![[SMC] — AL40-06-D Modular Lubricator (3/4 Port)](https://img.prosourcemro.com/2026/04/al-d.png)
Lubricators
SMC
[SMC] — AL40-06-D Modular Lubricator (3/4 Port)
Family ID: SMC-AL40-06-D
SMC modular pneumatic lubricator (clean/low-particle spec). Body size 40-06, port size: 3/4. Max working pressure 1.0 MPa, proof pressure 1.5 MPa. Operating temperature: -5 to 60°C. Recommended oil: turbine oil class 1 (ISO VG32). Oil capacity: 135 cm³. Minimum dripping flow: 50 L/min(ANR). Mass: 0.41 kg. Threads: Rc / NPT / G. Mounting option: bracket. Polycarbonate case (case guard standard on size 30+). Other options (alternative case materials including metal/nylon/level-gauge variants, drain cock, drain cock with barb fitting, reverse flow direction, psi units) available on request.
6 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| AL40-06-D | Rc 3/4, clean/low-particle spec | SMC | Body size: 40-06 | Thread: Rc | Port size: 3/4 | Mounting: No mounting option | Max working pressure: 1.0 MPa | Proof pressure: 1.5 MPa | Operating temperature: -5 to 60°C | Recommended oil: Turbine oil class 1 (ISO VG32) | Oil capacity: 135 cm³ | Minimum dripping flow: 50 L/min(ANR) | Mass: 0.41 kg | Case material: Polycarbonate (standard) | Spec: Clean/Low-particle (-D) | ||
| AL40-06B-D | Rc 3/4, Bracket, clean/low-particle spec | SMC | Body size: 40-06 | Thread: Rc | Port size: 3/4 | Mounting: Bracket | Max working pressure: 1.0 MPa | Proof pressure: 1.5 MPa | Operating temperature: -5 to 60°C | Recommended oil: Turbine oil class 1 (ISO VG32) | Oil capacity: 135 cm³ | Minimum dripping flow: 50 L/min(ANR) | Mass: 0.41 kg | Case material: Polycarbonate (standard) | Spec: Clean/Low-particle (-D) | ||
| AL40-N06-D | NPT 3/4, clean/low-particle spec | SMC | Body size: 40-06 | Thread: NPT | Port size: 3/4 | Mounting: No mounting option | Max working pressure: 1.0 MPa | Proof pressure: 1.5 MPa | Operating temperature: -5 to 60°C | Recommended oil: Turbine oil class 1 (ISO VG32) | Oil capacity: 135 cm³ | Minimum dripping flow: 50 L/min(ANR) | Mass: 0.41 kg | Case material: Polycarbonate (standard) | Spec: Clean/Low-particle (-D) | ||
| AL40-N06B-D | NPT 3/4, Bracket, clean/low-particle spec | SMC | Body size: 40-06 | Thread: NPT | Port size: 3/4 | Mounting: Bracket | Max working pressure: 1.0 MPa | Proof pressure: 1.5 MPa | Operating temperature: -5 to 60°C | Recommended oil: Turbine oil class 1 (ISO VG32) | Oil capacity: 135 cm³ | Minimum dripping flow: 50 L/min(ANR) | Mass: 0.41 kg | Case material: Polycarbonate (standard) | Spec: Clean/Low-particle (-D) | ||
| AL40-F06-D | G 3/4, clean/low-particle spec | SMC | Body size: 40-06 | Thread: G | Port size: 3/4 | Mounting: No mounting option | Max working pressure: 1.0 MPa | Proof pressure: 1.5 MPa | Operating temperature: -5 to 60°C | Recommended oil: Turbine oil class 1 (ISO VG32) | Oil capacity: 135 cm³ | Minimum dripping flow: 50 L/min(ANR) | Mass: 0.41 kg | Case material: Polycarbonate (standard) | Spec: Clean/Low-particle (-D) | ||
| AL40-F06B-D | G 3/4, Bracket, clean/low-particle spec | SMC | Body size: 40-06 | Thread: G | Port size: 3/4 | Mounting: Bracket | Max working pressure: 1.0 MPa | Proof pressure: 1.5 MPa | Operating temperature: -5 to 60°C | Recommended oil: Turbine oil class 1 (ISO VG32) | Oil capacity: 135 cm³ | Minimum dripping flow: 50 L/min(ANR) | Mass: 0.41 kg | Case material: Polycarbonate (standard) | Spec: Clean/Low-particle (-D) |
