Couplers & Air Guns
Sangah
[Sangah] — 623-6546 Corrugated Nozzle
Family ID: 623-6546
The Sangah 623-6546 Corrugated Nozzle is a pneumatic air nozzle designed to direct and concentrate airflow for blowoff and cleaning tasks, sourced direct from Korea. Corrugated nozzles are commonly used in assembly lines, machine shops, and maintenance environments where controlled air discharge is needed to clear debris, dust, or coolant from workpieces and equipment surfaces. Request a quote today for export-ready supply of this pneumatic accessory at competitive pricing through a KITA-registered Korean exporter.
7 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| 623-6546 | — | Sangah | JC1/4-01 Male Thread Connector | A: 23 | R: R1/8 | H: 14 | B: 26 | ΦD: 6.3 | ||
| 623-6555 | — | Sangah | JC1/4-02 Male Connector | A: 23 | R: R1/4 | H: 14 | B: 26 | ΦD: 6.3 | ||
| 623-6564 | — | Sangah | JC3/8-03 Male Thread Connector | A: 27.5 | R: R3/8 | H: 19 | B: 32 | ΦD: 9.5 | ||
| 623-6573 | — | Sangah | JC3/8-04 Male Thread Connector | A: 27.5 | R: R1/2 | H: 21 | B: 32 | ΦD: 9.5 | ||
| 623-6582 | — | Sangah | JC1/2-03 Male Thread Connector | A: 33 | R: R3/8 | H: 19 | B: 38.5 | ΦD: 12.7 | ||
| 623-6591 | — | Sangah | JC1/2-04 Male Thread Connector | A: 33 | R: R1/2 | H: 22 | B: 38.5 | ΦD: 12.7 | ||
| 623-6607 | — | Sangah | JC3/4-06 Male Connector | A: 34.5 | R: R3/4 | H: 28 | B: 40 | ΦD: 19.5 |
