    CKD Hydraulically Operated 2-Position Gas Shut-Off Valve HK1 Series

    CKD Hydraulically Operated 2-Position Gas Shut-Off Valve HK1 Series

    Highly reliable 2-position gas shut-off valve with built-in motor and hydraulic pump, ideal for main gas lines.

    Key features

    • Opening in 30 s or less, closing in 1 s or less; Rp1-1/2 to Rp2-1/2 threaded, 40A to 80A JIS flange and 100A to 200A DIN flange versions
    • Codes are the base models; voltage and options are added when ordering

    Specifications

    Rated voltage AC100V, AC200V
    Fluid city gas, natural gas, LPG
    HK1-40 Port: Rp1-1/2 | Working pressure (MPa): 0-0.4 | Flow natural gas, dP 0.25 kPa (m3/h ANR): 59 | Cv: 39 | Mass (kg): 9 | Rated voltage: AC100V, AC200V | Fluid: city gas, natural gas, LPG
    HK1-40J Port: 40A JIS 10K RF flange | Working pressure (MPa): 0-0.4 | Flow natural gas, dP 0.25 kPa (m3/h ANR): 59 | Cv: 39 | Mass (kg): 21.5 | Rated voltage: AC100V, AC200V | Fluid: city gas, natural gas, LPG
    HK1-50 Port: Rp2 | Working pressure (MPa): 0-0.25 | Flow natural gas, dP 0.25 kPa (m3/h ANR): 96 | Cv: 64 | Mass (kg): 9.2 | Rated voltage: AC100V, AC200V | Fluid: city gas, natural gas, LPG
    HK1-50J Port: 50A JIS 10K RF flange | Working pressure (MPa): 0-0.25 | Flow natural gas, dP 0.25 kPa (m3/h ANR): 96 | Cv: 64 | Mass (kg): 10.7 | Rated voltage: AC100V, AC200V | Fluid: city gas, natural gas, LPG
    HK1-65 Port: Rp2-1/2 | Working pressure (MPa): 0-0.2 | Flow natural gas, dP 0.25 kPa (m3/h ANR): 145 | Cv: 97 | Mass (kg): 12.7 | Rated voltage: AC100V, AC200V | Fluid: city gas, natural gas, LPG
    HK1-65J Port: 65A JIS 10K RF flange | Working pressure (MPa): 0-0.2 | Flow natural gas, dP 0.25 kPa (m3/h ANR): 145 | Cv: 97 | Mass (kg): 14.3 | Rated voltage: AC100V, AC200V | Fluid: city gas, natural gas, LPG
    HK1-80J Port: 80A JIS 10K RF flange | Working pressure (MPa): 0-0.14 | Flow natural gas, dP 0.25 kPa (m3/h ANR): 196 | Cv: 132 | Mass (kg): 15.3 | Rated voltage: AC100V, AC200V | Fluid: city gas, natural gas, LPG
    HK1-V100F Port: 100A DIN PN16 flange | Working pressure (MPa): 0-0.1 | Flow natural gas, dP 0.25 kPa (m3/h ANR): 287 | Cv: 191 | Mass (kg): 19 | Rated voltage: AC100V, AC200V | Fluid: city gas, natural gas, LPG
    HK1-V125F Port: 125A DIN PN16 flange | Working pressure (MPa): 0-0.06 | Flow natural gas, dP 0.25 kPa (m3/h ANR): 399 | Cv: 265 | Mass (kg): 24 | Rated voltage: AC100V, AC200V | Fluid: city gas, natural gas, LPG
    HK1-V150F Port: 150A DIN PN16 flange | Working pressure (MPa): 0-0.04 | Flow natural gas, dP 0.25 kPa (m3/h ANR): 601 | Cv: 399 | Mass (kg): 32 | Rated voltage: AC100V, AC200V | Fluid: city gas, natural gas, LPG
    HK1-V200F Port: 200A DIN PN16 flange | Working pressure (MPa): 0-0.023 | Flow natural gas, dP 0.25 kPa (m3/h ANR): 950 | Cv: 631 | Mass (kg): 52 | Rated voltage: AC100V, AC200V | Fluid: city gas, natural gas, LPG
    Gas ValvesCKD
    11 product codes available in this family
    Sourced direct from KoreaExport-ready supplyCompetitive pricing
    RFQ List 0 Email about this

    Need a different model, or a part not listed here? Send us your parts list →

    CKD Hydraulically Operated 2-Position Gas Shut-Off Valve HK1 Series

    Brand CKD·Gas Valves

    Available part numbers (11)

    HK1-40, HK1-40J, HK1-50, HK1-50J, HK1-65, HK1-65J, HK1-80J, HK1-V100F, HK1-V125F, HK1-V150F + 1 more — see full table ↓

    How to order

    Send the CKD part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

    RFQ List 0 →
    View full details
    Product codes & specifications
    0 selected
    RFQ List (0)
    Product codeSpec
    HK1-40Port: Rp1-1/2 | Working pressure (MPa): 0-0.4 | Flow natural gas, dP 0.25 kPa (m3/h ANR): 59 | Cv: 39 | Mass (kg): 9 | Rated voltage: AC100V, AC200V | Fluid: city gas, natural gas, LPG
    HK1-40JPort: 40A JIS 10K RF flange | Working pressure (MPa): 0-0.4 | Flow natural gas, dP 0.25 kPa (m3/h ANR): 59 | Cv: 39 | Mass (kg): 21.5 | Rated voltage: AC100V, AC200V | Fluid: city gas, natural gas, LPG
    HK1-50Port: Rp2 | Working pressure (MPa): 0-0.25 | Flow natural gas, dP 0.25 kPa (m3/h ANR): 96 | Cv: 64 | Mass (kg): 9.2 | Rated voltage: AC100V, AC200V | Fluid: city gas, natural gas, LPG
    HK1-50JPort: 50A JIS 10K RF flange | Working pressure (MPa): 0-0.25 | Flow natural gas, dP 0.25 kPa (m3/h ANR): 96 | Cv: 64 | Mass (kg): 10.7 | Rated voltage: AC100V, AC200V | Fluid: city gas, natural gas, LPG
    HK1-65Port: Rp2-1/2 | Working pressure (MPa): 0-0.2 | Flow natural gas, dP 0.25 kPa (m3/h ANR): 145 | Cv: 97 | Mass (kg): 12.7 | Rated voltage: AC100V, AC200V | Fluid: city gas, natural gas, LPG
    HK1-65JPort: 65A JIS 10K RF flange | Working pressure (MPa): 0-0.2 | Flow natural gas, dP 0.25 kPa (m3/h ANR): 145 | Cv: 97 | Mass (kg): 14.3 | Rated voltage: AC100V, AC200V | Fluid: city gas, natural gas, LPG
    HK1-80JPort: 80A JIS 10K RF flange | Working pressure (MPa): 0-0.14 | Flow natural gas, dP 0.25 kPa (m3/h ANR): 196 | Cv: 132 | Mass (kg): 15.3 | Rated voltage: AC100V, AC200V | Fluid: city gas, natural gas, LPG
    HK1-V100FPort: 100A DIN PN16 flange | Working pressure (MPa): 0-0.1 | Flow natural gas, dP 0.25 kPa (m3/h ANR): 287 | Cv: 191 | Mass (kg): 19 | Rated voltage: AC100V, AC200V | Fluid: city gas, natural gas, LPG
    HK1-V125FPort: 125A DIN PN16 flange | Working pressure (MPa): 0-0.06 | Flow natural gas, dP 0.25 kPa (m3/h ANR): 399 | Cv: 265 | Mass (kg): 24 | Rated voltage: AC100V, AC200V | Fluid: city gas, natural gas, LPG
    HK1-V150FPort: 150A DIN PN16 flange | Working pressure (MPa): 0-0.04 | Flow natural gas, dP 0.25 kPa (m3/h ANR): 601 | Cv: 399 | Mass (kg): 32 | Rated voltage: AC100V, AC200V | Fluid: city gas, natural gas, LPG
    HK1-V200FPort: 200A DIN PN16 flange | Working pressure (MPa): 0-0.023 | Flow natural gas, dP 0.25 kPa (m3/h ANR): 950 | Cv: 631 | Mass (kg): 52 | Rated voltage: AC100V, AC200V | Fluid: city gas, natural gas, LPG
