[Yuken] — SB1110 Proportional Pressure Control Valve (3/8 sub-plate, max 30 L/min)
Family ID: YK-SB1110
Proportional Electro-Hydraulic Pressure Control Valves. Normally-open, closed-loop pressure control controlling system pressure proportionally to input voltage, stable even at low flow. Port 3/8, sub-plate mounting. Max flow 30 L/min. Pressure adjustment range: B (0.2–6.9 MPa), H (0.2–24.5 MPa). Coil resistance 10Ω, supply DC24V. Hysteresis 1% max. Built-in fault-detection output.
2 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| SB1110-B-20 | SB1110 Proportional Pressure Control, B 0.2–6.9 MPa, 3/8, max 30 L/min | Yuken | Type: Proportional Pressure Control Valve | Series: SB1110 | Mounting: Sub-plate | Port: 3/8 | Max Flow: 30 L/min | Pressure Adj. Range: B (0.2–6.9 MPa) | Max Pressure: 6.9 MPa | Control: Closed loop (normally open) | Coil: 10Ω, DC24V | Hysteresis: 1% max | Design No.: 20 | ||
| SB1110-H-20 | SB1110 Proportional Pressure Control, H 0.2–24.5 MPa, 3/8, max 30 L/min | Yuken | Type: Proportional Pressure Control Valve | Series: SB1110 | Mounting: Sub-plate | Port: 3/8 | Max Flow: 30 L/min | Pressure Adj. Range: H (0.2–24.5 MPa) | Max Pressure: 24.5 MPa | Control: Closed loop (normally open) | Coil: 10Ω, DC24V | Hysteresis: 1% max | Design No.: 20 |
