[SMC] — AC30A-D F.R.L. Combination (Filter Regulator + Lubricator)

SMC modular F.R.L. combination for compressed air preparation. Body size 30, port size: 1/4, 3/8. Constituent units: AW (filter regulator with 5μm filter) + AL (lubricator). Setting pressure: 0.05–0.85 MPa (low-pressure 0.02–0.2 MPa available on request). Max working pressure 1.0 MPa, proof pressure 1.5 MPa. Operating temperature: -5 to 60°C. Threads: Rc / NPT / G. Drain options: manual, N.C. auto drain, or N.O. auto drain available. Pressure gauge option: square embedded gauge. Mounting: bracket. Polycarbonate case (case guard standard on size 30+). Other options (round gauge G/M, color zone gauge, digital pressure switch E1–E4, residual pressure relief 3-port valve V/V1, low-pressure spec, alternative case materials, drain port variants J/W, non-relief regulator, reverse flow direction, psi units) available on request.
