Apex Dynamics AD High-Speed Precision Planetary Gearboxes (047-255)

Apex Dynamics AD High-Speed Precision Planetary Gearboxes (047-255)

APEX Dynamics AD series high-precision, high-speed inline planetary gearboxes with ISO 9409 flange output, in seven frame sizes from 047 to 255 and ratios 4 to 100 in one or two stages.

Key features

  • Seven frame sizes AD047, AD064, AD090, AD110, AD140, AD200, AD255 with ISO 9409 output flange (AD064-AD255)
  • 1-stage ratios 4, 5, 7, 10; 2-stage ratios 16, 20, 21, 25, 31, 35, 40, 50, 61, 70, 91, 100
  • Backlash classes P0 micro (<=1/<=3 arcmin, AD090 1-stage and AD110-AD255), P1 reduced (<=3/<=5), P2 standard (<=5/<=7)
  • Nominal output torque 14 to 2,000 Nm; emergency stop torque 3 times nominal
  • Nominal input speed 2,000-5,000 rpm, max. input speed up to 10,000 rpm; efficiency >=97% (1-stage), >=94% (2-stage)
  • Order code ends with the motor designation (manufacturer, type and model), e.g. AD047-010-P1 / SIEMENS 1FT6 041-4AF71

Specifications

Type Inline planetary gearbox, flange output
Code format AD<size>-<ratio>-<backlash> / motor
Torsional rigidity 7 to 1,006 Nm/arcmin (047-255)
Max. tilting moment M2K 55 to 5,500 Nm
Max. axial load F2aB 990 to 29,430 N
Weight 0.7 to 70.4 kg
Noise <=56 to <=70 dB(A)
Lubrication Synthetic lubrication oil, lubricated for life
Protection / mounting IP65, any mounting position
Operating temperature -10 to +90 C
Motor adapter Specify motor make and model when ordering
Source APEX Dynamics AD catalog, p. 3-7, 14-16
AD047-004-P1 Frame: 047 | Ratio i: 4 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Nominal torque T2N: 19 Nm
AD047-004-P2 Frame: 047 | Ratio i: 4 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Nominal torque T2N: 19 Nm
AD047-005-P1 Frame: 047 | Ratio i: 5 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Nominal torque T2N: 22 Nm
AD047-005-P2 Frame: 047 | Ratio i: 5 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Nominal torque T2N: 22 Nm
AD047-007-P1 Frame: 047 | Ratio i: 7 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Nominal torque T2N: 19 Nm
AD047-007-P2 Frame: 047 | Ratio i: 7 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Nominal torque T2N: 19 Nm
AD047-010-P1 Frame: 047 | Ratio i: 10 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Nominal torque T2N: 14 Nm
AD047-010-P2 Frame: 047 | Ratio i: 10 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Nominal torque T2N: 14 Nm
AD047-020-P1 Frame: 047 | Ratio i: 20 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 19 Nm
AD047-020-P2 Frame: 047 | Ratio i: 20 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 19 Nm
AD047-025-P1 Frame: 047 | Ratio i: 25 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 22 Nm
AD047-025-P2 Frame: 047 | Ratio i: 25 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 22 Nm
AD047-035-P1 Frame: 047 | Ratio i: 35 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 19 Nm
AD047-035-P2 Frame: 047 | Ratio i: 35 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 19 Nm
AD047-040-P1 Frame: 047 | Ratio i: 40 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 19 Nm
AD047-040-P2 Frame: 047 | Ratio i: 40 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 19 Nm
AD047-050-P1 Frame: 047 | Ratio i: 50 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 22 Nm
AD047-050-P2 Frame: 047 | Ratio i: 50 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 22 Nm
AD047-070-P1 Frame: 047 | Ratio i: 70 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 19 Nm
AD047-070-P2 Frame: 047 | Ratio i: 70 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 19 Nm
AD047-100-P1 Frame: 047 | Ratio i: 100 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 14 Nm
AD047-100-P2 Frame: 047 | Ratio i: 100 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 14 Nm
AD047-016-P1 Frame: 047 | Ratio i: 16 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 19 Nm
AD047-016-P2 Frame: 047 | Ratio i: 16 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 19 Nm
AD047-021-P1 Frame: 047 | Ratio i: 21 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 22 Nm
AD047-021-P2 Frame: 047 | Ratio i: 21 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 22 Nm
AD047-031-P1 Frame: 047 | Ratio i: 31 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 19 Nm
AD047-031-P2 Frame: 047 | Ratio i: 31 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 19 Nm
AD047-061-P1 Frame: 047 | Ratio i: 61 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 19 Nm
AD047-061-P2 Frame: 047 | Ratio i: 61 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 19 Nm
AD047-091-P1 Frame: 047 | Ratio i: 91 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 14 Nm
AD047-091-P2 Frame: 047 | Ratio i: 91 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 14 Nm
AD064-004-P1 Frame: 064 | Ratio i: 4 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Nominal torque T2N: 48 Nm
AD064-004-P2 Frame: 064 | Ratio i: 4 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Nominal torque T2N: 48 Nm
AD064-005-P1 Frame: 064 | Ratio i: 5 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Nominal torque T2N: 60 Nm
AD064-005-P2 Frame: 064 | Ratio i: 5 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Nominal torque T2N: 60 Nm
AD064-007-P1 Frame: 064 | Ratio i: 7 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Nominal torque T2N: 50 Nm
AD064-007-P2 Frame: 064 | Ratio i: 7 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Nominal torque T2N: 50 Nm
AD064-010-P1 Frame: 064 | Ratio i: 10 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Nominal torque T2N: 40 Nm
AD064-010-P2 Frame: 064 | Ratio i: 10 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Nominal torque T2N: 40 Nm
AD064-020-P1 Frame: 064 | Ratio i: 20 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 48 Nm
AD064-020-P2 Frame: 064 | Ratio i: 20 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 48 Nm
AD064-025-P1 Frame: 064 | Ratio i: 25 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 60 Nm
AD064-025-P2 Frame: 064 | Ratio i: 25 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 60 Nm
AD064-035-P1 Frame: 064 | Ratio i: 35 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 50 Nm
AD064-035-P2 Frame: 064 | Ratio i: 35 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 50 Nm
AD064-040-P1 Frame: 064 | Ratio i: 40 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 48 Nm
AD064-040-P2 Frame: 064 | Ratio i: 40 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 48 Nm
AD064-050-P1 Frame: 064 | Ratio i: 50 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 60 Nm
AD064-050-P2 Frame: 064 | Ratio i: 50 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 60 Nm
AD064-070-P1 Frame: 064 | Ratio i: 70 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 50 Nm
AD064-070-P2 Frame: 064 | Ratio i: 70 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 50 Nm
AD064-100-P1 Frame: 064 | Ratio i: 100 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 40 Nm
AD064-100-P2 Frame: 064 | Ratio i: 100 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 40 Nm
AD064-016-P1 Frame: 064 | Ratio i: 16 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 48 Nm
AD064-016-P2 Frame: 064 | Ratio i: 16 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 48 Nm
AD064-021-P1 Frame: 064 | Ratio i: 21 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 60 Nm
AD064-021-P2 Frame: 064 | Ratio i: 21 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 60 Nm
AD064-031-P1 Frame: 064 | Ratio i: 31 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 50 Nm
AD064-031-P2 Frame: 064 | Ratio i: 31 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 50 Nm
AD064-061-P1 Frame: 064 | Ratio i: 61 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 50 Nm
AD064-061-P2 Frame: 064 | Ratio i: 61 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 50 Nm
AD064-091-P1 Frame: 064 | Ratio i: 91 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 40 Nm
AD064-091-P2 Frame: 064 | Ratio i: 91 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 40 Nm
AD090-004-P0 Frame: 090 | Ratio i: 4 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Nominal torque T2N: 130 Nm
AD090-004-P1 Frame: 090 | Ratio i: 4 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Nominal torque T2N: 130 Nm
AD090-004-P2 Frame: 090 | Ratio i: 4 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Nominal torque T2N: 130 Nm
AD090-005-P0 Frame: 090 | Ratio i: 5 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Nominal torque T2N: 160 Nm
AD090-005-P1 Frame: 090 | Ratio i: 5 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Nominal torque T2N: 160 Nm
AD090-005-P2 Frame: 090 | Ratio i: 5 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Nominal torque T2N: 160 Nm
AD090-007-P0 Frame: 090 | Ratio i: 7 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Nominal torque T2N: 140 Nm
AD090-007-P1 Frame: 090 | Ratio i: 7 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Nominal torque T2N: 140 Nm
AD090-007-P2 Frame: 090 | Ratio i: 7 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Nominal torque T2N: 140 Nm
AD090-010-P0 Frame: 090 | Ratio i: 10 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Nominal torque T2N: 100 Nm
AD090-010-P1 Frame: 090 | Ratio i: 10 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Nominal torque T2N: 100 Nm
AD090-010-P2 Frame: 090 | Ratio i: 10 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Nominal torque T2N: 100 Nm
AD090-020-P1 Frame: 090 | Ratio i: 20 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 130 Nm
AD090-020-P2 Frame: 090 | Ratio i: 20 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 130 Nm
AD090-025-P1 Frame: 090 | Ratio i: 25 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 160 Nm
AD090-025-P2 Frame: 090 | Ratio i: 25 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 160 Nm
AD090-035-P1 Frame: 090 | Ratio i: 35 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 140 Nm
AD090-035-P2 Frame: 090 | Ratio i: 35 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 140 Nm
AD090-040-P1 Frame: 090 | Ratio i: 40 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 130 Nm
AD090-040-P2 Frame: 090 | Ratio i: 40 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 130 Nm
AD090-050-P1 Frame: 090 | Ratio i: 50 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 160 Nm
AD090-050-P2 Frame: 090 | Ratio i: 50 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 160 Nm
AD090-070-P1 Frame: 090 | Ratio i: 70 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 140 Nm
AD090-070-P2 Frame: 090 | Ratio i: 70 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 140 Nm
AD090-100-P1 Frame: 090 | Ratio i: 100 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 100 Nm
AD090-100-P2 Frame: 090 | Ratio i: 100 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 100 Nm
AD090-016-P1 Frame: 090 | Ratio i: 16 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 130 Nm
AD090-016-P2 Frame: 090 | Ratio i: 16 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 130 Nm
AD090-021-P1 Frame: 090 | Ratio i: 21 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 160 Nm
AD090-021-P2 Frame: 090 | Ratio i: 21 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 160 Nm
AD090-031-P1 Frame: 090 | Ratio i: 31 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 140 Nm
AD090-031-P2 Frame: 090 | Ratio i: 31 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 140 Nm
AD090-061-P1 Frame: 090 | Ratio i: 61 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 140 Nm
AD090-061-P2 Frame: 090 | Ratio i: 61 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 140 Nm
AD090-091-P1 Frame: 090 | Ratio i: 91 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 100 Nm
AD090-091-P2 Frame: 090 | Ratio i: 91 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 100 Nm
AD110-004-P0 Frame: 110 | Ratio i: 4 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Nominal torque T2N: 270 Nm
AD110-004-P1 Frame: 110 | Ratio i: 4 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Nominal torque T2N: 270 Nm
AD110-004-P2 Frame: 110 | Ratio i: 4 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Nominal torque T2N: 270 Nm
AD110-005-P0 Frame: 110 | Ratio i: 5 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Nominal torque T2N: 330 Nm
AD110-005-P1 Frame: 110 | Ratio i: 5 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Nominal torque T2N: 330 Nm
AD110-005-P2 Frame: 110 | Ratio i: 5 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Nominal torque T2N: 330 Nm
AD110-007-P0 Frame: 110 | Ratio i: 7 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Nominal torque T2N: 300 Nm
AD110-007-P1 Frame: 110 | Ratio i: 7 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Nominal torque T2N: 300 Nm
AD110-007-P2 Frame: 110 | Ratio i: 7 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Nominal torque T2N: 300 Nm
AD110-010-P0 Frame: 110 | Ratio i: 10 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Nominal torque T2N: 230 Nm
AD110-010-P1 Frame: 110 | Ratio i: 10 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Nominal torque T2N: 230 Nm
AD110-010-P2 Frame: 110 | Ratio i: 10 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Nominal torque T2N: 230 Nm
AD110-020-P0 Frame: 110 | Ratio i: 20 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 270 Nm
AD110-020-P1 Frame: 110 | Ratio i: 20 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 270 Nm
AD110-020-P2 Frame: 110 | Ratio i: 20 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 270 Nm
AD110-025-P0 Frame: 110 | Ratio i: 25 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 330 Nm
AD110-025-P1 Frame: 110 | Ratio i: 25 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 330 Nm
AD110-025-P2 Frame: 110 | Ratio i: 25 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 330 Nm
AD110-035-P0 Frame: 110 | Ratio i: 35 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 300 Nm
AD110-035-P1 Frame: 110 | Ratio i: 35 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 300 Nm
AD110-035-P2 Frame: 110 | Ratio i: 35 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 300 Nm
AD110-040-P0 Frame: 110 | Ratio i: 40 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 270 Nm
AD110-040-P1 Frame: 110 | Ratio i: 40 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 270 Nm
AD110-040-P2 Frame: 110 | Ratio i: 40 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 270 Nm
AD110-050-P0 Frame: 110 | Ratio i: 50 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 330 Nm
AD110-050-P1 Frame: 110 | Ratio i: 50 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 330 Nm
AD110-050-P2 Frame: 110 | Ratio i: 50 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 330 Nm
AD110-070-P0 Frame: 110 | Ratio i: 70 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 300 Nm
AD110-070-P1 Frame: 110 | Ratio i: 70 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 300 Nm
AD110-070-P2 Frame: 110 | Ratio i: 70 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 300 Nm
AD110-100-P0 Frame: 110 | Ratio i: 100 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 230 Nm
AD110-100-P1 Frame: 110 | Ratio i: 100 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 230 Nm
AD110-100-P2 Frame: 110 | Ratio i: 100 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 230 Nm
AD110-016-P0 Frame: 110 | Ratio i: 16 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 270 Nm
AD110-016-P1 Frame: 110 | Ratio i: 16 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 270 Nm
AD110-016-P2 Frame: 110 | Ratio i: 16 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 270 Nm
AD110-021-P0 Frame: 110 | Ratio i: 21 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 330 Nm
AD110-021-P1 Frame: 110 | Ratio i: 21 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 330 Nm
AD110-021-P2 Frame: 110 | Ratio i: 21 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 330 Nm
AD110-031-P0 Frame: 110 | Ratio i: 31 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 300 Nm
AD110-031-P1 Frame: 110 | Ratio i: 31 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 300 Nm
AD110-031-P2 Frame: 110 | Ratio i: 31 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 300 Nm
AD110-061-P0 Frame: 110 | Ratio i: 61 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 300 Nm
AD110-061-P1 Frame: 110 | Ratio i: 61 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 300 Nm
AD110-061-P2 Frame: 110 | Ratio i: 61 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 300 Nm
AD110-091-P0 Frame: 110 | Ratio i: 91 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 230 Nm
AD110-091-P1 Frame: 110 | Ratio i: 91 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 230 Nm
AD110-091-P2 Frame: 110 | Ratio i: 91 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 230 Nm
AD140-004-P0 Frame: 140 | Ratio i: 4 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Nominal torque T2N: 560 Nm
AD140-004-P1 Frame: 140 | Ratio i: 4 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Nominal torque T2N: 560 Nm
AD140-004-P2 Frame: 140 | Ratio i: 4 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Nominal torque T2N: 560 Nm
AD140-005-P0 Frame: 140 | Ratio i: 5 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Nominal torque T2N: 650 Nm
AD140-005-P1 Frame: 140 | Ratio i: 5 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Nominal torque T2N: 650 Nm
AD140-005-P2 Frame: 140 | Ratio i: 5 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Nominal torque T2N: 650 Nm
AD140-007-P0 Frame: 140 | Ratio i: 7 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Nominal torque T2N: 550 Nm
AD140-007-P1 Frame: 140 | Ratio i: 7 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Nominal torque T2N: 550 Nm
AD140-007-P2 Frame: 140 | Ratio i: 7 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Nominal torque T2N: 550 Nm
AD140-010-P0 Frame: 140 | Ratio i: 10 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Nominal torque T2N: 450 Nm
AD140-010-P1 Frame: 140 | Ratio i: 10 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Nominal torque T2N: 450 Nm
AD140-010-P2 Frame: 140 | Ratio i: 10 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Nominal torque T2N: 450 Nm
AD140-020-P0 Frame: 140 | Ratio i: 20 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 560 Nm
AD140-020-P1 Frame: 140 | Ratio i: 20 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 560 Nm
AD140-020-P2 Frame: 140 | Ratio i: 20 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 560 Nm
AD140-025-P0 Frame: 140 | Ratio i: 25 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 650 Nm
AD140-025-P1 Frame: 140 | Ratio i: 25 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 650 Nm
AD140-025-P2 Frame: 140 | Ratio i: 25 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 650 Nm
AD140-035-P0 Frame: 140 | Ratio i: 35 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 550 Nm
AD140-035-P1 Frame: 140 | Ratio i: 35 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 550 Nm
AD140-035-P2 Frame: 140 | Ratio i: 35 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 550 Nm
AD140-040-P0 Frame: 140 | Ratio i: 40 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 560 Nm
AD140-040-P1 Frame: 140 | Ratio i: 40 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 560 Nm
AD140-040-P2 Frame: 140 | Ratio i: 40 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 560 Nm
AD140-050-P0 Frame: 140 | Ratio i: 50 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 650 Nm
AD140-050-P1 Frame: 140 | Ratio i: 50 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 650 Nm
AD140-050-P2 Frame: 140 | Ratio i: 50 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 650 Nm
AD140-070-P0 Frame: 140 | Ratio i: 70 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 550 Nm
AD140-070-P1 Frame: 140 | Ratio i: 70 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 550 Nm
AD140-070-P2 Frame: 140 | Ratio i: 70 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 550 Nm
AD140-100-P0 Frame: 140 | Ratio i: 100 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 450 Nm
AD140-100-P1 Frame: 140 | Ratio i: 100 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 450 Nm
AD140-100-P2 Frame: 140 | Ratio i: 100 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 450 Nm
AD140-016-P0 Frame: 140 | Ratio i: 16 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 560 Nm
AD140-016-P1 Frame: 140 | Ratio i: 16 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 560 Nm
AD140-016-P2 Frame: 140 | Ratio i: 16 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 560 Nm
AD140-021-P0 Frame: 140 | Ratio i: 21 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 650 Nm
AD140-021-P1 Frame: 140 | Ratio i: 21 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 650 Nm
AD140-021-P2 Frame: 140 | Ratio i: 21 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 650 Nm
AD140-031-P0 Frame: 140 | Ratio i: 31 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 550 Nm
AD140-031-P1 Frame: 140 | Ratio i: 31 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 550 Nm
AD140-031-P2 Frame: 140 | Ratio i: 31 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 550 Nm
AD140-061-P0 Frame: 140 | Ratio i: 61 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 550 Nm
AD140-061-P1 Frame: 140 | Ratio i: 61 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 550 Nm
AD140-061-P2 Frame: 140 | Ratio i: 61 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 550 Nm
AD140-091-P0 Frame: 140 | Ratio i: 91 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 450 Nm
AD140-091-P1 Frame: 140 | Ratio i: 91 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 450 Nm
AD140-091-P2 Frame: 140 | Ratio i: 91 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 450 Nm
AD200-004-P0 Frame: 200 | Ratio i: 4 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Nominal torque T2N: 1,100 Nm
AD200-004-P1 Frame: 200 | Ratio i: 4 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Nominal torque T2N: 1,100 Nm
AD200-004-P2 Frame: 200 | Ratio i: 4 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Nominal torque T2N: 1,100 Nm
AD200-005-P0 Frame: 200 | Ratio i: 5 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Nominal torque T2N: 1,200 Nm
AD200-005-P1 Frame: 200 | Ratio i: 5 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Nominal torque T2N: 1,200 Nm
AD200-005-P2 Frame: 200 | Ratio i: 5 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Nominal torque T2N: 1,200 Nm
AD200-007-P0 Frame: 200 | Ratio i: 7 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Nominal torque T2N: 1,100 Nm
AD200-007-P1 Frame: 200 | Ratio i: 7 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Nominal torque T2N: 1,100 Nm
AD200-007-P2 Frame: 200 | Ratio i: 7 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Nominal torque T2N: 1,100 Nm
AD200-010-P0 Frame: 200 | Ratio i: 10 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Nominal torque T2N: 900 Nm
AD200-010-P1 Frame: 200 | Ratio i: 10 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Nominal torque T2N: 900 Nm
AD200-010-P2 Frame: 200 | Ratio i: 10 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Nominal torque T2N: 900 Nm
AD200-020-P0 Frame: 200 | Ratio i: 20 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 1,100 Nm
AD200-020-P1 Frame: 200 | Ratio i: 20 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 1,100 Nm
AD200-020-P2 Frame: 200 | Ratio i: 20 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 1,100 Nm
AD200-025-P0 Frame: 200 | Ratio i: 25 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 1,200 Nm
AD200-025-P1 Frame: 200 | Ratio i: 25 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 1,200 Nm
AD200-025-P2 Frame: 200 | Ratio i: 25 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 1,200 Nm
AD200-035-P0 Frame: 200 | Ratio i: 35 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 1,100 Nm
AD200-035-P1 Frame: 200 | Ratio i: 35 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 1,100 Nm
AD200-035-P2 Frame: 200 | Ratio i: 35 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 1,100 Nm
AD200-040-P0 Frame: 200 | Ratio i: 40 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 1,100 Nm
AD200-040-P1 Frame: 200 | Ratio i: 40 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 1,100 Nm
AD200-040-P2 Frame: 200 | Ratio i: 40 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 1,100 Nm
AD200-050-P0 Frame: 200 | Ratio i: 50 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 1,200 Nm
AD200-050-P1 Frame: 200 | Ratio i: 50 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 1,200 Nm
AD200-050-P2 Frame: 200 | Ratio i: 50 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 1,200 Nm
AD200-070-P0 Frame: 200 | Ratio i: 70 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 1,100 Nm
AD200-070-P1 Frame: 200 | Ratio i: 70 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 1,100 Nm
AD200-070-P2 Frame: 200 | Ratio i: 70 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 1,100 Nm
AD200-100-P0 Frame: 200 | Ratio i: 100 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 900 Nm
AD200-100-P1 Frame: 200 | Ratio i: 100 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 900 Nm
AD200-100-P2 Frame: 200 | Ratio i: 100 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 900 Nm
AD200-016-P0 Frame: 200 | Ratio i: 16 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 1,100 Nm
AD200-016-P1 Frame: 200 | Ratio i: 16 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 1,100 Nm
AD200-016-P2 Frame: 200 | Ratio i: 16 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 1,100 Nm
AD200-021-P0 Frame: 200 | Ratio i: 21 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 1,200 Nm
AD200-021-P1 Frame: 200 | Ratio i: 21 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 1,200 Nm
AD200-021-P2 Frame: 200 | Ratio i: 21 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 1,200 Nm
AD200-031-P0 Frame: 200 | Ratio i: 31 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 1,100 Nm
AD200-031-P1 Frame: 200 | Ratio i: 31 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 1,100 Nm
AD200-031-P2 Frame: 200 | Ratio i: 31 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 1,100 Nm
AD200-061-P0 Frame: 200 | Ratio i: 61 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 1,100 Nm
AD200-061-P1 Frame: 200 | Ratio i: 61 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 1,100 Nm
AD200-061-P2 Frame: 200 | Ratio i: 61 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 1,100 Nm
AD200-091-P0 Frame: 200 | Ratio i: 91 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 900 Nm
AD200-091-P1 Frame: 200 | Ratio i: 91 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 900 Nm
AD200-091-P2 Frame: 200 | Ratio i: 91 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 900 Nm
AD255-004-P0 Frame: 255 | Ratio i: 4 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Nominal torque T2N: 1,700 Nm
AD255-004-P1 Frame: 255 | Ratio i: 4 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Nominal torque T2N: 1,700 Nm
AD255-004-P2 Frame: 255 | Ratio i: 4 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Nominal torque T2N: 1,700 Nm
AD255-005-P0 Frame: 255 | Ratio i: 5 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Nominal torque T2N: 2,000 Nm
AD255-005-P1 Frame: 255 | Ratio i: 5 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Nominal torque T2N: 2,000 Nm
AD255-005-P2 Frame: 255 | Ratio i: 5 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Nominal torque T2N: 2,000 Nm
AD255-007-P0 Frame: 255 | Ratio i: 7 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Nominal torque T2N: 1,800 Nm
AD255-007-P1 Frame: 255 | Ratio i: 7 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Nominal torque T2N: 1,800 Nm
AD255-007-P2 Frame: 255 | Ratio i: 7 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Nominal torque T2N: 1,800 Nm
AD255-010-P0 Frame: 255 | Ratio i: 10 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Nominal torque T2N: 1,500 Nm
AD255-010-P1 Frame: 255 | Ratio i: 10 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Nominal torque T2N: 1,500 Nm
AD255-010-P2 Frame: 255 | Ratio i: 10 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Nominal torque T2N: 1,500 Nm
AD255-020-P0 Frame: 255 | Ratio i: 20 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 1,700 Nm
AD255-020-P1 Frame: 255 | Ratio i: 20 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 1,700 Nm
AD255-020-P2 Frame: 255 | Ratio i: 20 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 1,700 Nm
AD255-025-P0 Frame: 255 | Ratio i: 25 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 2,000 Nm
AD255-025-P1 Frame: 255 | Ratio i: 25 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 2,000 Nm
AD255-025-P2 Frame: 255 | Ratio i: 25 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 2,000 Nm
AD255-035-P0 Frame: 255 | Ratio i: 35 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 1,800 Nm
AD255-035-P1 Frame: 255 | Ratio i: 35 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 1,800 Nm
AD255-035-P2 Frame: 255 | Ratio i: 35 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 1,800 Nm
AD255-040-P0 Frame: 255 | Ratio i: 40 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 1,700 Nm
AD255-040-P1 Frame: 255 | Ratio i: 40 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 1,700 Nm
AD255-040-P2 Frame: 255 | Ratio i: 40 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 1,700 Nm
AD255-050-P0 Frame: 255 | Ratio i: 50 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 2,000 Nm
AD255-050-P1 Frame: 255 | Ratio i: 50 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 2,000 Nm
AD255-050-P2 Frame: 255 | Ratio i: 50 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 2,000 Nm
AD255-070-P0 Frame: 255 | Ratio i: 70 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 1,800 Nm
AD255-070-P1 Frame: 255 | Ratio i: 70 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 1,800 Nm
AD255-070-P2 Frame: 255 | Ratio i: 70 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 1,800 Nm
AD255-100-P0 Frame: 255 | Ratio i: 100 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 1,500 Nm
AD255-100-P1 Frame: 255 | Ratio i: 100 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 1,500 Nm
AD255-100-P2 Frame: 255 | Ratio i: 100 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 1,500 Nm
AD255-016-P0 Frame: 255 | Ratio i: 16 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 1,700 Nm
AD255-016-P1 Frame: 255 | Ratio i: 16 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 1,700 Nm
AD255-016-P2 Frame: 255 | Ratio i: 16 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 1,700 Nm
AD255-021-P0 Frame: 255 | Ratio i: 21 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 2,000 Nm
AD255-021-P1 Frame: 255 | Ratio i: 21 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 2,000 Nm
AD255-021-P2 Frame: 255 | Ratio i: 21 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 2,000 Nm
AD255-031-P0 Frame: 255 | Ratio i: 31 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 1,800 Nm
AD255-031-P1 Frame: 255 | Ratio i: 31 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 1,800 Nm
AD255-031-P2 Frame: 255 | Ratio i: 31 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 1,800 Nm
AD255-061-P0 Frame: 255 | Ratio i: 61 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 1,800 Nm
AD255-061-P1 Frame: 255 | Ratio i: 61 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 1,800 Nm
AD255-061-P2 Frame: 255 | Ratio i: 61 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 1,800 Nm
AD255-091-P0 Frame: 255 | Ratio i: 91 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 1,500 Nm
AD255-091-P1 Frame: 255 | Ratio i: 91 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 1,500 Nm
AD255-091-P2 Frame: 255 | Ratio i: 91 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 1,500 Nm
Planetary GearboxesApex Dynamics
292 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Apex Dynamics AD High-Speed Precision Planetary Gearboxes (047-255)

Brand Apex Dynamics·Planetary Gearboxes

Available part numbers (292)

AD047-004-P1, AD047-004-P2, AD047-005-P1, AD047-005-P2, AD047-007-P1, AD047-007-P2, AD047-010-P1, AD047-010-P2, AD047-020-P1, AD047-020-P2 + 282 more — see full table ↓

How to order

Send the Apex Dynamics part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
AD047-004-P1Frame: 047 | Ratio i: 4 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Nominal torque T2N: 19 Nm
AD047-004-P2Frame: 047 | Ratio i: 4 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Nominal torque T2N: 19 Nm
AD047-005-P1Frame: 047 | Ratio i: 5 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Nominal torque T2N: 22 Nm
AD047-005-P2Frame: 047 | Ratio i: 5 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Nominal torque T2N: 22 Nm
AD047-007-P1Frame: 047 | Ratio i: 7 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Nominal torque T2N: 19 Nm
AD047-007-P2Frame: 047 | Ratio i: 7 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Nominal torque T2N: 19 Nm
AD047-010-P1Frame: 047 | Ratio i: 10 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Nominal torque T2N: 14 Nm
AD047-010-P2Frame: 047 | Ratio i: 10 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Nominal torque T2N: 14 Nm
AD047-020-P1Frame: 047 | Ratio i: 20 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 19 Nm
AD047-020-P2Frame: 047 | Ratio i: 20 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 19 Nm
AD047-025-P1Frame: 047 | Ratio i: 25 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 22 Nm
AD047-025-P2Frame: 047 | Ratio i: 25 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 22 Nm
AD047-035-P1Frame: 047 | Ratio i: 35 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 19 Nm
AD047-035-P2Frame: 047 | Ratio i: 35 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 19 Nm
AD047-040-P1Frame: 047 | Ratio i: 40 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 19 Nm
AD047-040-P2Frame: 047 | Ratio i: 40 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 19 Nm
AD047-050-P1Frame: 047 | Ratio i: 50 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 22 Nm
AD047-050-P2Frame: 047 | Ratio i: 50 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 22 Nm
AD047-070-P1Frame: 047 | Ratio i: 70 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 19 Nm
AD047-070-P2Frame: 047 | Ratio i: 70 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 19 Nm
AD047-100-P1Frame: 047 | Ratio i: 100 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 14 Nm
AD047-100-P2Frame: 047 | Ratio i: 100 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 14 Nm
AD047-016-P1Frame: 047 | Ratio i: 16 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 19 Nm
AD047-016-P2Frame: 047 | Ratio i: 16 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 19 Nm
AD047-021-P1Frame: 047 | Ratio i: 21 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 22 Nm
AD047-021-P2Frame: 047 | Ratio i: 21 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 22 Nm
AD047-031-P1Frame: 047 | Ratio i: 31 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 19 Nm
AD047-031-P2Frame: 047 | Ratio i: 31 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 19 Nm
AD047-061-P1Frame: 047 | Ratio i: 61 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 19 Nm
AD047-061-P2Frame: 047 | Ratio i: 61 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 19 Nm
AD047-091-P1Frame: 047 | Ratio i: 91 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 14 Nm
AD047-091-P2Frame: 047 | Ratio i: 91 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 14 Nm
AD064-004-P1Frame: 064 | Ratio i: 4 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Nominal torque T2N: 48 Nm
AD064-004-P2Frame: 064 | Ratio i: 4 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Nominal torque T2N: 48 Nm
AD064-005-P1Frame: 064 | Ratio i: 5 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Nominal torque T2N: 60 Nm
AD064-005-P2Frame: 064 | Ratio i: 5 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Nominal torque T2N: 60 Nm
AD064-007-P1Frame: 064 | Ratio i: 7 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Nominal torque T2N: 50 Nm
AD064-007-P2Frame: 064 | Ratio i: 7 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Nominal torque T2N: 50 Nm
AD064-010-P1Frame: 064 | Ratio i: 10 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Nominal torque T2N: 40 Nm
AD064-010-P2Frame: 064 | Ratio i: 10 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Nominal torque T2N: 40 Nm
AD064-020-P1Frame: 064 | Ratio i: 20 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 48 Nm
AD064-020-P2Frame: 064 | Ratio i: 20 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 48 Nm
AD064-025-P1Frame: 064 | Ratio i: 25 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 60 Nm
AD064-025-P2Frame: 064 | Ratio i: 25 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 60 Nm
AD064-035-P1Frame: 064 | Ratio i: 35 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 50 Nm
AD064-035-P2Frame: 064 | Ratio i: 35 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 50 Nm
AD064-040-P1Frame: 064 | Ratio i: 40 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 48 Nm
AD064-040-P2Frame: 064 | Ratio i: 40 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 48 Nm
AD064-050-P1Frame: 064 | Ratio i: 50 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 60 Nm
AD064-050-P2Frame: 064 | Ratio i: 50 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 60 Nm
AD064-070-P1Frame: 064 | Ratio i: 70 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 50 Nm
AD064-070-P2Frame: 064 | Ratio i: 70 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 50 Nm
AD064-100-P1Frame: 064 | Ratio i: 100 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 40 Nm
AD064-100-P2Frame: 064 | Ratio i: 100 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 40 Nm
AD064-016-P1Frame: 064 | Ratio i: 16 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 48 Nm
AD064-016-P2Frame: 064 | Ratio i: 16 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 48 Nm
AD064-021-P1Frame: 064 | Ratio i: 21 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 60 Nm
AD064-021-P2Frame: 064 | Ratio i: 21 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 60 Nm
AD064-031-P1Frame: 064 | Ratio i: 31 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 50 Nm
AD064-031-P2Frame: 064 | Ratio i: 31 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 50 Nm
AD064-061-P1Frame: 064 | Ratio i: 61 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 50 Nm
AD064-061-P2Frame: 064 | Ratio i: 61 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 50 Nm
AD064-091-P1Frame: 064 | Ratio i: 91 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 40 Nm
AD064-091-P2Frame: 064 | Ratio i: 91 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 40 Nm
AD090-004-P0Frame: 090 | Ratio i: 4 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Nominal torque T2N: 130 Nm
AD090-004-P1Frame: 090 | Ratio i: 4 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Nominal torque T2N: 130 Nm
AD090-004-P2Frame: 090 | Ratio i: 4 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Nominal torque T2N: 130 Nm
AD090-005-P0Frame: 090 | Ratio i: 5 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Nominal torque T2N: 160 Nm
AD090-005-P1Frame: 090 | Ratio i: 5 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Nominal torque T2N: 160 Nm
AD090-005-P2Frame: 090 | Ratio i: 5 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Nominal torque T2N: 160 Nm
AD090-007-P0Frame: 090 | Ratio i: 7 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Nominal torque T2N: 140 Nm
AD090-007-P1Frame: 090 | Ratio i: 7 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Nominal torque T2N: 140 Nm
AD090-007-P2Frame: 090 | Ratio i: 7 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Nominal torque T2N: 140 Nm
AD090-010-P0Frame: 090 | Ratio i: 10 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Nominal torque T2N: 100 Nm
AD090-010-P1Frame: 090 | Ratio i: 10 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Nominal torque T2N: 100 Nm
AD090-010-P2Frame: 090 | Ratio i: 10 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Nominal torque T2N: 100 Nm
AD090-020-P1Frame: 090 | Ratio i: 20 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 130 Nm
AD090-020-P2Frame: 090 | Ratio i: 20 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 130 Nm
AD090-025-P1Frame: 090 | Ratio i: 25 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 160 Nm
AD090-025-P2Frame: 090 | Ratio i: 25 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 160 Nm
AD090-035-P1Frame: 090 | Ratio i: 35 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 140 Nm
AD090-035-P2Frame: 090 | Ratio i: 35 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 140 Nm
AD090-040-P1Frame: 090 | Ratio i: 40 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 130 Nm
AD090-040-P2Frame: 090 | Ratio i: 40 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 130 Nm
AD090-050-P1Frame: 090 | Ratio i: 50 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 160 Nm
AD090-050-P2Frame: 090 | Ratio i: 50 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 160 Nm
AD090-070-P1Frame: 090 | Ratio i: 70 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 140 Nm
AD090-070-P2Frame: 090 | Ratio i: 70 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 140 Nm
AD090-100-P1Frame: 090 | Ratio i: 100 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 100 Nm
AD090-100-P2Frame: 090 | Ratio i: 100 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 100 Nm
AD090-016-P1Frame: 090 | Ratio i: 16 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 130 Nm
AD090-016-P2Frame: 090 | Ratio i: 16 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 130 Nm
AD090-021-P1Frame: 090 | Ratio i: 21 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 160 Nm
AD090-021-P2Frame: 090 | Ratio i: 21 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 160 Nm
AD090-031-P1Frame: 090 | Ratio i: 31 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 140 Nm
AD090-031-P2Frame: 090 | Ratio i: 31 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 140 Nm
AD090-061-P1Frame: 090 | Ratio i: 61 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 140 Nm
AD090-061-P2Frame: 090 | Ratio i: 61 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 140 Nm
AD090-091-P1Frame: 090 | Ratio i: 91 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 100 Nm
AD090-091-P2Frame: 090 | Ratio i: 91 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 100 Nm
AD110-004-P0Frame: 110 | Ratio i: 4 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Nominal torque T2N: 270 Nm
AD110-004-P1Frame: 110 | Ratio i: 4 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Nominal torque T2N: 270 Nm
AD110-004-P2Frame: 110 | Ratio i: 4 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Nominal torque T2N: 270 Nm
AD110-005-P0Frame: 110 | Ratio i: 5 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Nominal torque T2N: 330 Nm
AD110-005-P1Frame: 110 | Ratio i: 5 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Nominal torque T2N: 330 Nm
AD110-005-P2Frame: 110 | Ratio i: 5 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Nominal torque T2N: 330 Nm
AD110-007-P0Frame: 110 | Ratio i: 7 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Nominal torque T2N: 300 Nm
AD110-007-P1Frame: 110 | Ratio i: 7 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Nominal torque T2N: 300 Nm
AD110-007-P2Frame: 110 | Ratio i: 7 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Nominal torque T2N: 300 Nm
AD110-010-P0Frame: 110 | Ratio i: 10 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Nominal torque T2N: 230 Nm
AD110-010-P1Frame: 110 | Ratio i: 10 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Nominal torque T2N: 230 Nm
AD110-010-P2Frame: 110 | Ratio i: 10 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Nominal torque T2N: 230 Nm
AD110-020-P0Frame: 110 | Ratio i: 20 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 270 Nm
AD110-020-P1Frame: 110 | Ratio i: 20 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 270 Nm
AD110-020-P2Frame: 110 | Ratio i: 20 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 270 Nm
AD110-025-P0Frame: 110 | Ratio i: 25 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 330 Nm
AD110-025-P1Frame: 110 | Ratio i: 25 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 330 Nm
AD110-025-P2Frame: 110 | Ratio i: 25 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 330 Nm
AD110-035-P0Frame: 110 | Ratio i: 35 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 300 Nm
AD110-035-P1Frame: 110 | Ratio i: 35 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 300 Nm
AD110-035-P2Frame: 110 | Ratio i: 35 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 300 Nm
AD110-040-P0Frame: 110 | Ratio i: 40 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 270 Nm
AD110-040-P1Frame: 110 | Ratio i: 40 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 270 Nm
AD110-040-P2Frame: 110 | Ratio i: 40 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 270 Nm
AD110-050-P0Frame: 110 | Ratio i: 50 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 330 Nm
AD110-050-P1Frame: 110 | Ratio i: 50 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 330 Nm
AD110-050-P2Frame: 110 | Ratio i: 50 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 330 Nm
AD110-070-P0Frame: 110 | Ratio i: 70 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 300 Nm
AD110-070-P1Frame: 110 | Ratio i: 70 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 300 Nm
AD110-070-P2Frame: 110 | Ratio i: 70 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 300 Nm
AD110-100-P0Frame: 110 | Ratio i: 100 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 230 Nm
AD110-100-P1Frame: 110 | Ratio i: 100 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 230 Nm
AD110-100-P2Frame: 110 | Ratio i: 100 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 230 Nm
AD110-016-P0Frame: 110 | Ratio i: 16 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 270 Nm
AD110-016-P1Frame: 110 | Ratio i: 16 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 270 Nm
AD110-016-P2Frame: 110 | Ratio i: 16 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 270 Nm
AD110-021-P0Frame: 110 | Ratio i: 21 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 330 Nm
AD110-021-P1Frame: 110 | Ratio i: 21 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 330 Nm
AD110-021-P2Frame: 110 | Ratio i: 21 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 330 Nm
AD110-031-P0Frame: 110 | Ratio i: 31 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 300 Nm
AD110-031-P1Frame: 110 | Ratio i: 31 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 300 Nm
AD110-031-P2Frame: 110 | Ratio i: 31 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 300 Nm
AD110-061-P0Frame: 110 | Ratio i: 61 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 300 Nm
AD110-061-P1Frame: 110 | Ratio i: 61 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 300 Nm
AD110-061-P2Frame: 110 | Ratio i: 61 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 300 Nm
AD110-091-P0Frame: 110 | Ratio i: 91 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 230 Nm
AD110-091-P1Frame: 110 | Ratio i: 91 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 230 Nm
AD110-091-P2Frame: 110 | Ratio i: 91 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 230 Nm
AD140-004-P0Frame: 140 | Ratio i: 4 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Nominal torque T2N: 560 Nm
AD140-004-P1Frame: 140 | Ratio i: 4 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Nominal torque T2N: 560 Nm
AD140-004-P2Frame: 140 | Ratio i: 4 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Nominal torque T2N: 560 Nm
AD140-005-P0Frame: 140 | Ratio i: 5 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Nominal torque T2N: 650 Nm
AD140-005-P1Frame: 140 | Ratio i: 5 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Nominal torque T2N: 650 Nm
AD140-005-P2Frame: 140 | Ratio i: 5 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Nominal torque T2N: 650 Nm
AD140-007-P0Frame: 140 | Ratio i: 7 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Nominal torque T2N: 550 Nm
AD140-007-P1Frame: 140 | Ratio i: 7 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Nominal torque T2N: 550 Nm
AD140-007-P2Frame: 140 | Ratio i: 7 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Nominal torque T2N: 550 Nm
AD140-010-P0Frame: 140 | Ratio i: 10 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Nominal torque T2N: 450 Nm
AD140-010-P1Frame: 140 | Ratio i: 10 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Nominal torque T2N: 450 Nm
AD140-010-P2Frame: 140 | Ratio i: 10 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Nominal torque T2N: 450 Nm
AD140-020-P0Frame: 140 | Ratio i: 20 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 560 Nm
AD140-020-P1Frame: 140 | Ratio i: 20 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 560 Nm
AD140-020-P2Frame: 140 | Ratio i: 20 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 560 Nm
AD140-025-P0Frame: 140 | Ratio i: 25 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 650 Nm
AD140-025-P1Frame: 140 | Ratio i: 25 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 650 Nm
AD140-025-P2Frame: 140 | Ratio i: 25 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 650 Nm
AD140-035-P0Frame: 140 | Ratio i: 35 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 550 Nm
AD140-035-P1Frame: 140 | Ratio i: 35 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 550 Nm
AD140-035-P2Frame: 140 | Ratio i: 35 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 550 Nm
AD140-040-P0Frame: 140 | Ratio i: 40 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 560 Nm
AD140-040-P1Frame: 140 | Ratio i: 40 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 560 Nm
AD140-040-P2Frame: 140 | Ratio i: 40 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 560 Nm
AD140-050-P0Frame: 140 | Ratio i: 50 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 650 Nm
AD140-050-P1Frame: 140 | Ratio i: 50 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 650 Nm
AD140-050-P2Frame: 140 | Ratio i: 50 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 650 Nm
AD140-070-P0Frame: 140 | Ratio i: 70 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 550 Nm
AD140-070-P1Frame: 140 | Ratio i: 70 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 550 Nm
AD140-070-P2Frame: 140 | Ratio i: 70 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 550 Nm
AD140-100-P0Frame: 140 | Ratio i: 100 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 450 Nm
AD140-100-P1Frame: 140 | Ratio i: 100 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 450 Nm
AD140-100-P2Frame: 140 | Ratio i: 100 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 450 Nm
AD140-016-P0Frame: 140 | Ratio i: 16 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 560 Nm
AD140-016-P1Frame: 140 | Ratio i: 16 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 560 Nm
AD140-016-P2Frame: 140 | Ratio i: 16 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 560 Nm
AD140-021-P0Frame: 140 | Ratio i: 21 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 650 Nm
AD140-021-P1Frame: 140 | Ratio i: 21 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 650 Nm
AD140-021-P2Frame: 140 | Ratio i: 21 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 650 Nm
AD140-031-P0Frame: 140 | Ratio i: 31 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 550 Nm
AD140-031-P1Frame: 140 | Ratio i: 31 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 550 Nm
AD140-031-P2Frame: 140 | Ratio i: 31 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 550 Nm
AD140-061-P0Frame: 140 | Ratio i: 61 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 550 Nm
AD140-061-P1Frame: 140 | Ratio i: 61 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 550 Nm
AD140-061-P2Frame: 140 | Ratio i: 61 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 550 Nm
AD140-091-P0Frame: 140 | Ratio i: 91 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 450 Nm
AD140-091-P1Frame: 140 | Ratio i: 91 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 450 Nm
AD140-091-P2Frame: 140 | Ratio i: 91 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 450 Nm
AD200-004-P0Frame: 200 | Ratio i: 4 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Nominal torque T2N: 1,100 Nm
AD200-004-P1Frame: 200 | Ratio i: 4 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Nominal torque T2N: 1,100 Nm
AD200-004-P2Frame: 200 | Ratio i: 4 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Nominal torque T2N: 1,100 Nm
AD200-005-P0Frame: 200 | Ratio i: 5 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Nominal torque T2N: 1,200 Nm
AD200-005-P1Frame: 200 | Ratio i: 5 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Nominal torque T2N: 1,200 Nm
AD200-005-P2Frame: 200 | Ratio i: 5 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Nominal torque T2N: 1,200 Nm
AD200-007-P0Frame: 200 | Ratio i: 7 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Nominal torque T2N: 1,100 Nm
AD200-007-P1Frame: 200 | Ratio i: 7 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Nominal torque T2N: 1,100 Nm
AD200-007-P2Frame: 200 | Ratio i: 7 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Nominal torque T2N: 1,100 Nm
AD200-010-P0Frame: 200 | Ratio i: 10 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Nominal torque T2N: 900 Nm
AD200-010-P1Frame: 200 | Ratio i: 10 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Nominal torque T2N: 900 Nm
AD200-010-P2Frame: 200 | Ratio i: 10 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Nominal torque T2N: 900 Nm
AD200-020-P0Frame: 200 | Ratio i: 20 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 1,100 Nm
AD200-020-P1Frame: 200 | Ratio i: 20 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 1,100 Nm
AD200-020-P2Frame: 200 | Ratio i: 20 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 1,100 Nm
AD200-025-P0Frame: 200 | Ratio i: 25 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 1,200 Nm
AD200-025-P1Frame: 200 | Ratio i: 25 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 1,200 Nm
AD200-025-P2Frame: 200 | Ratio i: 25 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 1,200 Nm
AD200-035-P0Frame: 200 | Ratio i: 35 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 1,100 Nm
AD200-035-P1Frame: 200 | Ratio i: 35 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 1,100 Nm
AD200-035-P2Frame: 200 | Ratio i: 35 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 1,100 Nm
AD200-040-P0Frame: 200 | Ratio i: 40 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 1,100 Nm
AD200-040-P1Frame: 200 | Ratio i: 40 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 1,100 Nm
AD200-040-P2Frame: 200 | Ratio i: 40 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 1,100 Nm
AD200-050-P0Frame: 200 | Ratio i: 50 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 1,200 Nm
AD200-050-P1Frame: 200 | Ratio i: 50 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 1,200 Nm
AD200-050-P2Frame: 200 | Ratio i: 50 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 1,200 Nm
AD200-070-P0Frame: 200 | Ratio i: 70 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 1,100 Nm
AD200-070-P1Frame: 200 | Ratio i: 70 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 1,100 Nm
AD200-070-P2Frame: 200 | Ratio i: 70 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 1,100 Nm
AD200-100-P0Frame: 200 | Ratio i: 100 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 900 Nm
AD200-100-P1Frame: 200 | Ratio i: 100 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 900 Nm
AD200-100-P2Frame: 200 | Ratio i: 100 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 900 Nm
AD200-016-P0Frame: 200 | Ratio i: 16 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 1,100 Nm
AD200-016-P1Frame: 200 | Ratio i: 16 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 1,100 Nm
AD200-016-P2Frame: 200 | Ratio i: 16 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 1,100 Nm
AD200-021-P0Frame: 200 | Ratio i: 21 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 1,200 Nm
AD200-021-P1Frame: 200 | Ratio i: 21 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 1,200 Nm
AD200-021-P2Frame: 200 | Ratio i: 21 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 1,200 Nm
AD200-031-P0Frame: 200 | Ratio i: 31 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 1,100 Nm
AD200-031-P1Frame: 200 | Ratio i: 31 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 1,100 Nm
AD200-031-P2Frame: 200 | Ratio i: 31 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 1,100 Nm
AD200-061-P0Frame: 200 | Ratio i: 61 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 1,100 Nm
AD200-061-P1Frame: 200 | Ratio i: 61 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 1,100 Nm
AD200-061-P2Frame: 200 | Ratio i: 61 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 1,100 Nm
AD200-091-P0Frame: 200 | Ratio i: 91 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 900 Nm
AD200-091-P1Frame: 200 | Ratio i: 91 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 900 Nm
AD200-091-P2Frame: 200 | Ratio i: 91 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 900 Nm
AD255-004-P0Frame: 255 | Ratio i: 4 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Nominal torque T2N: 1,700 Nm
AD255-004-P1Frame: 255 | Ratio i: 4 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Nominal torque T2N: 1,700 Nm
AD255-004-P2Frame: 255 | Ratio i: 4 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Nominal torque T2N: 1,700 Nm
AD255-005-P0Frame: 255 | Ratio i: 5 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Nominal torque T2N: 2,000 Nm
AD255-005-P1Frame: 255 | Ratio i: 5 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Nominal torque T2N: 2,000 Nm
AD255-005-P2Frame: 255 | Ratio i: 5 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Nominal torque T2N: 2,000 Nm
AD255-007-P0Frame: 255 | Ratio i: 7 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Nominal torque T2N: 1,800 Nm
AD255-007-P1Frame: 255 | Ratio i: 7 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Nominal torque T2N: 1,800 Nm
AD255-007-P2Frame: 255 | Ratio i: 7 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Nominal torque T2N: 1,800 Nm
AD255-010-P0Frame: 255 | Ratio i: 10 | Stages: 1 | Backlash: P0 Micro <=1 arcmin | Nominal torque T2N: 1,500 Nm
AD255-010-P1Frame: 255 | Ratio i: 10 | Stages: 1 | Backlash: P1 Reduced <=3 arcmin | Nominal torque T2N: 1,500 Nm
AD255-010-P2Frame: 255 | Ratio i: 10 | Stages: 1 | Backlash: P2 Standard <=5 arcmin | Nominal torque T2N: 1,500 Nm
AD255-020-P0Frame: 255 | Ratio i: 20 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 1,700 Nm
AD255-020-P1Frame: 255 | Ratio i: 20 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 1,700 Nm
AD255-020-P2Frame: 255 | Ratio i: 20 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 1,700 Nm
AD255-025-P0Frame: 255 | Ratio i: 25 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 2,000 Nm
AD255-025-P1Frame: 255 | Ratio i: 25 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 2,000 Nm
AD255-025-P2Frame: 255 | Ratio i: 25 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 2,000 Nm
AD255-035-P0Frame: 255 | Ratio i: 35 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 1,800 Nm
AD255-035-P1Frame: 255 | Ratio i: 35 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 1,800 Nm
AD255-035-P2Frame: 255 | Ratio i: 35 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 1,800 Nm
AD255-040-P0Frame: 255 | Ratio i: 40 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 1,700 Nm
AD255-040-P1Frame: 255 | Ratio i: 40 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 1,700 Nm
AD255-040-P2Frame: 255 | Ratio i: 40 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 1,700 Nm
AD255-050-P0Frame: 255 | Ratio i: 50 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 2,000 Nm
AD255-050-P1Frame: 255 | Ratio i: 50 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 2,000 Nm
AD255-050-P2Frame: 255 | Ratio i: 50 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 2,000 Nm
AD255-070-P0Frame: 255 | Ratio i: 70 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 1,800 Nm
AD255-070-P1Frame: 255 | Ratio i: 70 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 1,800 Nm
AD255-070-P2Frame: 255 | Ratio i: 70 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 1,800 Nm
AD255-100-P0Frame: 255 | Ratio i: 100 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 1,500 Nm
AD255-100-P1Frame: 255 | Ratio i: 100 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 1,500 Nm
AD255-100-P2Frame: 255 | Ratio i: 100 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 1,500 Nm
AD255-016-P0Frame: 255 | Ratio i: 16 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 1,700 Nm
AD255-016-P1Frame: 255 | Ratio i: 16 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 1,700 Nm
AD255-016-P2Frame: 255 | Ratio i: 16 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 1,700 Nm
AD255-021-P0Frame: 255 | Ratio i: 21 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 2,000 Nm
AD255-021-P1Frame: 255 | Ratio i: 21 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 2,000 Nm
AD255-021-P2Frame: 255 | Ratio i: 21 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 2,000 Nm
AD255-031-P0Frame: 255 | Ratio i: 31 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 1,800 Nm
AD255-031-P1Frame: 255 | Ratio i: 31 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 1,800 Nm
AD255-031-P2Frame: 255 | Ratio i: 31 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 1,800 Nm
AD255-061-P0Frame: 255 | Ratio i: 61 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 1,800 Nm
AD255-061-P1Frame: 255 | Ratio i: 61 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 1,800 Nm
AD255-061-P2Frame: 255 | Ratio i: 61 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 1,800 Nm
AD255-091-P0Frame: 255 | Ratio i: 91 | Stages: 2 | Backlash: P0 Micro <=3 arcmin | Nominal torque T2N: 1,500 Nm
AD255-091-P1Frame: 255 | Ratio i: 91 | Stages: 2 | Backlash: P1 Reduced <=5 arcmin | Nominal torque T2N: 1,500 Nm
AD255-091-P2Frame: 255 | Ratio i: 91 | Stages: 2 | Backlash: P2 Standard <=7 arcmin | Nominal torque T2N: 1,500 Nm

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Motors & Gearheads →
