• CP System Double Cable Clamp (Ø06-34mm, CA2/C2)
1 1

CP System Double Cable Clamp (Ø06-34mm, CA2/C2)

CP System Double Cable Clamp (Ø06-34mm, CA2/C2)

CP SYSTEM Cable Clamp, double type — fixes two stacked cables with a high-strength steel clamp that minimizes cable damage when tightened (holding force approx. 89 Kgf, about 3x a tie wrap).

Key features

  • Each part is marked with its product no
  • Clamp ASM (CA2) and clamp-only (C2) part numbers available per cable diameter (Ø06-34mm)

Specifications

Type Double Cable Clamp
Material High strength steel
CA2.0612 Double cable clamp ASM, Ø06~12mm | Type: Double Cable Clamp | Part Category: Clamp ASM (assembly w/ bolt) | Applicable Cable: Ø06~12mm | Dimension A: 16.5±0.2mm | Dimension H: 65.0+5mm | Material: High strength steel
C2.0612 Double cable clamp body, Ø06~12mm | Type: Double Cable Clamp | Part Category: Clamp (body only) | Applicable Cable: Ø06~12mm | Dimension A: 16.5±0.2mm | Dimension H: 65.0+5mm | Material: High strength steel
CA2.1214 Double cable clamp ASM, Ø12~14mm | Type: Double Cable Clamp | Part Category: Clamp ASM (assembly w/ bolt) | Applicable Cable: Ø12~14mm | Dimension A: 17.5±0.2mm | Dimension H: 69.0+5mm | Material: High strength steel
C2.1214 Double cable clamp body, Ø12~14mm | Type: Double Cable Clamp | Part Category: Clamp (body only) | Applicable Cable: Ø12~14mm | Dimension A: 17.5±0.2mm | Dimension H: 69.0+5mm | Material: High strength steel
CA2.1416 Double cable clamp ASM, Ø14~16mm | Type: Double Cable Clamp | Part Category: Clamp ASM (assembly w/ bolt) | Applicable Cable: Ø14~16mm | Dimension A: 20.0±0.2mm | Dimension H: 73.0+5mm | Material: High strength steel
C2.1416 Double cable clamp body, Ø14~16mm | Type: Double Cable Clamp | Part Category: Clamp (body only) | Applicable Cable: Ø14~16mm | Dimension A: 20.0±0.2mm | Dimension H: 73.0+5mm | Material: High strength steel
CA2.1618 Double cable clamp ASM, Ø16~18mm | Type: Double Cable Clamp | Part Category: Clamp ASM (assembly w/ bolt) | Applicable Cable: Ø16~18mm | Dimension A: 22.0±0.2mm | Dimension H: 77.0+5mm | Material: High strength steel
C2.1618 Double cable clamp body, Ø16~18mm | Type: Double Cable Clamp | Part Category: Clamp (body only) | Applicable Cable: Ø16~18mm | Dimension A: 22.0±0.2mm | Dimension H: 77.0+5mm | Material: High strength steel
CA2.1820 Double cable clamp ASM, Ø18~20mm | Type: Double Cable Clamp | Part Category: Clamp ASM (assembly w/ bolt) | Applicable Cable: Ø18~20mm | Dimension A: 24.0±0.2mm | Dimension H: 81.0+5mm | Material: High strength steel
C2.1820 Double cable clamp body, Ø18~20mm | Type: Double Cable Clamp | Part Category: Clamp (body only) | Applicable Cable: Ø18~20mm | Dimension A: 24.0±0.2mm | Dimension H: 81.0+5mm | Material: High strength steel
CA2.2022 Double cable clamp ASM, Ø20~22mm | Type: Double Cable Clamp | Part Category: Clamp ASM (assembly w/ bolt) | Applicable Cable: Ø20~22mm | Dimension A: 26.0±0.2mm | Dimension H: 85.0+5mm | Material: High strength steel
C2.2022 Double cable clamp body, Ø20~22mm | Type: Double Cable Clamp | Part Category: Clamp (body only) | Applicable Cable: Ø20~22mm | Dimension A: 26.0±0.2mm | Dimension H: 85.0+5mm | Material: High strength steel
CA2.2226 Double cable clamp ASM, Ø22~26mm | Type: Double Cable Clamp | Part Category: Clamp ASM (assembly w/ bolt) | Applicable Cable: Ø22~26mm | Dimension A: 30.0±0.2mm | Dimension H: 94.5+5mm | Material: High strength steel
C2.2226 Double cable clamp body, Ø22~26mm | Type: Double Cable Clamp | Part Category: Clamp (body only) | Applicable Cable: Ø22~26mm | Dimension A: 30.0±0.2mm | Dimension H: 94.5+5mm | Material: High strength steel
CA2.2630 Double cable clamp ASM, Ø26~30mm | Type: Double Cable Clamp | Part Category: Clamp ASM (assembly w/ bolt) | Applicable Cable: Ø26~30mm | Dimension A: 34.0±0.2mm | Dimension H: 101.0+5mm | Material: High strength steel
C2.2630 Double cable clamp body, Ø26~30mm | Type: Double Cable Clamp | Part Category: Clamp (body only) | Applicable Cable: Ø26~30mm | Dimension A: 34.0±0.2mm | Dimension H: 101.0+5mm | Material: High strength steel
CA2.3034 Double cable clamp ASM, Ø30~34mm | Type: Double Cable Clamp | Part Category: Clamp ASM (assembly w/ bolt) | Applicable Cable: Ø30~34mm | Dimension A: 38.0±0.2mm | Dimension H: 110.0+5mm | Material: High strength steel
C2.3034 Double cable clamp body, Ø30~34mm | Type: Double Cable Clamp | Part Category: Clamp (body only) | Applicable Cable: Ø30~34mm | Dimension A: 38.0±0.2mm | Dimension H: 110.0+5mm | Material: High strength steel
