![[Yuken] — Feed Control Valve 1-stage (UCF1G)](https://img.prosourcemro.com/2026/05/002-42-1024x842.png)
Feed Control Valves
Yuken
[Yuken] — Feed Control Valve 1-stage (UCF1G)
Family ID: YUK-FC-UCF1
Feed Control Valves. Compact combination of flow control + check valve and deceleration valve for machine-tool rapid→feed switching by cam. Pressure/temperature compensated. Max. operating pressure: 14 MPa. 1-stage control type. Sizes 01/03/04. Deceleration valve max. flow A:12 / B:8 / C:4 L/min (size 01). Internal / external (-E) drain.
15 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| UCF1G-01-4-A-11 | Feed Control Valve UCF1G-01-4-A-11, internal drain | Yuken | Type: Feed Control Valve (1-stage) | Mounting: Gasket | Valve Size: 01 | Adjustable Flow: 4 L/min | Deceleration Valve Max. Flow: A (12 L/min) | Max. Flow: 16 (12 at ≥7 MPa) L/min | Adjustment Range: 0.03–4 L/min | Free Flow: 20 L/min | Drain: Internal | Max. Operating Pressure: 14 MPa | Mass: 1.6 kg | Design No.: 11 | ||
| UCF1G-01-4-A-E-11 | Feed Control Valve UCF1G-01-4-A-E-11, external drain | Yuken | Type: Feed Control Valve (1-stage) | Mounting: Gasket | Valve Size: 01 | Adjustable Flow: 4 L/min | Deceleration Valve Max. Flow: A (12 L/min) | Max. Flow: 16 (12 at ≥7 MPa) L/min | Adjustment Range: 0.03–4 L/min | Free Flow: 20 L/min | Drain: External (-E) | Max. Operating Pressure: 14 MPa | Mass: 1.6 kg | Design No.: 11 | ||
| UCF1G-01-4-B-11 | Feed Control Valve UCF1G-01-4-B-11, internal drain | Yuken | Type: Feed Control Valve (1-stage) | Mounting: Gasket | Valve Size: 01 | Adjustable Flow: 4 L/min | Deceleration Valve Max. Flow: B (8 L/min) | Max. Flow: 12 (8) L/min | Adjustment Range: 0.05–4 L/min | Free Flow: 20 L/min | Drain: Internal | Max. Operating Pressure: 14 MPa | Mass: 1.6 kg | Design No.: 11 | ||
| UCF1G-01-4-B-E-11 | Feed Control Valve UCF1G-01-4-B-E-11, external drain | Yuken | Type: Feed Control Valve (1-stage) | Mounting: Gasket | Valve Size: 01 | Adjustable Flow: 4 L/min | Deceleration Valve Max. Flow: B (8 L/min) | Max. Flow: 12 (8) L/min | Adjustment Range: 0.05–4 L/min | Free Flow: 20 L/min | Drain: External (-E) | Max. Operating Pressure: 14 MPa | Mass: 1.6 kg | Design No.: 11 | ||
| UCF1G-01-4-C-11 | Feed Control Valve UCF1G-01-4-C-11, internal drain | Yuken | Type: Feed Control Valve (1-stage) | Mounting: Gasket | Valve Size: 01 | Adjustable Flow: 4 L/min | Deceleration Valve Max. Flow: C (4 L/min) | Max. Flow: 8 (4) L/min | Adjustment Range: 0.05–4 L/min | Free Flow: 20 L/min | Drain: Internal | Max. Operating Pressure: 14 MPa | Mass: 1.6 kg | Design No.: 11 | ||
| UCF1G-01-4-C-E-11 | Feed Control Valve UCF1G-01-4-C-E-11, external drain | Yuken | Type: Feed Control Valve (1-stage) | Mounting: Gasket | Valve Size: 01 | Adjustable Flow: 4 L/min | Deceleration Valve Max. Flow: C (4 L/min) | Max. Flow: 8 (4) L/min | Adjustment Range: 0.05–4 L/min | Free Flow: 20 L/min | Drain: External (-E) | Max. Operating Pressure: 14 MPa | Mass: 1.6 kg | Design No.: 11 | ||
| UCF1G-01-8-A-11 | Feed Control Valve UCF1G-01-8-A-11, internal drain | Yuken | Type: Feed Control Valve (1-stage) | Mounting: Gasket | Valve Size: 01 | Adjustable Flow: 8 L/min | Deceleration Valve Max. Flow: A (12 L/min) | Max. Flow: 20 (12) L/min | Adjustment Range: 0.03–8 L/min | Free Flow: 20 L/min | Drain: Internal | Max. Operating Pressure: 14 MPa | Mass: 1.6 kg | Design No.: 11 | ||
| UCF1G-01-8-A-E-11 | Feed Control Valve UCF1G-01-8-A-E-11, external drain | Yuken | Type: Feed Control Valve (1-stage) | Mounting: Gasket | Valve Size: 01 | Adjustable Flow: 8 L/min | Deceleration Valve Max. Flow: A (12 L/min) | Max. Flow: 20 (12) L/min | Adjustment Range: 0.03–8 L/min | Free Flow: 20 L/min | Drain: External (-E) | Max. Operating Pressure: 14 MPa | Mass: 1.6 kg | Design No.: 11 | ||
| UCF1G-01-8-B-11 | Feed Control Valve UCF1G-01-8-B-11, internal drain | Yuken | Type: Feed Control Valve (1-stage) | Mounting: Gasket | Valve Size: 01 | Adjustable Flow: 8 L/min | Deceleration Valve Max. Flow: B (8 L/min) | Max. Flow: 16 (8) L/min | Adjustment Range: 0.05–8 L/min | Free Flow: 20 L/min | Drain: Internal | Max. Operating Pressure: 14 MPa | Mass: 1.6 kg | Design No.: 11 | ||
| UCF1G-01-8-B-E-11 | Feed Control Valve UCF1G-01-8-B-E-11, external drain | Yuken | Type: Feed Control Valve (1-stage) | Mounting: Gasket | Valve Size: 01 | Adjustable Flow: 8 L/min | Deceleration Valve Max. Flow: B (8 L/min) | Max. Flow: 16 (8) L/min | Adjustment Range: 0.05–8 L/min | Free Flow: 20 L/min | Drain: External (-E) | Max. Operating Pressure: 14 MPa | Mass: 1.6 kg | Design No.: 11 | ||
| UCF1G-01-8-C-11 | Feed Control Valve UCF1G-01-8-C-11, internal drain | Yuken | Type: Feed Control Valve (1-stage) | Mounting: Gasket | Valve Size: 01 | Adjustable Flow: 8 L/min | Deceleration Valve Max. Flow: C (4 L/min) | Max. Flow: 12 (4) L/min | Adjustment Range: 0.05–8 L/min | Free Flow: 20 L/min | Drain: Internal | Max. Operating Pressure: 14 MPa | Mass: 1.6 kg | Design No.: 11 | ||
| UCF1G-01-8-C-E-11 | Feed Control Valve UCF1G-01-8-C-E-11, external drain | Yuken | Type: Feed Control Valve (1-stage) | Mounting: Gasket | Valve Size: 01 | Adjustable Flow: 8 L/min | Deceleration Valve Max. Flow: C (4 L/min) | Max. Flow: 12 (4) L/min | Adjustment Range: 0.05–8 L/min | Free Flow: 20 L/min | Drain: External (-E) | Max. Operating Pressure: 14 MPa | Mass: 1.6 kg | Design No.: 11 | ||
| UCF1G-03-4-10 | Feed Control Valve UCF1G-03-4-10, external drain | Yuken | Type: Feed Control Valve (1-stage) | Mounting: Gasket | Valve Size: 03 | Adjustable Flow: 4 L/min | Max. Flow: 40 L/min | Adjustment Range: 0.05–4 L/min | Free Flow: 40 L/min | Drain: External | Max. Operating Pressure: 14 MPa | Mass: 2.6 kg | Design No.: 10 | ||
| UCF1G-03-8-10 | Feed Control Valve UCF1G-03-8-10, external drain | Yuken | Type: Feed Control Valve (1-stage) | Mounting: Gasket | Valve Size: 03 | Adjustable Flow: 8 L/min | Max. Flow: 40 L/min | Adjustment Range: 0.05–8 L/min | Free Flow: 40 L/min | Drain: External | Max. Operating Pressure: 14 MPa | Mass: 2.6 kg | Design No.: 10 | ||
| UCF1G-04-30-30 | Feed Control Valve UCF1G-04-30-30, external drain | Yuken | Type: Feed Control Valve (1-stage) | Mounting: Gasket | Valve Size: 04 | Adjustable Flow: 30 L/min | Max. Flow: 80 (40) L/min | Adjustment Range: 0.1–22 L/min | Free Flow: 80 L/min | Drain: External | Max. Operating Pressure: 14 MPa | Mass: 6.5 kg | Design No.: 30 |
