APEX Dynamics AFH new-generation inline precision planetary gearboxes with round output flange, frame sizes 060-240, 1- and 2-stage ratios 3-100.

Key features

  • Ordering code: size - ratio - output shaft / motor, e.g. AFH075-003-S1
  • Output shaft S1 smooth, S2 keyed, S3 DIN 5480 spline or S4 hollow with shrink disc (S4 on 060-180)
  • Backlash <=1 arcmin (1-stage, 075-240), <=2 arcmin (2-stage); frame 060 <=2 / <=3 arcmin
  • Optimized output torque and inertia; nominal torque up to 4,430 Nm (frame 240)
  • Shrink disc power locks SSD-18 to SSD-68 for S4 hollow shaft (frames 060-180)
  • Low noise, limited temperature rise, synthetic grease lubrication, any mounting position

Specifications

Gear type Planetary, inline, round output flange
Efficiency >=97% (1-stage), >=94% (2-stage)
Emergency stop torque T2NOT 3 x T2N
Max. acceleration torque T2B 1.5 x T2N
Max. input speed n1 7,000 rpm (060) to 3,500/4,500 rpm (240)
Torsional rigidity 4.6 (060) to 550 (240) Nm/arcmin
Protection class IP65
Operating temperature -10 to +90 C
Lubrication Synthetic lubrication grease, all directions
Motor adapter Specify motor make and model when ordering (code suffix / MOTOR)
Source APEX Dynamics AFH/AFHK catalog, p. 3-7
AFH060-003-S1 Frame: 060 | Ratio i: 3 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 90 Nm
AFH060-003-S2 Frame: 060 | Ratio i: 3 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 90 Nm
AFH060-003-S3 Frame: 060 | Ratio i: 3 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 90 Nm
AFH060-003-S4 Frame: 060 | Ratio i: 3 | Stages: 1 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 90 Nm
AFH060-004-S1 Frame: 060 | Ratio i: 4 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 100 Nm
AFH060-004-S2 Frame: 060 | Ratio i: 4 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 100 Nm
AFH060-004-S3 Frame: 060 | Ratio i: 4 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 100 Nm
AFH060-004-S4 Frame: 060 | Ratio i: 4 | Stages: 1 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 100 Nm
AFH060-005-S1 Frame: 060 | Ratio i: 5 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 85 Nm
AFH060-005-S2 Frame: 060 | Ratio i: 5 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 85 Nm
AFH060-005-S3 Frame: 060 | Ratio i: 5 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 85 Nm
AFH060-005-S4 Frame: 060 | Ratio i: 5 | Stages: 1 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 85 Nm
AFH060-007-S1 Frame: 060 | Ratio i: 7 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 60 Nm
AFH060-007-S2 Frame: 060 | Ratio i: 7 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 60 Nm
AFH060-007-S3 Frame: 060 | Ratio i: 7 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 60 Nm
AFH060-007-S4 Frame: 060 | Ratio i: 7 | Stages: 1 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 60 Nm
AFH060-010-S1 Frame: 060 | Ratio i: 10 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 24 Nm
AFH060-010-S2 Frame: 060 | Ratio i: 10 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 24 Nm
AFH060-010-S3 Frame: 060 | Ratio i: 10 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 24 Nm
AFH060-010-S4 Frame: 060 | Ratio i: 10 | Stages: 1 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 24 Nm
AFH060-016-S1 Frame: 060 | Ratio i: 16 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=3 arcmin | Nominal torque T2N: 100 Nm
AFH060-016-S2 Frame: 060 | Ratio i: 16 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=3 arcmin | Nominal torque T2N: 100 Nm
AFH060-016-S3 Frame: 060 | Ratio i: 16 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=3 arcmin | Nominal torque T2N: 100 Nm
AFH060-016-S4 Frame: 060 | Ratio i: 16 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=3 arcmin | Nominal torque T2N: 100 Nm
AFH060-020-S1 Frame: 060 | Ratio i: 20 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=3 arcmin | Nominal torque T2N: 100 Nm
AFH060-020-S2 Frame: 060 | Ratio i: 20 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=3 arcmin | Nominal torque T2N: 100 Nm
AFH060-020-S3 Frame: 060 | Ratio i: 20 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=3 arcmin | Nominal torque T2N: 100 Nm
AFH060-020-S4 Frame: 060 | Ratio i: 20 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=3 arcmin | Nominal torque T2N: 100 Nm
AFH060-025-S1 Frame: 060 | Ratio i: 25 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=3 arcmin | Nominal torque T2N: 90 Nm
AFH060-025-S2 Frame: 060 | Ratio i: 25 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=3 arcmin | Nominal torque T2N: 90 Nm
AFH060-025-S3 Frame: 060 | Ratio i: 25 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=3 arcmin | Nominal torque T2N: 90 Nm
AFH060-025-S4 Frame: 060 | Ratio i: 25 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=3 arcmin | Nominal torque T2N: 90 Nm
AFH060-028-S1 Frame: 060 | Ratio i: 28 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=3 arcmin | Nominal torque T2N: 60 Nm
AFH060-028-S2 Frame: 060 | Ratio i: 28 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=3 arcmin | Nominal torque T2N: 60 Nm
AFH060-028-S3 Frame: 060 | Ratio i: 28 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=3 arcmin | Nominal torque T2N: 60 Nm
AFH060-028-S4 Frame: 060 | Ratio i: 28 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=3 arcmin | Nominal torque T2N: 60 Nm
AFH060-035-S1 Frame: 060 | Ratio i: 35 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=3 arcmin | Nominal torque T2N: 75 Nm
AFH060-035-S2 Frame: 060 | Ratio i: 35 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=3 arcmin | Nominal torque T2N: 75 Nm
AFH060-035-S3 Frame: 060 | Ratio i: 35 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=3 arcmin | Nominal torque T2N: 75 Nm
AFH060-035-S4 Frame: 060 | Ratio i: 35 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=3 arcmin | Nominal torque T2N: 75 Nm
AFH060-040-S1 Frame: 060 | Ratio i: 40 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=3 arcmin | Nominal torque T2N: 40 Nm
AFH060-040-S2 Frame: 060 | Ratio i: 40 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=3 arcmin | Nominal torque T2N: 40 Nm
AFH060-040-S3 Frame: 060 | Ratio i: 40 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=3 arcmin | Nominal torque T2N: 40 Nm
AFH060-040-S4 Frame: 060 | Ratio i: 40 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=3 arcmin | Nominal torque T2N: 40 Nm
AFH060-050-S1 Frame: 060 | Ratio i: 50 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=3 arcmin | Nominal torque T2N: 50 Nm
AFH060-050-S2 Frame: 060 | Ratio i: 50 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=3 arcmin | Nominal torque T2N: 50 Nm
AFH060-050-S3 Frame: 060 | Ratio i: 50 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=3 arcmin | Nominal torque T2N: 50 Nm
AFH060-050-S4 Frame: 060 | Ratio i: 50 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=3 arcmin | Nominal torque T2N: 50 Nm
AFH060-070-S1 Frame: 060 | Ratio i: 70 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=3 arcmin | Nominal torque T2N: 60 Nm
AFH060-070-S2 Frame: 060 | Ratio i: 70 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=3 arcmin | Nominal torque T2N: 60 Nm
AFH060-070-S3 Frame: 060 | Ratio i: 70 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=3 arcmin | Nominal torque T2N: 60 Nm
AFH060-070-S4 Frame: 060 | Ratio i: 70 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=3 arcmin | Nominal torque T2N: 60 Nm
AFH060-100-S1 Frame: 060 | Ratio i: 100 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=3 arcmin | Nominal torque T2N: 24 Nm
AFH060-100-S2 Frame: 060 | Ratio i: 100 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=3 arcmin | Nominal torque T2N: 24 Nm
AFH060-100-S3 Frame: 060 | Ratio i: 100 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=3 arcmin | Nominal torque T2N: 24 Nm
AFH060-100-S4 Frame: 060 | Ratio i: 100 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=3 arcmin | Nominal torque T2N: 24 Nm
AFH075-003-S1 Frame: 075 | Ratio i: 3 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=1 arcmin | Nominal torque T2N: 155 Nm
AFH075-003-S2 Frame: 075 | Ratio i: 3 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=1 arcmin | Nominal torque T2N: 155 Nm
AFH075-003-S3 Frame: 075 | Ratio i: 3 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=1 arcmin | Nominal torque T2N: 155 Nm
AFH075-003-S4 Frame: 075 | Ratio i: 3 | Stages: 1 | Output shaft: S4 hollow (shrink disc) | Backlash: <=1 arcmin | Nominal torque T2N: 155 Nm
AFH075-004-S1 Frame: 075 | Ratio i: 4 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=1 arcmin | Nominal torque T2N: 205 Nm
AFH075-004-S2 Frame: 075 | Ratio i: 4 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=1 arcmin | Nominal torque T2N: 205 Nm
AFH075-004-S3 Frame: 075 | Ratio i: 4 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=1 arcmin | Nominal torque T2N: 205 Nm
AFH075-004-S4 Frame: 075 | Ratio i: 4 | Stages: 1 | Output shaft: S4 hollow (shrink disc) | Backlash: <=1 arcmin | Nominal torque T2N: 205 Nm
AFH075-005-S1 Frame: 075 | Ratio i: 5 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=1 arcmin | Nominal torque T2N: 185 Nm
AFH075-005-S2 Frame: 075 | Ratio i: 5 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=1 arcmin | Nominal torque T2N: 185 Nm
AFH075-005-S3 Frame: 075 | Ratio i: 5 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=1 arcmin | Nominal torque T2N: 185 Nm
AFH075-005-S4 Frame: 075 | Ratio i: 5 | Stages: 1 | Output shaft: S4 hollow (shrink disc) | Backlash: <=1 arcmin | Nominal torque T2N: 185 Nm
AFH075-007-S1 Frame: 075 | Ratio i: 7 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=1 arcmin | Nominal torque T2N: 135 Nm
AFH075-007-S2 Frame: 075 | Ratio i: 7 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=1 arcmin | Nominal torque T2N: 135 Nm
AFH075-007-S3 Frame: 075 | Ratio i: 7 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=1 arcmin | Nominal torque T2N: 135 Nm
AFH075-007-S4 Frame: 075 | Ratio i: 7 | Stages: 1 | Output shaft: S4 hollow (shrink disc) | Backlash: <=1 arcmin | Nominal torque T2N: 135 Nm
AFH075-010-S1 Frame: 075 | Ratio i: 10 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=1 arcmin | Nominal torque T2N: 55 Nm
AFH075-010-S2 Frame: 075 | Ratio i: 10 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=1 arcmin | Nominal torque T2N: 55 Nm
AFH075-010-S3 Frame: 075 | Ratio i: 10 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=1 arcmin | Nominal torque T2N: 55 Nm
AFH075-010-S4 Frame: 075 | Ratio i: 10 | Stages: 1 | Output shaft: S4 hollow (shrink disc) | Backlash: <=1 arcmin | Nominal torque T2N: 55 Nm
AFH075-016-S1 Frame: 075 | Ratio i: 16 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 205 Nm
AFH075-016-S2 Frame: 075 | Ratio i: 16 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 205 Nm
AFH075-016-S3 Frame: 075 | Ratio i: 16 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 205 Nm
AFH075-016-S4 Frame: 075 | Ratio i: 16 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 205 Nm
AFH075-020-S1 Frame: 075 | Ratio i: 20 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 205 Nm
AFH075-020-S2 Frame: 075 | Ratio i: 20 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 205 Nm
AFH075-020-S3 Frame: 075 | Ratio i: 20 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 205 Nm
AFH075-020-S4 Frame: 075 | Ratio i: 20 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 205 Nm
AFH075-025-S1 Frame: 075 | Ratio i: 25 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 195 Nm
AFH075-025-S2 Frame: 075 | Ratio i: 25 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 195 Nm
AFH075-025-S3 Frame: 075 | Ratio i: 25 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 195 Nm
AFH075-025-S4 Frame: 075 | Ratio i: 25 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 195 Nm
AFH075-028-S1 Frame: 075 | Ratio i: 28 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 205 Nm
AFH075-028-S2 Frame: 075 | Ratio i: 28 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 205 Nm
AFH075-028-S3 Frame: 075 | Ratio i: 28 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 205 Nm
AFH075-028-S4 Frame: 075 | Ratio i: 28 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 205 Nm
AFH075-035-S1 Frame: 075 | Ratio i: 35 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 195 Nm
AFH075-035-S2 Frame: 075 | Ratio i: 35 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 195 Nm
AFH075-035-S3 Frame: 075 | Ratio i: 35 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 195 Nm
AFH075-035-S4 Frame: 075 | Ratio i: 35 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 195 Nm
AFH075-040-S1 Frame: 075 | Ratio i: 40 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 96 Nm
AFH075-040-S2 Frame: 075 | Ratio i: 40 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 96 Nm
AFH075-040-S3 Frame: 075 | Ratio i: 40 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 96 Nm
AFH075-040-S4 Frame: 075 | Ratio i: 40 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 96 Nm
AFH075-050-S1 Frame: 075 | Ratio i: 50 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 120 Nm
AFH075-050-S2 Frame: 075 | Ratio i: 50 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 120 Nm
AFH075-050-S3 Frame: 075 | Ratio i: 50 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 120 Nm
AFH075-050-S4 Frame: 075 | Ratio i: 50 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 120 Nm
AFH075-070-S1 Frame: 075 | Ratio i: 70 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 135 Nm
AFH075-070-S2 Frame: 075 | Ratio i: 70 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 135 Nm
AFH075-070-S3 Frame: 075 | Ratio i: 70 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 135 Nm
AFH075-070-S4 Frame: 075 | Ratio i: 70 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 135 Nm
AFH075-100-S1 Frame: 075 | Ratio i: 100 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 55 Nm
AFH075-100-S2 Frame: 075 | Ratio i: 100 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 55 Nm
AFH075-100-S3 Frame: 075 | Ratio i: 100 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 55 Nm
AFH075-100-S4 Frame: 075 | Ratio i: 100 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 55 Nm
AFH100-003-S1 Frame: 100 | Ratio i: 3 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=1 arcmin | Nominal torque T2N: 415 Nm
AFH100-003-S2 Frame: 100 | Ratio i: 3 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=1 arcmin | Nominal torque T2N: 415 Nm
AFH100-003-S3 Frame: 100 | Ratio i: 3 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=1 arcmin | Nominal torque T2N: 415 Nm
AFH100-003-S4 Frame: 100 | Ratio i: 3 | Stages: 1 | Output shaft: S4 hollow (shrink disc) | Backlash: <=1 arcmin | Nominal torque T2N: 415 Nm
AFH100-004-S1 Frame: 100 | Ratio i: 4 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=1 arcmin | Nominal torque T2N: 380 Nm
AFH100-004-S2 Frame: 100 | Ratio i: 4 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=1 arcmin | Nominal torque T2N: 380 Nm
AFH100-004-S3 Frame: 100 | Ratio i: 4 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=1 arcmin | Nominal torque T2N: 380 Nm
AFH100-004-S4 Frame: 100 | Ratio i: 4 | Stages: 1 | Output shaft: S4 hollow (shrink disc) | Backlash: <=1 arcmin | Nominal torque T2N: 380 Nm
AFH100-005-S1 Frame: 100 | Ratio i: 5 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=1 arcmin | Nominal torque T2N: 325 Nm
AFH100-005-S2 Frame: 100 | Ratio i: 5 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=1 arcmin | Nominal torque T2N: 325 Nm
AFH100-005-S3 Frame: 100 | Ratio i: 5 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=1 arcmin | Nominal torque T2N: 325 Nm
AFH100-005-S4 Frame: 100 | Ratio i: 5 | Stages: 1 | Output shaft: S4 hollow (shrink disc) | Backlash: <=1 arcmin | Nominal torque T2N: 325 Nm
AFH100-007-S1 Frame: 100 | Ratio i: 7 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=1 arcmin | Nominal torque T2N: 260 Nm
AFH100-007-S2 Frame: 100 | Ratio i: 7 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=1 arcmin | Nominal torque T2N: 260 Nm
AFH100-007-S3 Frame: 100 | Ratio i: 7 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=1 arcmin | Nominal torque T2N: 260 Nm
AFH100-007-S4 Frame: 100 | Ratio i: 7 | Stages: 1 | Output shaft: S4 hollow (shrink disc) | Backlash: <=1 arcmin | Nominal torque T2N: 260 Nm
AFH100-010-S1 Frame: 100 | Ratio i: 10 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=1 arcmin | Nominal torque T2N: 160 Nm
AFH100-010-S2 Frame: 100 | Ratio i: 10 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=1 arcmin | Nominal torque T2N: 160 Nm
AFH100-010-S3 Frame: 100 | Ratio i: 10 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=1 arcmin | Nominal torque T2N: 160 Nm
AFH100-010-S4 Frame: 100 | Ratio i: 10 | Stages: 1 | Output shaft: S4 hollow (shrink disc) | Backlash: <=1 arcmin | Nominal torque T2N: 160 Nm
AFH100-016-S1 Frame: 100 | Ratio i: 16 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 400 Nm
AFH100-016-S2 Frame: 100 | Ratio i: 16 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 400 Nm
AFH100-016-S3 Frame: 100 | Ratio i: 16 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 400 Nm
AFH100-016-S4 Frame: 100 | Ratio i: 16 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 400 Nm
AFH100-020-S1 Frame: 100 | Ratio i: 20 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 400 Nm
AFH100-020-S2 Frame: 100 | Ratio i: 20 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 400 Nm
AFH100-020-S3 Frame: 100 | Ratio i: 20 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 400 Nm
AFH100-020-S4 Frame: 100 | Ratio i: 20 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 400 Nm
AFH100-025-S1 Frame: 100 | Ratio i: 25 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 345 Nm
AFH100-025-S2 Frame: 100 | Ratio i: 25 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 345 Nm
AFH100-025-S3 Frame: 100 | Ratio i: 25 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 345 Nm
AFH100-025-S4 Frame: 100 | Ratio i: 25 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 345 Nm
AFH100-028-S1 Frame: 100 | Ratio i: 28 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 405 Nm
AFH100-028-S2 Frame: 100 | Ratio i: 28 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 405 Nm
AFH100-028-S3 Frame: 100 | Ratio i: 28 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 405 Nm
AFH100-028-S4 Frame: 100 | Ratio i: 28 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 405 Nm
AFH100-035-S1 Frame: 100 | Ratio i: 35 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 350 Nm
AFH100-035-S2 Frame: 100 | Ratio i: 35 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 350 Nm
AFH100-035-S3 Frame: 100 | Ratio i: 35 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 350 Nm
AFH100-035-S4 Frame: 100 | Ratio i: 35 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 350 Nm
AFH100-040-S1 Frame: 100 | Ratio i: 40 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 220 Nm
AFH100-040-S2 Frame: 100 | Ratio i: 40 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 220 Nm
AFH100-040-S3 Frame: 100 | Ratio i: 40 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 220 Nm
AFH100-040-S4 Frame: 100 | Ratio i: 40 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 220 Nm
AFH100-050-S1 Frame: 100 | Ratio i: 50 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 275 Nm
AFH100-050-S2 Frame: 100 | Ratio i: 50 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 275 Nm
AFH100-050-S3 Frame: 100 | Ratio i: 50 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 275 Nm
AFH100-050-S4 Frame: 100 | Ratio i: 50 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 275 Nm
AFH100-070-S1 Frame: 100 | Ratio i: 70 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 300 Nm
AFH100-070-S2 Frame: 100 | Ratio i: 70 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 300 Nm
AFH100-070-S3 Frame: 100 | Ratio i: 70 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 300 Nm
AFH100-070-S4 Frame: 100 | Ratio i: 70 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 300 Nm
AFH100-100-S1 Frame: 100 | Ratio i: 100 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 160 Nm
AFH100-100-S2 Frame: 100 | Ratio i: 100 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 160 Nm
AFH100-100-S3 Frame: 100 | Ratio i: 100 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 160 Nm
AFH100-100-S4 Frame: 100 | Ratio i: 100 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 160 Nm
AFH140-003-S1 Frame: 140 | Ratio i: 3 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=1 arcmin | Nominal torque T2N: 635 Nm
AFH140-003-S2 Frame: 140 | Ratio i: 3 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=1 arcmin | Nominal torque T2N: 635 Nm
AFH140-003-S3 Frame: 140 | Ratio i: 3 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=1 arcmin | Nominal torque T2N: 635 Nm
AFH140-003-S4 Frame: 140 | Ratio i: 3 | Stages: 1 | Output shaft: S4 hollow (shrink disc) | Backlash: <=1 arcmin | Nominal torque T2N: 635 Nm
AFH140-004-S1 Frame: 140 | Ratio i: 4 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=1 arcmin | Nominal torque T2N: 765 Nm
AFH140-004-S2 Frame: 140 | Ratio i: 4 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=1 arcmin | Nominal torque T2N: 765 Nm
AFH140-004-S3 Frame: 140 | Ratio i: 4 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=1 arcmin | Nominal torque T2N: 765 Nm
AFH140-004-S4 Frame: 140 | Ratio i: 4 | Stages: 1 | Output shaft: S4 hollow (shrink disc) | Backlash: <=1 arcmin | Nominal torque T2N: 765 Nm
AFH140-005-S1 Frame: 140 | Ratio i: 5 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=1 arcmin | Nominal torque T2N: 660 Nm
AFH140-005-S2 Frame: 140 | Ratio i: 5 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=1 arcmin | Nominal torque T2N: 660 Nm
AFH140-005-S3 Frame: 140 | Ratio i: 5 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=1 arcmin | Nominal torque T2N: 660 Nm
AFH140-005-S4 Frame: 140 | Ratio i: 5 | Stages: 1 | Output shaft: S4 hollow (shrink disc) | Backlash: <=1 arcmin | Nominal torque T2N: 660 Nm
AFH140-007-S1 Frame: 140 | Ratio i: 7 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=1 arcmin | Nominal torque T2N: 515 Nm
AFH140-007-S2 Frame: 140 | Ratio i: 7 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=1 arcmin | Nominal torque T2N: 515 Nm
AFH140-007-S3 Frame: 140 | Ratio i: 7 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=1 arcmin | Nominal torque T2N: 515 Nm
AFH140-007-S4 Frame: 140 | Ratio i: 7 | Stages: 1 | Output shaft: S4 hollow (shrink disc) | Backlash: <=1 arcmin | Nominal torque T2N: 515 Nm
AFH140-010-S1 Frame: 140 | Ratio i: 10 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=1 arcmin | Nominal torque T2N: 315 Nm
AFH140-010-S2 Frame: 140 | Ratio i: 10 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=1 arcmin | Nominal torque T2N: 315 Nm
AFH140-010-S3 Frame: 140 | Ratio i: 10 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=1 arcmin | Nominal torque T2N: 315 Nm
AFH140-010-S4 Frame: 140 | Ratio i: 10 | Stages: 1 | Output shaft: S4 hollow (shrink disc) | Backlash: <=1 arcmin | Nominal torque T2N: 315 Nm
AFH140-016-S1 Frame: 140 | Ratio i: 16 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 805 Nm
AFH140-016-S2 Frame: 140 | Ratio i: 16 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 805 Nm
AFH140-016-S3 Frame: 140 | Ratio i: 16 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 805 Nm
AFH140-016-S4 Frame: 140 | Ratio i: 16 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 805 Nm
AFH140-020-S1 Frame: 140 | Ratio i: 20 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 810 Nm
AFH140-020-S2 Frame: 140 | Ratio i: 20 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 810 Nm
AFH140-020-S3 Frame: 140 | Ratio i: 20 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 810 Nm
AFH140-020-S4 Frame: 140 | Ratio i: 20 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 810 Nm
AFH140-025-S1 Frame: 140 | Ratio i: 25 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 700 Nm
AFH140-025-S2 Frame: 140 | Ratio i: 25 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 700 Nm
AFH140-025-S3 Frame: 140 | Ratio i: 25 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 700 Nm
AFH140-025-S4 Frame: 140 | Ratio i: 25 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 700 Nm
AFH140-028-S1 Frame: 140 | Ratio i: 28 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 820 Nm
AFH140-028-S2 Frame: 140 | Ratio i: 28 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 820 Nm
AFH140-028-S3 Frame: 140 | Ratio i: 28 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 820 Nm
AFH140-028-S4 Frame: 140 | Ratio i: 28 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 820 Nm
AFH140-035-S1 Frame: 140 | Ratio i: 35 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 705 Nm
AFH140-035-S2 Frame: 140 | Ratio i: 35 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 705 Nm
AFH140-035-S3 Frame: 140 | Ratio i: 35 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 705 Nm
AFH140-035-S4 Frame: 140 | Ratio i: 35 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 705 Nm
AFH140-040-S1 Frame: 140 | Ratio i: 40 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 615 Nm
AFH140-040-S2 Frame: 140 | Ratio i: 40 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 615 Nm
AFH140-040-S3 Frame: 140 | Ratio i: 40 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 615 Nm
AFH140-040-S4 Frame: 140 | Ratio i: 40 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 615 Nm
AFH140-050-S1 Frame: 140 | Ratio i: 50 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 715 Nm
AFH140-050-S2 Frame: 140 | Ratio i: 50 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 715 Nm
AFH140-050-S3 Frame: 140 | Ratio i: 50 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 715 Nm
AFH140-050-S4 Frame: 140 | Ratio i: 50 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 715 Nm
AFH140-070-S1 Frame: 140 | Ratio i: 70 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 585 Nm
AFH140-070-S2 Frame: 140 | Ratio i: 70 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 585 Nm
AFH140-070-S3 Frame: 140 | Ratio i: 70 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 585 Nm
AFH140-070-S4 Frame: 140 | Ratio i: 70 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 585 Nm
AFH140-100-S1 Frame: 140 | Ratio i: 100 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 345 Nm
AFH140-100-S2 Frame: 140 | Ratio i: 100 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 345 Nm
AFH140-100-S3 Frame: 140 | Ratio i: 100 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 345 Nm
AFH140-100-S4 Frame: 140 | Ratio i: 100 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 345 Nm
AFH180-003-S1 Frame: 180 | Ratio i: 3 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=1 arcmin | Nominal torque T2N: 1,560 Nm
AFH180-003-S2 Frame: 180 | Ratio i: 3 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=1 arcmin | Nominal torque T2N: 1,560 Nm
AFH180-003-S3 Frame: 180 | Ratio i: 3 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=1 arcmin | Nominal torque T2N: 1,560 Nm
AFH180-003-S4 Frame: 180 | Ratio i: 3 | Stages: 1 | Output shaft: S4 hollow (shrink disc) | Backlash: <=1 arcmin | Nominal torque T2N: 1,560 Nm
AFH180-004-S1 Frame: 180 | Ratio i: 4 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=1 arcmin | Nominal torque T2N: 1,415 Nm
AFH180-004-S2 Frame: 180 | Ratio i: 4 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=1 arcmin | Nominal torque T2N: 1,415 Nm
AFH180-004-S3 Frame: 180 | Ratio i: 4 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=1 arcmin | Nominal torque T2N: 1,415 Nm
AFH180-004-S4 Frame: 180 | Ratio i: 4 | Stages: 1 | Output shaft: S4 hollow (shrink disc) | Backlash: <=1 arcmin | Nominal torque T2N: 1,415 Nm
AFH180-005-S1 Frame: 180 | Ratio i: 5 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=1 arcmin | Nominal torque T2N: 1,225 Nm
AFH180-005-S2 Frame: 180 | Ratio i: 5 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=1 arcmin | Nominal torque T2N: 1,225 Nm
AFH180-005-S3 Frame: 180 | Ratio i: 5 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=1 arcmin | Nominal torque T2N: 1,225 Nm
AFH180-005-S4 Frame: 180 | Ratio i: 5 | Stages: 1 | Output shaft: S4 hollow (shrink disc) | Backlash: <=1 arcmin | Nominal torque T2N: 1,225 Nm
AFH180-007-S1 Frame: 180 | Ratio i: 7 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=1 arcmin | Nominal torque T2N: 980 Nm
AFH180-007-S2 Frame: 180 | Ratio i: 7 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=1 arcmin | Nominal torque T2N: 980 Nm
AFH180-007-S3 Frame: 180 | Ratio i: 7 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=1 arcmin | Nominal torque T2N: 980 Nm
AFH180-007-S4 Frame: 180 | Ratio i: 7 | Stages: 1 | Output shaft: S4 hollow (shrink disc) | Backlash: <=1 arcmin | Nominal torque T2N: 980 Nm
AFH180-010-S1 Frame: 180 | Ratio i: 10 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=1 arcmin | Nominal torque T2N: 700 Nm
AFH180-010-S2 Frame: 180 | Ratio i: 10 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=1 arcmin | Nominal torque T2N: 700 Nm
AFH180-010-S3 Frame: 180 | Ratio i: 10 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=1 arcmin | Nominal torque T2N: 700 Nm
AFH180-010-S4 Frame: 180 | Ratio i: 10 | Stages: 1 | Output shaft: S4 hollow (shrink disc) | Backlash: <=1 arcmin | Nominal torque T2N: 700 Nm
AFH180-016-S1 Frame: 180 | Ratio i: 16 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 1,485 Nm
AFH180-016-S2 Frame: 180 | Ratio i: 16 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 1,485 Nm
AFH180-016-S3 Frame: 180 | Ratio i: 16 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 1,485 Nm
AFH180-016-S4 Frame: 180 | Ratio i: 16 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 1,485 Nm
AFH180-020-S1 Frame: 180 | Ratio i: 20 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 1,495 Nm
AFH180-020-S2 Frame: 180 | Ratio i: 20 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 1,495 Nm
AFH180-020-S3 Frame: 180 | Ratio i: 20 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 1,495 Nm
AFH180-020-S4 Frame: 180 | Ratio i: 20 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 1,495 Nm
AFH180-025-S1 Frame: 180 | Ratio i: 25 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 1,295 Nm
AFH180-025-S2 Frame: 180 | Ratio i: 25 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 1,295 Nm
AFH180-025-S3 Frame: 180 | Ratio i: 25 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 1,295 Nm
AFH180-025-S4 Frame: 180 | Ratio i: 25 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 1,295 Nm
AFH180-028-S1 Frame: 180 | Ratio i: 28 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 1,510 Nm
AFH180-028-S2 Frame: 180 | Ratio i: 28 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 1,510 Nm
AFH180-028-S3 Frame: 180 | Ratio i: 28 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 1,510 Nm
AFH180-028-S4 Frame: 180 | Ratio i: 28 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 1,510 Nm
AFH180-035-S1 Frame: 180 | Ratio i: 35 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 1,310 Nm
AFH180-035-S2 Frame: 180 | Ratio i: 35 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 1,310 Nm
AFH180-035-S3 Frame: 180 | Ratio i: 35 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 1,310 Nm
AFH180-035-S4 Frame: 180 | Ratio i: 35 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 1,310 Nm
AFH180-040-S1 Frame: 180 | Ratio i: 40 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 1,260 Nm
AFH180-040-S2 Frame: 180 | Ratio i: 40 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 1,260 Nm
AFH180-040-S3 Frame: 180 | Ratio i: 40 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 1,260 Nm
AFH180-040-S4 Frame: 180 | Ratio i: 40 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 1,260 Nm
AFH180-050-S1 Frame: 180 | Ratio i: 50 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 1,325 Nm
AFH180-050-S2 Frame: 180 | Ratio i: 50 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 1,325 Nm
AFH180-050-S3 Frame: 180 | Ratio i: 50 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 1,325 Nm
AFH180-050-S4 Frame: 180 | Ratio i: 50 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 1,325 Nm
AFH180-070-S1 Frame: 180 | Ratio i: 70 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 1,095 Nm
AFH180-070-S2 Frame: 180 | Ratio i: 70 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 1,095 Nm
AFH180-070-S3 Frame: 180 | Ratio i: 70 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 1,095 Nm
AFH180-070-S4 Frame: 180 | Ratio i: 70 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 1,095 Nm
AFH180-100-S1 Frame: 180 | Ratio i: 100 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 660 Nm
AFH180-100-S2 Frame: 180 | Ratio i: 100 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 660 Nm
AFH180-100-S3 Frame: 180 | Ratio i: 100 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 660 Nm
AFH180-100-S4 Frame: 180 | Ratio i: 100 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 660 Nm
AFH210-003-S1 Frame: 210 | Ratio i: 3 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=1 arcmin | Nominal torque T2N: 2,465 Nm
AFH210-003-S2 Frame: 210 | Ratio i: 3 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=1 arcmin | Nominal torque T2N: 2,465 Nm
AFH210-003-S3 Frame: 210 | Ratio i: 3 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=1 arcmin | Nominal torque T2N: 2,465 Nm
AFH210-004-S1 Frame: 210 | Ratio i: 4 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=1 arcmin | Nominal torque T2N: 2,190 Nm
AFH210-004-S2 Frame: 210 | Ratio i: 4 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=1 arcmin | Nominal torque T2N: 2,190 Nm
AFH210-004-S3 Frame: 210 | Ratio i: 4 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=1 arcmin | Nominal torque T2N: 2,190 Nm
AFH210-005-S1 Frame: 210 | Ratio i: 5 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=1 arcmin | Nominal torque T2N: 1,905 Nm
AFH210-005-S2 Frame: 210 | Ratio i: 5 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=1 arcmin | Nominal torque T2N: 1,905 Nm
AFH210-005-S3 Frame: 210 | Ratio i: 5 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=1 arcmin | Nominal torque T2N: 1,905 Nm
AFH210-007-S1 Frame: 210 | Ratio i: 7 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=1 arcmin | Nominal torque T2N: 1,530 Nm
AFH210-007-S2 Frame: 210 | Ratio i: 7 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=1 arcmin | Nominal torque T2N: 1,530 Nm
AFH210-007-S3 Frame: 210 | Ratio i: 7 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=1 arcmin | Nominal torque T2N: 1,530 Nm
AFH210-010-S1 Frame: 210 | Ratio i: 10 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=1 arcmin | Nominal torque T2N: 1,070 Nm
AFH210-010-S2 Frame: 210 | Ratio i: 10 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=1 arcmin | Nominal torque T2N: 1,070 Nm
AFH210-010-S3 Frame: 210 | Ratio i: 10 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=1 arcmin | Nominal torque T2N: 1,070 Nm
AFH210-016-S1 Frame: 210 | Ratio i: 16 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 2,295 Nm
AFH210-016-S2 Frame: 210 | Ratio i: 16 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 2,295 Nm
AFH210-016-S3 Frame: 210 | Ratio i: 16 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 2,295 Nm
AFH210-020-S1 Frame: 210 | Ratio i: 20 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 2,310 Nm
AFH210-020-S2 Frame: 210 | Ratio i: 20 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 2,310 Nm
AFH210-020-S3 Frame: 210 | Ratio i: 20 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 2,310 Nm
AFH210-025-S1 Frame: 210 | Ratio i: 25 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 2,005 Nm
AFH210-025-S2 Frame: 210 | Ratio i: 25 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 2,005 Nm
AFH210-025-S3 Frame: 210 | Ratio i: 25 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 2,005 Nm
AFH210-028-S1 Frame: 210 | Ratio i: 28 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 2,335 Nm
AFH210-028-S2 Frame: 210 | Ratio i: 28 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 2,335 Nm
AFH210-028-S3 Frame: 210 | Ratio i: 28 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 2,335 Nm
AFH210-035-S1 Frame: 210 | Ratio i: 35 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 2,030 Nm
AFH210-035-S2 Frame: 210 | Ratio i: 35 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 2,030 Nm
AFH210-035-S3 Frame: 210 | Ratio i: 35 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 2,030 Nm
AFH210-040-S1 Frame: 210 | Ratio i: 40 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 2,360 Nm
AFH210-040-S2 Frame: 210 | Ratio i: 40 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 2,360 Nm
AFH210-040-S3 Frame: 210 | Ratio i: 40 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 2,360 Nm
AFH210-050-S1 Frame: 210 | Ratio i: 50 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 2,050 Nm
AFH210-050-S2 Frame: 210 | Ratio i: 50 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 2,050 Nm
AFH210-050-S3 Frame: 210 | Ratio i: 50 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 2,050 Nm
AFH210-070-S1 Frame: 210 | Ratio i: 70 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 1,670 Nm
AFH210-070-S2 Frame: 210 | Ratio i: 70 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 1,670 Nm
AFH210-070-S3 Frame: 210 | Ratio i: 70 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 1,670 Nm
AFH210-100-S1 Frame: 210 | Ratio i: 100 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 1,005 Nm
AFH210-100-S2 Frame: 210 | Ratio i: 100 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 1,005 Nm
AFH210-100-S3 Frame: 210 | Ratio i: 100 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 1,005 Nm
AFH240-003-S1 Frame: 240 | Ratio i: 3 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=1 arcmin | Nominal torque T2N: 4,360 Nm
AFH240-003-S2 Frame: 240 | Ratio i: 3 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=1 arcmin | Nominal torque T2N: 4,360 Nm
AFH240-003-S3 Frame: 240 | Ratio i: 3 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=1 arcmin | Nominal torque T2N: 4,360 Nm
AFH240-004-S1 Frame: 240 | Ratio i: 4 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=1 arcmin | Nominal torque T2N: 4,035 Nm
AFH240-004-S2 Frame: 240 | Ratio i: 4 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=1 arcmin | Nominal torque T2N: 4,035 Nm
AFH240-004-S3 Frame: 240 | Ratio i: 4 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=1 arcmin | Nominal torque T2N: 4,035 Nm
AFH240-005-S1 Frame: 240 | Ratio i: 5 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=1 arcmin | Nominal torque T2N: 3,505 Nm
AFH240-005-S2 Frame: 240 | Ratio i: 5 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=1 arcmin | Nominal torque T2N: 3,505 Nm
AFH240-005-S3 Frame: 240 | Ratio i: 5 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=1 arcmin | Nominal torque T2N: 3,505 Nm
AFH240-007-S1 Frame: 240 | Ratio i: 7 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=1 arcmin | Nominal torque T2N: 2,630 Nm
AFH240-007-S2 Frame: 240 | Ratio i: 7 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=1 arcmin | Nominal torque T2N: 2,630 Nm
AFH240-007-S3 Frame: 240 | Ratio i: 7 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=1 arcmin | Nominal torque T2N: 2,630 Nm
AFH240-010-S1 Frame: 240 | Ratio i: 10 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=1 arcmin | Nominal torque T2N: 1,810 Nm
AFH240-010-S2 Frame: 240 | Ratio i: 10 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=1 arcmin | Nominal torque T2N: 1,810 Nm
AFH240-010-S3 Frame: 240 | Ratio i: 10 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=1 arcmin | Nominal torque T2N: 1,810 Nm
AFH240-016-S1 Frame: 240 | Ratio i: 16 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 4,215 Nm
AFH240-016-S2 Frame: 240 | Ratio i: 16 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 4,215 Nm
AFH240-016-S3 Frame: 240 | Ratio i: 16 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 4,215 Nm
AFH240-020-S1 Frame: 240 | Ratio i: 20 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 4,425 Nm
AFH240-020-S2 Frame: 240 | Ratio i: 20 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 4,425 Nm
AFH240-020-S3 Frame: 240 | Ratio i: 20 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 4,425 Nm
AFH240-025-S1 Frame: 240 | Ratio i: 25 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 3,685 Nm
AFH240-025-S2 Frame: 240 | Ratio i: 25 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 3,685 Nm
AFH240-025-S3 Frame: 240 | Ratio i: 25 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 3,685 Nm
AFH240-028-S1 Frame: 240 | Ratio i: 28 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 4,425 Nm
AFH240-028-S2 Frame: 240 | Ratio i: 28 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 4,425 Nm
AFH240-028-S3 Frame: 240 | Ratio i: 28 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 4,425 Nm
AFH240-035-S1 Frame: 240 | Ratio i: 35 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 3,725 Nm
AFH240-035-S2 Frame: 240 | Ratio i: 35 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 3,725 Nm
AFH240-035-S3 Frame: 240 | Ratio i: 35 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 3,725 Nm
AFH240-040-S1 Frame: 240 | Ratio i: 40 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 4,430 Nm
AFH240-040-S2 Frame: 240 | Ratio i: 40 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 4,430 Nm
AFH240-040-S3 Frame: 240 | Ratio i: 40 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 4,430 Nm
AFH240-050-S1 Frame: 240 | Ratio i: 50 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 3,765 Nm
AFH240-050-S2 Frame: 240 | Ratio i: 50 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 3,765 Nm
AFH240-050-S3 Frame: 240 | Ratio i: 50 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 3,765 Nm
AFH240-070-S1 Frame: 240 | Ratio i: 70 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 2,675 Nm
AFH240-070-S2 Frame: 240 | Ratio i: 70 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 2,675 Nm
AFH240-070-S3 Frame: 240 | Ratio i: 70 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 2,675 Nm
AFH240-100-S1 Frame: 240 | Ratio i: 100 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 1,700 Nm
AFH240-100-S2 Frame: 240 | Ratio i: 100 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 1,700 Nm
AFH240-100-S3 Frame: 240 | Ratio i: 100 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 1,700 Nm
Planetary GearboxesApex Dynamics
364 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Apex Dynamics AFH New Generation Planetary Gearboxes (Frame 060-240)

Brand Apex Dynamics·Planetary Gearboxes

Available part numbers (364)

AFH060-003-S1, AFH060-003-S2, AFH060-003-S3, AFH060-003-S4, AFH060-004-S1, AFH060-004-S2, AFH060-004-S3, AFH060-004-S4, AFH060-005-S1, AFH060-005-S2 + 354 more — see full table ↓

How to order

Send the Apex Dynamics part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
AFH060-003-S1Frame: 060 | Ratio i: 3 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 90 Nm
AFH060-003-S2Frame: 060 | Ratio i: 3 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 90 Nm
AFH060-003-S3Frame: 060 | Ratio i: 3 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 90 Nm
AFH060-003-S4Frame: 060 | Ratio i: 3 | Stages: 1 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 90 Nm
AFH060-004-S1Frame: 060 | Ratio i: 4 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 100 Nm
AFH060-004-S2Frame: 060 | Ratio i: 4 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 100 Nm
AFH060-004-S3Frame: 060 | Ratio i: 4 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 100 Nm
AFH060-004-S4Frame: 060 | Ratio i: 4 | Stages: 1 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 100 Nm
AFH060-005-S1Frame: 060 | Ratio i: 5 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 85 Nm
AFH060-005-S2Frame: 060 | Ratio i: 5 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 85 Nm
AFH060-005-S3Frame: 060 | Ratio i: 5 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 85 Nm
AFH060-005-S4Frame: 060 | Ratio i: 5 | Stages: 1 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 85 Nm
AFH060-007-S1Frame: 060 | Ratio i: 7 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 60 Nm
AFH060-007-S2Frame: 060 | Ratio i: 7 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 60 Nm
AFH060-007-S3Frame: 060 | Ratio i: 7 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 60 Nm
AFH060-007-S4Frame: 060 | Ratio i: 7 | Stages: 1 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 60 Nm
AFH060-010-S1Frame: 060 | Ratio i: 10 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 24 Nm
AFH060-010-S2Frame: 060 | Ratio i: 10 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 24 Nm
AFH060-010-S3Frame: 060 | Ratio i: 10 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 24 Nm
AFH060-010-S4Frame: 060 | Ratio i: 10 | Stages: 1 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 24 Nm
AFH060-016-S1Frame: 060 | Ratio i: 16 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=3 arcmin | Nominal torque T2N: 100 Nm
AFH060-016-S2Frame: 060 | Ratio i: 16 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=3 arcmin | Nominal torque T2N: 100 Nm
AFH060-016-S3Frame: 060 | Ratio i: 16 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=3 arcmin | Nominal torque T2N: 100 Nm
AFH060-016-S4Frame: 060 | Ratio i: 16 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=3 arcmin | Nominal torque T2N: 100 Nm
AFH060-020-S1Frame: 060 | Ratio i: 20 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=3 arcmin | Nominal torque T2N: 100 Nm
AFH060-020-S2Frame: 060 | Ratio i: 20 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=3 arcmin | Nominal torque T2N: 100 Nm
AFH060-020-S3Frame: 060 | Ratio i: 20 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=3 arcmin | Nominal torque T2N: 100 Nm
AFH060-020-S4Frame: 060 | Ratio i: 20 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=3 arcmin | Nominal torque T2N: 100 Nm
AFH060-025-S1Frame: 060 | Ratio i: 25 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=3 arcmin | Nominal torque T2N: 90 Nm
AFH060-025-S2Frame: 060 | Ratio i: 25 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=3 arcmin | Nominal torque T2N: 90 Nm
AFH060-025-S3Frame: 060 | Ratio i: 25 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=3 arcmin | Nominal torque T2N: 90 Nm
AFH060-025-S4Frame: 060 | Ratio i: 25 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=3 arcmin | Nominal torque T2N: 90 Nm
AFH060-028-S1Frame: 060 | Ratio i: 28 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=3 arcmin | Nominal torque T2N: 60 Nm
AFH060-028-S2Frame: 060 | Ratio i: 28 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=3 arcmin | Nominal torque T2N: 60 Nm
AFH060-028-S3Frame: 060 | Ratio i: 28 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=3 arcmin | Nominal torque T2N: 60 Nm
AFH060-028-S4Frame: 060 | Ratio i: 28 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=3 arcmin | Nominal torque T2N: 60 Nm
AFH060-035-S1Frame: 060 | Ratio i: 35 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=3 arcmin | Nominal torque T2N: 75 Nm
AFH060-035-S2Frame: 060 | Ratio i: 35 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=3 arcmin | Nominal torque T2N: 75 Nm
AFH060-035-S3Frame: 060 | Ratio i: 35 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=3 arcmin | Nominal torque T2N: 75 Nm
AFH060-035-S4Frame: 060 | Ratio i: 35 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=3 arcmin | Nominal torque T2N: 75 Nm
AFH060-040-S1Frame: 060 | Ratio i: 40 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=3 arcmin | Nominal torque T2N: 40 Nm
AFH060-040-S2Frame: 060 | Ratio i: 40 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=3 arcmin | Nominal torque T2N: 40 Nm
AFH060-040-S3Frame: 060 | Ratio i: 40 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=3 arcmin | Nominal torque T2N: 40 Nm
AFH060-040-S4Frame: 060 | Ratio i: 40 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=3 arcmin | Nominal torque T2N: 40 Nm
AFH060-050-S1Frame: 060 | Ratio i: 50 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=3 arcmin | Nominal torque T2N: 50 Nm
AFH060-050-S2Frame: 060 | Ratio i: 50 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=3 arcmin | Nominal torque T2N: 50 Nm
AFH060-050-S3Frame: 060 | Ratio i: 50 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=3 arcmin | Nominal torque T2N: 50 Nm
AFH060-050-S4Frame: 060 | Ratio i: 50 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=3 arcmin | Nominal torque T2N: 50 Nm
AFH060-070-S1Frame: 060 | Ratio i: 70 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=3 arcmin | Nominal torque T2N: 60 Nm
AFH060-070-S2Frame: 060 | Ratio i: 70 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=3 arcmin | Nominal torque T2N: 60 Nm
AFH060-070-S3Frame: 060 | Ratio i: 70 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=3 arcmin | Nominal torque T2N: 60 Nm
AFH060-070-S4Frame: 060 | Ratio i: 70 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=3 arcmin | Nominal torque T2N: 60 Nm
AFH060-100-S1Frame: 060 | Ratio i: 100 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=3 arcmin | Nominal torque T2N: 24 Nm
AFH060-100-S2Frame: 060 | Ratio i: 100 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=3 arcmin | Nominal torque T2N: 24 Nm
AFH060-100-S3Frame: 060 | Ratio i: 100 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=3 arcmin | Nominal torque T2N: 24 Nm
AFH060-100-S4Frame: 060 | Ratio i: 100 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=3 arcmin | Nominal torque T2N: 24 Nm
AFH075-003-S1Frame: 075 | Ratio i: 3 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=1 arcmin | Nominal torque T2N: 155 Nm
AFH075-003-S2Frame: 075 | Ratio i: 3 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=1 arcmin | Nominal torque T2N: 155 Nm
AFH075-003-S3Frame: 075 | Ratio i: 3 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=1 arcmin | Nominal torque T2N: 155 Nm
AFH075-003-S4Frame: 075 | Ratio i: 3 | Stages: 1 | Output shaft: S4 hollow (shrink disc) | Backlash: <=1 arcmin | Nominal torque T2N: 155 Nm
AFH075-004-S1Frame: 075 | Ratio i: 4 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=1 arcmin | Nominal torque T2N: 205 Nm
AFH075-004-S2Frame: 075 | Ratio i: 4 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=1 arcmin | Nominal torque T2N: 205 Nm
AFH075-004-S3Frame: 075 | Ratio i: 4 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=1 arcmin | Nominal torque T2N: 205 Nm
AFH075-004-S4Frame: 075 | Ratio i: 4 | Stages: 1 | Output shaft: S4 hollow (shrink disc) | Backlash: <=1 arcmin | Nominal torque T2N: 205 Nm
AFH075-005-S1Frame: 075 | Ratio i: 5 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=1 arcmin | Nominal torque T2N: 185 Nm
AFH075-005-S2Frame: 075 | Ratio i: 5 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=1 arcmin | Nominal torque T2N: 185 Nm
AFH075-005-S3Frame: 075 | Ratio i: 5 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=1 arcmin | Nominal torque T2N: 185 Nm
AFH075-005-S4Frame: 075 | Ratio i: 5 | Stages: 1 | Output shaft: S4 hollow (shrink disc) | Backlash: <=1 arcmin | Nominal torque T2N: 185 Nm
AFH075-007-S1Frame: 075 | Ratio i: 7 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=1 arcmin | Nominal torque T2N: 135 Nm
AFH075-007-S2Frame: 075 | Ratio i: 7 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=1 arcmin | Nominal torque T2N: 135 Nm
AFH075-007-S3Frame: 075 | Ratio i: 7 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=1 arcmin | Nominal torque T2N: 135 Nm
AFH075-007-S4Frame: 075 | Ratio i: 7 | Stages: 1 | Output shaft: S4 hollow (shrink disc) | Backlash: <=1 arcmin | Nominal torque T2N: 135 Nm
AFH075-010-S1Frame: 075 | Ratio i: 10 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=1 arcmin | Nominal torque T2N: 55 Nm
AFH075-010-S2Frame: 075 | Ratio i: 10 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=1 arcmin | Nominal torque T2N: 55 Nm
AFH075-010-S3Frame: 075 | Ratio i: 10 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=1 arcmin | Nominal torque T2N: 55 Nm
AFH075-010-S4Frame: 075 | Ratio i: 10 | Stages: 1 | Output shaft: S4 hollow (shrink disc) | Backlash: <=1 arcmin | Nominal torque T2N: 55 Nm
AFH075-016-S1Frame: 075 | Ratio i: 16 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 205 Nm
AFH075-016-S2Frame: 075 | Ratio i: 16 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 205 Nm
AFH075-016-S3Frame: 075 | Ratio i: 16 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 205 Nm
AFH075-016-S4Frame: 075 | Ratio i: 16 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 205 Nm
AFH075-020-S1Frame: 075 | Ratio i: 20 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 205 Nm
AFH075-020-S2Frame: 075 | Ratio i: 20 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 205 Nm
AFH075-020-S3Frame: 075 | Ratio i: 20 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 205 Nm
AFH075-020-S4Frame: 075 | Ratio i: 20 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 205 Nm
AFH075-025-S1Frame: 075 | Ratio i: 25 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 195 Nm
AFH075-025-S2Frame: 075 | Ratio i: 25 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 195 Nm
AFH075-025-S3Frame: 075 | Ratio i: 25 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 195 Nm
AFH075-025-S4Frame: 075 | Ratio i: 25 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 195 Nm
AFH075-028-S1Frame: 075 | Ratio i: 28 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 205 Nm
AFH075-028-S2Frame: 075 | Ratio i: 28 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 205 Nm
AFH075-028-S3Frame: 075 | Ratio i: 28 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 205 Nm
AFH075-028-S4Frame: 075 | Ratio i: 28 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 205 Nm
AFH075-035-S1Frame: 075 | Ratio i: 35 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 195 Nm
AFH075-035-S2Frame: 075 | Ratio i: 35 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 195 Nm
AFH075-035-S3Frame: 075 | Ratio i: 35 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 195 Nm
AFH075-035-S4Frame: 075 | Ratio i: 35 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 195 Nm
AFH075-040-S1Frame: 075 | Ratio i: 40 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 96 Nm
AFH075-040-S2Frame: 075 | Ratio i: 40 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 96 Nm
AFH075-040-S3Frame: 075 | Ratio i: 40 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 96 Nm
AFH075-040-S4Frame: 075 | Ratio i: 40 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 96 Nm
AFH075-050-S1Frame: 075 | Ratio i: 50 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 120 Nm
AFH075-050-S2Frame: 075 | Ratio i: 50 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 120 Nm
AFH075-050-S3Frame: 075 | Ratio i: 50 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 120 Nm
AFH075-050-S4Frame: 075 | Ratio i: 50 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 120 Nm
AFH075-070-S1Frame: 075 | Ratio i: 70 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 135 Nm
AFH075-070-S2Frame: 075 | Ratio i: 70 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 135 Nm
AFH075-070-S3Frame: 075 | Ratio i: 70 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 135 Nm
AFH075-070-S4Frame: 075 | Ratio i: 70 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 135 Nm
AFH075-100-S1Frame: 075 | Ratio i: 100 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 55 Nm
AFH075-100-S2Frame: 075 | Ratio i: 100 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 55 Nm
AFH075-100-S3Frame: 075 | Ratio i: 100 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 55 Nm
AFH075-100-S4Frame: 075 | Ratio i: 100 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 55 Nm
AFH100-003-S1Frame: 100 | Ratio i: 3 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=1 arcmin | Nominal torque T2N: 415 Nm
AFH100-003-S2Frame: 100 | Ratio i: 3 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=1 arcmin | Nominal torque T2N: 415 Nm
AFH100-003-S3Frame: 100 | Ratio i: 3 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=1 arcmin | Nominal torque T2N: 415 Nm
AFH100-003-S4Frame: 100 | Ratio i: 3 | Stages: 1 | Output shaft: S4 hollow (shrink disc) | Backlash: <=1 arcmin | Nominal torque T2N: 415 Nm
AFH100-004-S1Frame: 100 | Ratio i: 4 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=1 arcmin | Nominal torque T2N: 380 Nm
AFH100-004-S2Frame: 100 | Ratio i: 4 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=1 arcmin | Nominal torque T2N: 380 Nm
AFH100-004-S3Frame: 100 | Ratio i: 4 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=1 arcmin | Nominal torque T2N: 380 Nm
AFH100-004-S4Frame: 100 | Ratio i: 4 | Stages: 1 | Output shaft: S4 hollow (shrink disc) | Backlash: <=1 arcmin | Nominal torque T2N: 380 Nm
AFH100-005-S1Frame: 100 | Ratio i: 5 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=1 arcmin | Nominal torque T2N: 325 Nm
AFH100-005-S2Frame: 100 | Ratio i: 5 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=1 arcmin | Nominal torque T2N: 325 Nm
AFH100-005-S3Frame: 100 | Ratio i: 5 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=1 arcmin | Nominal torque T2N: 325 Nm
AFH100-005-S4Frame: 100 | Ratio i: 5 | Stages: 1 | Output shaft: S4 hollow (shrink disc) | Backlash: <=1 arcmin | Nominal torque T2N: 325 Nm
AFH100-007-S1Frame: 100 | Ratio i: 7 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=1 arcmin | Nominal torque T2N: 260 Nm
AFH100-007-S2Frame: 100 | Ratio i: 7 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=1 arcmin | Nominal torque T2N: 260 Nm
AFH100-007-S3Frame: 100 | Ratio i: 7 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=1 arcmin | Nominal torque T2N: 260 Nm
AFH100-007-S4Frame: 100 | Ratio i: 7 | Stages: 1 | Output shaft: S4 hollow (shrink disc) | Backlash: <=1 arcmin | Nominal torque T2N: 260 Nm
AFH100-010-S1Frame: 100 | Ratio i: 10 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=1 arcmin | Nominal torque T2N: 160 Nm
AFH100-010-S2Frame: 100 | Ratio i: 10 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=1 arcmin | Nominal torque T2N: 160 Nm
AFH100-010-S3Frame: 100 | Ratio i: 10 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=1 arcmin | Nominal torque T2N: 160 Nm
AFH100-010-S4Frame: 100 | Ratio i: 10 | Stages: 1 | Output shaft: S4 hollow (shrink disc) | Backlash: <=1 arcmin | Nominal torque T2N: 160 Nm
AFH100-016-S1Frame: 100 | Ratio i: 16 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 400 Nm
AFH100-016-S2Frame: 100 | Ratio i: 16 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 400 Nm
AFH100-016-S3Frame: 100 | Ratio i: 16 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 400 Nm
AFH100-016-S4Frame: 100 | Ratio i: 16 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 400 Nm
AFH100-020-S1Frame: 100 | Ratio i: 20 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 400 Nm
AFH100-020-S2Frame: 100 | Ratio i: 20 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 400 Nm
AFH100-020-S3Frame: 100 | Ratio i: 20 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 400 Nm
AFH100-020-S4Frame: 100 | Ratio i: 20 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 400 Nm
AFH100-025-S1Frame: 100 | Ratio i: 25 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 345 Nm
AFH100-025-S2Frame: 100 | Ratio i: 25 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 345 Nm
AFH100-025-S3Frame: 100 | Ratio i: 25 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 345 Nm
AFH100-025-S4Frame: 100 | Ratio i: 25 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 345 Nm
AFH100-028-S1Frame: 100 | Ratio i: 28 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 405 Nm
AFH100-028-S2Frame: 100 | Ratio i: 28 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 405 Nm
AFH100-028-S3Frame: 100 | Ratio i: 28 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 405 Nm
AFH100-028-S4Frame: 100 | Ratio i: 28 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 405 Nm
AFH100-035-S1Frame: 100 | Ratio i: 35 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 350 Nm
AFH100-035-S2Frame: 100 | Ratio i: 35 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 350 Nm
AFH100-035-S3Frame: 100 | Ratio i: 35 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 350 Nm
AFH100-035-S4Frame: 100 | Ratio i: 35 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 350 Nm
AFH100-040-S1Frame: 100 | Ratio i: 40 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 220 Nm
AFH100-040-S2Frame: 100 | Ratio i: 40 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 220 Nm
AFH100-040-S3Frame: 100 | Ratio i: 40 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 220 Nm
AFH100-040-S4Frame: 100 | Ratio i: 40 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 220 Nm
AFH100-050-S1Frame: 100 | Ratio i: 50 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 275 Nm
AFH100-050-S2Frame: 100 | Ratio i: 50 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 275 Nm
AFH100-050-S3Frame: 100 | Ratio i: 50 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 275 Nm
AFH100-050-S4Frame: 100 | Ratio i: 50 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 275 Nm
AFH100-070-S1Frame: 100 | Ratio i: 70 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 300 Nm
AFH100-070-S2Frame: 100 | Ratio i: 70 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 300 Nm
AFH100-070-S3Frame: 100 | Ratio i: 70 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 300 Nm
AFH100-070-S4Frame: 100 | Ratio i: 70 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 300 Nm
AFH100-100-S1Frame: 100 | Ratio i: 100 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 160 Nm
AFH100-100-S2Frame: 100 | Ratio i: 100 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 160 Nm
AFH100-100-S3Frame: 100 | Ratio i: 100 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 160 Nm
AFH100-100-S4Frame: 100 | Ratio i: 100 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 160 Nm
AFH140-003-S1Frame: 140 | Ratio i: 3 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=1 arcmin | Nominal torque T2N: 635 Nm
AFH140-003-S2Frame: 140 | Ratio i: 3 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=1 arcmin | Nominal torque T2N: 635 Nm
AFH140-003-S3Frame: 140 | Ratio i: 3 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=1 arcmin | Nominal torque T2N: 635 Nm
AFH140-003-S4Frame: 140 | Ratio i: 3 | Stages: 1 | Output shaft: S4 hollow (shrink disc) | Backlash: <=1 arcmin | Nominal torque T2N: 635 Nm
AFH140-004-S1Frame: 140 | Ratio i: 4 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=1 arcmin | Nominal torque T2N: 765 Nm
AFH140-004-S2Frame: 140 | Ratio i: 4 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=1 arcmin | Nominal torque T2N: 765 Nm
AFH140-004-S3Frame: 140 | Ratio i: 4 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=1 arcmin | Nominal torque T2N: 765 Nm
AFH140-004-S4Frame: 140 | Ratio i: 4 | Stages: 1 | Output shaft: S4 hollow (shrink disc) | Backlash: <=1 arcmin | Nominal torque T2N: 765 Nm
AFH140-005-S1Frame: 140 | Ratio i: 5 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=1 arcmin | Nominal torque T2N: 660 Nm
AFH140-005-S2Frame: 140 | Ratio i: 5 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=1 arcmin | Nominal torque T2N: 660 Nm
AFH140-005-S3Frame: 140 | Ratio i: 5 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=1 arcmin | Nominal torque T2N: 660 Nm
AFH140-005-S4Frame: 140 | Ratio i: 5 | Stages: 1 | Output shaft: S4 hollow (shrink disc) | Backlash: <=1 arcmin | Nominal torque T2N: 660 Nm
AFH140-007-S1Frame: 140 | Ratio i: 7 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=1 arcmin | Nominal torque T2N: 515 Nm
AFH140-007-S2Frame: 140 | Ratio i: 7 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=1 arcmin | Nominal torque T2N: 515 Nm
AFH140-007-S3Frame: 140 | Ratio i: 7 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=1 arcmin | Nominal torque T2N: 515 Nm
AFH140-007-S4Frame: 140 | Ratio i: 7 | Stages: 1 | Output shaft: S4 hollow (shrink disc) | Backlash: <=1 arcmin | Nominal torque T2N: 515 Nm
AFH140-010-S1Frame: 140 | Ratio i: 10 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=1 arcmin | Nominal torque T2N: 315 Nm
AFH140-010-S2Frame: 140 | Ratio i: 10 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=1 arcmin | Nominal torque T2N: 315 Nm
AFH140-010-S3Frame: 140 | Ratio i: 10 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=1 arcmin | Nominal torque T2N: 315 Nm
AFH140-010-S4Frame: 140 | Ratio i: 10 | Stages: 1 | Output shaft: S4 hollow (shrink disc) | Backlash: <=1 arcmin | Nominal torque T2N: 315 Nm
AFH140-016-S1Frame: 140 | Ratio i: 16 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 805 Nm
AFH140-016-S2Frame: 140 | Ratio i: 16 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 805 Nm
AFH140-016-S3Frame: 140 | Ratio i: 16 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 805 Nm
AFH140-016-S4Frame: 140 | Ratio i: 16 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 805 Nm
AFH140-020-S1Frame: 140 | Ratio i: 20 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 810 Nm
AFH140-020-S2Frame: 140 | Ratio i: 20 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 810 Nm
AFH140-020-S3Frame: 140 | Ratio i: 20 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 810 Nm
AFH140-020-S4Frame: 140 | Ratio i: 20 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 810 Nm
AFH140-025-S1Frame: 140 | Ratio i: 25 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 700 Nm
AFH140-025-S2Frame: 140 | Ratio i: 25 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 700 Nm
AFH140-025-S3Frame: 140 | Ratio i: 25 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 700 Nm
AFH140-025-S4Frame: 140 | Ratio i: 25 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 700 Nm
AFH140-028-S1Frame: 140 | Ratio i: 28 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 820 Nm
AFH140-028-S2Frame: 140 | Ratio i: 28 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 820 Nm
AFH140-028-S3Frame: 140 | Ratio i: 28 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 820 Nm
AFH140-028-S4Frame: 140 | Ratio i: 28 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 820 Nm
AFH140-035-S1Frame: 140 | Ratio i: 35 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 705 Nm
AFH140-035-S2Frame: 140 | Ratio i: 35 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 705 Nm
AFH140-035-S3Frame: 140 | Ratio i: 35 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 705 Nm
AFH140-035-S4Frame: 140 | Ratio i: 35 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 705 Nm
AFH140-040-S1Frame: 140 | Ratio i: 40 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 615 Nm
AFH140-040-S2Frame: 140 | Ratio i: 40 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 615 Nm
AFH140-040-S3Frame: 140 | Ratio i: 40 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 615 Nm
AFH140-040-S4Frame: 140 | Ratio i: 40 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 615 Nm
AFH140-050-S1Frame: 140 | Ratio i: 50 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 715 Nm
AFH140-050-S2Frame: 140 | Ratio i: 50 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 715 Nm
AFH140-050-S3Frame: 140 | Ratio i: 50 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 715 Nm
AFH140-050-S4Frame: 140 | Ratio i: 50 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 715 Nm
AFH140-070-S1Frame: 140 | Ratio i: 70 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 585 Nm
AFH140-070-S2Frame: 140 | Ratio i: 70 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 585 Nm
AFH140-070-S3Frame: 140 | Ratio i: 70 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 585 Nm
AFH140-070-S4Frame: 140 | Ratio i: 70 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 585 Nm
AFH140-100-S1Frame: 140 | Ratio i: 100 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 345 Nm
AFH140-100-S2Frame: 140 | Ratio i: 100 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 345 Nm
AFH140-100-S3Frame: 140 | Ratio i: 100 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 345 Nm
AFH140-100-S4Frame: 140 | Ratio i: 100 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 345 Nm
AFH180-003-S1Frame: 180 | Ratio i: 3 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=1 arcmin | Nominal torque T2N: 1,560 Nm
AFH180-003-S2Frame: 180 | Ratio i: 3 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=1 arcmin | Nominal torque T2N: 1,560 Nm
AFH180-003-S3Frame: 180 | Ratio i: 3 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=1 arcmin | Nominal torque T2N: 1,560 Nm
AFH180-003-S4Frame: 180 | Ratio i: 3 | Stages: 1 | Output shaft: S4 hollow (shrink disc) | Backlash: <=1 arcmin | Nominal torque T2N: 1,560 Nm
AFH180-004-S1Frame: 180 | Ratio i: 4 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=1 arcmin | Nominal torque T2N: 1,415 Nm
AFH180-004-S2Frame: 180 | Ratio i: 4 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=1 arcmin | Nominal torque T2N: 1,415 Nm
AFH180-004-S3Frame: 180 | Ratio i: 4 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=1 arcmin | Nominal torque T2N: 1,415 Nm
AFH180-004-S4Frame: 180 | Ratio i: 4 | Stages: 1 | Output shaft: S4 hollow (shrink disc) | Backlash: <=1 arcmin | Nominal torque T2N: 1,415 Nm
AFH180-005-S1Frame: 180 | Ratio i: 5 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=1 arcmin | Nominal torque T2N: 1,225 Nm
AFH180-005-S2Frame: 180 | Ratio i: 5 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=1 arcmin | Nominal torque T2N: 1,225 Nm
AFH180-005-S3Frame: 180 | Ratio i: 5 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=1 arcmin | Nominal torque T2N: 1,225 Nm
AFH180-005-S4Frame: 180 | Ratio i: 5 | Stages: 1 | Output shaft: S4 hollow (shrink disc) | Backlash: <=1 arcmin | Nominal torque T2N: 1,225 Nm
AFH180-007-S1Frame: 180 | Ratio i: 7 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=1 arcmin | Nominal torque T2N: 980 Nm
AFH180-007-S2Frame: 180 | Ratio i: 7 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=1 arcmin | Nominal torque T2N: 980 Nm
AFH180-007-S3Frame: 180 | Ratio i: 7 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=1 arcmin | Nominal torque T2N: 980 Nm
AFH180-007-S4Frame: 180 | Ratio i: 7 | Stages: 1 | Output shaft: S4 hollow (shrink disc) | Backlash: <=1 arcmin | Nominal torque T2N: 980 Nm
AFH180-010-S1Frame: 180 | Ratio i: 10 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=1 arcmin | Nominal torque T2N: 700 Nm
AFH180-010-S2Frame: 180 | Ratio i: 10 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=1 arcmin | Nominal torque T2N: 700 Nm
AFH180-010-S3Frame: 180 | Ratio i: 10 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=1 arcmin | Nominal torque T2N: 700 Nm
AFH180-010-S4Frame: 180 | Ratio i: 10 | Stages: 1 | Output shaft: S4 hollow (shrink disc) | Backlash: <=1 arcmin | Nominal torque T2N: 700 Nm
AFH180-016-S1Frame: 180 | Ratio i: 16 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 1,485 Nm
AFH180-016-S2Frame: 180 | Ratio i: 16 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 1,485 Nm
AFH180-016-S3Frame: 180 | Ratio i: 16 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 1,485 Nm
AFH180-016-S4Frame: 180 | Ratio i: 16 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 1,485 Nm
AFH180-020-S1Frame: 180 | Ratio i: 20 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 1,495 Nm
AFH180-020-S2Frame: 180 | Ratio i: 20 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 1,495 Nm
AFH180-020-S3Frame: 180 | Ratio i: 20 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 1,495 Nm
AFH180-020-S4Frame: 180 | Ratio i: 20 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 1,495 Nm
AFH180-025-S1Frame: 180 | Ratio i: 25 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 1,295 Nm
AFH180-025-S2Frame: 180 | Ratio i: 25 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 1,295 Nm
AFH180-025-S3Frame: 180 | Ratio i: 25 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 1,295 Nm
AFH180-025-S4Frame: 180 | Ratio i: 25 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 1,295 Nm
AFH180-028-S1Frame: 180 | Ratio i: 28 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 1,510 Nm
AFH180-028-S2Frame: 180 | Ratio i: 28 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 1,510 Nm
AFH180-028-S3Frame: 180 | Ratio i: 28 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 1,510 Nm
AFH180-028-S4Frame: 180 | Ratio i: 28 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 1,510 Nm
AFH180-035-S1Frame: 180 | Ratio i: 35 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 1,310 Nm
AFH180-035-S2Frame: 180 | Ratio i: 35 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 1,310 Nm
AFH180-035-S3Frame: 180 | Ratio i: 35 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 1,310 Nm
AFH180-035-S4Frame: 180 | Ratio i: 35 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 1,310 Nm
AFH180-040-S1Frame: 180 | Ratio i: 40 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 1,260 Nm
AFH180-040-S2Frame: 180 | Ratio i: 40 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 1,260 Nm
AFH180-040-S3Frame: 180 | Ratio i: 40 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 1,260 Nm
AFH180-040-S4Frame: 180 | Ratio i: 40 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 1,260 Nm
AFH180-050-S1Frame: 180 | Ratio i: 50 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 1,325 Nm
AFH180-050-S2Frame: 180 | Ratio i: 50 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 1,325 Nm
AFH180-050-S3Frame: 180 | Ratio i: 50 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 1,325 Nm
AFH180-050-S4Frame: 180 | Ratio i: 50 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 1,325 Nm
AFH180-070-S1Frame: 180 | Ratio i: 70 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 1,095 Nm
AFH180-070-S2Frame: 180 | Ratio i: 70 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 1,095 Nm
AFH180-070-S3Frame: 180 | Ratio i: 70 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 1,095 Nm
AFH180-070-S4Frame: 180 | Ratio i: 70 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 1,095 Nm
AFH180-100-S1Frame: 180 | Ratio i: 100 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 660 Nm
AFH180-100-S2Frame: 180 | Ratio i: 100 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 660 Nm
AFH180-100-S3Frame: 180 | Ratio i: 100 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 660 Nm
AFH180-100-S4Frame: 180 | Ratio i: 100 | Stages: 2 | Output shaft: S4 hollow (shrink disc) | Backlash: <=2 arcmin | Nominal torque T2N: 660 Nm
AFH210-003-S1Frame: 210 | Ratio i: 3 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=1 arcmin | Nominal torque T2N: 2,465 Nm
AFH210-003-S2Frame: 210 | Ratio i: 3 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=1 arcmin | Nominal torque T2N: 2,465 Nm
AFH210-003-S3Frame: 210 | Ratio i: 3 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=1 arcmin | Nominal torque T2N: 2,465 Nm
AFH210-004-S1Frame: 210 | Ratio i: 4 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=1 arcmin | Nominal torque T2N: 2,190 Nm
AFH210-004-S2Frame: 210 | Ratio i: 4 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=1 arcmin | Nominal torque T2N: 2,190 Nm
AFH210-004-S3Frame: 210 | Ratio i: 4 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=1 arcmin | Nominal torque T2N: 2,190 Nm
AFH210-005-S1Frame: 210 | Ratio i: 5 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=1 arcmin | Nominal torque T2N: 1,905 Nm
AFH210-005-S2Frame: 210 | Ratio i: 5 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=1 arcmin | Nominal torque T2N: 1,905 Nm
AFH210-005-S3Frame: 210 | Ratio i: 5 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=1 arcmin | Nominal torque T2N: 1,905 Nm
AFH210-007-S1Frame: 210 | Ratio i: 7 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=1 arcmin | Nominal torque T2N: 1,530 Nm
AFH210-007-S2Frame: 210 | Ratio i: 7 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=1 arcmin | Nominal torque T2N: 1,530 Nm
AFH210-007-S3Frame: 210 | Ratio i: 7 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=1 arcmin | Nominal torque T2N: 1,530 Nm
AFH210-010-S1Frame: 210 | Ratio i: 10 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=1 arcmin | Nominal torque T2N: 1,070 Nm
AFH210-010-S2Frame: 210 | Ratio i: 10 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=1 arcmin | Nominal torque T2N: 1,070 Nm
AFH210-010-S3Frame: 210 | Ratio i: 10 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=1 arcmin | Nominal torque T2N: 1,070 Nm
AFH210-016-S1Frame: 210 | Ratio i: 16 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 2,295 Nm
AFH210-016-S2Frame: 210 | Ratio i: 16 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 2,295 Nm
AFH210-016-S3Frame: 210 | Ratio i: 16 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 2,295 Nm
AFH210-020-S1Frame: 210 | Ratio i: 20 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 2,310 Nm
AFH210-020-S2Frame: 210 | Ratio i: 20 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 2,310 Nm
AFH210-020-S3Frame: 210 | Ratio i: 20 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 2,310 Nm
AFH210-025-S1Frame: 210 | Ratio i: 25 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 2,005 Nm
AFH210-025-S2Frame: 210 | Ratio i: 25 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 2,005 Nm
AFH210-025-S3Frame: 210 | Ratio i: 25 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 2,005 Nm
AFH210-028-S1Frame: 210 | Ratio i: 28 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 2,335 Nm
AFH210-028-S2Frame: 210 | Ratio i: 28 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 2,335 Nm
AFH210-028-S3Frame: 210 | Ratio i: 28 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 2,335 Nm
AFH210-035-S1Frame: 210 | Ratio i: 35 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 2,030 Nm
AFH210-035-S2Frame: 210 | Ratio i: 35 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 2,030 Nm
AFH210-035-S3Frame: 210 | Ratio i: 35 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 2,030 Nm
AFH210-040-S1Frame: 210 | Ratio i: 40 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 2,360 Nm
AFH210-040-S2Frame: 210 | Ratio i: 40 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 2,360 Nm
AFH210-040-S3Frame: 210 | Ratio i: 40 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 2,360 Nm
AFH210-050-S1Frame: 210 | Ratio i: 50 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 2,050 Nm
AFH210-050-S2Frame: 210 | Ratio i: 50 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 2,050 Nm
AFH210-050-S3Frame: 210 | Ratio i: 50 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 2,050 Nm
AFH210-070-S1Frame: 210 | Ratio i: 70 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 1,670 Nm
AFH210-070-S2Frame: 210 | Ratio i: 70 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 1,670 Nm
AFH210-070-S3Frame: 210 | Ratio i: 70 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 1,670 Nm
AFH210-100-S1Frame: 210 | Ratio i: 100 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 1,005 Nm
AFH210-100-S2Frame: 210 | Ratio i: 100 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 1,005 Nm
AFH210-100-S3Frame: 210 | Ratio i: 100 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 1,005 Nm
AFH240-003-S1Frame: 240 | Ratio i: 3 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=1 arcmin | Nominal torque T2N: 4,360 Nm
AFH240-003-S2Frame: 240 | Ratio i: 3 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=1 arcmin | Nominal torque T2N: 4,360 Nm
AFH240-003-S3Frame: 240 | Ratio i: 3 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=1 arcmin | Nominal torque T2N: 4,360 Nm
AFH240-004-S1Frame: 240 | Ratio i: 4 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=1 arcmin | Nominal torque T2N: 4,035 Nm
AFH240-004-S2Frame: 240 | Ratio i: 4 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=1 arcmin | Nominal torque T2N: 4,035 Nm
AFH240-004-S3Frame: 240 | Ratio i: 4 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=1 arcmin | Nominal torque T2N: 4,035 Nm
AFH240-005-S1Frame: 240 | Ratio i: 5 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=1 arcmin | Nominal torque T2N: 3,505 Nm
AFH240-005-S2Frame: 240 | Ratio i: 5 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=1 arcmin | Nominal torque T2N: 3,505 Nm
AFH240-005-S3Frame: 240 | Ratio i: 5 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=1 arcmin | Nominal torque T2N: 3,505 Nm
AFH240-007-S1Frame: 240 | Ratio i: 7 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=1 arcmin | Nominal torque T2N: 2,630 Nm
AFH240-007-S2Frame: 240 | Ratio i: 7 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=1 arcmin | Nominal torque T2N: 2,630 Nm
AFH240-007-S3Frame: 240 | Ratio i: 7 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=1 arcmin | Nominal torque T2N: 2,630 Nm
AFH240-010-S1Frame: 240 | Ratio i: 10 | Stages: 1 | Output shaft: S1 smooth | Backlash: <=1 arcmin | Nominal torque T2N: 1,810 Nm
AFH240-010-S2Frame: 240 | Ratio i: 10 | Stages: 1 | Output shaft: S2 keyed | Backlash: <=1 arcmin | Nominal torque T2N: 1,810 Nm
AFH240-010-S3Frame: 240 | Ratio i: 10 | Stages: 1 | Output shaft: S3 DIN 5480 spline | Backlash: <=1 arcmin | Nominal torque T2N: 1,810 Nm
AFH240-016-S1Frame: 240 | Ratio i: 16 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 4,215 Nm
AFH240-016-S2Frame: 240 | Ratio i: 16 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 4,215 Nm
AFH240-016-S3Frame: 240 | Ratio i: 16 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 4,215 Nm
AFH240-020-S1Frame: 240 | Ratio i: 20 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 4,425 Nm
AFH240-020-S2Frame: 240 | Ratio i: 20 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 4,425 Nm
AFH240-020-S3Frame: 240 | Ratio i: 20 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 4,425 Nm
AFH240-025-S1Frame: 240 | Ratio i: 25 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 3,685 Nm
AFH240-025-S2Frame: 240 | Ratio i: 25 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 3,685 Nm
AFH240-025-S3Frame: 240 | Ratio i: 25 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 3,685 Nm
AFH240-028-S1Frame: 240 | Ratio i: 28 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 4,425 Nm
AFH240-028-S2Frame: 240 | Ratio i: 28 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 4,425 Nm
AFH240-028-S3Frame: 240 | Ratio i: 28 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 4,425 Nm
AFH240-035-S1Frame: 240 | Ratio i: 35 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 3,725 Nm
AFH240-035-S2Frame: 240 | Ratio i: 35 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 3,725 Nm
AFH240-035-S3Frame: 240 | Ratio i: 35 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 3,725 Nm
AFH240-040-S1Frame: 240 | Ratio i: 40 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 4,430 Nm
AFH240-040-S2Frame: 240 | Ratio i: 40 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 4,430 Nm
AFH240-040-S3Frame: 240 | Ratio i: 40 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 4,430 Nm
AFH240-050-S1Frame: 240 | Ratio i: 50 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 3,765 Nm
AFH240-050-S2Frame: 240 | Ratio i: 50 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 3,765 Nm
AFH240-050-S3Frame: 240 | Ratio i: 50 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 3,765 Nm
AFH240-070-S1Frame: 240 | Ratio i: 70 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 2,675 Nm
AFH240-070-S2Frame: 240 | Ratio i: 70 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 2,675 Nm
AFH240-070-S3Frame: 240 | Ratio i: 70 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 2,675 Nm
AFH240-100-S1Frame: 240 | Ratio i: 100 | Stages: 2 | Output shaft: S1 smooth | Backlash: <=2 arcmin | Nominal torque T2N: 1,700 Nm
AFH240-100-S2Frame: 240 | Ratio i: 100 | Stages: 2 | Output shaft: S2 keyed | Backlash: <=2 arcmin | Nominal torque T2N: 1,700 Nm
AFH240-100-S3Frame: 240 | Ratio i: 100 | Stages: 2 | Output shaft: S3 DIN 5480 spline | Backlash: <=2 arcmin | Nominal torque T2N: 1,700 Nm

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Motors & Gearheads →
