Motor Pumps
Yuken
[Yuken] — PAL Pump PM16 Motor-Pump (Pressure Compensator Type, 1.5/2.2 kW x 4P)
Family ID: YKN-PM16-MP
PAL Pump, Pressure Compensator Type (PM series motor-pump). Theoretical displacement: 15.8 cm3/rev. Min. adjustable flow: 6.0 cm3/rev. Pressure adjustment range: B 1.2-7 MPa / C 2-16 MPa. Motor: 1.5/2.2 kW x 4P, 50Hz AC200V / 60Hz AC200/220/230V. Control type: 01 (pressure compensator).
4 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| PM16-01B-1.5-30 | PAL Pump PM16, 1.5kW, pressure range B (1.2~7 MPa) | Yuken | Series: PM16 | Type: Motor-Pump (variable piston pump + motor) | Control: 01 Pressure Compensator | Theoretical Displacement: 15.8 cm3/rev | Min Adjustable Flow: 6.0 cm3/rev | Pressure Range Code: B (1.2~7 MPa) | Max Working Pressure: 7 MPa | Motor Output: 1.5 kW x 4P | Motor Voltage: 50Hz AC200V / 60Hz AC200/220/230V | Mass (approx): 39.5 kg | Design No: 30 | ||
| PM16-01C-1.5-30 | PAL Pump PM16, 1.5kW, pressure range C (2~16 MPa) | Yuken | Series: PM16 | Type: Motor-Pump (variable piston pump + motor) | Control: 01 Pressure Compensator | Theoretical Displacement: 15.8 cm3/rev | Min Adjustable Flow: 6.0 cm3/rev | Pressure Range Code: C (2~16 MPa) | Max Working Pressure: 16 MPa | Motor Output: 1.5 kW x 4P | Motor Voltage: 50Hz AC200V / 60Hz AC200/220/230V | Mass (approx): 39.5 kg | Design No: 30 | ||
| PM16-01B-2.2-30 | PAL Pump PM16, 2.2kW, pressure range B (1.2~7 MPa) | Yuken | Series: PM16 | Type: Motor-Pump (variable piston pump + motor) | Control: 01 Pressure Compensator | Theoretical Displacement: 15.8 cm3/rev | Min Adjustable Flow: 6.0 cm3/rev | Pressure Range Code: B (1.2~7 MPa) | Max Working Pressure: 7 MPa | Motor Output: 2.2 kW x 4P | Motor Voltage: 50Hz AC200V / 60Hz AC200/220/230V | Mass (approx): 43.6 kg | Design No: 30 | ||
| PM16-01C-2.2-30 | PAL Pump PM16, 2.2kW, pressure range C (2~16 MPa) | Yuken | Series: PM16 | Type: Motor-Pump (variable piston pump + motor) | Control: 01 Pressure Compensator | Theoretical Displacement: 15.8 cm3/rev | Min Adjustable Flow: 6.0 cm3/rev | Pressure Range Code: C (2~16 MPa) | Max Working Pressure: 16 MPa | Motor Output: 2.2 kW x 4P | Motor Voltage: 50Hz AC200V / 60Hz AC200/220/230V | Mass (approx): 43.6 kg | Design No: 30 |
