CKD ETS-650P Multi-Axis Actuator (X-Z)

CKD ETS-650P Multi-Axis Actuator (X-Z)

CKD ETS-650P motorless X-Z 2-Axis combination of ETS ball-screw sliders, listed with full order codes by combination direction and both axis strokes.

Key features

  • Pre-engineered 2-axis X-Z combination: 1st axis ETS-14 (lead 20, 400W, built-in), 2nd axis ETS-13 (lead 10, 200W, built-in, brake)
  • 1st-axis stroke 100-1050 mm, 2nd-axis stroke 50-550 mm, both in 50 mm steps
  • Combination directions P1, P2 set motor and grease-nipple orientation
  • Codes shown with motor flange spec M; replace with Y (Yaskawa/Keyence), P (Panasonic) or O (Omron) as required
  • Brake on the 2nd (vertical) axis is standard (B); home/limit sensors (3 per axis) available by changing the last symbol from N to W
  • Cable carrier assemblies, combination brackets are listed under the ETS Multi-Axis combination parts

Specifications

Series ETS Multi-Axis
Combination Model ETS-650P
Combination Type P: X-Z
1st Axis ETS-14 (lead 20, 400W, built-in)
2nd Axis ETS-13 (lead 10, 200W, built-in, brake)
Motor Flange Spec (in code) M
Brake (in code) B (2nd axis)
Origin/Limit Sensor (in code) N (none); W = with sensors
Compliance RoHS
Source CKD Korea catalog CB-055K, p. 228-229, 230-233
ETS-650P1-010005-MBN Combination Direction: P1 | 1st-Axis Stroke: 100 mm | 2nd-Axis Stroke: 50 mm
ETS-650P1-010010-MBN Combination Direction: P1 | 1st-Axis Stroke: 100 mm | 2nd-Axis Stroke: 100 mm
ETS-650P1-010015-MBN Combination Direction: P1 | 1st-Axis Stroke: 100 mm | 2nd-Axis Stroke: 150 mm
ETS-650P1-010020-MBN Combination Direction: P1 | 1st-Axis Stroke: 100 mm | 2nd-Axis Stroke: 200 mm
ETS-650P1-010025-MBN Combination Direction: P1 | 1st-Axis Stroke: 100 mm | 2nd-Axis Stroke: 250 mm
ETS-650P1-010030-MBN Combination Direction: P1 | 1st-Axis Stroke: 100 mm | 2nd-Axis Stroke: 300 mm
ETS-650P1-010035-MBN Combination Direction: P1 | 1st-Axis Stroke: 100 mm | 2nd-Axis Stroke: 350 mm
ETS-650P1-010040-MBN Combination Direction: P1 | 1st-Axis Stroke: 100 mm | 2nd-Axis Stroke: 400 mm
ETS-650P1-010045-MBN Combination Direction: P1 | 1st-Axis Stroke: 100 mm | 2nd-Axis Stroke: 450 mm
ETS-650P1-010050-MBN Combination Direction: P1 | 1st-Axis Stroke: 100 mm | 2nd-Axis Stroke: 500 mm
ETS-650P1-010055-MBN Combination Direction: P1 | 1st-Axis Stroke: 100 mm | 2nd-Axis Stroke: 550 mm
ETS-650P1-015005-MBN Combination Direction: P1 | 1st-Axis Stroke: 150 mm | 2nd-Axis Stroke: 50 mm
ETS-650P1-015010-MBN Combination Direction: P1 | 1st-Axis Stroke: 150 mm | 2nd-Axis Stroke: 100 mm
ETS-650P1-015015-MBN Combination Direction: P1 | 1st-Axis Stroke: 150 mm | 2nd-Axis Stroke: 150 mm
ETS-650P1-015020-MBN Combination Direction: P1 | 1st-Axis Stroke: 150 mm | 2nd-Axis Stroke: 200 mm
ETS-650P1-015025-MBN Combination Direction: P1 | 1st-Axis Stroke: 150 mm | 2nd-Axis Stroke: 250 mm
ETS-650P1-015030-MBN Combination Direction: P1 | 1st-Axis Stroke: 150 mm | 2nd-Axis Stroke: 300 mm
ETS-650P1-015035-MBN Combination Direction: P1 | 1st-Axis Stroke: 150 mm | 2nd-Axis Stroke: 350 mm
ETS-650P1-015040-MBN Combination Direction: P1 | 1st-Axis Stroke: 150 mm | 2nd-Axis Stroke: 400 mm
ETS-650P1-015045-MBN Combination Direction: P1 | 1st-Axis Stroke: 150 mm | 2nd-Axis Stroke: 450 mm
ETS-650P1-015050-MBN Combination Direction: P1 | 1st-Axis Stroke: 150 mm | 2nd-Axis Stroke: 500 mm
ETS-650P1-015055-MBN Combination Direction: P1 | 1st-Axis Stroke: 150 mm | 2nd-Axis Stroke: 550 mm
ETS-650P1-020005-MBN Combination Direction: P1 | 1st-Axis Stroke: 200 mm | 2nd-Axis Stroke: 50 mm
ETS-650P1-020010-MBN Combination Direction: P1 | 1st-Axis Stroke: 200 mm | 2nd-Axis Stroke: 100 mm
ETS-650P1-020015-MBN Combination Direction: P1 | 1st-Axis Stroke: 200 mm | 2nd-Axis Stroke: 150 mm
ETS-650P1-020020-MBN Combination Direction: P1 | 1st-Axis Stroke: 200 mm | 2nd-Axis Stroke: 200 mm
ETS-650P1-020025-MBN Combination Direction: P1 | 1st-Axis Stroke: 200 mm | 2nd-Axis Stroke: 250 mm
ETS-650P1-020030-MBN Combination Direction: P1 | 1st-Axis Stroke: 200 mm | 2nd-Axis Stroke: 300 mm
ETS-650P1-020035-MBN Combination Direction: P1 | 1st-Axis Stroke: 200 mm | 2nd-Axis Stroke: 350 mm
ETS-650P1-020040-MBN Combination Direction: P1 | 1st-Axis Stroke: 200 mm | 2nd-Axis Stroke: 400 mm
ETS-650P1-020045-MBN Combination Direction: P1 | 1st-Axis Stroke: 200 mm | 2nd-Axis Stroke: 450 mm
ETS-650P1-020050-MBN Combination Direction: P1 | 1st-Axis Stroke: 200 mm | 2nd-Axis Stroke: 500 mm
ETS-650P1-020055-MBN Combination Direction: P1 | 1st-Axis Stroke: 200 mm | 2nd-Axis Stroke: 550 mm
ETS-650P1-025005-MBN Combination Direction: P1 | 1st-Axis Stroke: 250 mm | 2nd-Axis Stroke: 50 mm
ETS-650P1-025010-MBN Combination Direction: P1 | 1st-Axis Stroke: 250 mm | 2nd-Axis Stroke: 100 mm
ETS-650P1-025015-MBN Combination Direction: P1 | 1st-Axis Stroke: 250 mm | 2nd-Axis Stroke: 150 mm
ETS-650P1-025020-MBN Combination Direction: P1 | 1st-Axis Stroke: 250 mm | 2nd-Axis Stroke: 200 mm
ETS-650P1-025025-MBN Combination Direction: P1 | 1st-Axis Stroke: 250 mm | 2nd-Axis Stroke: 250 mm
ETS-650P1-025030-MBN Combination Direction: P1 | 1st-Axis Stroke: 250 mm | 2nd-Axis Stroke: 300 mm
ETS-650P1-025035-MBN Combination Direction: P1 | 1st-Axis Stroke: 250 mm | 2nd-Axis Stroke: 350 mm
ETS-650P1-025040-MBN Combination Direction: P1 | 1st-Axis Stroke: 250 mm | 2nd-Axis Stroke: 400 mm
ETS-650P1-025045-MBN Combination Direction: P1 | 1st-Axis Stroke: 250 mm | 2nd-Axis Stroke: 450 mm
ETS-650P1-025050-MBN Combination Direction: P1 | 1st-Axis Stroke: 250 mm | 2nd-Axis Stroke: 500 mm
ETS-650P1-025055-MBN Combination Direction: P1 | 1st-Axis Stroke: 250 mm | 2nd-Axis Stroke: 550 mm
ETS-650P1-030005-MBN Combination Direction: P1 | 1st-Axis Stroke: 300 mm | 2nd-Axis Stroke: 50 mm
ETS-650P1-030010-MBN Combination Direction: P1 | 1st-Axis Stroke: 300 mm | 2nd-Axis Stroke: 100 mm
ETS-650P1-030015-MBN Combination Direction: P1 | 1st-Axis Stroke: 300 mm | 2nd-Axis Stroke: 150 mm
ETS-650P1-030020-MBN Combination Direction: P1 | 1st-Axis Stroke: 300 mm | 2nd-Axis Stroke: 200 mm
ETS-650P1-030025-MBN Combination Direction: P1 | 1st-Axis Stroke: 300 mm | 2nd-Axis Stroke: 250 mm
ETS-650P1-030030-MBN Combination Direction: P1 | 1st-Axis Stroke: 300 mm | 2nd-Axis Stroke: 300 mm
ETS-650P1-030035-MBN Combination Direction: P1 | 1st-Axis Stroke: 300 mm | 2nd-Axis Stroke: 350 mm
ETS-650P1-030040-MBN Combination Direction: P1 | 1st-Axis Stroke: 300 mm | 2nd-Axis Stroke: 400 mm
ETS-650P1-030045-MBN Combination Direction: P1 | 1st-Axis Stroke: 300 mm | 2nd-Axis Stroke: 450 mm
ETS-650P1-030050-MBN Combination Direction: P1 | 1st-Axis Stroke: 300 mm | 2nd-Axis Stroke: 500 mm
ETS-650P1-030055-MBN Combination Direction: P1 | 1st-Axis Stroke: 300 mm | 2nd-Axis Stroke: 550 mm
ETS-650P1-035005-MBN Combination Direction: P1 | 1st-Axis Stroke: 350 mm | 2nd-Axis Stroke: 50 mm
ETS-650P1-035010-MBN Combination Direction: P1 | 1st-Axis Stroke: 350 mm | 2nd-Axis Stroke: 100 mm
ETS-650P1-035015-MBN Combination Direction: P1 | 1st-Axis Stroke: 350 mm | 2nd-Axis Stroke: 150 mm
ETS-650P1-035020-MBN Combination Direction: P1 | 1st-Axis Stroke: 350 mm | 2nd-Axis Stroke: 200 mm
ETS-650P1-035025-MBN Combination Direction: P1 | 1st-Axis Stroke: 350 mm | 2nd-Axis Stroke: 250 mm
ETS-650P1-035030-MBN Combination Direction: P1 | 1st-Axis Stroke: 350 mm | 2nd-Axis Stroke: 300 mm
ETS-650P1-035035-MBN Combination Direction: P1 | 1st-Axis Stroke: 350 mm | 2nd-Axis Stroke: 350 mm
ETS-650P1-035040-MBN Combination Direction: P1 | 1st-Axis Stroke: 350 mm | 2nd-Axis Stroke: 400 mm
ETS-650P1-035045-MBN Combination Direction: P1 | 1st-Axis Stroke: 350 mm | 2nd-Axis Stroke: 450 mm
ETS-650P1-035050-MBN Combination Direction: P1 | 1st-Axis Stroke: 350 mm | 2nd-Axis Stroke: 500 mm
ETS-650P1-035055-MBN Combination Direction: P1 | 1st-Axis Stroke: 350 mm | 2nd-Axis Stroke: 550 mm
ETS-650P1-040005-MBN Combination Direction: P1 | 1st-Axis Stroke: 400 mm | 2nd-Axis Stroke: 50 mm
ETS-650P1-040010-MBN Combination Direction: P1 | 1st-Axis Stroke: 400 mm | 2nd-Axis Stroke: 100 mm
ETS-650P1-040015-MBN Combination Direction: P1 | 1st-Axis Stroke: 400 mm | 2nd-Axis Stroke: 150 mm
ETS-650P1-040020-MBN Combination Direction: P1 | 1st-Axis Stroke: 400 mm | 2nd-Axis Stroke: 200 mm
ETS-650P1-040025-MBN Combination Direction: P1 | 1st-Axis Stroke: 400 mm | 2nd-Axis Stroke: 250 mm
ETS-650P1-040030-MBN Combination Direction: P1 | 1st-Axis Stroke: 400 mm | 2nd-Axis Stroke: 300 mm
ETS-650P1-040035-MBN Combination Direction: P1 | 1st-Axis Stroke: 400 mm | 2nd-Axis Stroke: 350 mm
ETS-650P1-040040-MBN Combination Direction: P1 | 1st-Axis Stroke: 400 mm | 2nd-Axis Stroke: 400 mm
ETS-650P1-040045-MBN Combination Direction: P1 | 1st-Axis Stroke: 400 mm | 2nd-Axis Stroke: 450 mm
ETS-650P1-040050-MBN Combination Direction: P1 | 1st-Axis Stroke: 400 mm | 2nd-Axis Stroke: 500 mm
ETS-650P1-040055-MBN Combination Direction: P1 | 1st-Axis Stroke: 400 mm | 2nd-Axis Stroke: 550 mm
ETS-650P1-045005-MBN Combination Direction: P1 | 1st-Axis Stroke: 450 mm | 2nd-Axis Stroke: 50 mm
ETS-650P1-045010-MBN Combination Direction: P1 | 1st-Axis Stroke: 450 mm | 2nd-Axis Stroke: 100 mm
ETS-650P1-045015-MBN Combination Direction: P1 | 1st-Axis Stroke: 450 mm | 2nd-Axis Stroke: 150 mm
ETS-650P1-045020-MBN Combination Direction: P1 | 1st-Axis Stroke: 450 mm | 2nd-Axis Stroke: 200 mm
ETS-650P1-045025-MBN Combination Direction: P1 | 1st-Axis Stroke: 450 mm | 2nd-Axis Stroke: 250 mm
ETS-650P1-045030-MBN Combination Direction: P1 | 1st-Axis Stroke: 450 mm | 2nd-Axis Stroke: 300 mm
ETS-650P1-045035-MBN Combination Direction: P1 | 1st-Axis Stroke: 450 mm | 2nd-Axis Stroke: 350 mm
ETS-650P1-045040-MBN Combination Direction: P1 | 1st-Axis Stroke: 450 mm | 2nd-Axis Stroke: 400 mm
ETS-650P1-045045-MBN Combination Direction: P1 | 1st-Axis Stroke: 450 mm | 2nd-Axis Stroke: 450 mm
ETS-650P1-045050-MBN Combination Direction: P1 | 1st-Axis Stroke: 450 mm | 2nd-Axis Stroke: 500 mm
ETS-650P1-045055-MBN Combination Direction: P1 | 1st-Axis Stroke: 450 mm | 2nd-Axis Stroke: 550 mm
ETS-650P1-050005-MBN Combination Direction: P1 | 1st-Axis Stroke: 500 mm | 2nd-Axis Stroke: 50 mm
ETS-650P1-050010-MBN Combination Direction: P1 | 1st-Axis Stroke: 500 mm | 2nd-Axis Stroke: 100 mm
ETS-650P1-050015-MBN Combination Direction: P1 | 1st-Axis Stroke: 500 mm | 2nd-Axis Stroke: 150 mm
ETS-650P1-050020-MBN Combination Direction: P1 | 1st-Axis Stroke: 500 mm | 2nd-Axis Stroke: 200 mm
ETS-650P1-050025-MBN Combination Direction: P1 | 1st-Axis Stroke: 500 mm | 2nd-Axis Stroke: 250 mm
ETS-650P1-050030-MBN Combination Direction: P1 | 1st-Axis Stroke: 500 mm | 2nd-Axis Stroke: 300 mm
ETS-650P1-050035-MBN Combination Direction: P1 | 1st-Axis Stroke: 500 mm | 2nd-Axis Stroke: 350 mm
ETS-650P1-050040-MBN Combination Direction: P1 | 1st-Axis Stroke: 500 mm | 2nd-Axis Stroke: 400 mm
ETS-650P1-050045-MBN Combination Direction: P1 | 1st-Axis Stroke: 500 mm | 2nd-Axis Stroke: 450 mm
ETS-650P1-050050-MBN Combination Direction: P1 | 1st-Axis Stroke: 500 mm | 2nd-Axis Stroke: 500 mm
ETS-650P1-050055-MBN Combination Direction: P1 | 1st-Axis Stroke: 500 mm | 2nd-Axis Stroke: 550 mm
ETS-650P1-055005-MBN Combination Direction: P1 | 1st-Axis Stroke: 550 mm | 2nd-Axis Stroke: 50 mm
ETS-650P1-055010-MBN Combination Direction: P1 | 1st-Axis Stroke: 550 mm | 2nd-Axis Stroke: 100 mm
ETS-650P1-055015-MBN Combination Direction: P1 | 1st-Axis Stroke: 550 mm | 2nd-Axis Stroke: 150 mm
ETS-650P1-055020-MBN Combination Direction: P1 | 1st-Axis Stroke: 550 mm | 2nd-Axis Stroke: 200 mm
ETS-650P1-055025-MBN Combination Direction: P1 | 1st-Axis Stroke: 550 mm | 2nd-Axis Stroke: 250 mm
ETS-650P1-055030-MBN Combination Direction: P1 | 1st-Axis Stroke: 550 mm | 2nd-Axis Stroke: 300 mm
ETS-650P1-055035-MBN Combination Direction: P1 | 1st-Axis Stroke: 550 mm | 2nd-Axis Stroke: 350 mm
ETS-650P1-055040-MBN Combination Direction: P1 | 1st-Axis Stroke: 550 mm | 2nd-Axis Stroke: 400 mm
ETS-650P1-055045-MBN Combination Direction: P1 | 1st-Axis Stroke: 550 mm | 2nd-Axis Stroke: 450 mm
ETS-650P1-055050-MBN Combination Direction: P1 | 1st-Axis Stroke: 550 mm | 2nd-Axis Stroke: 500 mm
ETS-650P1-055055-MBN Combination Direction: P1 | 1st-Axis Stroke: 550 mm | 2nd-Axis Stroke: 550 mm
ETS-650P1-060005-MBN Combination Direction: P1 | 1st-Axis Stroke: 600 mm | 2nd-Axis Stroke: 50 mm
ETS-650P1-060010-MBN Combination Direction: P1 | 1st-Axis Stroke: 600 mm | 2nd-Axis Stroke: 100 mm
ETS-650P1-060015-MBN Combination Direction: P1 | 1st-Axis Stroke: 600 mm | 2nd-Axis Stroke: 150 mm
ETS-650P1-060020-MBN Combination Direction: P1 | 1st-Axis Stroke: 600 mm | 2nd-Axis Stroke: 200 mm
ETS-650P1-060025-MBN Combination Direction: P1 | 1st-Axis Stroke: 600 mm | 2nd-Axis Stroke: 250 mm
ETS-650P1-060030-MBN Combination Direction: P1 | 1st-Axis Stroke: 600 mm | 2nd-Axis Stroke: 300 mm
ETS-650P1-060035-MBN Combination Direction: P1 | 1st-Axis Stroke: 600 mm | 2nd-Axis Stroke: 350 mm
ETS-650P1-060040-MBN Combination Direction: P1 | 1st-Axis Stroke: 600 mm | 2nd-Axis Stroke: 400 mm
ETS-650P1-060045-MBN Combination Direction: P1 | 1st-Axis Stroke: 600 mm | 2nd-Axis Stroke: 450 mm
ETS-650P1-060050-MBN Combination Direction: P1 | 1st-Axis Stroke: 600 mm | 2nd-Axis Stroke: 500 mm
ETS-650P1-060055-MBN Combination Direction: P1 | 1st-Axis Stroke: 600 mm | 2nd-Axis Stroke: 550 mm
ETS-650P1-065005-MBN Combination Direction: P1 | 1st-Axis Stroke: 650 mm | 2nd-Axis Stroke: 50 mm
ETS-650P1-065010-MBN Combination Direction: P1 | 1st-Axis Stroke: 650 mm | 2nd-Axis Stroke: 100 mm
ETS-650P1-065015-MBN Combination Direction: P1 | 1st-Axis Stroke: 650 mm | 2nd-Axis Stroke: 150 mm
ETS-650P1-065020-MBN Combination Direction: P1 | 1st-Axis Stroke: 650 mm | 2nd-Axis Stroke: 200 mm
ETS-650P1-065025-MBN Combination Direction: P1 | 1st-Axis Stroke: 650 mm | 2nd-Axis Stroke: 250 mm
ETS-650P1-065030-MBN Combination Direction: P1 | 1st-Axis Stroke: 650 mm | 2nd-Axis Stroke: 300 mm
ETS-650P1-065035-MBN Combination Direction: P1 | 1st-Axis Stroke: 650 mm | 2nd-Axis Stroke: 350 mm
ETS-650P1-065040-MBN Combination Direction: P1 | 1st-Axis Stroke: 650 mm | 2nd-Axis Stroke: 400 mm
ETS-650P1-065045-MBN Combination Direction: P1 | 1st-Axis Stroke: 650 mm | 2nd-Axis Stroke: 450 mm
ETS-650P1-065050-MBN Combination Direction: P1 | 1st-Axis Stroke: 650 mm | 2nd-Axis Stroke: 500 mm
ETS-650P1-065055-MBN Combination Direction: P1 | 1st-Axis Stroke: 650 mm | 2nd-Axis Stroke: 550 mm
ETS-650P1-070005-MBN Combination Direction: P1 | 1st-Axis Stroke: 700 mm | 2nd-Axis Stroke: 50 mm
ETS-650P1-070010-MBN Combination Direction: P1 | 1st-Axis Stroke: 700 mm | 2nd-Axis Stroke: 100 mm
ETS-650P1-070015-MBN Combination Direction: P1 | 1st-Axis Stroke: 700 mm | 2nd-Axis Stroke: 150 mm
ETS-650P1-070020-MBN Combination Direction: P1 | 1st-Axis Stroke: 700 mm | 2nd-Axis Stroke: 200 mm
ETS-650P1-070025-MBN Combination Direction: P1 | 1st-Axis Stroke: 700 mm | 2nd-Axis Stroke: 250 mm
ETS-650P1-070030-MBN Combination Direction: P1 | 1st-Axis Stroke: 700 mm | 2nd-Axis Stroke: 300 mm
ETS-650P1-070035-MBN Combination Direction: P1 | 1st-Axis Stroke: 700 mm | 2nd-Axis Stroke: 350 mm
ETS-650P1-070040-MBN Combination Direction: P1 | 1st-Axis Stroke: 700 mm | 2nd-Axis Stroke: 400 mm
ETS-650P1-070045-MBN Combination Direction: P1 | 1st-Axis Stroke: 700 mm | 2nd-Axis Stroke: 450 mm
ETS-650P1-070050-MBN Combination Direction: P1 | 1st-Axis Stroke: 700 mm | 2nd-Axis Stroke: 500 mm
ETS-650P1-070055-MBN Combination Direction: P1 | 1st-Axis Stroke: 700 mm | 2nd-Axis Stroke: 550 mm
ETS-650P1-075005-MBN Combination Direction: P1 | 1st-Axis Stroke: 750 mm | 2nd-Axis Stroke: 50 mm
ETS-650P1-075010-MBN Combination Direction: P1 | 1st-Axis Stroke: 750 mm | 2nd-Axis Stroke: 100 mm
ETS-650P1-075015-MBN Combination Direction: P1 | 1st-Axis Stroke: 750 mm | 2nd-Axis Stroke: 150 mm
ETS-650P1-075020-MBN Combination Direction: P1 | 1st-Axis Stroke: 750 mm | 2nd-Axis Stroke: 200 mm
ETS-650P1-075025-MBN Combination Direction: P1 | 1st-Axis Stroke: 750 mm | 2nd-Axis Stroke: 250 mm
ETS-650P1-075030-MBN Combination Direction: P1 | 1st-Axis Stroke: 750 mm | 2nd-Axis Stroke: 300 mm
ETS-650P1-075035-MBN Combination Direction: P1 | 1st-Axis Stroke: 750 mm | 2nd-Axis Stroke: 350 mm
ETS-650P1-075040-MBN Combination Direction: P1 | 1st-Axis Stroke: 750 mm | 2nd-Axis Stroke: 400 mm
ETS-650P1-075045-MBN Combination Direction: P1 | 1st-Axis Stroke: 750 mm | 2nd-Axis Stroke: 450 mm
ETS-650P1-075050-MBN Combination Direction: P1 | 1st-Axis Stroke: 750 mm | 2nd-Axis Stroke: 500 mm
ETS-650P1-075055-MBN Combination Direction: P1 | 1st-Axis Stroke: 750 mm | 2nd-Axis Stroke: 550 mm
ETS-650P1-080005-MBN Combination Direction: P1 | 1st-Axis Stroke: 800 mm | 2nd-Axis Stroke: 50 mm
ETS-650P1-080010-MBN Combination Direction: P1 | 1st-Axis Stroke: 800 mm | 2nd-Axis Stroke: 100 mm
ETS-650P1-080015-MBN Combination Direction: P1 | 1st-Axis Stroke: 800 mm | 2nd-Axis Stroke: 150 mm
ETS-650P1-080020-MBN Combination Direction: P1 | 1st-Axis Stroke: 800 mm | 2nd-Axis Stroke: 200 mm
ETS-650P1-080025-MBN Combination Direction: P1 | 1st-Axis Stroke: 800 mm | 2nd-Axis Stroke: 250 mm
ETS-650P1-080030-MBN Combination Direction: P1 | 1st-Axis Stroke: 800 mm | 2nd-Axis Stroke: 300 mm
ETS-650P1-080035-MBN Combination Direction: P1 | 1st-Axis Stroke: 800 mm | 2nd-Axis Stroke: 350 mm
ETS-650P1-080040-MBN Combination Direction: P1 | 1st-Axis Stroke: 800 mm | 2nd-Axis Stroke: 400 mm
ETS-650P1-080045-MBN Combination Direction: P1 | 1st-Axis Stroke: 800 mm | 2nd-Axis Stroke: 450 mm
ETS-650P1-080050-MBN Combination Direction: P1 | 1st-Axis Stroke: 800 mm | 2nd-Axis Stroke: 500 mm
ETS-650P1-080055-MBN Combination Direction: P1 | 1st-Axis Stroke: 800 mm | 2nd-Axis Stroke: 550 mm
ETS-650P1-085005-MBN Combination Direction: P1 | 1st-Axis Stroke: 850 mm | 2nd-Axis Stroke: 50 mm
ETS-650P1-085010-MBN Combination Direction: P1 | 1st-Axis Stroke: 850 mm | 2nd-Axis Stroke: 100 mm
ETS-650P1-085015-MBN Combination Direction: P1 | 1st-Axis Stroke: 850 mm | 2nd-Axis Stroke: 150 mm
ETS-650P1-085020-MBN Combination Direction: P1 | 1st-Axis Stroke: 850 mm | 2nd-Axis Stroke: 200 mm
ETS-650P1-085025-MBN Combination Direction: P1 | 1st-Axis Stroke: 850 mm | 2nd-Axis Stroke: 250 mm
ETS-650P1-085030-MBN Combination Direction: P1 | 1st-Axis Stroke: 850 mm | 2nd-Axis Stroke: 300 mm
ETS-650P1-085035-MBN Combination Direction: P1 | 1st-Axis Stroke: 850 mm | 2nd-Axis Stroke: 350 mm
ETS-650P1-085040-MBN Combination Direction: P1 | 1st-Axis Stroke: 850 mm | 2nd-Axis Stroke: 400 mm
ETS-650P1-085045-MBN Combination Direction: P1 | 1st-Axis Stroke: 850 mm | 2nd-Axis Stroke: 450 mm
ETS-650P1-085050-MBN Combination Direction: P1 | 1st-Axis Stroke: 850 mm | 2nd-Axis Stroke: 500 mm
ETS-650P1-085055-MBN Combination Direction: P1 | 1st-Axis Stroke: 850 mm | 2nd-Axis Stroke: 550 mm
ETS-650P1-090005-MBN Combination Direction: P1 | 1st-Axis Stroke: 900 mm | 2nd-Axis Stroke: 50 mm
ETS-650P1-090010-MBN Combination Direction: P1 | 1st-Axis Stroke: 900 mm | 2nd-Axis Stroke: 100 mm
ETS-650P1-090015-MBN Combination Direction: P1 | 1st-Axis Stroke: 900 mm | 2nd-Axis Stroke: 150 mm
ETS-650P1-090020-MBN Combination Direction: P1 | 1st-Axis Stroke: 900 mm | 2nd-Axis Stroke: 200 mm
ETS-650P1-090025-MBN Combination Direction: P1 | 1st-Axis Stroke: 900 mm | 2nd-Axis Stroke: 250 mm
ETS-650P1-090030-MBN Combination Direction: P1 | 1st-Axis Stroke: 900 mm | 2nd-Axis Stroke: 300 mm
ETS-650P1-090035-MBN Combination Direction: P1 | 1st-Axis Stroke: 900 mm | 2nd-Axis Stroke: 350 mm
ETS-650P1-090040-MBN Combination Direction: P1 | 1st-Axis Stroke: 900 mm | 2nd-Axis Stroke: 400 mm
ETS-650P1-090045-MBN Combination Direction: P1 | 1st-Axis Stroke: 900 mm | 2nd-Axis Stroke: 450 mm
ETS-650P1-090050-MBN Combination Direction: P1 | 1st-Axis Stroke: 900 mm | 2nd-Axis Stroke: 500 mm
ETS-650P1-090055-MBN Combination Direction: P1 | 1st-Axis Stroke: 900 mm | 2nd-Axis Stroke: 550 mm
ETS-650P1-095005-MBN Combination Direction: P1 | 1st-Axis Stroke: 950 mm | 2nd-Axis Stroke: 50 mm
ETS-650P1-095010-MBN Combination Direction: P1 | 1st-Axis Stroke: 950 mm | 2nd-Axis Stroke: 100 mm
ETS-650P1-095015-MBN Combination Direction: P1 | 1st-Axis Stroke: 950 mm | 2nd-Axis Stroke: 150 mm
ETS-650P1-095020-MBN Combination Direction: P1 | 1st-Axis Stroke: 950 mm | 2nd-Axis Stroke: 200 mm
ETS-650P1-095025-MBN Combination Direction: P1 | 1st-Axis Stroke: 950 mm | 2nd-Axis Stroke: 250 mm
ETS-650P1-095030-MBN Combination Direction: P1 | 1st-Axis Stroke: 950 mm | 2nd-Axis Stroke: 300 mm
ETS-650P1-095035-MBN Combination Direction: P1 | 1st-Axis Stroke: 950 mm | 2nd-Axis Stroke: 350 mm
ETS-650P1-095040-MBN Combination Direction: P1 | 1st-Axis Stroke: 950 mm | 2nd-Axis Stroke: 400 mm
ETS-650P1-095045-MBN Combination Direction: P1 | 1st-Axis Stroke: 950 mm | 2nd-Axis Stroke: 450 mm
ETS-650P1-095050-MBN Combination Direction: P1 | 1st-Axis Stroke: 950 mm | 2nd-Axis Stroke: 500 mm
ETS-650P1-095055-MBN Combination Direction: P1 | 1st-Axis Stroke: 950 mm | 2nd-Axis Stroke: 550 mm
ETS-650P1-100005-MBN Combination Direction: P1 | 1st-Axis Stroke: 1000 mm | 2nd-Axis Stroke: 50 mm
ETS-650P1-100010-MBN Combination Direction: P1 | 1st-Axis Stroke: 1000 mm | 2nd-Axis Stroke: 100 mm
ETS-650P1-100015-MBN Combination Direction: P1 | 1st-Axis Stroke: 1000 mm | 2nd-Axis Stroke: 150 mm
ETS-650P1-100020-MBN Combination Direction: P1 | 1st-Axis Stroke: 1000 mm | 2nd-Axis Stroke: 200 mm
ETS-650P1-100025-MBN Combination Direction: P1 | 1st-Axis Stroke: 1000 mm | 2nd-Axis Stroke: 250 mm
ETS-650P1-100030-MBN Combination Direction: P1 | 1st-Axis Stroke: 1000 mm | 2nd-Axis Stroke: 300 mm
ETS-650P1-100035-MBN Combination Direction: P1 | 1st-Axis Stroke: 1000 mm | 2nd-Axis Stroke: 350 mm
ETS-650P1-100040-MBN Combination Direction: P1 | 1st-Axis Stroke: 1000 mm | 2nd-Axis Stroke: 400 mm
ETS-650P1-100045-MBN Combination Direction: P1 | 1st-Axis Stroke: 1000 mm | 2nd-Axis Stroke: 450 mm
ETS-650P1-100050-MBN Combination Direction: P1 | 1st-Axis Stroke: 1000 mm | 2nd-Axis Stroke: 500 mm
ETS-650P1-100055-MBN Combination Direction: P1 | 1st-Axis Stroke: 1000 mm | 2nd-Axis Stroke: 550 mm
ETS-650P1-105005-MBN Combination Direction: P1 | 1st-Axis Stroke: 1050 mm | 2nd-Axis Stroke: 50 mm
ETS-650P1-105010-MBN Combination Direction: P1 | 1st-Axis Stroke: 1050 mm | 2nd-Axis Stroke: 100 mm
ETS-650P1-105015-MBN Combination Direction: P1 | 1st-Axis Stroke: 1050 mm | 2nd-Axis Stroke: 150 mm
ETS-650P1-105020-MBN Combination Direction: P1 | 1st-Axis Stroke: 1050 mm | 2nd-Axis Stroke: 200 mm
ETS-650P1-105025-MBN Combination Direction: P1 | 1st-Axis Stroke: 1050 mm | 2nd-Axis Stroke: 250 mm
ETS-650P1-105030-MBN Combination Direction: P1 | 1st-Axis Stroke: 1050 mm | 2nd-Axis Stroke: 300 mm
ETS-650P1-105035-MBN Combination Direction: P1 | 1st-Axis Stroke: 1050 mm | 2nd-Axis Stroke: 350 mm
ETS-650P1-105040-MBN Combination Direction: P1 | 1st-Axis Stroke: 1050 mm | 2nd-Axis Stroke: 400 mm
ETS-650P1-105045-MBN Combination Direction: P1 | 1st-Axis Stroke: 1050 mm | 2nd-Axis Stroke: 450 mm
ETS-650P1-105050-MBN Combination Direction: P1 | 1st-Axis Stroke: 1050 mm | 2nd-Axis Stroke: 500 mm
ETS-650P1-105055-MBN Combination Direction: P1 | 1st-Axis Stroke: 1050 mm | 2nd-Axis Stroke: 550 mm
ETS-650P2-010005-MBN Combination Direction: P2 | 1st-Axis Stroke: 100 mm | 2nd-Axis Stroke: 50 mm
ETS-650P2-010010-MBN Combination Direction: P2 | 1st-Axis Stroke: 100 mm | 2nd-Axis Stroke: 100 mm
ETS-650P2-010015-MBN Combination Direction: P2 | 1st-Axis Stroke: 100 mm | 2nd-Axis Stroke: 150 mm
ETS-650P2-010020-MBN Combination Direction: P2 | 1st-Axis Stroke: 100 mm | 2nd-Axis Stroke: 200 mm
ETS-650P2-010025-MBN Combination Direction: P2 | 1st-Axis Stroke: 100 mm | 2nd-Axis Stroke: 250 mm
ETS-650P2-010030-MBN Combination Direction: P2 | 1st-Axis Stroke: 100 mm | 2nd-Axis Stroke: 300 mm
ETS-650P2-010035-MBN Combination Direction: P2 | 1st-Axis Stroke: 100 mm | 2nd-Axis Stroke: 350 mm
ETS-650P2-010040-MBN Combination Direction: P2 | 1st-Axis Stroke: 100 mm | 2nd-Axis Stroke: 400 mm
ETS-650P2-010045-MBN Combination Direction: P2 | 1st-Axis Stroke: 100 mm | 2nd-Axis Stroke: 450 mm
ETS-650P2-010050-MBN Combination Direction: P2 | 1st-Axis Stroke: 100 mm | 2nd-Axis Stroke: 500 mm
ETS-650P2-010055-MBN Combination Direction: P2 | 1st-Axis Stroke: 100 mm | 2nd-Axis Stroke: 550 mm
ETS-650P2-015005-MBN Combination Direction: P2 | 1st-Axis Stroke: 150 mm | 2nd-Axis Stroke: 50 mm
ETS-650P2-015010-MBN Combination Direction: P2 | 1st-Axis Stroke: 150 mm | 2nd-Axis Stroke: 100 mm
ETS-650P2-015015-MBN Combination Direction: P2 | 1st-Axis Stroke: 150 mm | 2nd-Axis Stroke: 150 mm
ETS-650P2-015020-MBN Combination Direction: P2 | 1st-Axis Stroke: 150 mm | 2nd-Axis Stroke: 200 mm
ETS-650P2-015025-MBN Combination Direction: P2 | 1st-Axis Stroke: 150 mm | 2nd-Axis Stroke: 250 mm
ETS-650P2-015030-MBN Combination Direction: P2 | 1st-Axis Stroke: 150 mm | 2nd-Axis Stroke: 300 mm
ETS-650P2-015035-MBN Combination Direction: P2 | 1st-Axis Stroke: 150 mm | 2nd-Axis Stroke: 350 mm
ETS-650P2-015040-MBN Combination Direction: P2 | 1st-Axis Stroke: 150 mm | 2nd-Axis Stroke: 400 mm
ETS-650P2-015045-MBN Combination Direction: P2 | 1st-Axis Stroke: 150 mm | 2nd-Axis Stroke: 450 mm
ETS-650P2-015050-MBN Combination Direction: P2 | 1st-Axis Stroke: 150 mm | 2nd-Axis Stroke: 500 mm
ETS-650P2-015055-MBN Combination Direction: P2 | 1st-Axis Stroke: 150 mm | 2nd-Axis Stroke: 550 mm
ETS-650P2-020005-MBN Combination Direction: P2 | 1st-Axis Stroke: 200 mm | 2nd-Axis Stroke: 50 mm
ETS-650P2-020010-MBN Combination Direction: P2 | 1st-Axis Stroke: 200 mm | 2nd-Axis Stroke: 100 mm
ETS-650P2-020015-MBN Combination Direction: P2 | 1st-Axis Stroke: 200 mm | 2nd-Axis Stroke: 150 mm
ETS-650P2-020020-MBN Combination Direction: P2 | 1st-Axis Stroke: 200 mm | 2nd-Axis Stroke: 200 mm
ETS-650P2-020025-MBN Combination Direction: P2 | 1st-Axis Stroke: 200 mm | 2nd-Axis Stroke: 250 mm
ETS-650P2-020030-MBN Combination Direction: P2 | 1st-Axis Stroke: 200 mm | 2nd-Axis Stroke: 300 mm
ETS-650P2-020035-MBN Combination Direction: P2 | 1st-Axis Stroke: 200 mm | 2nd-Axis Stroke: 350 mm
ETS-650P2-020040-MBN Combination Direction: P2 | 1st-Axis Stroke: 200 mm | 2nd-Axis Stroke: 400 mm
ETS-650P2-020045-MBN Combination Direction: P2 | 1st-Axis Stroke: 200 mm | 2nd-Axis Stroke: 450 mm
ETS-650P2-020050-MBN Combination Direction: P2 | 1st-Axis Stroke: 200 mm | 2nd-Axis Stroke: 500 mm
ETS-650P2-020055-MBN Combination Direction: P2 | 1st-Axis Stroke: 200 mm | 2nd-Axis Stroke: 550 mm
ETS-650P2-025005-MBN Combination Direction: P2 | 1st-Axis Stroke: 250 mm | 2nd-Axis Stroke: 50 mm
ETS-650P2-025010-MBN Combination Direction: P2 | 1st-Axis Stroke: 250 mm | 2nd-Axis Stroke: 100 mm
ETS-650P2-025015-MBN Combination Direction: P2 | 1st-Axis Stroke: 250 mm | 2nd-Axis Stroke: 150 mm
ETS-650P2-025020-MBN Combination Direction: P2 | 1st-Axis Stroke: 250 mm | 2nd-Axis Stroke: 200 mm
ETS-650P2-025025-MBN Combination Direction: P2 | 1st-Axis Stroke: 250 mm | 2nd-Axis Stroke: 250 mm
ETS-650P2-025030-MBN Combination Direction: P2 | 1st-Axis Stroke: 250 mm | 2nd-Axis Stroke: 300 mm
ETS-650P2-025035-MBN Combination Direction: P2 | 1st-Axis Stroke: 250 mm | 2nd-Axis Stroke: 350 mm
ETS-650P2-025040-MBN Combination Direction: P2 | 1st-Axis Stroke: 250 mm | 2nd-Axis Stroke: 400 mm
ETS-650P2-025045-MBN Combination Direction: P2 | 1st-Axis Stroke: 250 mm | 2nd-Axis Stroke: 450 mm
ETS-650P2-025050-MBN Combination Direction: P2 | 1st-Axis Stroke: 250 mm | 2nd-Axis Stroke: 500 mm
ETS-650P2-025055-MBN Combination Direction: P2 | 1st-Axis Stroke: 250 mm | 2nd-Axis Stroke: 550 mm
ETS-650P2-030005-MBN Combination Direction: P2 | 1st-Axis Stroke: 300 mm | 2nd-Axis Stroke: 50 mm
ETS-650P2-030010-MBN Combination Direction: P2 | 1st-Axis Stroke: 300 mm | 2nd-Axis Stroke: 100 mm
ETS-650P2-030015-MBN Combination Direction: P2 | 1st-Axis Stroke: 300 mm | 2nd-Axis Stroke: 150 mm
ETS-650P2-030020-MBN Combination Direction: P2 | 1st-Axis Stroke: 300 mm | 2nd-Axis Stroke: 200 mm
ETS-650P2-030025-MBN Combination Direction: P2 | 1st-Axis Stroke: 300 mm | 2nd-Axis Stroke: 250 mm
ETS-650P2-030030-MBN Combination Direction: P2 | 1st-Axis Stroke: 300 mm | 2nd-Axis Stroke: 300 mm
ETS-650P2-030035-MBN Combination Direction: P2 | 1st-Axis Stroke: 300 mm | 2nd-Axis Stroke: 350 mm
ETS-650P2-030040-MBN Combination Direction: P2 | 1st-Axis Stroke: 300 mm | 2nd-Axis Stroke: 400 mm
ETS-650P2-030045-MBN Combination Direction: P2 | 1st-Axis Stroke: 300 mm | 2nd-Axis Stroke: 450 mm
ETS-650P2-030050-MBN Combination Direction: P2 | 1st-Axis Stroke: 300 mm | 2nd-Axis Stroke: 500 mm
ETS-650P2-030055-MBN Combination Direction: P2 | 1st-Axis Stroke: 300 mm | 2nd-Axis Stroke: 550 mm
ETS-650P2-035005-MBN Combination Direction: P2 | 1st-Axis Stroke: 350 mm | 2nd-Axis Stroke: 50 mm
ETS-650P2-035010-MBN Combination Direction: P2 | 1st-Axis Stroke: 350 mm | 2nd-Axis Stroke: 100 mm
ETS-650P2-035015-MBN Combination Direction: P2 | 1st-Axis Stroke: 350 mm | 2nd-Axis Stroke: 150 mm
ETS-650P2-035020-MBN Combination Direction: P2 | 1st-Axis Stroke: 350 mm | 2nd-Axis Stroke: 200 mm
ETS-650P2-035025-MBN Combination Direction: P2 | 1st-Axis Stroke: 350 mm | 2nd-Axis Stroke: 250 mm
ETS-650P2-035030-MBN Combination Direction: P2 | 1st-Axis Stroke: 350 mm | 2nd-Axis Stroke: 300 mm
ETS-650P2-035035-MBN Combination Direction: P2 | 1st-Axis Stroke: 350 mm | 2nd-Axis Stroke: 350 mm
ETS-650P2-035040-MBN Combination Direction: P2 | 1st-Axis Stroke: 350 mm | 2nd-Axis Stroke: 400 mm
ETS-650P2-035045-MBN Combination Direction: P2 | 1st-Axis Stroke: 350 mm | 2nd-Axis Stroke: 450 mm
ETS-650P2-035050-MBN Combination Direction: P2 | 1st-Axis Stroke: 350 mm | 2nd-Axis Stroke: 500 mm
ETS-650P2-035055-MBN Combination Direction: P2 | 1st-Axis Stroke: 350 mm | 2nd-Axis Stroke: 550 mm
ETS-650P2-040005-MBN Combination Direction: P2 | 1st-Axis Stroke: 400 mm | 2nd-Axis Stroke: 50 mm
ETS-650P2-040010-MBN Combination Direction: P2 | 1st-Axis Stroke: 400 mm | 2nd-Axis Stroke: 100 mm
ETS-650P2-040015-MBN Combination Direction: P2 | 1st-Axis Stroke: 400 mm | 2nd-Axis Stroke: 150 mm
ETS-650P2-040020-MBN Combination Direction: P2 | 1st-Axis Stroke: 400 mm | 2nd-Axis Stroke: 200 mm
ETS-650P2-040025-MBN Combination Direction: P2 | 1st-Axis Stroke: 400 mm | 2nd-Axis Stroke: 250 mm
ETS-650P2-040030-MBN Combination Direction: P2 | 1st-Axis Stroke: 400 mm | 2nd-Axis Stroke: 300 mm
ETS-650P2-040035-MBN Combination Direction: P2 | 1st-Axis Stroke: 400 mm | 2nd-Axis Stroke: 350 mm
ETS-650P2-040040-MBN Combination Direction: P2 | 1st-Axis Stroke: 400 mm | 2nd-Axis Stroke: 400 mm
ETS-650P2-040045-MBN Combination Direction: P2 | 1st-Axis Stroke: 400 mm | 2nd-Axis Stroke: 450 mm
ETS-650P2-040050-MBN Combination Direction: P2 | 1st-Axis Stroke: 400 mm | 2nd-Axis Stroke: 500 mm
ETS-650P2-040055-MBN Combination Direction: P2 | 1st-Axis Stroke: 400 mm | 2nd-Axis Stroke: 550 mm
ETS-650P2-045005-MBN Combination Direction: P2 | 1st-Axis Stroke: 450 mm | 2nd-Axis Stroke: 50 mm
ETS-650P2-045010-MBN Combination Direction: P2 | 1st-Axis Stroke: 450 mm | 2nd-Axis Stroke: 100 mm
ETS-650P2-045015-MBN Combination Direction: P2 | 1st-Axis Stroke: 450 mm | 2nd-Axis Stroke: 150 mm
ETS-650P2-045020-MBN Combination Direction: P2 | 1st-Axis Stroke: 450 mm | 2nd-Axis Stroke: 200 mm
ETS-650P2-045025-MBN Combination Direction: P2 | 1st-Axis Stroke: 450 mm | 2nd-Axis Stroke: 250 mm
ETS-650P2-045030-MBN Combination Direction: P2 | 1st-Axis Stroke: 450 mm | 2nd-Axis Stroke: 300 mm
ETS-650P2-045035-MBN Combination Direction: P2 | 1st-Axis Stroke: 450 mm | 2nd-Axis Stroke: 350 mm
ETS-650P2-045040-MBN Combination Direction: P2 | 1st-Axis Stroke: 450 mm | 2nd-Axis Stroke: 400 mm
ETS-650P2-045045-MBN Combination Direction: P2 | 1st-Axis Stroke: 450 mm | 2nd-Axis Stroke: 450 mm
ETS-650P2-045050-MBN Combination Direction: P2 | 1st-Axis Stroke: 450 mm | 2nd-Axis Stroke: 500 mm
ETS-650P2-045055-MBN Combination Direction: P2 | 1st-Axis Stroke: 450 mm | 2nd-Axis Stroke: 550 mm
ETS-650P2-050005-MBN Combination Direction: P2 | 1st-Axis Stroke: 500 mm | 2nd-Axis Stroke: 50 mm
ETS-650P2-050010-MBN Combination Direction: P2 | 1st-Axis Stroke: 500 mm | 2nd-Axis Stroke: 100 mm
ETS-650P2-050015-MBN Combination Direction: P2 | 1st-Axis Stroke: 500 mm | 2nd-Axis Stroke: 150 mm
ETS-650P2-050020-MBN Combination Direction: P2 | 1st-Axis Stroke: 500 mm | 2nd-Axis Stroke: 200 mm
ETS-650P2-050025-MBN Combination Direction: P2 | 1st-Axis Stroke: 500 mm | 2nd-Axis Stroke: 250 mm
ETS-650P2-050030-MBN Combination Direction: P2 | 1st-Axis Stroke: 500 mm | 2nd-Axis Stroke: 300 mm
ETS-650P2-050035-MBN Combination Direction: P2 | 1st-Axis Stroke: 500 mm | 2nd-Axis Stroke: 350 mm
ETS-650P2-050040-MBN Combination Direction: P2 | 1st-Axis Stroke: 500 mm | 2nd-Axis Stroke: 400 mm
ETS-650P2-050045-MBN Combination Direction: P2 | 1st-Axis Stroke: 500 mm | 2nd-Axis Stroke: 450 mm
ETS-650P2-050050-MBN Combination Direction: P2 | 1st-Axis Stroke: 500 mm | 2nd-Axis Stroke: 500 mm
ETS-650P2-050055-MBN Combination Direction: P2 | 1st-Axis Stroke: 500 mm | 2nd-Axis Stroke: 550 mm
ETS-650P2-055005-MBN Combination Direction: P2 | 1st-Axis Stroke: 550 mm | 2nd-Axis Stroke: 50 mm
ETS-650P2-055010-MBN Combination Direction: P2 | 1st-Axis Stroke: 550 mm | 2nd-Axis Stroke: 100 mm
ETS-650P2-055015-MBN Combination Direction: P2 | 1st-Axis Stroke: 550 mm | 2nd-Axis Stroke: 150 mm
ETS-650P2-055020-MBN Combination Direction: P2 | 1st-Axis Stroke: 550 mm | 2nd-Axis Stroke: 200 mm
ETS-650P2-055025-MBN Combination Direction: P2 | 1st-Axis Stroke: 550 mm | 2nd-Axis Stroke: 250 mm
ETS-650P2-055030-MBN Combination Direction: P2 | 1st-Axis Stroke: 550 mm | 2nd-Axis Stroke: 300 mm
ETS-650P2-055035-MBN Combination Direction: P2 | 1st-Axis Stroke: 550 mm | 2nd-Axis Stroke: 350 mm
ETS-650P2-055040-MBN Combination Direction: P2 | 1st-Axis Stroke: 550 mm | 2nd-Axis Stroke: 400 mm
ETS-650P2-055045-MBN Combination Direction: P2 | 1st-Axis Stroke: 550 mm | 2nd-Axis Stroke: 450 mm
ETS-650P2-055050-MBN Combination Direction: P2 | 1st-Axis Stroke: 550 mm | 2nd-Axis Stroke: 500 mm
ETS-650P2-055055-MBN Combination Direction: P2 | 1st-Axis Stroke: 550 mm | 2nd-Axis Stroke: 550 mm
ETS-650P2-060005-MBN Combination Direction: P2 | 1st-Axis Stroke: 600 mm | 2nd-Axis Stroke: 50 mm
ETS-650P2-060010-MBN Combination Direction: P2 | 1st-Axis Stroke: 600 mm | 2nd-Axis Stroke: 100 mm
ETS-650P2-060015-MBN Combination Direction: P2 | 1st-Axis Stroke: 600 mm | 2nd-Axis Stroke: 150 mm
ETS-650P2-060020-MBN Combination Direction: P2 | 1st-Axis Stroke: 600 mm | 2nd-Axis Stroke: 200 mm
ETS-650P2-060025-MBN Combination Direction: P2 | 1st-Axis Stroke: 600 mm | 2nd-Axis Stroke: 250 mm
ETS-650P2-060030-MBN Combination Direction: P2 | 1st-Axis Stroke: 600 mm | 2nd-Axis Stroke: 300 mm
ETS-650P2-060035-MBN Combination Direction: P2 | 1st-Axis Stroke: 600 mm | 2nd-Axis Stroke: 350 mm
ETS-650P2-060040-MBN Combination Direction: P2 | 1st-Axis Stroke: 600 mm | 2nd-Axis Stroke: 400 mm
ETS-650P2-060045-MBN Combination Direction: P2 | 1st-Axis Stroke: 600 mm | 2nd-Axis Stroke: 450 mm
ETS-650P2-060050-MBN Combination Direction: P2 | 1st-Axis Stroke: 600 mm | 2nd-Axis Stroke: 500 mm
ETS-650P2-060055-MBN Combination Direction: P2 | 1st-Axis Stroke: 600 mm | 2nd-Axis Stroke: 550 mm
ETS-650P2-065005-MBN Combination Direction: P2 | 1st-Axis Stroke: 650 mm | 2nd-Axis Stroke: 50 mm
ETS-650P2-065010-MBN Combination Direction: P2 | 1st-Axis Stroke: 650 mm | 2nd-Axis Stroke: 100 mm
ETS-650P2-065015-MBN Combination Direction: P2 | 1st-Axis Stroke: 650 mm | 2nd-Axis Stroke: 150 mm
ETS-650P2-065020-MBN Combination Direction: P2 | 1st-Axis Stroke: 650 mm | 2nd-Axis Stroke: 200 mm
ETS-650P2-065025-MBN Combination Direction: P2 | 1st-Axis Stroke: 650 mm | 2nd-Axis Stroke: 250 mm
ETS-650P2-065030-MBN Combination Direction: P2 | 1st-Axis Stroke: 650 mm | 2nd-Axis Stroke: 300 mm
ETS-650P2-065035-MBN Combination Direction: P2 | 1st-Axis Stroke: 650 mm | 2nd-Axis Stroke: 350 mm
ETS-650P2-065040-MBN Combination Direction: P2 | 1st-Axis Stroke: 650 mm | 2nd-Axis Stroke: 400 mm
ETS-650P2-065045-MBN Combination Direction: P2 | 1st-Axis Stroke: 650 mm | 2nd-Axis Stroke: 450 mm
ETS-650P2-065050-MBN Combination Direction: P2 | 1st-Axis Stroke: 650 mm | 2nd-Axis Stroke: 500 mm
ETS-650P2-065055-MBN Combination Direction: P2 | 1st-Axis Stroke: 650 mm | 2nd-Axis Stroke: 550 mm
ETS-650P2-070005-MBN Combination Direction: P2 | 1st-Axis Stroke: 700 mm | 2nd-Axis Stroke: 50 mm
ETS-650P2-070010-MBN Combination Direction: P2 | 1st-Axis Stroke: 700 mm | 2nd-Axis Stroke: 100 mm
ETS-650P2-070015-MBN Combination Direction: P2 | 1st-Axis Stroke: 700 mm | 2nd-Axis Stroke: 150 mm
ETS-650P2-070020-MBN Combination Direction: P2 | 1st-Axis Stroke: 700 mm | 2nd-Axis Stroke: 200 mm
ETS-650P2-070025-MBN Combination Direction: P2 | 1st-Axis Stroke: 700 mm | 2nd-Axis Stroke: 250 mm
ETS-650P2-070030-MBN Combination Direction: P2 | 1st-Axis Stroke: 700 mm | 2nd-Axis Stroke: 300 mm
ETS-650P2-070035-MBN Combination Direction: P2 | 1st-Axis Stroke: 700 mm | 2nd-Axis Stroke: 350 mm
ETS-650P2-070040-MBN Combination Direction: P2 | 1st-Axis Stroke: 700 mm | 2nd-Axis Stroke: 400 mm
ETS-650P2-070045-MBN Combination Direction: P2 | 1st-Axis Stroke: 700 mm | 2nd-Axis Stroke: 450 mm
ETS-650P2-070050-MBN Combination Direction: P2 | 1st-Axis Stroke: 700 mm | 2nd-Axis Stroke: 500 mm
ETS-650P2-070055-MBN Combination Direction: P2 | 1st-Axis Stroke: 700 mm | 2nd-Axis Stroke: 550 mm
ETS-650P2-075005-MBN Combination Direction: P2 | 1st-Axis Stroke: 750 mm | 2nd-Axis Stroke: 50 mm
ETS-650P2-075010-MBN Combination Direction: P2 | 1st-Axis Stroke: 750 mm | 2nd-Axis Stroke: 100 mm
ETS-650P2-075015-MBN Combination Direction: P2 | 1st-Axis Stroke: 750 mm | 2nd-Axis Stroke: 150 mm
ETS-650P2-075020-MBN Combination Direction: P2 | 1st-Axis Stroke: 750 mm | 2nd-Axis Stroke: 200 mm
ETS-650P2-075025-MBN Combination Direction: P2 | 1st-Axis Stroke: 750 mm | 2nd-Axis Stroke: 250 mm
ETS-650P2-075030-MBN Combination Direction: P2 | 1st-Axis Stroke: 750 mm | 2nd-Axis Stroke: 300 mm
ETS-650P2-075035-MBN Combination Direction: P2 | 1st-Axis Stroke: 750 mm | 2nd-Axis Stroke: 350 mm
ETS-650P2-075040-MBN Combination Direction: P2 | 1st-Axis Stroke: 750 mm | 2nd-Axis Stroke: 400 mm
ETS-650P2-075045-MBN Combination Direction: P2 | 1st-Axis Stroke: 750 mm | 2nd-Axis Stroke: 450 mm
ETS-650P2-075050-MBN Combination Direction: P2 | 1st-Axis Stroke: 750 mm | 2nd-Axis Stroke: 500 mm
ETS-650P2-075055-MBN Combination Direction: P2 | 1st-Axis Stroke: 750 mm | 2nd-Axis Stroke: 550 mm
ETS-650P2-080005-MBN Combination Direction: P2 | 1st-Axis Stroke: 800 mm | 2nd-Axis Stroke: 50 mm
ETS-650P2-080010-MBN Combination Direction: P2 | 1st-Axis Stroke: 800 mm | 2nd-Axis Stroke: 100 mm
ETS-650P2-080015-MBN Combination Direction: P2 | 1st-Axis Stroke: 800 mm | 2nd-Axis Stroke: 150 mm
ETS-650P2-080020-MBN Combination Direction: P2 | 1st-Axis Stroke: 800 mm | 2nd-Axis Stroke: 200 mm
ETS-650P2-080025-MBN Combination Direction: P2 | 1st-Axis Stroke: 800 mm | 2nd-Axis Stroke: 250 mm
ETS-650P2-080030-MBN Combination Direction: P2 | 1st-Axis Stroke: 800 mm | 2nd-Axis Stroke: 300 mm
ETS-650P2-080035-MBN Combination Direction: P2 | 1st-Axis Stroke: 800 mm | 2nd-Axis Stroke: 350 mm
ETS-650P2-080040-MBN Combination Direction: P2 | 1st-Axis Stroke: 800 mm | 2nd-Axis Stroke: 400 mm
ETS-650P2-080045-MBN Combination Direction: P2 | 1st-Axis Stroke: 800 mm | 2nd-Axis Stroke: 450 mm
ETS-650P2-080050-MBN Combination Direction: P2 | 1st-Axis Stroke: 800 mm | 2nd-Axis Stroke: 500 mm
ETS-650P2-080055-MBN Combination Direction: P2 | 1st-Axis Stroke: 800 mm | 2nd-Axis Stroke: 550 mm
ETS-650P2-085005-MBN Combination Direction: P2 | 1st-Axis Stroke: 850 mm | 2nd-Axis Stroke: 50 mm
ETS-650P2-085010-MBN Combination Direction: P2 | 1st-Axis Stroke: 850 mm | 2nd-Axis Stroke: 100 mm
ETS-650P2-085015-MBN Combination Direction: P2 | 1st-Axis Stroke: 850 mm | 2nd-Axis Stroke: 150 mm
ETS-650P2-085020-MBN Combination Direction: P2 | 1st-Axis Stroke: 850 mm | 2nd-Axis Stroke: 200 mm
ETS-650P2-085025-MBN Combination Direction: P2 | 1st-Axis Stroke: 850 mm | 2nd-Axis Stroke: 250 mm
ETS-650P2-085030-MBN Combination Direction: P2 | 1st-Axis Stroke: 850 mm | 2nd-Axis Stroke: 300 mm
ETS-650P2-085035-MBN Combination Direction: P2 | 1st-Axis Stroke: 850 mm | 2nd-Axis Stroke: 350 mm
ETS-650P2-085040-MBN Combination Direction: P2 | 1st-Axis Stroke: 850 mm | 2nd-Axis Stroke: 400 mm
ETS-650P2-085045-MBN Combination Direction: P2 | 1st-Axis Stroke: 850 mm | 2nd-Axis Stroke: 450 mm
ETS-650P2-085050-MBN Combination Direction: P2 | 1st-Axis Stroke: 850 mm | 2nd-Axis Stroke: 500 mm
ETS-650P2-085055-MBN Combination Direction: P2 | 1st-Axis Stroke: 850 mm | 2nd-Axis Stroke: 550 mm
ETS-650P2-090005-MBN Combination Direction: P2 | 1st-Axis Stroke: 900 mm | 2nd-Axis Stroke: 50 mm
ETS-650P2-090010-MBN Combination Direction: P2 | 1st-Axis Stroke: 900 mm | 2nd-Axis Stroke: 100 mm
ETS-650P2-090015-MBN Combination Direction: P2 | 1st-Axis Stroke: 900 mm | 2nd-Axis Stroke: 150 mm
ETS-650P2-090020-MBN Combination Direction: P2 | 1st-Axis Stroke: 900 mm | 2nd-Axis Stroke: 200 mm
ETS-650P2-090025-MBN Combination Direction: P2 | 1st-Axis Stroke: 900 mm | 2nd-Axis Stroke: 250 mm
ETS-650P2-090030-MBN Combination Direction: P2 | 1st-Axis Stroke: 900 mm | 2nd-Axis Stroke: 300 mm
ETS-650P2-090035-MBN Combination Direction: P2 | 1st-Axis Stroke: 900 mm | 2nd-Axis Stroke: 350 mm
ETS-650P2-090040-MBN Combination Direction: P2 | 1st-Axis Stroke: 900 mm | 2nd-Axis Stroke: 400 mm
ETS-650P2-090045-MBN Combination Direction: P2 | 1st-Axis Stroke: 900 mm | 2nd-Axis Stroke: 450 mm
ETS-650P2-090050-MBN Combination Direction: P2 | 1st-Axis Stroke: 900 mm | 2nd-Axis Stroke: 500 mm
ETS-650P2-090055-MBN Combination Direction: P2 | 1st-Axis Stroke: 900 mm | 2nd-Axis Stroke: 550 mm
ETS-650P2-095005-MBN Combination Direction: P2 | 1st-Axis Stroke: 950 mm | 2nd-Axis Stroke: 50 mm
ETS-650P2-095010-MBN Combination Direction: P2 | 1st-Axis Stroke: 950 mm | 2nd-Axis Stroke: 100 mm
ETS-650P2-095015-MBN Combination Direction: P2 | 1st-Axis Stroke: 950 mm | 2nd-Axis Stroke: 150 mm
ETS-650P2-095020-MBN Combination Direction: P2 | 1st-Axis Stroke: 950 mm | 2nd-Axis Stroke: 200 mm
ETS-650P2-095025-MBN Combination Direction: P2 | 1st-Axis Stroke: 950 mm | 2nd-Axis Stroke: 250 mm
ETS-650P2-095030-MBN Combination Direction: P2 | 1st-Axis Stroke: 950 mm | 2nd-Axis Stroke: 300 mm
ETS-650P2-095035-MBN Combination Direction: P2 | 1st-Axis Stroke: 950 mm | 2nd-Axis Stroke: 350 mm
ETS-650P2-095040-MBN Combination Direction: P2 | 1st-Axis Stroke: 950 mm | 2nd-Axis Stroke: 400 mm
ETS-650P2-095045-MBN Combination Direction: P2 | 1st-Axis Stroke: 950 mm | 2nd-Axis Stroke: 450 mm
ETS-650P2-095050-MBN Combination Direction: P2 | 1st-Axis Stroke: 950 mm | 2nd-Axis Stroke: 500 mm
ETS-650P2-095055-MBN Combination Direction: P2 | 1st-Axis Stroke: 950 mm | 2nd-Axis Stroke: 550 mm
ETS-650P2-100005-MBN Combination Direction: P2 | 1st-Axis Stroke: 1000 mm | 2nd-Axis Stroke: 50 mm
ETS-650P2-100010-MBN Combination Direction: P2 | 1st-Axis Stroke: 1000 mm | 2nd-Axis Stroke: 100 mm
ETS-650P2-100015-MBN Combination Direction: P2 | 1st-Axis Stroke: 1000 mm | 2nd-Axis Stroke: 150 mm
ETS-650P2-100020-MBN Combination Direction: P2 | 1st-Axis Stroke: 1000 mm | 2nd-Axis Stroke: 200 mm
ETS-650P2-100025-MBN Combination Direction: P2 | 1st-Axis Stroke: 1000 mm | 2nd-Axis Stroke: 250 mm
ETS-650P2-100030-MBN Combination Direction: P2 | 1st-Axis Stroke: 1000 mm | 2nd-Axis Stroke: 300 mm
ETS-650P2-100035-MBN Combination Direction: P2 | 1st-Axis Stroke: 1000 mm | 2nd-Axis Stroke: 350 mm
ETS-650P2-100040-MBN Combination Direction: P2 | 1st-Axis Stroke: 1000 mm | 2nd-Axis Stroke: 400 mm
ETS-650P2-100045-MBN Combination Direction: P2 | 1st-Axis Stroke: 1000 mm | 2nd-Axis Stroke: 450 mm
ETS-650P2-100050-MBN Combination Direction: P2 | 1st-Axis Stroke: 1000 mm | 2nd-Axis Stroke: 500 mm
ETS-650P2-100055-MBN Combination Direction: P2 | 1st-Axis Stroke: 1000 mm | 2nd-Axis Stroke: 550 mm
ETS-650P2-105005-MBN Combination Direction: P2 | 1st-Axis Stroke: 1050 mm | 2nd-Axis Stroke: 50 mm
ETS-650P2-105010-MBN Combination Direction: P2 | 1st-Axis Stroke: 1050 mm | 2nd-Axis Stroke: 100 mm
ETS-650P2-105015-MBN Combination Direction: P2 | 1st-Axis Stroke: 1050 mm | 2nd-Axis Stroke: 150 mm
ETS-650P2-105020-MBN Combination Direction: P2 | 1st-Axis Stroke: 1050 mm | 2nd-Axis Stroke: 200 mm
ETS-650P2-105025-MBN Combination Direction: P2 | 1st-Axis Stroke: 1050 mm | 2nd-Axis Stroke: 250 mm
ETS-650P2-105030-MBN Combination Direction: P2 | 1st-Axis Stroke: 1050 mm | 2nd-Axis Stroke: 300 mm
ETS-650P2-105035-MBN Combination Direction: P2 | 1st-Axis Stroke: 1050 mm | 2nd-Axis Stroke: 350 mm
ETS-650P2-105040-MBN Combination Direction: P2 | 1st-Axis Stroke: 1050 mm | 2nd-Axis Stroke: 400 mm
ETS-650P2-105045-MBN Combination Direction: P2 | 1st-Axis Stroke: 1050 mm | 2nd-Axis Stroke: 450 mm
ETS-650P2-105050-MBN Combination Direction: P2 | 1st-Axis Stroke: 1050 mm | 2nd-Axis Stroke: 500 mm
ETS-650P2-105055-MBN Combination Direction: P2 | 1st-Axis Stroke: 1050 mm | 2nd-Axis Stroke: 550 mm
ETS-650P1 Legacy code: base combination ETS-650P1 | Combination Direction: P1 | 1st-Axis Stroke: All | 2nd-Axis Stroke: All
ETS-650P2 Legacy code: base combination ETS-650P2 | Combination Direction: P2 | 1st-Axis Stroke: All | 2nd-Axis Stroke: All
Electric ActuatorsCKD
442 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

CKD ETS-650P Multi-Axis Actuator (X-Z)

Brand CKD·Electric Actuators

Available part numbers (442)

ETS-650P1-010005-MBN, ETS-650P1-010010-MBN, ETS-650P1-010015-MBN, ETS-650P1-010020-MBN, ETS-650P1-010025-MBN, ETS-650P1-010030-MBN, ETS-650P1-010035-MBN, ETS-650P1-010040-MBN, ETS-650P1-010045-MBN, ETS-650P1-010050-MBN + 432 more — see full table ↓

How to order

Send the CKD part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
ETS-650P1-010005-MBNCombination Direction: P1 | 1st-Axis Stroke: 100 mm | 2nd-Axis Stroke: 50 mm
ETS-650P1-010010-MBNCombination Direction: P1 | 1st-Axis Stroke: 100 mm | 2nd-Axis Stroke: 100 mm
ETS-650P1-010015-MBNCombination Direction: P1 | 1st-Axis Stroke: 100 mm | 2nd-Axis Stroke: 150 mm
ETS-650P1-010020-MBNCombination Direction: P1 | 1st-Axis Stroke: 100 mm | 2nd-Axis Stroke: 200 mm
ETS-650P1-010025-MBNCombination Direction: P1 | 1st-Axis Stroke: 100 mm | 2nd-Axis Stroke: 250 mm
ETS-650P1-010030-MBNCombination Direction: P1 | 1st-Axis Stroke: 100 mm | 2nd-Axis Stroke: 300 mm
ETS-650P1-010035-MBNCombination Direction: P1 | 1st-Axis Stroke: 100 mm | 2nd-Axis Stroke: 350 mm
ETS-650P1-010040-MBNCombination Direction: P1 | 1st-Axis Stroke: 100 mm | 2nd-Axis Stroke: 400 mm
ETS-650P1-010045-MBNCombination Direction: P1 | 1st-Axis Stroke: 100 mm | 2nd-Axis Stroke: 450 mm
ETS-650P1-010050-MBNCombination Direction: P1 | 1st-Axis Stroke: 100 mm | 2nd-Axis Stroke: 500 mm
ETS-650P1-010055-MBNCombination Direction: P1 | 1st-Axis Stroke: 100 mm | 2nd-Axis Stroke: 550 mm
ETS-650P1-015005-MBNCombination Direction: P1 | 1st-Axis Stroke: 150 mm | 2nd-Axis Stroke: 50 mm
ETS-650P1-015010-MBNCombination Direction: P1 | 1st-Axis Stroke: 150 mm | 2nd-Axis Stroke: 100 mm
ETS-650P1-015015-MBNCombination Direction: P1 | 1st-Axis Stroke: 150 mm | 2nd-Axis Stroke: 150 mm
ETS-650P1-015020-MBNCombination Direction: P1 | 1st-Axis Stroke: 150 mm | 2nd-Axis Stroke: 200 mm
ETS-650P1-015025-MBNCombination Direction: P1 | 1st-Axis Stroke: 150 mm | 2nd-Axis Stroke: 250 mm
ETS-650P1-015030-MBNCombination Direction: P1 | 1st-Axis Stroke: 150 mm | 2nd-Axis Stroke: 300 mm
ETS-650P1-015035-MBNCombination Direction: P1 | 1st-Axis Stroke: 150 mm | 2nd-Axis Stroke: 350 mm
ETS-650P1-015040-MBNCombination Direction: P1 | 1st-Axis Stroke: 150 mm | 2nd-Axis Stroke: 400 mm
ETS-650P1-015045-MBNCombination Direction: P1 | 1st-Axis Stroke: 150 mm | 2nd-Axis Stroke: 450 mm
ETS-650P1-015050-MBNCombination Direction: P1 | 1st-Axis Stroke: 150 mm | 2nd-Axis Stroke: 500 mm
ETS-650P1-015055-MBNCombination Direction: P1 | 1st-Axis Stroke: 150 mm | 2nd-Axis Stroke: 550 mm
ETS-650P1-020005-MBNCombination Direction: P1 | 1st-Axis Stroke: 200 mm | 2nd-Axis Stroke: 50 mm
ETS-650P1-020010-MBNCombination Direction: P1 | 1st-Axis Stroke: 200 mm | 2nd-Axis Stroke: 100 mm
ETS-650P1-020015-MBNCombination Direction: P1 | 1st-Axis Stroke: 200 mm | 2nd-Axis Stroke: 150 mm
ETS-650P1-020020-MBNCombination Direction: P1 | 1st-Axis Stroke: 200 mm | 2nd-Axis Stroke: 200 mm
ETS-650P1-020025-MBNCombination Direction: P1 | 1st-Axis Stroke: 200 mm | 2nd-Axis Stroke: 250 mm
ETS-650P1-020030-MBNCombination Direction: P1 | 1st-Axis Stroke: 200 mm | 2nd-Axis Stroke: 300 mm
ETS-650P1-020035-MBNCombination Direction: P1 | 1st-Axis Stroke: 200 mm | 2nd-Axis Stroke: 350 mm
ETS-650P1-020040-MBNCombination Direction: P1 | 1st-Axis Stroke: 200 mm | 2nd-Axis Stroke: 400 mm
ETS-650P1-020045-MBNCombination Direction: P1 | 1st-Axis Stroke: 200 mm | 2nd-Axis Stroke: 450 mm
ETS-650P1-020050-MBNCombination Direction: P1 | 1st-Axis Stroke: 200 mm | 2nd-Axis Stroke: 500 mm
ETS-650P1-020055-MBNCombination Direction: P1 | 1st-Axis Stroke: 200 mm | 2nd-Axis Stroke: 550 mm
ETS-650P1-025005-MBNCombination Direction: P1 | 1st-Axis Stroke: 250 mm | 2nd-Axis Stroke: 50 mm
ETS-650P1-025010-MBNCombination Direction: P1 | 1st-Axis Stroke: 250 mm | 2nd-Axis Stroke: 100 mm
ETS-650P1-025015-MBNCombination Direction: P1 | 1st-Axis Stroke: 250 mm | 2nd-Axis Stroke: 150 mm
ETS-650P1-025020-MBNCombination Direction: P1 | 1st-Axis Stroke: 250 mm | 2nd-Axis Stroke: 200 mm
ETS-650P1-025025-MBNCombination Direction: P1 | 1st-Axis Stroke: 250 mm | 2nd-Axis Stroke: 250 mm
ETS-650P1-025030-MBNCombination Direction: P1 | 1st-Axis Stroke: 250 mm | 2nd-Axis Stroke: 300 mm
ETS-650P1-025035-MBNCombination Direction: P1 | 1st-Axis Stroke: 250 mm | 2nd-Axis Stroke: 350 mm
ETS-650P1-025040-MBNCombination Direction: P1 | 1st-Axis Stroke: 250 mm | 2nd-Axis Stroke: 400 mm
ETS-650P1-025045-MBNCombination Direction: P1 | 1st-Axis Stroke: 250 mm | 2nd-Axis Stroke: 450 mm
ETS-650P1-025050-MBNCombination Direction: P1 | 1st-Axis Stroke: 250 mm | 2nd-Axis Stroke: 500 mm
ETS-650P1-025055-MBNCombination Direction: P1 | 1st-Axis Stroke: 250 mm | 2nd-Axis Stroke: 550 mm
ETS-650P1-030005-MBNCombination Direction: P1 | 1st-Axis Stroke: 300 mm | 2nd-Axis Stroke: 50 mm
ETS-650P1-030010-MBNCombination Direction: P1 | 1st-Axis Stroke: 300 mm | 2nd-Axis Stroke: 100 mm
ETS-650P1-030015-MBNCombination Direction: P1 | 1st-Axis Stroke: 300 mm | 2nd-Axis Stroke: 150 mm
ETS-650P1-030020-MBNCombination Direction: P1 | 1st-Axis Stroke: 300 mm | 2nd-Axis Stroke: 200 mm
ETS-650P1-030025-MBNCombination Direction: P1 | 1st-Axis Stroke: 300 mm | 2nd-Axis Stroke: 250 mm
ETS-650P1-030030-MBNCombination Direction: P1 | 1st-Axis Stroke: 300 mm | 2nd-Axis Stroke: 300 mm
ETS-650P1-030035-MBNCombination Direction: P1 | 1st-Axis Stroke: 300 mm | 2nd-Axis Stroke: 350 mm
ETS-650P1-030040-MBNCombination Direction: P1 | 1st-Axis Stroke: 300 mm | 2nd-Axis Stroke: 400 mm
ETS-650P1-030045-MBNCombination Direction: P1 | 1st-Axis Stroke: 300 mm | 2nd-Axis Stroke: 450 mm
ETS-650P1-030050-MBNCombination Direction: P1 | 1st-Axis Stroke: 300 mm | 2nd-Axis Stroke: 500 mm
ETS-650P1-030055-MBNCombination Direction: P1 | 1st-Axis Stroke: 300 mm | 2nd-Axis Stroke: 550 mm
ETS-650P1-035005-MBNCombination Direction: P1 | 1st-Axis Stroke: 350 mm | 2nd-Axis Stroke: 50 mm
ETS-650P1-035010-MBNCombination Direction: P1 | 1st-Axis Stroke: 350 mm | 2nd-Axis Stroke: 100 mm
ETS-650P1-035015-MBNCombination Direction: P1 | 1st-Axis Stroke: 350 mm | 2nd-Axis Stroke: 150 mm
ETS-650P1-035020-MBNCombination Direction: P1 | 1st-Axis Stroke: 350 mm | 2nd-Axis Stroke: 200 mm
ETS-650P1-035025-MBNCombination Direction: P1 | 1st-Axis Stroke: 350 mm | 2nd-Axis Stroke: 250 mm
ETS-650P1-035030-MBNCombination Direction: P1 | 1st-Axis Stroke: 350 mm | 2nd-Axis Stroke: 300 mm
ETS-650P1-035035-MBNCombination Direction: P1 | 1st-Axis Stroke: 350 mm | 2nd-Axis Stroke: 350 mm
ETS-650P1-035040-MBNCombination Direction: P1 | 1st-Axis Stroke: 350 mm | 2nd-Axis Stroke: 400 mm
ETS-650P1-035045-MBNCombination Direction: P1 | 1st-Axis Stroke: 350 mm | 2nd-Axis Stroke: 450 mm
ETS-650P1-035050-MBNCombination Direction: P1 | 1st-Axis Stroke: 350 mm | 2nd-Axis Stroke: 500 mm
ETS-650P1-035055-MBNCombination Direction: P1 | 1st-Axis Stroke: 350 mm | 2nd-Axis Stroke: 550 mm
ETS-650P1-040005-MBNCombination Direction: P1 | 1st-Axis Stroke: 400 mm | 2nd-Axis Stroke: 50 mm
ETS-650P1-040010-MBNCombination Direction: P1 | 1st-Axis Stroke: 400 mm | 2nd-Axis Stroke: 100 mm
ETS-650P1-040015-MBNCombination Direction: P1 | 1st-Axis Stroke: 400 mm | 2nd-Axis Stroke: 150 mm
ETS-650P1-040020-MBNCombination Direction: P1 | 1st-Axis Stroke: 400 mm | 2nd-Axis Stroke: 200 mm
ETS-650P1-040025-MBNCombination Direction: P1 | 1st-Axis Stroke: 400 mm | 2nd-Axis Stroke: 250 mm
ETS-650P1-040030-MBNCombination Direction: P1 | 1st-Axis Stroke: 400 mm | 2nd-Axis Stroke: 300 mm
ETS-650P1-040035-MBNCombination Direction: P1 | 1st-Axis Stroke: 400 mm | 2nd-Axis Stroke: 350 mm
ETS-650P1-040040-MBNCombination Direction: P1 | 1st-Axis Stroke: 400 mm | 2nd-Axis Stroke: 400 mm
ETS-650P1-040045-MBNCombination Direction: P1 | 1st-Axis Stroke: 400 mm | 2nd-Axis Stroke: 450 mm
ETS-650P1-040050-MBNCombination Direction: P1 | 1st-Axis Stroke: 400 mm | 2nd-Axis Stroke: 500 mm
ETS-650P1-040055-MBNCombination Direction: P1 | 1st-Axis Stroke: 400 mm | 2nd-Axis Stroke: 550 mm
ETS-650P1-045005-MBNCombination Direction: P1 | 1st-Axis Stroke: 450 mm | 2nd-Axis Stroke: 50 mm
ETS-650P1-045010-MBNCombination Direction: P1 | 1st-Axis Stroke: 450 mm | 2nd-Axis Stroke: 100 mm
ETS-650P1-045015-MBNCombination Direction: P1 | 1st-Axis Stroke: 450 mm | 2nd-Axis Stroke: 150 mm
ETS-650P1-045020-MBNCombination Direction: P1 | 1st-Axis Stroke: 450 mm | 2nd-Axis Stroke: 200 mm
ETS-650P1-045025-MBNCombination Direction: P1 | 1st-Axis Stroke: 450 mm | 2nd-Axis Stroke: 250 mm
ETS-650P1-045030-MBNCombination Direction: P1 | 1st-Axis Stroke: 450 mm | 2nd-Axis Stroke: 300 mm
ETS-650P1-045035-MBNCombination Direction: P1 | 1st-Axis Stroke: 450 mm | 2nd-Axis Stroke: 350 mm
ETS-650P1-045040-MBNCombination Direction: P1 | 1st-Axis Stroke: 450 mm | 2nd-Axis Stroke: 400 mm
ETS-650P1-045045-MBNCombination Direction: P1 | 1st-Axis Stroke: 450 mm | 2nd-Axis Stroke: 450 mm
ETS-650P1-045050-MBNCombination Direction: P1 | 1st-Axis Stroke: 450 mm | 2nd-Axis Stroke: 500 mm
ETS-650P1-045055-MBNCombination Direction: P1 | 1st-Axis Stroke: 450 mm | 2nd-Axis Stroke: 550 mm
ETS-650P1-050005-MBNCombination Direction: P1 | 1st-Axis Stroke: 500 mm | 2nd-Axis Stroke: 50 mm
ETS-650P1-050010-MBNCombination Direction: P1 | 1st-Axis Stroke: 500 mm | 2nd-Axis Stroke: 100 mm
ETS-650P1-050015-MBNCombination Direction: P1 | 1st-Axis Stroke: 500 mm | 2nd-Axis Stroke: 150 mm
ETS-650P1-050020-MBNCombination Direction: P1 | 1st-Axis Stroke: 500 mm | 2nd-Axis Stroke: 200 mm
ETS-650P1-050025-MBNCombination Direction: P1 | 1st-Axis Stroke: 500 mm | 2nd-Axis Stroke: 250 mm
ETS-650P1-050030-MBNCombination Direction: P1 | 1st-Axis Stroke: 500 mm | 2nd-Axis Stroke: 300 mm
ETS-650P1-050035-MBNCombination Direction: P1 | 1st-Axis Stroke: 500 mm | 2nd-Axis Stroke: 350 mm
ETS-650P1-050040-MBNCombination Direction: P1 | 1st-Axis Stroke: 500 mm | 2nd-Axis Stroke: 400 mm
ETS-650P1-050045-MBNCombination Direction: P1 | 1st-Axis Stroke: 500 mm | 2nd-Axis Stroke: 450 mm
ETS-650P1-050050-MBNCombination Direction: P1 | 1st-Axis Stroke: 500 mm | 2nd-Axis Stroke: 500 mm
ETS-650P1-050055-MBNCombination Direction: P1 | 1st-Axis Stroke: 500 mm | 2nd-Axis Stroke: 550 mm
ETS-650P1-055005-MBNCombination Direction: P1 | 1st-Axis Stroke: 550 mm | 2nd-Axis Stroke: 50 mm
ETS-650P1-055010-MBNCombination Direction: P1 | 1st-Axis Stroke: 550 mm | 2nd-Axis Stroke: 100 mm
ETS-650P1-055015-MBNCombination Direction: P1 | 1st-Axis Stroke: 550 mm | 2nd-Axis Stroke: 150 mm
ETS-650P1-055020-MBNCombination Direction: P1 | 1st-Axis Stroke: 550 mm | 2nd-Axis Stroke: 200 mm
ETS-650P1-055025-MBNCombination Direction: P1 | 1st-Axis Stroke: 550 mm | 2nd-Axis Stroke: 250 mm
ETS-650P1-055030-MBNCombination Direction: P1 | 1st-Axis Stroke: 550 mm | 2nd-Axis Stroke: 300 mm
ETS-650P1-055035-MBNCombination Direction: P1 | 1st-Axis Stroke: 550 mm | 2nd-Axis Stroke: 350 mm
ETS-650P1-055040-MBNCombination Direction: P1 | 1st-Axis Stroke: 550 mm | 2nd-Axis Stroke: 400 mm
ETS-650P1-055045-MBNCombination Direction: P1 | 1st-Axis Stroke: 550 mm | 2nd-Axis Stroke: 450 mm
ETS-650P1-055050-MBNCombination Direction: P1 | 1st-Axis Stroke: 550 mm | 2nd-Axis Stroke: 500 mm
ETS-650P1-055055-MBNCombination Direction: P1 | 1st-Axis Stroke: 550 mm | 2nd-Axis Stroke: 550 mm
ETS-650P1-060005-MBNCombination Direction: P1 | 1st-Axis Stroke: 600 mm | 2nd-Axis Stroke: 50 mm
ETS-650P1-060010-MBNCombination Direction: P1 | 1st-Axis Stroke: 600 mm | 2nd-Axis Stroke: 100 mm
ETS-650P1-060015-MBNCombination Direction: P1 | 1st-Axis Stroke: 600 mm | 2nd-Axis Stroke: 150 mm
ETS-650P1-060020-MBNCombination Direction: P1 | 1st-Axis Stroke: 600 mm | 2nd-Axis Stroke: 200 mm
ETS-650P1-060025-MBNCombination Direction: P1 | 1st-Axis Stroke: 600 mm | 2nd-Axis Stroke: 250 mm
ETS-650P1-060030-MBNCombination Direction: P1 | 1st-Axis Stroke: 600 mm | 2nd-Axis Stroke: 300 mm
ETS-650P1-060035-MBNCombination Direction: P1 | 1st-Axis Stroke: 600 mm | 2nd-Axis Stroke: 350 mm
ETS-650P1-060040-MBNCombination Direction: P1 | 1st-Axis Stroke: 600 mm | 2nd-Axis Stroke: 400 mm
ETS-650P1-060045-MBNCombination Direction: P1 | 1st-Axis Stroke: 600 mm | 2nd-Axis Stroke: 450 mm
ETS-650P1-060050-MBNCombination Direction: P1 | 1st-Axis Stroke: 600 mm | 2nd-Axis Stroke: 500 mm
ETS-650P1-060055-MBNCombination Direction: P1 | 1st-Axis Stroke: 600 mm | 2nd-Axis Stroke: 550 mm
ETS-650P1-065005-MBNCombination Direction: P1 | 1st-Axis Stroke: 650 mm | 2nd-Axis Stroke: 50 mm
ETS-650P1-065010-MBNCombination Direction: P1 | 1st-Axis Stroke: 650 mm | 2nd-Axis Stroke: 100 mm
ETS-650P1-065015-MBNCombination Direction: P1 | 1st-Axis Stroke: 650 mm | 2nd-Axis Stroke: 150 mm
ETS-650P1-065020-MBNCombination Direction: P1 | 1st-Axis Stroke: 650 mm | 2nd-Axis Stroke: 200 mm
ETS-650P1-065025-MBNCombination Direction: P1 | 1st-Axis Stroke: 650 mm | 2nd-Axis Stroke: 250 mm
ETS-650P1-065030-MBNCombination Direction: P1 | 1st-Axis Stroke: 650 mm | 2nd-Axis Stroke: 300 mm
ETS-650P1-065035-MBNCombination Direction: P1 | 1st-Axis Stroke: 650 mm | 2nd-Axis Stroke: 350 mm
ETS-650P1-065040-MBNCombination Direction: P1 | 1st-Axis Stroke: 650 mm | 2nd-Axis Stroke: 400 mm
ETS-650P1-065045-MBNCombination Direction: P1 | 1st-Axis Stroke: 650 mm | 2nd-Axis Stroke: 450 mm
ETS-650P1-065050-MBNCombination Direction: P1 | 1st-Axis Stroke: 650 mm | 2nd-Axis Stroke: 500 mm
ETS-650P1-065055-MBNCombination Direction: P1 | 1st-Axis Stroke: 650 mm | 2nd-Axis Stroke: 550 mm
ETS-650P1-070005-MBNCombination Direction: P1 | 1st-Axis Stroke: 700 mm | 2nd-Axis Stroke: 50 mm
ETS-650P1-070010-MBNCombination Direction: P1 | 1st-Axis Stroke: 700 mm | 2nd-Axis Stroke: 100 mm
ETS-650P1-070015-MBNCombination Direction: P1 | 1st-Axis Stroke: 700 mm | 2nd-Axis Stroke: 150 mm
ETS-650P1-070020-MBNCombination Direction: P1 | 1st-Axis Stroke: 700 mm | 2nd-Axis Stroke: 200 mm
ETS-650P1-070025-MBNCombination Direction: P1 | 1st-Axis Stroke: 700 mm | 2nd-Axis Stroke: 250 mm
ETS-650P1-070030-MBNCombination Direction: P1 | 1st-Axis Stroke: 700 mm | 2nd-Axis Stroke: 300 mm
ETS-650P1-070035-MBNCombination Direction: P1 | 1st-Axis Stroke: 700 mm | 2nd-Axis Stroke: 350 mm
ETS-650P1-070040-MBNCombination Direction: P1 | 1st-Axis Stroke: 700 mm | 2nd-Axis Stroke: 400 mm
ETS-650P1-070045-MBNCombination Direction: P1 | 1st-Axis Stroke: 700 mm | 2nd-Axis Stroke: 450 mm
ETS-650P1-070050-MBNCombination Direction: P1 | 1st-Axis Stroke: 700 mm | 2nd-Axis Stroke: 500 mm
ETS-650P1-070055-MBNCombination Direction: P1 | 1st-Axis Stroke: 700 mm | 2nd-Axis Stroke: 550 mm
ETS-650P1-075005-MBNCombination Direction: P1 | 1st-Axis Stroke: 750 mm | 2nd-Axis Stroke: 50 mm
ETS-650P1-075010-MBNCombination Direction: P1 | 1st-Axis Stroke: 750 mm | 2nd-Axis Stroke: 100 mm
ETS-650P1-075015-MBNCombination Direction: P1 | 1st-Axis Stroke: 750 mm | 2nd-Axis Stroke: 150 mm
ETS-650P1-075020-MBNCombination Direction: P1 | 1st-Axis Stroke: 750 mm | 2nd-Axis Stroke: 200 mm
ETS-650P1-075025-MBNCombination Direction: P1 | 1st-Axis Stroke: 750 mm | 2nd-Axis Stroke: 250 mm
ETS-650P1-075030-MBNCombination Direction: P1 | 1st-Axis Stroke: 750 mm | 2nd-Axis Stroke: 300 mm
ETS-650P1-075035-MBNCombination Direction: P1 | 1st-Axis Stroke: 750 mm | 2nd-Axis Stroke: 350 mm
ETS-650P1-075040-MBNCombination Direction: P1 | 1st-Axis Stroke: 750 mm | 2nd-Axis Stroke: 400 mm
ETS-650P1-075045-MBNCombination Direction: P1 | 1st-Axis Stroke: 750 mm | 2nd-Axis Stroke: 450 mm
ETS-650P1-075050-MBNCombination Direction: P1 | 1st-Axis Stroke: 750 mm | 2nd-Axis Stroke: 500 mm
ETS-650P1-075055-MBNCombination Direction: P1 | 1st-Axis Stroke: 750 mm | 2nd-Axis Stroke: 550 mm
ETS-650P1-080005-MBNCombination Direction: P1 | 1st-Axis Stroke: 800 mm | 2nd-Axis Stroke: 50 mm
ETS-650P1-080010-MBNCombination Direction: P1 | 1st-Axis Stroke: 800 mm | 2nd-Axis Stroke: 100 mm
ETS-650P1-080015-MBNCombination Direction: P1 | 1st-Axis Stroke: 800 mm | 2nd-Axis Stroke: 150 mm
ETS-650P1-080020-MBNCombination Direction: P1 | 1st-Axis Stroke: 800 mm | 2nd-Axis Stroke: 200 mm
ETS-650P1-080025-MBNCombination Direction: P1 | 1st-Axis Stroke: 800 mm | 2nd-Axis Stroke: 250 mm
ETS-650P1-080030-MBNCombination Direction: P1 | 1st-Axis Stroke: 800 mm | 2nd-Axis Stroke: 300 mm
ETS-650P1-080035-MBNCombination Direction: P1 | 1st-Axis Stroke: 800 mm | 2nd-Axis Stroke: 350 mm
ETS-650P1-080040-MBNCombination Direction: P1 | 1st-Axis Stroke: 800 mm | 2nd-Axis Stroke: 400 mm
ETS-650P1-080045-MBNCombination Direction: P1 | 1st-Axis Stroke: 800 mm | 2nd-Axis Stroke: 450 mm
ETS-650P1-080050-MBNCombination Direction: P1 | 1st-Axis Stroke: 800 mm | 2nd-Axis Stroke: 500 mm
ETS-650P1-080055-MBNCombination Direction: P1 | 1st-Axis Stroke: 800 mm | 2nd-Axis Stroke: 550 mm
ETS-650P1-085005-MBNCombination Direction: P1 | 1st-Axis Stroke: 850 mm | 2nd-Axis Stroke: 50 mm
ETS-650P1-085010-MBNCombination Direction: P1 | 1st-Axis Stroke: 850 mm | 2nd-Axis Stroke: 100 mm
ETS-650P1-085015-MBNCombination Direction: P1 | 1st-Axis Stroke: 850 mm | 2nd-Axis Stroke: 150 mm
ETS-650P1-085020-MBNCombination Direction: P1 | 1st-Axis Stroke: 850 mm | 2nd-Axis Stroke: 200 mm
ETS-650P1-085025-MBNCombination Direction: P1 | 1st-Axis Stroke: 850 mm | 2nd-Axis Stroke: 250 mm
ETS-650P1-085030-MBNCombination Direction: P1 | 1st-Axis Stroke: 850 mm | 2nd-Axis Stroke: 300 mm
ETS-650P1-085035-MBNCombination Direction: P1 | 1st-Axis Stroke: 850 mm | 2nd-Axis Stroke: 350 mm
ETS-650P1-085040-MBNCombination Direction: P1 | 1st-Axis Stroke: 850 mm | 2nd-Axis Stroke: 400 mm
ETS-650P1-085045-MBNCombination Direction: P1 | 1st-Axis Stroke: 850 mm | 2nd-Axis Stroke: 450 mm
ETS-650P1-085050-MBNCombination Direction: P1 | 1st-Axis Stroke: 850 mm | 2nd-Axis Stroke: 500 mm
ETS-650P1-085055-MBNCombination Direction: P1 | 1st-Axis Stroke: 850 mm | 2nd-Axis Stroke: 550 mm
ETS-650P1-090005-MBNCombination Direction: P1 | 1st-Axis Stroke: 900 mm | 2nd-Axis Stroke: 50 mm
ETS-650P1-090010-MBNCombination Direction: P1 | 1st-Axis Stroke: 900 mm | 2nd-Axis Stroke: 100 mm
ETS-650P1-090015-MBNCombination Direction: P1 | 1st-Axis Stroke: 900 mm | 2nd-Axis Stroke: 150 mm
ETS-650P1-090020-MBNCombination Direction: P1 | 1st-Axis Stroke: 900 mm | 2nd-Axis Stroke: 200 mm
ETS-650P1-090025-MBNCombination Direction: P1 | 1st-Axis Stroke: 900 mm | 2nd-Axis Stroke: 250 mm
ETS-650P1-090030-MBNCombination Direction: P1 | 1st-Axis Stroke: 900 mm | 2nd-Axis Stroke: 300 mm
ETS-650P1-090035-MBNCombination Direction: P1 | 1st-Axis Stroke: 900 mm | 2nd-Axis Stroke: 350 mm
ETS-650P1-090040-MBNCombination Direction: P1 | 1st-Axis Stroke: 900 mm | 2nd-Axis Stroke: 400 mm
ETS-650P1-090045-MBNCombination Direction: P1 | 1st-Axis Stroke: 900 mm | 2nd-Axis Stroke: 450 mm
ETS-650P1-090050-MBNCombination Direction: P1 | 1st-Axis Stroke: 900 mm | 2nd-Axis Stroke: 500 mm
ETS-650P1-090055-MBNCombination Direction: P1 | 1st-Axis Stroke: 900 mm | 2nd-Axis Stroke: 550 mm
ETS-650P1-095005-MBNCombination Direction: P1 | 1st-Axis Stroke: 950 mm | 2nd-Axis Stroke: 50 mm
ETS-650P1-095010-MBNCombination Direction: P1 | 1st-Axis Stroke: 950 mm | 2nd-Axis Stroke: 100 mm
ETS-650P1-095015-MBNCombination Direction: P1 | 1st-Axis Stroke: 950 mm | 2nd-Axis Stroke: 150 mm
ETS-650P1-095020-MBNCombination Direction: P1 | 1st-Axis Stroke: 950 mm | 2nd-Axis Stroke: 200 mm
ETS-650P1-095025-MBNCombination Direction: P1 | 1st-Axis Stroke: 950 mm | 2nd-Axis Stroke: 250 mm
ETS-650P1-095030-MBNCombination Direction: P1 | 1st-Axis Stroke: 950 mm | 2nd-Axis Stroke: 300 mm
ETS-650P1-095035-MBNCombination Direction: P1 | 1st-Axis Stroke: 950 mm | 2nd-Axis Stroke: 350 mm
ETS-650P1-095040-MBNCombination Direction: P1 | 1st-Axis Stroke: 950 mm | 2nd-Axis Stroke: 400 mm
ETS-650P1-095045-MBNCombination Direction: P1 | 1st-Axis Stroke: 950 mm | 2nd-Axis Stroke: 450 mm
ETS-650P1-095050-MBNCombination Direction: P1 | 1st-Axis Stroke: 950 mm | 2nd-Axis Stroke: 500 mm
ETS-650P1-095055-MBNCombination Direction: P1 | 1st-Axis Stroke: 950 mm | 2nd-Axis Stroke: 550 mm
ETS-650P1-100005-MBNCombination Direction: P1 | 1st-Axis Stroke: 1000 mm | 2nd-Axis Stroke: 50 mm
ETS-650P1-100010-MBNCombination Direction: P1 | 1st-Axis Stroke: 1000 mm | 2nd-Axis Stroke: 100 mm
ETS-650P1-100015-MBNCombination Direction: P1 | 1st-Axis Stroke: 1000 mm | 2nd-Axis Stroke: 150 mm
ETS-650P1-100020-MBNCombination Direction: P1 | 1st-Axis Stroke: 1000 mm | 2nd-Axis Stroke: 200 mm
ETS-650P1-100025-MBNCombination Direction: P1 | 1st-Axis Stroke: 1000 mm | 2nd-Axis Stroke: 250 mm
ETS-650P1-100030-MBNCombination Direction: P1 | 1st-Axis Stroke: 1000 mm | 2nd-Axis Stroke: 300 mm
ETS-650P1-100035-MBNCombination Direction: P1 | 1st-Axis Stroke: 1000 mm | 2nd-Axis Stroke: 350 mm
ETS-650P1-100040-MBNCombination Direction: P1 | 1st-Axis Stroke: 1000 mm | 2nd-Axis Stroke: 400 mm
ETS-650P1-100045-MBNCombination Direction: P1 | 1st-Axis Stroke: 1000 mm | 2nd-Axis Stroke: 450 mm
ETS-650P1-100050-MBNCombination Direction: P1 | 1st-Axis Stroke: 1000 mm | 2nd-Axis Stroke: 500 mm
ETS-650P1-100055-MBNCombination Direction: P1 | 1st-Axis Stroke: 1000 mm | 2nd-Axis Stroke: 550 mm
ETS-650P1-105005-MBNCombination Direction: P1 | 1st-Axis Stroke: 1050 mm | 2nd-Axis Stroke: 50 mm
ETS-650P1-105010-MBNCombination Direction: P1 | 1st-Axis Stroke: 1050 mm | 2nd-Axis Stroke: 100 mm
ETS-650P1-105015-MBNCombination Direction: P1 | 1st-Axis Stroke: 1050 mm | 2nd-Axis Stroke: 150 mm
ETS-650P1-105020-MBNCombination Direction: P1 | 1st-Axis Stroke: 1050 mm | 2nd-Axis Stroke: 200 mm
ETS-650P1-105025-MBNCombination Direction: P1 | 1st-Axis Stroke: 1050 mm | 2nd-Axis Stroke: 250 mm
ETS-650P1-105030-MBNCombination Direction: P1 | 1st-Axis Stroke: 1050 mm | 2nd-Axis Stroke: 300 mm
ETS-650P1-105035-MBNCombination Direction: P1 | 1st-Axis Stroke: 1050 mm | 2nd-Axis Stroke: 350 mm
ETS-650P1-105040-MBNCombination Direction: P1 | 1st-Axis Stroke: 1050 mm | 2nd-Axis Stroke: 400 mm
ETS-650P1-105045-MBNCombination Direction: P1 | 1st-Axis Stroke: 1050 mm | 2nd-Axis Stroke: 450 mm
ETS-650P1-105050-MBNCombination Direction: P1 | 1st-Axis Stroke: 1050 mm | 2nd-Axis Stroke: 500 mm
ETS-650P1-105055-MBNCombination Direction: P1 | 1st-Axis Stroke: 1050 mm | 2nd-Axis Stroke: 550 mm
ETS-650P2-010005-MBNCombination Direction: P2 | 1st-Axis Stroke: 100 mm | 2nd-Axis Stroke: 50 mm
ETS-650P2-010010-MBNCombination Direction: P2 | 1st-Axis Stroke: 100 mm | 2nd-Axis Stroke: 100 mm
ETS-650P2-010015-MBNCombination Direction: P2 | 1st-Axis Stroke: 100 mm | 2nd-Axis Stroke: 150 mm
ETS-650P2-010020-MBNCombination Direction: P2 | 1st-Axis Stroke: 100 mm | 2nd-Axis Stroke: 200 mm
ETS-650P2-010025-MBNCombination Direction: P2 | 1st-Axis Stroke: 100 mm | 2nd-Axis Stroke: 250 mm
ETS-650P2-010030-MBNCombination Direction: P2 | 1st-Axis Stroke: 100 mm | 2nd-Axis Stroke: 300 mm
ETS-650P2-010035-MBNCombination Direction: P2 | 1st-Axis Stroke: 100 mm | 2nd-Axis Stroke: 350 mm
ETS-650P2-010040-MBNCombination Direction: P2 | 1st-Axis Stroke: 100 mm | 2nd-Axis Stroke: 400 mm
ETS-650P2-010045-MBNCombination Direction: P2 | 1st-Axis Stroke: 100 mm | 2nd-Axis Stroke: 450 mm
ETS-650P2-010050-MBNCombination Direction: P2 | 1st-Axis Stroke: 100 mm | 2nd-Axis Stroke: 500 mm
ETS-650P2-010055-MBNCombination Direction: P2 | 1st-Axis Stroke: 100 mm | 2nd-Axis Stroke: 550 mm
ETS-650P2-015005-MBNCombination Direction: P2 | 1st-Axis Stroke: 150 mm | 2nd-Axis Stroke: 50 mm
ETS-650P2-015010-MBNCombination Direction: P2 | 1st-Axis Stroke: 150 mm | 2nd-Axis Stroke: 100 mm
ETS-650P2-015015-MBNCombination Direction: P2 | 1st-Axis Stroke: 150 mm | 2nd-Axis Stroke: 150 mm
ETS-650P2-015020-MBNCombination Direction: P2 | 1st-Axis Stroke: 150 mm | 2nd-Axis Stroke: 200 mm
ETS-650P2-015025-MBNCombination Direction: P2 | 1st-Axis Stroke: 150 mm | 2nd-Axis Stroke: 250 mm
ETS-650P2-015030-MBNCombination Direction: P2 | 1st-Axis Stroke: 150 mm | 2nd-Axis Stroke: 300 mm
ETS-650P2-015035-MBNCombination Direction: P2 | 1st-Axis Stroke: 150 mm | 2nd-Axis Stroke: 350 mm
ETS-650P2-015040-MBNCombination Direction: P2 | 1st-Axis Stroke: 150 mm | 2nd-Axis Stroke: 400 mm
ETS-650P2-015045-MBNCombination Direction: P2 | 1st-Axis Stroke: 150 mm | 2nd-Axis Stroke: 450 mm
ETS-650P2-015050-MBNCombination Direction: P2 | 1st-Axis Stroke: 150 mm | 2nd-Axis Stroke: 500 mm
ETS-650P2-015055-MBNCombination Direction: P2 | 1st-Axis Stroke: 150 mm | 2nd-Axis Stroke: 550 mm
ETS-650P2-020005-MBNCombination Direction: P2 | 1st-Axis Stroke: 200 mm | 2nd-Axis Stroke: 50 mm
ETS-650P2-020010-MBNCombination Direction: P2 | 1st-Axis Stroke: 200 mm | 2nd-Axis Stroke: 100 mm
ETS-650P2-020015-MBNCombination Direction: P2 | 1st-Axis Stroke: 200 mm | 2nd-Axis Stroke: 150 mm
ETS-650P2-020020-MBNCombination Direction: P2 | 1st-Axis Stroke: 200 mm | 2nd-Axis Stroke: 200 mm
ETS-650P2-020025-MBNCombination Direction: P2 | 1st-Axis Stroke: 200 mm | 2nd-Axis Stroke: 250 mm
ETS-650P2-020030-MBNCombination Direction: P2 | 1st-Axis Stroke: 200 mm | 2nd-Axis Stroke: 300 mm
ETS-650P2-020035-MBNCombination Direction: P2 | 1st-Axis Stroke: 200 mm | 2nd-Axis Stroke: 350 mm
ETS-650P2-020040-MBNCombination Direction: P2 | 1st-Axis Stroke: 200 mm | 2nd-Axis Stroke: 400 mm
ETS-650P2-020045-MBNCombination Direction: P2 | 1st-Axis Stroke: 200 mm | 2nd-Axis Stroke: 450 mm
ETS-650P2-020050-MBNCombination Direction: P2 | 1st-Axis Stroke: 200 mm | 2nd-Axis Stroke: 500 mm
ETS-650P2-020055-MBNCombination Direction: P2 | 1st-Axis Stroke: 200 mm | 2nd-Axis Stroke: 550 mm
ETS-650P2-025005-MBNCombination Direction: P2 | 1st-Axis Stroke: 250 mm | 2nd-Axis Stroke: 50 mm
ETS-650P2-025010-MBNCombination Direction: P2 | 1st-Axis Stroke: 250 mm | 2nd-Axis Stroke: 100 mm
ETS-650P2-025015-MBNCombination Direction: P2 | 1st-Axis Stroke: 250 mm | 2nd-Axis Stroke: 150 mm
ETS-650P2-025020-MBNCombination Direction: P2 | 1st-Axis Stroke: 250 mm | 2nd-Axis Stroke: 200 mm
ETS-650P2-025025-MBNCombination Direction: P2 | 1st-Axis Stroke: 250 mm | 2nd-Axis Stroke: 250 mm
ETS-650P2-025030-MBNCombination Direction: P2 | 1st-Axis Stroke: 250 mm | 2nd-Axis Stroke: 300 mm
ETS-650P2-025035-MBNCombination Direction: P2 | 1st-Axis Stroke: 250 mm | 2nd-Axis Stroke: 350 mm
ETS-650P2-025040-MBNCombination Direction: P2 | 1st-Axis Stroke: 250 mm | 2nd-Axis Stroke: 400 mm
ETS-650P2-025045-MBNCombination Direction: P2 | 1st-Axis Stroke: 250 mm | 2nd-Axis Stroke: 450 mm
ETS-650P2-025050-MBNCombination Direction: P2 | 1st-Axis Stroke: 250 mm | 2nd-Axis Stroke: 500 mm
ETS-650P2-025055-MBNCombination Direction: P2 | 1st-Axis Stroke: 250 mm | 2nd-Axis Stroke: 550 mm
ETS-650P2-030005-MBNCombination Direction: P2 | 1st-Axis Stroke: 300 mm | 2nd-Axis Stroke: 50 mm
ETS-650P2-030010-MBNCombination Direction: P2 | 1st-Axis Stroke: 300 mm | 2nd-Axis Stroke: 100 mm
ETS-650P2-030015-MBNCombination Direction: P2 | 1st-Axis Stroke: 300 mm | 2nd-Axis Stroke: 150 mm
ETS-650P2-030020-MBNCombination Direction: P2 | 1st-Axis Stroke: 300 mm | 2nd-Axis Stroke: 200 mm
ETS-650P2-030025-MBNCombination Direction: P2 | 1st-Axis Stroke: 300 mm | 2nd-Axis Stroke: 250 mm
ETS-650P2-030030-MBNCombination Direction: P2 | 1st-Axis Stroke: 300 mm | 2nd-Axis Stroke: 300 mm
ETS-650P2-030035-MBNCombination Direction: P2 | 1st-Axis Stroke: 300 mm | 2nd-Axis Stroke: 350 mm
ETS-650P2-030040-MBNCombination Direction: P2 | 1st-Axis Stroke: 300 mm | 2nd-Axis Stroke: 400 mm
ETS-650P2-030045-MBNCombination Direction: P2 | 1st-Axis Stroke: 300 mm | 2nd-Axis Stroke: 450 mm
ETS-650P2-030050-MBNCombination Direction: P2 | 1st-Axis Stroke: 300 mm | 2nd-Axis Stroke: 500 mm
ETS-650P2-030055-MBNCombination Direction: P2 | 1st-Axis Stroke: 300 mm | 2nd-Axis Stroke: 550 mm
ETS-650P2-035005-MBNCombination Direction: P2 | 1st-Axis Stroke: 350 mm | 2nd-Axis Stroke: 50 mm
ETS-650P2-035010-MBNCombination Direction: P2 | 1st-Axis Stroke: 350 mm | 2nd-Axis Stroke: 100 mm
ETS-650P2-035015-MBNCombination Direction: P2 | 1st-Axis Stroke: 350 mm | 2nd-Axis Stroke: 150 mm
ETS-650P2-035020-MBNCombination Direction: P2 | 1st-Axis Stroke: 350 mm | 2nd-Axis Stroke: 200 mm
ETS-650P2-035025-MBNCombination Direction: P2 | 1st-Axis Stroke: 350 mm | 2nd-Axis Stroke: 250 mm
ETS-650P2-035030-MBNCombination Direction: P2 | 1st-Axis Stroke: 350 mm | 2nd-Axis Stroke: 300 mm
ETS-650P2-035035-MBNCombination Direction: P2 | 1st-Axis Stroke: 350 mm | 2nd-Axis Stroke: 350 mm
ETS-650P2-035040-MBNCombination Direction: P2 | 1st-Axis Stroke: 350 mm | 2nd-Axis Stroke: 400 mm
ETS-650P2-035045-MBNCombination Direction: P2 | 1st-Axis Stroke: 350 mm | 2nd-Axis Stroke: 450 mm
ETS-650P2-035050-MBNCombination Direction: P2 | 1st-Axis Stroke: 350 mm | 2nd-Axis Stroke: 500 mm
ETS-650P2-035055-MBNCombination Direction: P2 | 1st-Axis Stroke: 350 mm | 2nd-Axis Stroke: 550 mm
ETS-650P2-040005-MBNCombination Direction: P2 | 1st-Axis Stroke: 400 mm | 2nd-Axis Stroke: 50 mm
ETS-650P2-040010-MBNCombination Direction: P2 | 1st-Axis Stroke: 400 mm | 2nd-Axis Stroke: 100 mm
ETS-650P2-040015-MBNCombination Direction: P2 | 1st-Axis Stroke: 400 mm | 2nd-Axis Stroke: 150 mm
ETS-650P2-040020-MBNCombination Direction: P2 | 1st-Axis Stroke: 400 mm | 2nd-Axis Stroke: 200 mm
ETS-650P2-040025-MBNCombination Direction: P2 | 1st-Axis Stroke: 400 mm | 2nd-Axis Stroke: 250 mm
ETS-650P2-040030-MBNCombination Direction: P2 | 1st-Axis Stroke: 400 mm | 2nd-Axis Stroke: 300 mm
ETS-650P2-040035-MBNCombination Direction: P2 | 1st-Axis Stroke: 400 mm | 2nd-Axis Stroke: 350 mm
ETS-650P2-040040-MBNCombination Direction: P2 | 1st-Axis Stroke: 400 mm | 2nd-Axis Stroke: 400 mm
ETS-650P2-040045-MBNCombination Direction: P2 | 1st-Axis Stroke: 400 mm | 2nd-Axis Stroke: 450 mm
ETS-650P2-040050-MBNCombination Direction: P2 | 1st-Axis Stroke: 400 mm | 2nd-Axis Stroke: 500 mm
ETS-650P2-040055-MBNCombination Direction: P2 | 1st-Axis Stroke: 400 mm | 2nd-Axis Stroke: 550 mm
ETS-650P2-045005-MBNCombination Direction: P2 | 1st-Axis Stroke: 450 mm | 2nd-Axis Stroke: 50 mm
ETS-650P2-045010-MBNCombination Direction: P2 | 1st-Axis Stroke: 450 mm | 2nd-Axis Stroke: 100 mm
ETS-650P2-045015-MBNCombination Direction: P2 | 1st-Axis Stroke: 450 mm | 2nd-Axis Stroke: 150 mm
ETS-650P2-045020-MBNCombination Direction: P2 | 1st-Axis Stroke: 450 mm | 2nd-Axis Stroke: 200 mm
ETS-650P2-045025-MBNCombination Direction: P2 | 1st-Axis Stroke: 450 mm | 2nd-Axis Stroke: 250 mm
ETS-650P2-045030-MBNCombination Direction: P2 | 1st-Axis Stroke: 450 mm | 2nd-Axis Stroke: 300 mm
ETS-650P2-045035-MBNCombination Direction: P2 | 1st-Axis Stroke: 450 mm | 2nd-Axis Stroke: 350 mm
ETS-650P2-045040-MBNCombination Direction: P2 | 1st-Axis Stroke: 450 mm | 2nd-Axis Stroke: 400 mm
ETS-650P2-045045-MBNCombination Direction: P2 | 1st-Axis Stroke: 450 mm | 2nd-Axis Stroke: 450 mm
ETS-650P2-045050-MBNCombination Direction: P2 | 1st-Axis Stroke: 450 mm | 2nd-Axis Stroke: 500 mm
ETS-650P2-045055-MBNCombination Direction: P2 | 1st-Axis Stroke: 450 mm | 2nd-Axis Stroke: 550 mm
ETS-650P2-050005-MBNCombination Direction: P2 | 1st-Axis Stroke: 500 mm | 2nd-Axis Stroke: 50 mm
ETS-650P2-050010-MBNCombination Direction: P2 | 1st-Axis Stroke: 500 mm | 2nd-Axis Stroke: 100 mm
ETS-650P2-050015-MBNCombination Direction: P2 | 1st-Axis Stroke: 500 mm | 2nd-Axis Stroke: 150 mm
ETS-650P2-050020-MBNCombination Direction: P2 | 1st-Axis Stroke: 500 mm | 2nd-Axis Stroke: 200 mm
ETS-650P2-050025-MBNCombination Direction: P2 | 1st-Axis Stroke: 500 mm | 2nd-Axis Stroke: 250 mm
ETS-650P2-050030-MBNCombination Direction: P2 | 1st-Axis Stroke: 500 mm | 2nd-Axis Stroke: 300 mm
ETS-650P2-050035-MBNCombination Direction: P2 | 1st-Axis Stroke: 500 mm | 2nd-Axis Stroke: 350 mm
ETS-650P2-050040-MBNCombination Direction: P2 | 1st-Axis Stroke: 500 mm | 2nd-Axis Stroke: 400 mm
ETS-650P2-050045-MBNCombination Direction: P2 | 1st-Axis Stroke: 500 mm | 2nd-Axis Stroke: 450 mm
ETS-650P2-050050-MBNCombination Direction: P2 | 1st-Axis Stroke: 500 mm | 2nd-Axis Stroke: 500 mm
ETS-650P2-050055-MBNCombination Direction: P2 | 1st-Axis Stroke: 500 mm | 2nd-Axis Stroke: 550 mm
ETS-650P2-055005-MBNCombination Direction: P2 | 1st-Axis Stroke: 550 mm | 2nd-Axis Stroke: 50 mm
ETS-650P2-055010-MBNCombination Direction: P2 | 1st-Axis Stroke: 550 mm | 2nd-Axis Stroke: 100 mm
ETS-650P2-055015-MBNCombination Direction: P2 | 1st-Axis Stroke: 550 mm | 2nd-Axis Stroke: 150 mm
ETS-650P2-055020-MBNCombination Direction: P2 | 1st-Axis Stroke: 550 mm | 2nd-Axis Stroke: 200 mm
ETS-650P2-055025-MBNCombination Direction: P2 | 1st-Axis Stroke: 550 mm | 2nd-Axis Stroke: 250 mm
ETS-650P2-055030-MBNCombination Direction: P2 | 1st-Axis Stroke: 550 mm | 2nd-Axis Stroke: 300 mm
ETS-650P2-055035-MBNCombination Direction: P2 | 1st-Axis Stroke: 550 mm | 2nd-Axis Stroke: 350 mm
ETS-650P2-055040-MBNCombination Direction: P2 | 1st-Axis Stroke: 550 mm | 2nd-Axis Stroke: 400 mm
ETS-650P2-055045-MBNCombination Direction: P2 | 1st-Axis Stroke: 550 mm | 2nd-Axis Stroke: 450 mm
ETS-650P2-055050-MBNCombination Direction: P2 | 1st-Axis Stroke: 550 mm | 2nd-Axis Stroke: 500 mm
ETS-650P2-055055-MBNCombination Direction: P2 | 1st-Axis Stroke: 550 mm | 2nd-Axis Stroke: 550 mm
ETS-650P2-060005-MBNCombination Direction: P2 | 1st-Axis Stroke: 600 mm | 2nd-Axis Stroke: 50 mm
ETS-650P2-060010-MBNCombination Direction: P2 | 1st-Axis Stroke: 600 mm | 2nd-Axis Stroke: 100 mm
ETS-650P2-060015-MBNCombination Direction: P2 | 1st-Axis Stroke: 600 mm | 2nd-Axis Stroke: 150 mm
ETS-650P2-060020-MBNCombination Direction: P2 | 1st-Axis Stroke: 600 mm | 2nd-Axis Stroke: 200 mm
ETS-650P2-060025-MBNCombination Direction: P2 | 1st-Axis Stroke: 600 mm | 2nd-Axis Stroke: 250 mm
ETS-650P2-060030-MBNCombination Direction: P2 | 1st-Axis Stroke: 600 mm | 2nd-Axis Stroke: 300 mm
ETS-650P2-060035-MBNCombination Direction: P2 | 1st-Axis Stroke: 600 mm | 2nd-Axis Stroke: 350 mm
ETS-650P2-060040-MBNCombination Direction: P2 | 1st-Axis Stroke: 600 mm | 2nd-Axis Stroke: 400 mm
ETS-650P2-060045-MBNCombination Direction: P2 | 1st-Axis Stroke: 600 mm | 2nd-Axis Stroke: 450 mm
ETS-650P2-060050-MBNCombination Direction: P2 | 1st-Axis Stroke: 600 mm | 2nd-Axis Stroke: 500 mm
ETS-650P2-060055-MBNCombination Direction: P2 | 1st-Axis Stroke: 600 mm | 2nd-Axis Stroke: 550 mm
ETS-650P2-065005-MBNCombination Direction: P2 | 1st-Axis Stroke: 650 mm | 2nd-Axis Stroke: 50 mm
ETS-650P2-065010-MBNCombination Direction: P2 | 1st-Axis Stroke: 650 mm | 2nd-Axis Stroke: 100 mm
ETS-650P2-065015-MBNCombination Direction: P2 | 1st-Axis Stroke: 650 mm | 2nd-Axis Stroke: 150 mm
ETS-650P2-065020-MBNCombination Direction: P2 | 1st-Axis Stroke: 650 mm | 2nd-Axis Stroke: 200 mm
ETS-650P2-065025-MBNCombination Direction: P2 | 1st-Axis Stroke: 650 mm | 2nd-Axis Stroke: 250 mm
ETS-650P2-065030-MBNCombination Direction: P2 | 1st-Axis Stroke: 650 mm | 2nd-Axis Stroke: 300 mm
ETS-650P2-065035-MBNCombination Direction: P2 | 1st-Axis Stroke: 650 mm | 2nd-Axis Stroke: 350 mm
ETS-650P2-065040-MBNCombination Direction: P2 | 1st-Axis Stroke: 650 mm | 2nd-Axis Stroke: 400 mm
ETS-650P2-065045-MBNCombination Direction: P2 | 1st-Axis Stroke: 650 mm | 2nd-Axis Stroke: 450 mm
ETS-650P2-065050-MBNCombination Direction: P2 | 1st-Axis Stroke: 650 mm | 2nd-Axis Stroke: 500 mm
ETS-650P2-065055-MBNCombination Direction: P2 | 1st-Axis Stroke: 650 mm | 2nd-Axis Stroke: 550 mm
ETS-650P2-070005-MBNCombination Direction: P2 | 1st-Axis Stroke: 700 mm | 2nd-Axis Stroke: 50 mm
ETS-650P2-070010-MBNCombination Direction: P2 | 1st-Axis Stroke: 700 mm | 2nd-Axis Stroke: 100 mm
ETS-650P2-070015-MBNCombination Direction: P2 | 1st-Axis Stroke: 700 mm | 2nd-Axis Stroke: 150 mm
ETS-650P2-070020-MBNCombination Direction: P2 | 1st-Axis Stroke: 700 mm | 2nd-Axis Stroke: 200 mm
ETS-650P2-070025-MBNCombination Direction: P2 | 1st-Axis Stroke: 700 mm | 2nd-Axis Stroke: 250 mm
ETS-650P2-070030-MBNCombination Direction: P2 | 1st-Axis Stroke: 700 mm | 2nd-Axis Stroke: 300 mm
ETS-650P2-070035-MBNCombination Direction: P2 | 1st-Axis Stroke: 700 mm | 2nd-Axis Stroke: 350 mm
ETS-650P2-070040-MBNCombination Direction: P2 | 1st-Axis Stroke: 700 mm | 2nd-Axis Stroke: 400 mm
ETS-650P2-070045-MBNCombination Direction: P2 | 1st-Axis Stroke: 700 mm | 2nd-Axis Stroke: 450 mm
ETS-650P2-070050-MBNCombination Direction: P2 | 1st-Axis Stroke: 700 mm | 2nd-Axis Stroke: 500 mm
ETS-650P2-070055-MBNCombination Direction: P2 | 1st-Axis Stroke: 700 mm | 2nd-Axis Stroke: 550 mm
ETS-650P2-075005-MBNCombination Direction: P2 | 1st-Axis Stroke: 750 mm | 2nd-Axis Stroke: 50 mm
ETS-650P2-075010-MBNCombination Direction: P2 | 1st-Axis Stroke: 750 mm | 2nd-Axis Stroke: 100 mm
ETS-650P2-075015-MBNCombination Direction: P2 | 1st-Axis Stroke: 750 mm | 2nd-Axis Stroke: 150 mm
ETS-650P2-075020-MBNCombination Direction: P2 | 1st-Axis Stroke: 750 mm | 2nd-Axis Stroke: 200 mm
ETS-650P2-075025-MBNCombination Direction: P2 | 1st-Axis Stroke: 750 mm | 2nd-Axis Stroke: 250 mm
ETS-650P2-075030-MBNCombination Direction: P2 | 1st-Axis Stroke: 750 mm | 2nd-Axis Stroke: 300 mm
ETS-650P2-075035-MBNCombination Direction: P2 | 1st-Axis Stroke: 750 mm | 2nd-Axis Stroke: 350 mm
ETS-650P2-075040-MBNCombination Direction: P2 | 1st-Axis Stroke: 750 mm | 2nd-Axis Stroke: 400 mm
ETS-650P2-075045-MBNCombination Direction: P2 | 1st-Axis Stroke: 750 mm | 2nd-Axis Stroke: 450 mm
ETS-650P2-075050-MBNCombination Direction: P2 | 1st-Axis Stroke: 750 mm | 2nd-Axis Stroke: 500 mm
ETS-650P2-075055-MBNCombination Direction: P2 | 1st-Axis Stroke: 750 mm | 2nd-Axis Stroke: 550 mm
ETS-650P2-080005-MBNCombination Direction: P2 | 1st-Axis Stroke: 800 mm | 2nd-Axis Stroke: 50 mm
ETS-650P2-080010-MBNCombination Direction: P2 | 1st-Axis Stroke: 800 mm | 2nd-Axis Stroke: 100 mm
ETS-650P2-080015-MBNCombination Direction: P2 | 1st-Axis Stroke: 800 mm | 2nd-Axis Stroke: 150 mm
ETS-650P2-080020-MBNCombination Direction: P2 | 1st-Axis Stroke: 800 mm | 2nd-Axis Stroke: 200 mm
ETS-650P2-080025-MBNCombination Direction: P2 | 1st-Axis Stroke: 800 mm | 2nd-Axis Stroke: 250 mm
ETS-650P2-080030-MBNCombination Direction: P2 | 1st-Axis Stroke: 800 mm | 2nd-Axis Stroke: 300 mm
ETS-650P2-080035-MBNCombination Direction: P2 | 1st-Axis Stroke: 800 mm | 2nd-Axis Stroke: 350 mm
ETS-650P2-080040-MBNCombination Direction: P2 | 1st-Axis Stroke: 800 mm | 2nd-Axis Stroke: 400 mm
ETS-650P2-080045-MBNCombination Direction: P2 | 1st-Axis Stroke: 800 mm | 2nd-Axis Stroke: 450 mm
ETS-650P2-080050-MBNCombination Direction: P2 | 1st-Axis Stroke: 800 mm | 2nd-Axis Stroke: 500 mm
ETS-650P2-080055-MBNCombination Direction: P2 | 1st-Axis Stroke: 800 mm | 2nd-Axis Stroke: 550 mm
ETS-650P2-085005-MBNCombination Direction: P2 | 1st-Axis Stroke: 850 mm | 2nd-Axis Stroke: 50 mm
ETS-650P2-085010-MBNCombination Direction: P2 | 1st-Axis Stroke: 850 mm | 2nd-Axis Stroke: 100 mm
ETS-650P2-085015-MBNCombination Direction: P2 | 1st-Axis Stroke: 850 mm | 2nd-Axis Stroke: 150 mm
ETS-650P2-085020-MBNCombination Direction: P2 | 1st-Axis Stroke: 850 mm | 2nd-Axis Stroke: 200 mm
ETS-650P2-085025-MBNCombination Direction: P2 | 1st-Axis Stroke: 850 mm | 2nd-Axis Stroke: 250 mm
ETS-650P2-085030-MBNCombination Direction: P2 | 1st-Axis Stroke: 850 mm | 2nd-Axis Stroke: 300 mm
ETS-650P2-085035-MBNCombination Direction: P2 | 1st-Axis Stroke: 850 mm | 2nd-Axis Stroke: 350 mm
ETS-650P2-085040-MBNCombination Direction: P2 | 1st-Axis Stroke: 850 mm | 2nd-Axis Stroke: 400 mm
ETS-650P2-085045-MBNCombination Direction: P2 | 1st-Axis Stroke: 850 mm | 2nd-Axis Stroke: 450 mm
ETS-650P2-085050-MBNCombination Direction: P2 | 1st-Axis Stroke: 850 mm | 2nd-Axis Stroke: 500 mm
ETS-650P2-085055-MBNCombination Direction: P2 | 1st-Axis Stroke: 850 mm | 2nd-Axis Stroke: 550 mm
ETS-650P2-090005-MBNCombination Direction: P2 | 1st-Axis Stroke: 900 mm | 2nd-Axis Stroke: 50 mm
ETS-650P2-090010-MBNCombination Direction: P2 | 1st-Axis Stroke: 900 mm | 2nd-Axis Stroke: 100 mm
ETS-650P2-090015-MBNCombination Direction: P2 | 1st-Axis Stroke: 900 mm | 2nd-Axis Stroke: 150 mm
ETS-650P2-090020-MBNCombination Direction: P2 | 1st-Axis Stroke: 900 mm | 2nd-Axis Stroke: 200 mm
ETS-650P2-090025-MBNCombination Direction: P2 | 1st-Axis Stroke: 900 mm | 2nd-Axis Stroke: 250 mm
ETS-650P2-090030-MBNCombination Direction: P2 | 1st-Axis Stroke: 900 mm | 2nd-Axis Stroke: 300 mm
ETS-650P2-090035-MBNCombination Direction: P2 | 1st-Axis Stroke: 900 mm | 2nd-Axis Stroke: 350 mm
ETS-650P2-090040-MBNCombination Direction: P2 | 1st-Axis Stroke: 900 mm | 2nd-Axis Stroke: 400 mm
ETS-650P2-090045-MBNCombination Direction: P2 | 1st-Axis Stroke: 900 mm | 2nd-Axis Stroke: 450 mm
ETS-650P2-090050-MBNCombination Direction: P2 | 1st-Axis Stroke: 900 mm | 2nd-Axis Stroke: 500 mm
ETS-650P2-090055-MBNCombination Direction: P2 | 1st-Axis Stroke: 900 mm | 2nd-Axis Stroke: 550 mm
ETS-650P2-095005-MBNCombination Direction: P2 | 1st-Axis Stroke: 950 mm | 2nd-Axis Stroke: 50 mm
ETS-650P2-095010-MBNCombination Direction: P2 | 1st-Axis Stroke: 950 mm | 2nd-Axis Stroke: 100 mm
ETS-650P2-095015-MBNCombination Direction: P2 | 1st-Axis Stroke: 950 mm | 2nd-Axis Stroke: 150 mm
ETS-650P2-095020-MBNCombination Direction: P2 | 1st-Axis Stroke: 950 mm | 2nd-Axis Stroke: 200 mm
ETS-650P2-095025-MBNCombination Direction: P2 | 1st-Axis Stroke: 950 mm | 2nd-Axis Stroke: 250 mm
ETS-650P2-095030-MBNCombination Direction: P2 | 1st-Axis Stroke: 950 mm | 2nd-Axis Stroke: 300 mm
ETS-650P2-095035-MBNCombination Direction: P2 | 1st-Axis Stroke: 950 mm | 2nd-Axis Stroke: 350 mm
ETS-650P2-095040-MBNCombination Direction: P2 | 1st-Axis Stroke: 950 mm | 2nd-Axis Stroke: 400 mm
ETS-650P2-095045-MBNCombination Direction: P2 | 1st-Axis Stroke: 950 mm | 2nd-Axis Stroke: 450 mm
ETS-650P2-095050-MBNCombination Direction: P2 | 1st-Axis Stroke: 950 mm | 2nd-Axis Stroke: 500 mm
ETS-650P2-095055-MBNCombination Direction: P2 | 1st-Axis Stroke: 950 mm | 2nd-Axis Stroke: 550 mm
ETS-650P2-100005-MBNCombination Direction: P2 | 1st-Axis Stroke: 1000 mm | 2nd-Axis Stroke: 50 mm
ETS-650P2-100010-MBNCombination Direction: P2 | 1st-Axis Stroke: 1000 mm | 2nd-Axis Stroke: 100 mm
ETS-650P2-100015-MBNCombination Direction: P2 | 1st-Axis Stroke: 1000 mm | 2nd-Axis Stroke: 150 mm
ETS-650P2-100020-MBNCombination Direction: P2 | 1st-Axis Stroke: 1000 mm | 2nd-Axis Stroke: 200 mm
ETS-650P2-100025-MBNCombination Direction: P2 | 1st-Axis Stroke: 1000 mm | 2nd-Axis Stroke: 250 mm
ETS-650P2-100030-MBNCombination Direction: P2 | 1st-Axis Stroke: 1000 mm | 2nd-Axis Stroke: 300 mm
ETS-650P2-100035-MBNCombination Direction: P2 | 1st-Axis Stroke: 1000 mm | 2nd-Axis Stroke: 350 mm
ETS-650P2-100040-MBNCombination Direction: P2 | 1st-Axis Stroke: 1000 mm | 2nd-Axis Stroke: 400 mm
ETS-650P2-100045-MBNCombination Direction: P2 | 1st-Axis Stroke: 1000 mm | 2nd-Axis Stroke: 450 mm
ETS-650P2-100050-MBNCombination Direction: P2 | 1st-Axis Stroke: 1000 mm | 2nd-Axis Stroke: 500 mm
ETS-650P2-100055-MBNCombination Direction: P2 | 1st-Axis Stroke: 1000 mm | 2nd-Axis Stroke: 550 mm
ETS-650P2-105005-MBNCombination Direction: P2 | 1st-Axis Stroke: 1050 mm | 2nd-Axis Stroke: 50 mm
ETS-650P2-105010-MBNCombination Direction: P2 | 1st-Axis Stroke: 1050 mm | 2nd-Axis Stroke: 100 mm
ETS-650P2-105015-MBNCombination Direction: P2 | 1st-Axis Stroke: 1050 mm | 2nd-Axis Stroke: 150 mm
ETS-650P2-105020-MBNCombination Direction: P2 | 1st-Axis Stroke: 1050 mm | 2nd-Axis Stroke: 200 mm
ETS-650P2-105025-MBNCombination Direction: P2 | 1st-Axis Stroke: 1050 mm | 2nd-Axis Stroke: 250 mm
ETS-650P2-105030-MBNCombination Direction: P2 | 1st-Axis Stroke: 1050 mm | 2nd-Axis Stroke: 300 mm
ETS-650P2-105035-MBNCombination Direction: P2 | 1st-Axis Stroke: 1050 mm | 2nd-Axis Stroke: 350 mm
ETS-650P2-105040-MBNCombination Direction: P2 | 1st-Axis Stroke: 1050 mm | 2nd-Axis Stroke: 400 mm
ETS-650P2-105045-MBNCombination Direction: P2 | 1st-Axis Stroke: 1050 mm | 2nd-Axis Stroke: 450 mm
ETS-650P2-105050-MBNCombination Direction: P2 | 1st-Axis Stroke: 1050 mm | 2nd-Axis Stroke: 500 mm
ETS-650P2-105055-MBNCombination Direction: P2 | 1st-Axis Stroke: 1050 mm | 2nd-Axis Stroke: 550 mm
ETS-650P1Legacy code: base combination ETS-650P1 | Combination Direction: P1 | 1st-Axis Stroke: All | 2nd-Axis Stroke: All
ETS-650P2Legacy code: base combination ETS-650P2 | Combination Direction: P2 | 1st-Axis Stroke: All | 2nd-Axis Stroke: All

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Linear Motion & Bearings →
