• CP System Single Cable Clamp (Ø06-42mm, CA1/C1)
1 1

CP System Single Cable Clamp (Ø06-42mm, CA1/C1)

CP System Single Cable Clamp (Ø06-42mm, CA1/C1)

CP SYSTEM Cable Clamp, single type — fixes one cable with a high-strength steel clamp that minimizes cable damage when tightened (holding force approx. 89 Kgf, about 3x a tie wrap).

Key features

  • Each part is marked with its product no
  • Clamp ASM (CA1) and clamp-only (C1) part numbers available per cable diameter (Ø06-42mm)

Specifications

Type Single Cable Clamp
Material High strength steel
CA1.0612 Single cable clamp ASM, Ø06~12mm | Type: Single Cable Clamp | Part Category: Clamp ASM (assembly w/ bolt) | Applicable Cable: Ø06~12mm | Dimension A: 16.5±0.2mm | Dimension H: 49.0+5mm | Material: High strength steel
C1.0612 Single cable clamp body, Ø06~12mm | Type: Single Cable Clamp | Part Category: Clamp (body only) | Applicable Cable: Ø06~12mm | Dimension A: 16.5±0.2mm | Dimension H: 49.0+5mm | Material: High strength steel
CA1.1214 Single cable clamp ASM, Ø12~14mm | Type: Single Cable Clamp | Part Category: Clamp ASM (assembly w/ bolt) | Applicable Cable: Ø12~14mm | Dimension A: 17.5±0.2mm | Dimension H: 51.0+5mm | Material: High strength steel
C1.1214 Single cable clamp body, Ø12~14mm | Type: Single Cable Clamp | Part Category: Clamp (body only) | Applicable Cable: Ø12~14mm | Dimension A: 17.5±0.2mm | Dimension H: 51.0+5mm | Material: High strength steel
CA1.1416 Single cable clamp ASM, Ø14~16mm | Type: Single Cable Clamp | Part Category: Clamp ASM (assembly w/ bolt) | Applicable Cable: Ø14~16mm | Dimension A: 20.0±0.2mm | Dimension H: 53.0+5mm | Material: High strength steel
C1.1416 Single cable clamp body, Ø14~16mm | Type: Single Cable Clamp | Part Category: Clamp (body only) | Applicable Cable: Ø14~16mm | Dimension A: 20.0±0.2mm | Dimension H: 53.0+5mm | Material: High strength steel
CA1.1618 Single cable clamp ASM, Ø16~18mm | Type: Single Cable Clamp | Part Category: Clamp ASM (assembly w/ bolt) | Applicable Cable: Ø16~18mm | Dimension A: 22.0±0.2mm | Dimension H: 55.5+5mm | Material: High strength steel
C1.1618 Single cable clamp body, Ø16~18mm | Type: Single Cable Clamp | Part Category: Clamp (body only) | Applicable Cable: Ø16~18mm | Dimension A: 22.0±0.2mm | Dimension H: 55.5+5mm | Material: High strength steel
CA1.1820 Single cable clamp ASM, Ø18~20mm | Type: Single Cable Clamp | Part Category: Clamp ASM (assembly w/ bolt) | Applicable Cable: Ø18~20mm | Dimension A: 24.0±0.2mm | Dimension H: 57.0+5mm | Material: High strength steel
C1.1820 Single cable clamp body, Ø18~20mm | Type: Single Cable Clamp | Part Category: Clamp (body only) | Applicable Cable: Ø18~20mm | Dimension A: 24.0±0.2mm | Dimension H: 57.0+5mm | Material: High strength steel
CA1.2022 Single cable clamp ASM, Ø20~22mm | Type: Single Cable Clamp | Part Category: Clamp ASM (assembly w/ bolt) | Applicable Cable: Ø20~22mm | Dimension A: 26.0±0.2mm | Dimension H: 59.0+5mm | Material: High strength steel
C1.2022 Single cable clamp body, Ø20~22mm | Type: Single Cable Clamp | Part Category: Clamp (body only) | Applicable Cable: Ø20~22mm | Dimension A: 26.0±0.2mm | Dimension H: 59.0+5mm | Material: High strength steel
CA1.2226 Single cable clamp ASM, Ø22~26mm | Type: Single Cable Clamp | Part Category: Clamp ASM (assembly w/ bolt) | Applicable Cable: Ø22~26mm | Dimension A: 30.0±0.2mm | Dimension H: 63.0+5mm | Material: High strength steel
C1.2226 Single cable clamp body, Ø22~26mm | Type: Single Cable Clamp | Part Category: Clamp (body only) | Applicable Cable: Ø22~26mm | Dimension A: 30.0±0.2mm | Dimension H: 63.0+5mm | Material: High strength steel
CA1.2630 Single cable clamp ASM, Ø26~30mm | Type: Single Cable Clamp | Part Category: Clamp ASM (assembly w/ bolt) | Applicable Cable: Ø26~30mm | Dimension A: 34.0±0.2mm | Dimension H: 67.0+5mm | Material: High strength steel
C1.2630 Single cable clamp body, Ø26~30mm | Type: Single Cable Clamp | Part Category: Clamp (body only) | Applicable Cable: Ø26~30mm | Dimension A: 34.0±0.2mm | Dimension H: 67.0+5mm | Material: High strength steel
CA1.3034 Single cable clamp ASM, Ø30~34mm | Type: Single Cable Clamp | Part Category: Clamp ASM (assembly w/ bolt) | Applicable Cable: Ø30~34mm | Dimension A: 38.0±0.2mm | Dimension H: 71.0+5mm | Material: High strength steel
C1.3034 Single cable clamp body, Ø30~34mm | Type: Single Cable Clamp | Part Category: Clamp (body only) | Applicable Cable: Ø30~34mm | Dimension A: 38.0±0.2mm | Dimension H: 71.0+5mm | Material: High strength steel
CA1.3438 Single cable clamp ASM, Ø34~38mm | Type: Single Cable Clamp | Part Category: Clamp ASM (assembly w/ bolt) | Applicable Cable: Ø34~38mm | Dimension A: 42.0±0.2mm | Dimension H: 75.0+5mm | Material: High strength steel
C1.3438 Single cable clamp body, Ø34~38mm | Type: Single Cable Clamp | Part Category: Clamp (body only) | Applicable Cable: Ø34~38mm | Dimension A: 42.0±0.2mm | Dimension H: 75.0+5mm | Material: High strength steel
CA1.3842 Single cable clamp ASM, Ø38~42mm | Type: Single Cable Clamp | Part Category: Clamp ASM (assembly w/ bolt) | Applicable Cable: Ø38~42mm | Dimension A: 46.5±0.2mm | Dimension H: 80.0+5mm | Material: High strength steel
C1.3842 Single cable clamp body, Ø38~42mm | Type: Single Cable Clamp | Part Category: Clamp (body only) | Applicable Cable: Ø38~42mm | Dimension A: 46.5±0.2mm | Dimension H: 80.0+5mm | Material: High strength steel
Cable CarriersCP System
22 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

CP System Single Cable Clamp (Ø06-42mm, CA1/C1)

Brand CP System·Cable Carriers

Available part numbers (22)

CA1.0612, C1.0612, CA1.1214, C1.1214, CA1.1416, C1.1416, CA1.1618, C1.1618, CA1.1820, C1.1820 + 12 more — see full table ↓

How to order

Send the CP System part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
CA1.0612Single cable clamp ASM, Ø06~12mm | Type: Single Cable Clamp | Part Category: Clamp ASM (assembly w/ bolt) | Applicable Cable: Ø06~12mm | Dimension A: 16.5±0.2mm | Dimension H: 49.0+5mm | Material: High strength steel
C1.0612Single cable clamp body, Ø06~12mm | Type: Single Cable Clamp | Part Category: Clamp (body only) | Applicable Cable: Ø06~12mm | Dimension A: 16.5±0.2mm | Dimension H: 49.0+5mm | Material: High strength steel
CA1.1214Single cable clamp ASM, Ø12~14mm | Type: Single Cable Clamp | Part Category: Clamp ASM (assembly w/ bolt) | Applicable Cable: Ø12~14mm | Dimension A: 17.5±0.2mm | Dimension H: 51.0+5mm | Material: High strength steel
C1.1214Single cable clamp body, Ø12~14mm | Type: Single Cable Clamp | Part Category: Clamp (body only) | Applicable Cable: Ø12~14mm | Dimension A: 17.5±0.2mm | Dimension H: 51.0+5mm | Material: High strength steel
CA1.1416Single cable clamp ASM, Ø14~16mm | Type: Single Cable Clamp | Part Category: Clamp ASM (assembly w/ bolt) | Applicable Cable: Ø14~16mm | Dimension A: 20.0±0.2mm | Dimension H: 53.0+5mm | Material: High strength steel
C1.1416Single cable clamp body, Ø14~16mm | Type: Single Cable Clamp | Part Category: Clamp (body only) | Applicable Cable: Ø14~16mm | Dimension A: 20.0±0.2mm | Dimension H: 53.0+5mm | Material: High strength steel
CA1.1618Single cable clamp ASM, Ø16~18mm | Type: Single Cable Clamp | Part Category: Clamp ASM (assembly w/ bolt) | Applicable Cable: Ø16~18mm | Dimension A: 22.0±0.2mm | Dimension H: 55.5+5mm | Material: High strength steel
C1.1618Single cable clamp body, Ø16~18mm | Type: Single Cable Clamp | Part Category: Clamp (body only) | Applicable Cable: Ø16~18mm | Dimension A: 22.0±0.2mm | Dimension H: 55.5+5mm | Material: High strength steel
CA1.1820Single cable clamp ASM, Ø18~20mm | Type: Single Cable Clamp | Part Category: Clamp ASM (assembly w/ bolt) | Applicable Cable: Ø18~20mm | Dimension A: 24.0±0.2mm | Dimension H: 57.0+5mm | Material: High strength steel
C1.1820Single cable clamp body, Ø18~20mm | Type: Single Cable Clamp | Part Category: Clamp (body only) | Applicable Cable: Ø18~20mm | Dimension A: 24.0±0.2mm | Dimension H: 57.0+5mm | Material: High strength steel
CA1.2022Single cable clamp ASM, Ø20~22mm | Type: Single Cable Clamp | Part Category: Clamp ASM (assembly w/ bolt) | Applicable Cable: Ø20~22mm | Dimension A: 26.0±0.2mm | Dimension H: 59.0+5mm | Material: High strength steel
C1.2022Single cable clamp body, Ø20~22mm | Type: Single Cable Clamp | Part Category: Clamp (body only) | Applicable Cable: Ø20~22mm | Dimension A: 26.0±0.2mm | Dimension H: 59.0+5mm | Material: High strength steel
CA1.2226Single cable clamp ASM, Ø22~26mm | Type: Single Cable Clamp | Part Category: Clamp ASM (assembly w/ bolt) | Applicable Cable: Ø22~26mm | Dimension A: 30.0±0.2mm | Dimension H: 63.0+5mm | Material: High strength steel
C1.2226Single cable clamp body, Ø22~26mm | Type: Single Cable Clamp | Part Category: Clamp (body only) | Applicable Cable: Ø22~26mm | Dimension A: 30.0±0.2mm | Dimension H: 63.0+5mm | Material: High strength steel
CA1.2630Single cable clamp ASM, Ø26~30mm | Type: Single Cable Clamp | Part Category: Clamp ASM (assembly w/ bolt) | Applicable Cable: Ø26~30mm | Dimension A: 34.0±0.2mm | Dimension H: 67.0+5mm | Material: High strength steel
C1.2630Single cable clamp body, Ø26~30mm | Type: Single Cable Clamp | Part Category: Clamp (body only) | Applicable Cable: Ø26~30mm | Dimension A: 34.0±0.2mm | Dimension H: 67.0+5mm | Material: High strength steel
CA1.3034Single cable clamp ASM, Ø30~34mm | Type: Single Cable Clamp | Part Category: Clamp ASM (assembly w/ bolt) | Applicable Cable: Ø30~34mm | Dimension A: 38.0±0.2mm | Dimension H: 71.0+5mm | Material: High strength steel
C1.3034Single cable clamp body, Ø30~34mm | Type: Single Cable Clamp | Part Category: Clamp (body only) | Applicable Cable: Ø30~34mm | Dimension A: 38.0±0.2mm | Dimension H: 71.0+5mm | Material: High strength steel
CA1.3438Single cable clamp ASM, Ø34~38mm | Type: Single Cable Clamp | Part Category: Clamp ASM (assembly w/ bolt) | Applicable Cable: Ø34~38mm | Dimension A: 42.0±0.2mm | Dimension H: 75.0+5mm | Material: High strength steel
C1.3438Single cable clamp body, Ø34~38mm | Type: Single Cable Clamp | Part Category: Clamp (body only) | Applicable Cable: Ø34~38mm | Dimension A: 42.0±0.2mm | Dimension H: 75.0+5mm | Material: High strength steel
CA1.3842Single cable clamp ASM, Ø38~42mm | Type: Single Cable Clamp | Part Category: Clamp ASM (assembly w/ bolt) | Applicable Cable: Ø38~42mm | Dimension A: 46.5±0.2mm | Dimension H: 80.0+5mm | Material: High strength steel
C1.3842Single cable clamp body, Ø38~42mm | Type: Single Cable Clamp | Part Category: Clamp (body only) | Applicable Cable: Ø38~42mm | Dimension A: 46.5±0.2mm | Dimension H: 80.0+5mm | Material: High strength steel
