Apex Dynamics PFII Flange Planetary Gearboxes (070-120, i=3-1000)

Apex Dynamics PFII Flange Planetary Gearboxes (070-120, i=3-1000)

Apex Dynamics PFII inline planetary gearboxes with hollow flange output, frame sizes 070-120, ratios 3-100 plus 3-stage 120-1000 on sizes 070 and 090.

Key features

  • New Generation P series: economic, high efficiency, low noise, reduced backlash, compact and light
  • Flange output with H7 bore, frame sizes 070, 090 and 120
  • 3-stage ratios 120-1000 available on sizes 070 and 090
  • Ratios 3-10 (1-stage), 12-100 (2-stage) including i=9 and i=81; T2N 24-232 Nm
  • Efficiency >=97% (1-stage), >=94% (2-stage), >=91% (3-stage)
  • Motor adapter (input hub) matched to the servo motor; specify motor make and model when ordering

Specifications

Series PFII
Output Flange (H7 bore)
Emergency stop torque T2NOT 3 x T2N
Max. acceleration torque T2B 60% of T2NOT
Nominal input speed n1N 4,000 (070) to 3,600 (120) rpm
Max. input speed n1B 6,000 (070) to 4,800 (120) rpm
Torsional rigidity 2 to 12 Nm/arcmin
Efficiency >=97% / >=94% / >=91%
Protection IP65
Operating temperature 0 to +90 C
Source APEX Dynamics PII/PIIR catalog, p. 39-41
PFII070-003 Frame: 070 | Ratio i: 3 | Stages: 1 | Backlash: <=7 arcmin | Nominal torque T2N: 42 Nm
PFII070-004 Frame: 070 | Ratio i: 4 | Stages: 1 | Backlash: <=7 arcmin | Nominal torque T2N: 42 Nm
PFII070-005 Frame: 070 | Ratio i: 5 | Stages: 1 | Backlash: <=7 arcmin | Nominal torque T2N: 40 Nm
PFII070-007 Frame: 070 | Ratio i: 7 | Stages: 1 | Backlash: <=7 arcmin | Nominal torque T2N: 35 Nm
PFII070-009 Frame: 070 | Ratio i: 9 | Stages: 1 | Backlash: <=7 arcmin | Nominal torque T2N: 24 Nm
PFII070-010 Frame: 070 | Ratio i: 10 | Stages: 1 | Backlash: <=7 arcmin | Nominal torque T2N: 27 Nm
PFII070-012 Frame: 070 | Ratio i: 12 | Stages: 2 | Backlash: <=9 arcmin | Nominal torque T2N: 42 Nm
PFII070-015 Frame: 070 | Ratio i: 15 | Stages: 2 | Backlash: <=9 arcmin | Nominal torque T2N: 40 Nm
PFII070-016 Frame: 070 | Ratio i: 16 | Stages: 2 | Backlash: <=9 arcmin | Nominal torque T2N: 42 Nm
PFII070-020 Frame: 070 | Ratio i: 20 | Stages: 2 | Backlash: <=9 arcmin | Nominal torque T2N: 42 Nm
PFII070-025 Frame: 070 | Ratio i: 25 | Stages: 2 | Backlash: <=9 arcmin | Nominal torque T2N: 40 Nm
PFII070-030 Frame: 070 | Ratio i: 30 | Stages: 2 | Backlash: <=9 arcmin | Nominal torque T2N: 40 Nm
PFII070-035 Frame: 070 | Ratio i: 35 | Stages: 2 | Backlash: <=9 arcmin | Nominal torque T2N: 35 Nm
PFII070-040 Frame: 070 | Ratio i: 40 | Stages: 2 | Backlash: <=9 arcmin | Nominal torque T2N: 43 Nm
PFII070-050 Frame: 070 | Ratio i: 50 | Stages: 2 | Backlash: <=9 arcmin | Nominal torque T2N: 40 Nm
PFII070-070 Frame: 070 | Ratio i: 70 | Stages: 2 | Backlash: <=9 arcmin | Nominal torque T2N: 35 Nm
PFII070-081 Frame: 070 | Ratio i: 81 | Stages: 2 | Backlash: <=9 arcmin | Nominal torque T2N: 24 Nm
PFII070-100 Frame: 070 | Ratio i: 100 | Stages: 2 | Backlash: <=9 arcmin | Nominal torque T2N: 27 Nm
PFII070-120 Frame: 070 | Ratio i: 120 | Stages: 3 | Backlash: <=11 arcmin | Nominal torque T2N: 50 Nm
PFII070-160 Frame: 070 | Ratio i: 160 | Stages: 3 | Backlash: <=11 arcmin | Nominal torque T2N: 43 Nm
PFII070-200 Frame: 070 | Ratio i: 200 | Stages: 3 | Backlash: <=11 arcmin | Nominal torque T2N: 43 Nm
PFII070-280 Frame: 070 | Ratio i: 280 | Stages: 3 | Backlash: <=11 arcmin | Nominal torque T2N: 35 Nm
PFII070-350 Frame: 070 | Ratio i: 350 | Stages: 3 | Backlash: <=11 arcmin | Nominal torque T2N: 35 Nm
PFII070-500 Frame: 070 | Ratio i: 500 | Stages: 3 | Backlash: <=11 arcmin | Nominal torque T2N: 40 Nm
PFII070-700 Frame: 070 | Ratio i: 700 | Stages: 3 | Backlash: <=11 arcmin | Nominal torque T2N: 35 Nm
PFII070-1000 Frame: 070 | Ratio i: 1000 | Stages: 3 | Backlash: <=11 arcmin | Nominal torque T2N: 27 Nm
PFII090-003 Frame: 090 | Ratio i: 3 | Stages: 1 | Backlash: <=6 arcmin | Nominal torque T2N: 100 Nm
PFII090-004 Frame: 090 | Ratio i: 4 | Stages: 1 | Backlash: <=6 arcmin | Nominal torque T2N: 100 Nm
PFII090-005 Frame: 090 | Ratio i: 5 | Stages: 1 | Backlash: <=6 arcmin | Nominal torque T2N: 100 Nm
PFII090-007 Frame: 090 | Ratio i: 7 | Stages: 1 | Backlash: <=6 arcmin | Nominal torque T2N: 96 Nm
PFII090-009 Frame: 090 | Ratio i: 9 | Stages: 1 | Backlash: <=6 arcmin | Nominal torque T2N: 60 Nm
PFII090-010 Frame: 090 | Ratio i: 10 | Stages: 1 | Backlash: <=6 arcmin | Nominal torque T2N: 68 Nm
PFII090-012 Frame: 090 | Ratio i: 12 | Stages: 2 | Backlash: <=8 arcmin | Nominal torque T2N: 100 Nm
PFII090-015 Frame: 090 | Ratio i: 15 | Stages: 2 | Backlash: <=8 arcmin | Nominal torque T2N: 100 Nm
PFII090-016 Frame: 090 | Ratio i: 16 | Stages: 2 | Backlash: <=8 arcmin | Nominal torque T2N: 100 Nm
PFII090-020 Frame: 090 | Ratio i: 20 | Stages: 2 | Backlash: <=8 arcmin | Nominal torque T2N: 100 Nm
PFII090-025 Frame: 090 | Ratio i: 25 | Stages: 2 | Backlash: <=8 arcmin | Nominal torque T2N: 100 Nm
PFII090-030 Frame: 090 | Ratio i: 30 | Stages: 2 | Backlash: <=8 arcmin | Nominal torque T2N: 100 Nm
PFII090-035 Frame: 090 | Ratio i: 35 | Stages: 2 | Backlash: <=8 arcmin | Nominal torque T2N: 100 Nm
PFII090-040 Frame: 090 | Ratio i: 40 | Stages: 2 | Backlash: <=8 arcmin | Nominal torque T2N: 100 Nm
PFII090-050 Frame: 090 | Ratio i: 50 | Stages: 2 | Backlash: <=8 arcmin | Nominal torque T2N: 100 Nm
PFII090-070 Frame: 090 | Ratio i: 70 | Stages: 2 | Backlash: <=8 arcmin | Nominal torque T2N: 100 Nm
PFII090-081 Frame: 090 | Ratio i: 81 | Stages: 2 | Backlash: <=8 arcmin | Nominal torque T2N: 59 Nm
PFII090-100 Frame: 090 | Ratio i: 100 | Stages: 2 | Backlash: <=8 arcmin | Nominal torque T2N: 70 Nm
PFII090-120 Frame: 090 | Ratio i: 120 | Stages: 3 | Backlash: <=10 arcmin | Nominal torque T2N: 100 Nm
PFII090-160 Frame: 090 | Ratio i: 160 | Stages: 3 | Backlash: <=10 arcmin | Nominal torque T2N: 100 Nm
PFII090-200 Frame: 090 | Ratio i: 200 | Stages: 3 | Backlash: <=10 arcmin | Nominal torque T2N: 100 Nm
PFII090-280 Frame: 090 | Ratio i: 280 | Stages: 3 | Backlash: <=10 arcmin | Nominal torque T2N: 99 Nm
PFII090-350 Frame: 090 | Ratio i: 350 | Stages: 3 | Backlash: <=10 arcmin | Nominal torque T2N: 99 Nm
PFII090-500 Frame: 090 | Ratio i: 500 | Stages: 3 | Backlash: <=10 arcmin | Nominal torque T2N: 100 Nm
PFII090-700 Frame: 090 | Ratio i: 700 | Stages: 3 | Backlash: <=10 arcmin | Nominal torque T2N: 99 Nm
PFII090-1000 Frame: 090 | Ratio i: 1000 | Stages: 3 | Backlash: <=10 arcmin | Nominal torque T2N: 70 Nm
PFII120-003 Frame: 120 | Ratio i: 3 | Stages: 1 | Backlash: <=6 arcmin | Nominal torque T2N: 217 Nm
PFII120-004 Frame: 120 | Ratio i: 4 | Stages: 1 | Backlash: <=6 arcmin | Nominal torque T2N: 223 Nm
PFII120-005 Frame: 120 | Ratio i: 5 | Stages: 1 | Backlash: <=6 arcmin | Nominal torque T2N: 220 Nm
PFII120-007 Frame: 120 | Ratio i: 7 | Stages: 1 | Backlash: <=6 arcmin | Nominal torque T2N: 198 Nm
PFII120-009 Frame: 120 | Ratio i: 9 | Stages: 1 | Backlash: <=6 arcmin | Nominal torque T2N: 125 Nm
PFII120-010 Frame: 120 | Ratio i: 10 | Stages: 1 | Backlash: <=6 arcmin | Nominal torque T2N: 155 Nm
PFII120-012 Frame: 120 | Ratio i: 12 | Stages: 2 | Backlash: <=8 arcmin | Nominal torque T2N: 217 Nm
PFII120-015 Frame: 120 | Ratio i: 15 | Stages: 2 | Backlash: <=8 arcmin | Nominal torque T2N: 213 Nm
PFII120-016 Frame: 120 | Ratio i: 16 | Stages: 2 | Backlash: <=8 arcmin | Nominal torque T2N: 228 Nm
PFII120-020 Frame: 120 | Ratio i: 20 | Stages: 2 | Backlash: <=8 arcmin | Nominal torque T2N: 230 Nm
PFII120-025 Frame: 120 | Ratio i: 25 | Stages: 2 | Backlash: <=8 arcmin | Nominal torque T2N: 228 Nm
PFII120-030 Frame: 120 | Ratio i: 30 | Stages: 2 | Backlash: <=8 arcmin | Nominal torque T2N: 212 Nm
PFII120-035 Frame: 120 | Ratio i: 35 | Stages: 2 | Backlash: <=8 arcmin | Nominal torque T2N: 206 Nm
PFII120-040 Frame: 120 | Ratio i: 40 | Stages: 2 | Backlash: <=8 arcmin | Nominal torque T2N: 232 Nm
PFII120-050 Frame: 120 | Ratio i: 50 | Stages: 2 | Backlash: <=8 arcmin | Nominal torque T2N: 228 Nm
PFII120-070 Frame: 120 | Ratio i: 70 | Stages: 2 | Backlash: <=8 arcmin | Nominal torque T2N: 206 Nm
PFII120-081 Frame: 120 | Ratio i: 81 | Stages: 2 | Backlash: <=8 arcmin | Nominal torque T2N: 131 Nm
PFII120-100 Frame: 120 | Ratio i: 100 | Stages: 2 | Backlash: <=8 arcmin | Nominal torque T2N: 162 Nm
