CKD LN Linear Gnome Sensor, Amplifier and Display Units

CKD LN Linear Gnome Sensor, Amplifier and Display Units

CKD LN linear gnome sensor heads, amplifier units, LN-DN display and analog ON-OFF switches for SSD-LN cylinders and BH-LN hands.

Key features

  • Maintenance codes: sensor LN-<05/10><H/V>C, amp-integrated sensor LN-<05/10>VS1PA<H/V>, amp LN-<S2S/S12S/LS/LDS>
  • Analog output 1-5V (linearity +/-5% F.S.) over the full jaw stroke or any 8 mm cylinder range
  • LN-DN display: 7-segment, 2 channels, 4 NPN switch outputs per channel, 1-5V analog output
  • Sensor IP67, amp IP65; sensor cable 2 m, amp output cable 3 m
  • Analog ON-OFF switch: SW-T0H5/T0V5 (LS amp) or LN-TH/LN-TV (display type)

Specifications

Power supply DC24V +/-10%
Switch output NPN open collector, 30V 50mA
Repeatability +/-0.1 mm
Ambient -10 to 60 C, 85% RH max
Insulation 20 MOhm at DC500V
Mounting Dedicated bracket / DIN rail or direct
Source CKD Korea catalog CB-030SK-9, p. 1558-1561
LN-05HC Part: Sensor head (Hand 01CS/03CS) | Output: To separate amp | Lead: Straight, M8 connector
LN-05VC Part: Sensor head (Hand 01CS/03CS) | Output: To separate amp | Lead: L type, M8 connector
LN-10HC Part: Sensor head (Hand 04CS/05CS, SSD-LN) | Output: To separate amp | Lead: Straight, M8 connector
LN-10VC Part: Sensor head (Hand 04CS/05CS, SSD-LN) | Output: To separate amp | Lead: L type, M8 connector
LN-05VS1PAH Part: Sensor with built-in amp | Output: NPN 1-point switch | Lead: L sensor, straight output
LN-05VS1PAV Part: Sensor with built-in amp | Output: NPN 1-point switch | Lead: L sensor, L output
LN-10VS1PAH Part: Sensor with built-in amp | Output: NPN 1-point switch | Lead: L sensor, straight output
LN-10VS1PAV Part: Sensor with built-in amp | Output: NPN 1-point switch | Lead: L sensor, L output
LN-S2S Part: Separate amp unit (05 sensor) | Output: NPN 2-point switch | Lead: 3 m cable
LN-S12S Part: Separate amp unit (10 sensor) | Output: NPN 2-point switch | Lead: 3 m cable
LN-LS Part: Separate amp unit | Output: Analog 1-5V | Lead: 3 m shielded cable
LN-LDS Part: Separate amp unit | Output: For LN-DN display | Lead: 3 m 7-core shielded
LN-DN Part: Display unit (2 ch) | Output: Analog 1-5V x2, 4 NPN x2 | Lead: DIN rail / direct
LN-TH Part: Analog ON-OFF switch | Output: Display type | Lead: Straight
LN-TV Part: Analog ON-OFF switch | Output: Display type | Lead: L type
SW-T0H5 Part: Analog ON-OFF switch | Output: Analog output type (LS) | Lead: Straight, 5 m
SW-T0V5 Part: Analog ON-OFF switch | Output: Analog output type (LS) | Lead: L type, 5 m
