Autonics AiC-D Series Closed-Loop Stepper Drivers w/ Controller

Autonics AiC-D Series Closed-Loop Stepper Drivers w/ Controller

The AiC-D series motors drivers are 2-phase closed loop stepper motor drivers with integrated controllers.

Key features

  • Closed loop system for precise real-time position control
  • High speed and high torque drive without missed steps
  • Motor driver + integrated controller type
  • Control up to 31 axes with RS-485 communication
  • Windows-based motion control software (atMotion) provided
  • 4 operation modes: jog, continuous, index, program

Specifications

Brand Autonics (Korea)
Series AiC-D
Driver Comm. specifications Modbus RTU
Driver Power supply 24VDC DC
Source Autonics official model list (autonics.com, AiC-D series page)
AiC-D-35MB Driver Max. Power: ≤ 60 W | Driver Max. Run Current: 1.2A/Phase
AiC-D-35SB Driver Max. Power: ≤ 60 W | Driver Max. Run Current: 1.2A/Phase
AiC-D-20MA Driver Max. Power: ≤ 60 W | Driver Max. Run Current: 0.6A/Phase
AiC-D-28MB Driver Max. Power: ≤ 60 W | Driver Max. Run Current: 1.0A/Phase
AiC-D-28SB Driver Max. Power: ≤ 60 W | Driver Max. Run Current: 1.0A/Phase
AiC-D-35LB Driver Max. Power: ≤ 60 W | Driver Max. Run Current: 1.2A/Phase
AiC-D-20LA Driver Max. Power: ≤ 60 W | Driver Max. Run Current: 0.6A/Phase
AiC-D-28LB Driver Max. Power: ≤ 60 W | Driver Max. Run Current: 1.0A/Phase
AiC-D-60LA-B Driver Max. Power: ≤ 240 W | Driver Max. Run Current: 3.5A/Phase
AiC-D-60MA-B Driver Max. Power: ≤ 240 W | Driver Max. Run Current: 3.5A/Phase
AiC-D-60SA-B Driver Max. Power: ≤ 240 W | Driver Max. Run Current: 3.5A/Phase
AiC-D-56LA-B Driver Max. Power: ≤ 120 W | Driver Max. Run Current: 3.5A/Phase
AiC-D-56MA-B Driver Max. Power: ≤ 120 W | Driver Max. Run Current: 3.5A/Phase
AiC-D-56SA-B Driver Max. Power: ≤ 120 W | Driver Max. Run Current: 3.5A/Phase
AiC-D-42LA-B Driver Max. Power: ≤ 60 W | Driver Max. Run Current: 1.7A/Phase
AiC-D-42MA-B Driver Max. Power: ≤ 60 W | Driver Max. Run Current: 1.7A/Phase
AiC-D-42SA-B Driver Max. Power: ≤ 60 W | Driver Max. Run Current: 1.7A/Phase
Closed-Loop Stepper SystemAutonics
17 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Autonics AiC-D Series Closed-Loop Stepper Drivers w/ Controller

Brand Autonics·Closed-Loop Stepper System

Available part numbers (17)

AiC-D-35MB, AiC-D-35SB, AiC-D-20MA, AiC-D-28MB, AiC-D-28SB, AiC-D-35LB, AiC-D-20LA, AiC-D-28LB, AiC-D-60LA-B, AiC-D-60MA-B + 7 more — see full table ↓

How to order

Send the Autonics part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
AiC-D-35MBDriver Max. Power: ≤ 60 W | Driver Max. Run Current: 1.2A/Phase
AiC-D-35SBDriver Max. Power: ≤ 60 W | Driver Max. Run Current: 1.2A/Phase
AiC-D-20MADriver Max. Power: ≤ 60 W | Driver Max. Run Current: 0.6A/Phase
AiC-D-28MBDriver Max. Power: ≤ 60 W | Driver Max. Run Current: 1.0A/Phase
AiC-D-28SBDriver Max. Power: ≤ 60 W | Driver Max. Run Current: 1.0A/Phase
AiC-D-35LBDriver Max. Power: ≤ 60 W | Driver Max. Run Current: 1.2A/Phase
AiC-D-20LADriver Max. Power: ≤ 60 W | Driver Max. Run Current: 0.6A/Phase
AiC-D-28LBDriver Max. Power: ≤ 60 W | Driver Max. Run Current: 1.0A/Phase
AiC-D-60LA-BDriver Max. Power: ≤ 240 W | Driver Max. Run Current: 3.5A/Phase
AiC-D-60MA-BDriver Max. Power: ≤ 240 W | Driver Max. Run Current: 3.5A/Phase
AiC-D-60SA-BDriver Max. Power: ≤ 240 W | Driver Max. Run Current: 3.5A/Phase
AiC-D-56LA-BDriver Max. Power: ≤ 120 W | Driver Max. Run Current: 3.5A/Phase
AiC-D-56MA-BDriver Max. Power: ≤ 120 W | Driver Max. Run Current: 3.5A/Phase
AiC-D-56SA-BDriver Max. Power: ≤ 120 W | Driver Max. Run Current: 3.5A/Phase
AiC-D-42LA-BDriver Max. Power: ≤ 60 W | Driver Max. Run Current: 1.7A/Phase
AiC-D-42MA-BDriver Max. Power: ≤ 60 W | Driver Max. Run Current: 1.7A/Phase
AiC-D-42SA-BDriver Max. Power: ≤ 60 W | Driver Max. Run Current: 1.7A/Phase
