Motors
Yuken
[Yuken] — 'M' Series Electric Motor M5 (Coupling / separate housing, 5.5/7.5/11/15/18.5 kW x 4P)
Family ID: YKN-M5-MOTOR
'M' Series Electric Motors (Type M5). Coupling / separate housing (커플링) mounting type for Yuken hydraulic pumps: A37(04E)/A56 (single), A1637/A2237/A1656/A2256 (double), A37R1/A56R1 (var/fixed double). Output: 5.5/7.5/11/15/18.5 kW x 4P. Voltage: 50Hz AC200V / 60Hz AC200/220/230V. Insulation class F. Totally enclosed, surface-cooled (IP44 / IC411 / IEC60034-1).
5 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| M5-5.5-40 | M Series motor M5, 5.5kW x 4P, Coupling / separate housing | Yuken | Motor Type: M5 | Mounting: Coupling / separate housing (커플링) | Output: 5.5 kW x 4P | Electrical: 200V-50Hz: 23.4A rated / 200A start / 1465rpm; 200V-60Hz: 21.4A rated / 166A start / 1760rpm; 220V-60Hz: 20.6A rated / 183A start / 1765rpm | Insulation Class: F | Enclosure: Totally enclosed, surface-cooled (IP44, IC411, IEC60034-1) | Ambient: Indoor, -20 to +40C, RH <=100% (no condensation), altitude <=1000m | Mass (approx): 68 kg | Applicable Pumps: A37(04E)/A56 (single), A1637/A2237/A1656/A2256 (double), A37R1/A56R1 (var/fixed double) | Design No: 40 | ||
| M5-7.5-40 | M Series motor M5, 7.5kW x 4P, Coupling / separate housing | Yuken | Motor Type: M5 | Mounting: Coupling / separate housing (커플링) | Output: 7.5 kW x 4P | Electrical: 200V-50Hz: 30.8A rated / 264A start / 1460rpm; 200V-60Hz: 28.6A rated / 218A start / 1755rpm; 220V-60Hz: 27.4A rated / 240A start / 1765rpm | Insulation Class: F | Enclosure: Totally enclosed, surface-cooled (IP44, IC411, IEC60034-1) | Ambient: Indoor, -20 to +40C, RH <=100% (no condensation), altitude <=1000m | Mass (approx): 76 kg | Applicable Pumps: A37(04E)/A56 (single), A1637/A2237/A1656/A2256 (double), A37R1/A56R1 (var/fixed double) | Design No: 40 | ||
| M5-11-40 | M Series motor M5, 11kW x 4P, Coupling / separate housing | Yuken | Motor Type: M5 | Mounting: Coupling / separate housing (커플링) | Output: 11 kW x 4P | Electrical: 200V-50Hz: 46.0A rated / 365A start / 1475rpm; 200V-60Hz: 42.0A rated / 302A start / 1770rpm; 220V-60Hz: 40.0A rated / 332A start / 1775rpm | Insulation Class: F | Enclosure: Totally enclosed, surface-cooled (IP44, IC411, IEC60034-1) | Ambient: Indoor, -20 to +40C, RH <=100% (no condensation), altitude <=1000m | Mass (approx): 114 kg | Applicable Pumps: A37(04E)/A56 (single), A1637/A2237/A1656/A2256 (double), A37R1/A56R1 (var/fixed double) | Design No: 40 | ||
| M5-15-40 | M Series motor M5, 15kW x 4P, Coupling / separate housing | Yuken | Motor Type: M5 | Mounting: Coupling / separate housing (커플링) | Output: 15 kW x 4P | Electrical: 200V-50Hz: 58.8A rated / 484A start / 1470rpm; 200V-60Hz: 55.6A rated / 408A start / 1760rpm; 220V-60Hz: 52.0A rated / 449A start / 1770rpm | Insulation Class: F | Enclosure: Totally enclosed, surface-cooled (IP44, IC411, IEC60034-1) | Ambient: Indoor, -20 to +40C, RH <=100% (no condensation), altitude <=1000m | Mass (approx): 131 kg | Applicable Pumps: A37(04E)/A56 (single), A1637/A2237/A1656/A2256 (double), A37R1/A56R1 (var/fixed double) | Design No: 40 | ||
| M5-18.5-40 | M Series motor M5, 18.5kW x 4P, Coupling / separate housing | Yuken | Motor Type: M5 | Mounting: Coupling / separate housing (커플링) | Output: 18.5 kW x 4P | Electrical: 200V-50Hz: 74.0A rated / 668A start / 1475rpm; 200V-60Hz: 69.0A rated / 524A start / 1770rpm; 220V-60Hz: 65.0A rated / 576A start / 1775rpm | Insulation Class: F | Enclosure: Totally enclosed, surface-cooled (IP44, IC411, IEC60034-1) | Ambient: Indoor, -20 to +40C, RH <=100% (no condensation), altitude <=1000m | Mass (approx): 193 kg | Applicable Pumps: A37(04E)/A56 (single), A1637/A2237/A1656/A2256 (double), A37R1/A56R1 (var/fixed double) | Design No: 40 |
