cover | ||
| XW6T-COM1.5X16YL | XW6T 1.5 mm², 16-pin, Yellow short bar | OMRON | Max Conductor Cross Section: 1.5 mm² (fine stranded) | Number of Pins: 16 | Short Bar Color: Yellow | Weight: Approx. 29 g | Mounting: DIN Rail | Set Contents: Terminal block units + short bar + end cover | ||
| XW6T-COM1.5X20RD | XW6T 1.5 mm², 20-pin, Red short bar | OMRON | Max Conductor Cross Section: 1.5 mm² (fine stranded) | Number of Pins: 20 | Short Bar Color: Red | Weight: Approx. 36 g | Mounting: DIN Rail | Set Contents: Terminal block units + short bar + end cover | ||
| XW6T-COM1.5X20BL | XW6T 1.5 mm², 20-pin, Blue short bar | OMRON | Max Conductor Cross Section: 1.5 mm² (fine stranded) | Number of Pins: 20 | Short Bar Color: Blue | Weight: Approx. 36 g | Mounting: DIN Rail | Set Contents: Terminal block units + short bar + end cover | ||
| XW6T-COM1.5X20YL | XW6T 1.5 mm², 20-pin, Yellow short bar | OMRON | Max Conductor Cross Section: 1.5 mm² (fine stranded) | Number of Pins: 20 | Short Bar Color: Yellow | Weight: Approx. 36 g | Mounting: DIN Rail | Set Contents: Terminal block units + short bar + end cover | ||
| XW6T-COM1.5X40RD | XW6T 1.5 mm², 40-pin, Red short bar | OMRON | Max Conductor Cross Section: 1.5 mm² (fine stranded) | Number of Pins: 40 | Short Bar Color: Red | Weight: Approx. 68 g | Mounting: DIN Rail | Set Contents: Terminal block units + short bar + end cover | ||
| XW6T-COM1.5X40BL | XW6T 1.5 mm², 40-pin, Blue short bar | OMRON | Max Conductor Cross Section: 1.5 mm² (fine stranded) | Number of Pins: 40 | Short Bar Color: Blue | Weight: Approx. 68 g | Mounting: DIN Rail | Set Contents: Terminal block units + short bar + end cover | ||
| XW6T-COM1.5X40YL | XW6T 1.5 mm², 40-pin, Yellow short bar | OMRON | Max Conductor Cross Section: 1.5 mm² (fine stranded) | Number of Pins: 40 | Short Bar Color: Yellow | Weight: Approx. 68 g | Mounting: DIN Rail | Set Contents: Terminal block units + short bar + end cover |
