CKD High Performance Oil Mist Filter MX1000-W to MX8000-W Series (Outlet Oil 0.001 mg/m3, Port 1/8 to 1)

CKD High Performance Oil Mist Filter MX1000-W to MX8000-W Series (Outlet Oil 0.001 mg/m3, Port 1/8 to 1)

High performance oil mist filter achieving secondary oil concentration of 0.001 mg/m3 or less, about 10 times the oil removal capacity of the M series.

Key features

  • Suited to optical equipment such as positioning devices and laser processing machines
  • Standard white series modular (SELEX FRL) design; units connect with joiners and brackets

Specifications

Fluid Compressed air
Working pressure (MPa) 0.1~1.0
Proof pressure (MPa) 1.5
Ambient/fluid temp. (℃) 5~60
MX1000-W Fluid: Compressed air | Working pressure (MPa): 0.1~1.0 | Proof pressure (MPa): 1.5 | Ambient/fluid temp. (℃): 5~60 | Drain capacity (cm3): 3 | Port size (Rc, NPT, G): 1/8, 1/4 | Mass (kg): 0.096
MX3000-W Fluid: Compressed air | Working pressure (MPa): 0.1~1.0 | Proof pressure (MPa): 1.5 | Ambient/fluid temp. (℃): 5~60 | Drain capacity (cm3): 45 | Port size (Rc, NPT, G): 1/4, 3/8 | Mass (kg): 0.28
MX4000-W Fluid: Compressed air | Working pressure (MPa): 0.1~1.0 | Proof pressure (MPa): 1.5 | Ambient/fluid temp. (℃): 5~60 | Drain capacity (cm3): 80 | Port size (Rc, NPT, G): 1/4, 3/8, 1/2 | Mass (kg): 0.52
MX6000-W Fluid: Compressed air | Working pressure (MPa): 0.1~1.0 | Proof pressure (MPa): 1.5 | Ambient/fluid temp. (℃): 5~60 | Drain capacity (cm3): 80 | Port size (Rc, NPT, G): 3/4, 1 | Mass (kg): 0.95
MX8000-W Fluid: Compressed air | Working pressure (MPa): 0.1~1.0 | Proof pressure (MPa): 1.5 | Ambient/fluid temp. (℃): 5~60 | Drain capacity (cm3): 80 | Port size (Rc, NPT, G): 3/4, 1 | Mass (kg): 1.35
Air FiltersCKD
5 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

CKD High Performance Oil Mist Filter MX1000-W to MX8000-W Series (Outlet Oil 0.001 mg/m3, Port 1/8 to 1)

Brand CKD·Air Filters

Available part numbers (5)

MX1000-W, MX3000-W, MX4000-W, MX6000-W, MX8000-W

How to order

Send the CKD part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
MX1000-WFluid: Compressed air | Working pressure (MPa): 0.1~1.0 | Proof pressure (MPa): 1.5 | Ambient/fluid temp. (℃): 5~60 | Drain capacity (cm3): 3 | Port size (Rc, NPT, G): 1/8, 1/4 | Mass (kg): 0.096
MX3000-WFluid: Compressed air | Working pressure (MPa): 0.1~1.0 | Proof pressure (MPa): 1.5 | Ambient/fluid temp. (℃): 5~60 | Drain capacity (cm3): 45 | Port size (Rc, NPT, G): 1/4, 3/8 | Mass (kg): 0.28
MX4000-WFluid: Compressed air | Working pressure (MPa): 0.1~1.0 | Proof pressure (MPa): 1.5 | Ambient/fluid temp. (℃): 5~60 | Drain capacity (cm3): 80 | Port size (Rc, NPT, G): 1/4, 3/8, 1/2 | Mass (kg): 0.52
MX6000-WFluid: Compressed air | Working pressure (MPa): 0.1~1.0 | Proof pressure (MPa): 1.5 | Ambient/fluid temp. (℃): 5~60 | Drain capacity (cm3): 80 | Port size (Rc, NPT, G): 3/4, 1 | Mass (kg): 0.95
MX8000-WFluid: Compressed air | Working pressure (MPa): 0.1~1.0 | Proof pressure (MPa): 1.5 | Ambient/fluid temp. (℃): 5~60 | Drain capacity (cm3): 80 | Port size (Rc, NPT, G): 3/4, 1 | Mass (kg): 1.35
