Deceleration Valves
Yuken
[Yuken] — Deceleration Valve (ZT/ZG-03/06/10)
Family ID: YUK-FC-ZDEC
Deceleration Valves · Deceleration and Check Valves. Cam-operated flow increase/decrease and passage open/close. Max. operating pressure: 21 MPa. Max. flow: 30 (03) / 80 (06) / 200 (10) L/min. Threaded (T) / sub-plate (G). Bypass throttle valve built-in (-T) keeps actuator creep feed even when spool blocks the passage. Spool type: normal open / normal close (-C).
24 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| ZT-03-22 | Deceleration Valve ZT-03-22, Threaded | Yuken | Type: Deceleration Valve | Mounting: Threaded | Valve Size: 03 | Bypass Throttle Valve: No | Spool Type: Normal Open | Max. Operating Pressure: 21 MPa | Max. Flow: 30 L/min | Check Valve: No | Mass: 4.3 kg | Design No.: 22 | ||
| ZT-03-C-22 | Deceleration Valve ZT-03-C-22, Threaded | Yuken | Type: Deceleration Valve | Mounting: Threaded | Valve Size: 03 | Bypass Throttle Valve: No | Spool Type: Normal Close (-C) | Max. Operating Pressure: 21 MPa | Max. Flow: 30 L/min | Check Valve: No | Mass: 4.3 kg | Design No.: 22 | ||
| ZT-03-T-22 | Deceleration Valve ZT-03-T-22, Threaded | Yuken | Type: Deceleration Valve | Mounting: Threaded | Valve Size: 03 | Bypass Throttle Valve: Yes (-T) | Spool Type: Normal Open | Max. Operating Pressure: 21 MPa | Max. Flow: 30 L/min | Check Valve: No | Mass: 4.3 kg | Design No.: 22 | ||
| ZT-03-T-C-22 | Deceleration Valve ZT-03-T-C-22, Threaded | Yuken | Type: Deceleration Valve | Mounting: Threaded | Valve Size: 03 | Bypass Throttle Valve: Yes (-T) | Spool Type: Normal Close (-C) | Max. Operating Pressure: 21 MPa | Max. Flow: 30 L/min | Check Valve: No | Mass: 4.3 kg | Design No.: 22 | ||
| ZT-06-22 | Deceleration Valve ZT-06-22, Threaded | Yuken | Type: Deceleration Valve | Mounting: Threaded | Valve Size: 06 | Bypass Throttle Valve: No | Spool Type: Normal Open | Max. Operating Pressure: 21 MPa | Max. Flow: 80 L/min | Check Valve: No | Mass: 8.7 kg | Design No.: 22 | ||
| ZT-06-C-22 | Deceleration Valve ZT-06-C-22, Threaded | Yuken | Type: Deceleration Valve | Mounting: Threaded | Valve Size: 06 | Bypass Throttle Valve: No | Spool Type: Normal Close (-C) | Max. Operating Pressure: 21 MPa | Max. Flow: 80 L/min | Check Valve: No | Mass: 8.7 kg | Design No.: 22 | ||
| ZT-06-T-22 | Deceleration Valve ZT-06-T-22, Threaded | Yuken | Type: Deceleration Valve | Mounting: Threaded | Valve Size: 06 | Bypass Throttle Valve: Yes (-T) | Spool Type: Normal Open | Max. Operating Pressure: 21 MPa | Max. Flow: 80 L/min | Check Valve: No | Mass: 8.7 kg | Design No.: 22 | ||
| ZT-06-T-C-22 | Deceleration Valve ZT-06-T-C-22, Threaded | Yuken | Type: Deceleration Valve | Mounting: Threaded | Valve Size: 06 | Bypass Throttle Valve: Yes (-T) | Spool Type: Normal Close (-C) | Max. Operating Pressure: 21 MPa | Max. Flow: 80 L/min | Check Valve: No | Mass: 8.7 kg | Design No.: 22 | ||
| ZT-10-22 | Deceleration Valve ZT-10-22, Threaded | Yuken | Type: Deceleration Valve | Mounting: Threaded | Valve Size: 10 | Bypass Throttle Valve: No | Spool Type: Normal Open | Max. Operating Pressure: 21 MPa | Max. Flow: 200 L/min | Check Valve: No | Mass: 17 kg | Design No.: 22 | ||
| ZT-10-C-22 | Deceleration Valve ZT-10-C-22, Threaded | Yuken | Type: Deceleration Valve | Mounting: Threaded | Valve Size: 10 | Bypass Throttle Valve: No | Spool Type: Normal Close (-C) | Max. Operating Pressure: 21 MPa | Max. Flow: 200 L/min | Check Valve: No | Mass: 17 kg | Design No.: 22 | ||
| ZT-10-T-22 | Deceleration Valve ZT-10-T-22, Threaded | Yuken | Type: Deceleration Valve | Mounting: Threaded | Valve Size: 10 | Bypass Throttle Valve: Yes (-T) | Spool Type: Normal Open | Max. Operating Pressure: 21 MPa | Max. Flow: 200 L/min | Check Valve: No | Mass: 17 kg | Design No.: 22 | ||
| ZT-10-T-C-22 | Deceleration Valve ZT-10-T-C-22, Threaded | Yuken | Type: Deceleration Valve | Mounting: Threaded | Valve Size: 10 | Bypass Throttle Valve: Yes (-T) | Spool Type: Normal Close (-C) | Max. Operating Pressure: 21 MPa | Max. Flow: 200 L/min | Check Valve: No | Mass: 17 kg | Design No.: 22 | ||
| ZG-03-22 | Deceleration Valve ZG-03-22, Sub-plate | Yuken | Type: Deceleration Valve | Mounting: Sub-plate | Valve Size: 03 | Bypass Throttle Valve: No | Spool Type: Normal Open | Max. Operating Pressure: 21 MPa | Max. Flow: 30 L/min | Check Valve: No | Mass: 4.3 kg | Design No.: 22 | ||
| ZG-03-C-22 | Deceleration Valve ZG-03-C-22, Sub-plate | Yuken | Type: Deceleration Valve | Mounting: Sub-plate | Valve Size: 03 | Bypass Throttle Valve: No | Spool Type: Normal Close (-C) | Max. Operating Pressure: 21 MPa | Max. Flow: 30 L/min | Check Valve: No | Mass: 4.3 kg | Design No.: 22 | ||
| ZG-03-T-22 | Deceleration Valve ZG-03-T-22, Sub-plate | Yuken | Type: Deceleration Valve | Mounting: Sub-plate | Valve Size: 03 | Bypass Throttle Valve: Yes (-T) | Spool Type: Normal Open | Max. Operating Pressure: 21 MPa | Max. Flow: 30 L/min | Check Valve: No | Mass: 4.3 kg | Design No.: 22 | ||
| ZG-03-T-C-22 | Deceleration Valve ZG-03-T-C-22, Sub-plate | Yuken | Type: Deceleration Valve | Mounting: Sub-plate | Valve Size: 03 | Bypass Throttle Valve: Yes (-T) | Spool Type: Normal Close (-C) | Max. Operating Pressure: 21 MPa | Max. Flow: 30 L/min | Check Valve: No | Mass: 4.3 kg | Design No.: 22 | ||
| ZG-06-22 | Deceleration Valve ZG-06-22, Sub-plate | Yuken | Type: Deceleration Valve | Mounting: Sub-plate | Valve Size: 06 | Bypass Throttle Valve: No | Spool Type: Normal Open | Max. Operating Pressure: 21 MPa | Max. Flow: 80 L/min | Check Valve: No | Mass: 8.7 kg | Design No.: 22 | ||
| ZG-06-C-22 | Deceleration Valve ZG-06-C-22, Sub-plate | Yuken | Type: Deceleration Valve | Mounting: Sub-plate | Valve Size: 06 | Bypass Throttle Valve: No | Spool Type: Normal Close (-C) | Max. Operating Pressure: 21 MPa | Max. Flow: 80 L/min | Check Valve: No | Mass: 8.7 kg | Design No.: 22 | ||
| ZG-06-T-22 | Deceleration Valve ZG-06-T-22, Sub-plate | Yuken | Type: Deceleration Valve | Mounting: Sub-plate | Valve Size: 06 | Bypass Throttle Valve: Yes (-T) | Spool Type: Normal Open | Max. Operating Pressure: 21 MPa | Max. Flow: 80 L/min | Check Valve: No | Mass: 8.7 kg | Design No.: 22 | ||
| ZG-06-T-C-22 | Deceleration Valve ZG-06-T-C-22, Sub-plate | Yuken | Type: Deceleration Valve | Mounting: Sub-plate | Valve Size: 06 | Bypass Throttle Valve: Yes (-T) | Spool Type: Normal Close (-C) | Max. Operating Pressure: 21 MPa | Max. Flow: 80 L/min | Check Valve: No | Mass: 8.7 kg | Design No.: 22 | ||
| ZG-10-22 | Deceleration Valve ZG-10-22, Sub-plate | Yuken | Type: Deceleration Valve | Mounting: Sub-plate | Valve Size: 10 | Bypass Throttle Valve: No | Spool Type: Normal Open | Max. Operating Pressure: 21 MPa | Max. Flow: 200 L/min | Check Valve: No | Mass: 17 kg | Design No.: 22 | ||
| ZG-10-C-22 | Deceleration Valve ZG-10-C-22, Sub-plate | Yuken | Type: Deceleration Valve | Mounting: Sub-plate | Valve Size: 10 | Bypass Throttle Valve: No | Spool Type: Normal Close (-C) | Max. Operating Pressure: 21 MPa | Max. Flow: 200 L/min | Check Valve: No | Mass: 17 kg | Design No.: 22 | ||
| ZG-10-T-22 | Deceleration Valve ZG-10-T-22, Sub-plate | Yuken | Type: Deceleration Valve | Mounting: Sub-plate | Valve Size: 10 | Bypass Throttle Valve: Yes (-T) | Spool Type: Normal Open | Max. Operating Pressure: 21 MPa | Max. Flow: 200 L/min | Check Valve: No | Mass: 17 kg | Design No.: 22 | ||
| ZG-10-T-C-22 | Deceleration Valve ZG-10-T-C-22, Sub-plate | Yuken | Type: Deceleration Valve | Mounting: Sub-plate | Valve Size: 10 | Bypass Throttle Valve: Yes (-T) | Spool Type: Normal Close (-C) | Max. Operating Pressure: 21 MPa | Max. Flow: 200 L/min | Check Valve: No | Mass: 17 kg | Design No.: 22 |
