[Yuken] — Needle Valve (GCT/GCTR-02)

Family ID: YUK-FC-GCT

Needle Valves. Used as stop valves for pressure-gauge / small-flow lines or as throttle valves for pilot lines. Max. operating pressure: 35 MPa. Inline type (GCT) / angle type (GCTR), threaded. Adapter AG-02S/03S/04S available separately for pressure-gauge mounting (with pressure snubber).

2 product codes available in this family

RFQ Cart (0)

Product Codes & Specifications

	Product Code	Description	Brand	Spec
	GCT-02-34	Needle Valve GCT-02-34, inline type, threaded	Yuken	Type: Needle Valve \| Configuration: Inline type \| Connection: Threaded \| Valve Size: 02 \| Max. Operating Pressure: 35 MPa \| Mass: 0.34 kg \| Adapter (separate order): AG-02S / AG-03S / AG-04S (with pressure snubber) \| Design No.: 34
	GCTR-02-34	Needle Valve GCTR-02-34, angle type, threaded	Yuken	Type: Needle Valve \| Configuration: Angle type \| Connection: Threaded \| Valve Size: 02 \| Max. Operating Pressure: 35 MPa \| Mass: 0.34 kg \| Adapter (separate order): AG-02S / AG-03S / AG-04S (with pressure snubber) \| Design No.: 34
