![[Yuken] — HC Type Pressure Control Valve (HCT-06)](https://img.prosourcemro.com/2026/05/002-31-765x1024.png)
Pressure Control (H/HC)
Yuken
[Yuken] — HC Type Pressure Control Valve (HCT-06)
Family ID: YUK-PC-HHC-HCT-06
H/HC Type Pressure Control Valves. Max. operating pressure: 21 MPa. Max. flow: 125 L/min. HC type, Threaded mounting. Pressure ranges: L/M/N/A/B/C (0.25–14 MPa). Valve forms 1–4. Auxiliary pilot (-P) available on N/A/B/C ranges (forms per Yuken combination table). Mass 7.1 kg.
40 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| HCT-06-L1-22 | HC Type Pressure Control Valve HCT-06-L1, Counter Balance Valve, range L | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: L (0.25–0.45 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | ||
| HCT-06-M1-22 | HC Type Pressure Control Valve HCT-06-M1, Counter Balance Valve, range M | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: M (0.45–0.9 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | ||
| HCT-06-N1-22 | HC Type Pressure Control Valve HCT-06-N1, Counter Balance Valve, range N | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | ||
| HCT-06-N1-P-22 | HC Type Pressure Control Valve HCT-06-N1-P, Counter Balance Valve, range N, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | ||
| HCT-06-A1-22 | HC Type Pressure Control Valve HCT-06-A1, Counter Balance Valve, range A | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | ||
| HCT-06-A1-P-22 | HC Type Pressure Control Valve HCT-06-A1-P, Counter Balance Valve, range A, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | ||
| HCT-06-B1-22 | HC Type Pressure Control Valve HCT-06-B1, Counter Balance Valve, range B | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | ||
| HCT-06-B1-P-22 | HC Type Pressure Control Valve HCT-06-B1-P, Counter Balance Valve, range B, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | ||
| HCT-06-C1-22 | HC Type Pressure Control Valve HCT-06-C1, Counter Balance Valve, range C | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | ||
| HCT-06-C1-P-22 | HC Type Pressure Control Valve HCT-06-C1-P, Counter Balance Valve, range C, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 1 – Counter Balance Valve (Internal pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | ||
| HCT-06-L2-22 | HC Type Pressure Control Valve HCT-06-L2, Sequence Valve with Check Valve, range L | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: L (0.25–0.45 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | ||
| HCT-06-M2-22 | HC Type Pressure Control Valve HCT-06-M2, Sequence Valve with Check Valve, range M | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: M (0.45–0.9 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | ||
| HCT-06-N2-22 | HC Type Pressure Control Valve HCT-06-N2, Sequence Valve with Check Valve, range N | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | ||
| HCT-06-N2-P-22 | HC Type Pressure Control Valve HCT-06-N2-P, Sequence Valve with Check Valve, range N, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | ||
| HCT-06-A2-22 | HC Type Pressure Control Valve HCT-06-A2, Sequence Valve with Check Valve, range A | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | ||
| HCT-06-A2-P-22 | HC Type Pressure Control Valve HCT-06-A2-P, Sequence Valve with Check Valve, range A, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | ||
| HCT-06-B2-22 | HC Type Pressure Control Valve HCT-06-B2, Sequence Valve with Check Valve, range B | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | ||
| HCT-06-B2-P-22 | HC Type Pressure Control Valve HCT-06-B2-P, Sequence Valve with Check Valve, range B, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | ||
| HCT-06-C2-22 | HC Type Pressure Control Valve HCT-06-C2, Sequence Valve with Check Valve, range C | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | ||
| HCT-06-C2-P-22 | HC Type Pressure Control Valve HCT-06-C2-P, Sequence Valve with Check Valve, range C, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 2 – Sequence Valve with Check Valve (Internal pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | ||
| HCT-06-L3-22 | HC Type Pressure Control Valve HCT-06-L3, Sequence Valve with Check Valve, range L | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: L (0.25–0.45 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | ||
| HCT-06-M3-22 | HC Type Pressure Control Valve HCT-06-M3, Sequence Valve with Check Valve, range M | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: M (0.45–0.9 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | ||
| HCT-06-N3-22 | HC Type Pressure Control Valve HCT-06-N3, Sequence Valve with Check Valve, range N | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | ||
| HCT-06-N3-P-22 | HC Type Pressure Control Valve HCT-06-N3-P, Sequence Valve with Check Valve, range N, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | ||
| HCT-06-A3-22 | HC Type Pressure Control Valve HCT-06-A3, Sequence Valve with Check Valve, range A | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | ||
| HCT-06-A3-P-22 | HC Type Pressure Control Valve HCT-06-A3-P, Sequence Valve with Check Valve, range A, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | ||
| HCT-06-B3-22 | HC Type Pressure Control Valve HCT-06-B3, Sequence Valve with Check Valve, range B | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | ||
| HCT-06-B3-P-22 | HC Type Pressure Control Valve HCT-06-B3-P, Sequence Valve with Check Valve, range B, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | ||
| HCT-06-C3-22 | HC Type Pressure Control Valve HCT-06-C3, Sequence Valve with Check Valve, range C | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | ||
| HCT-06-C3-P-22 | HC Type Pressure Control Valve HCT-06-C3-P, Sequence Valve with Check Valve, range C, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 3 – Sequence Valve with Check Valve (External pilot, external drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | ||
| HCT-06-L4-22 | HC Type Pressure Control Valve HCT-06-L4, Counter Balance Valve, range L | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: L (0.25–0.45 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | ||
| HCT-06-M4-22 | HC Type Pressure Control Valve HCT-06-M4, Counter Balance Valve, range M | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: M (0.45–0.9 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | ||
| HCT-06-N4-22 | HC Type Pressure Control Valve HCT-06-N4, Counter Balance Valve, range N | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | ||
| HCT-06-N4-P-22 | HC Type Pressure Control Valve HCT-06-N4-P, Counter Balance Valve, range N, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: N (0.9–1.8 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | ||
| HCT-06-A4-22 | HC Type Pressure Control Valve HCT-06-A4, Counter Balance Valve, range A | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | ||
| HCT-06-A4-P-22 | HC Type Pressure Control Valve HCT-06-A4-P, Counter Balance Valve, range A, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: A (1.8–3.5 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | ||
| HCT-06-B4-22 | HC Type Pressure Control Valve HCT-06-B4, Counter Balance Valve, range B | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | ||
| HCT-06-B4-P-22 | HC Type Pressure Control Valve HCT-06-B4-P, Counter Balance Valve, range B, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: B (3.5–7.0 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | ||
| HCT-06-C4-22 | HC Type Pressure Control Valve HCT-06-C4, Counter Balance Valve, range C | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: No | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 | ||
| HCT-06-C4-P-22 | HC Type Pressure Control Valve HCT-06-C4-P, Counter Balance Valve, range C, aux pilot | Yuken | Type: HC Type Pressure Control Valve | Mounting: Threaded | Valve Size: 06 | Pressure Range: C (7.0–14.0 MPa) | Valve Form: 4 – Counter Balance Valve (External pilot, internal drain) | Auxiliary Pilot: Yes (-P) | Max. Operating Pressure: 21 MPa | Max. Flow: 125 L/min | Mass: 7.1 kg | Design No.: 22 |
