CP System Unity System ST072E (Shift Chain Enclosed (E), Guide Channel Supported)

CP System Unity System ST072E (Shift Chain Enclosed (E), Guide Channel Supported)

Unity System - long-travel cable carrier where the ST072E Shift Chain is supported inside a Guide Channel (GC) for stable horizontal runs.

Key features

  • CPS-Amide chain, speed 6-10 m/s, CE / ATEX(Ex) / RoHs2 certified

Specifications

Type Shift Chain Enclosed (E), Guide Channel supported
Guide Channel GC300 (L300, hole A226) / GC500 (L500, hole A426)
Bracket G (Horizontal GC End Bracket) / GT (Tie Wrap)
Length & Divider made-to-order
Material CPS-Amide (PA6+G.F)
Speed 6-10 m/s
Acceleration 15-20 m/s2
Temperature -30 to +130C
Certificate CE, ATEX(Ex), RoHs2
ST072E.35/G Unity System ST072E (Shift Chain Enclosed (E)), inside width 35mm, Guide Channel supported | Type: Shift Chain Enclosed (E), Guide Channel supported | Inside Width (C): 35 mm | Frame (D): 50 mm | FEB Hole Width (E): 62 mm | FEB Width (F): 100 mm | GC Hole Width (G): 62 mm | Chain Outer Width (I): 82 mm | Guide Channel: GC300 (L300, hole A226) / GC500 (L500, hole A426) | Bracket: G (Horizontal GC End Bracket) / GT (Tie Wrap) | Length & Divider: made-to-order | Material: CPS-Amide (PA6+G.F) | Speed: 6-10 m/s | Acceleration: 15-20 m/s2 | Temperature: -30 to +130C | Certificate: CE, ATEX(Ex), RoHs2
ST072E.60/G Unity System ST072E (Shift Chain Enclosed (E)), inside width 60mm, Guide Channel supported | Type: Shift Chain Enclosed (E), Guide Channel supported | Inside Width (C): 60 mm | Frame (D): 75 mm | FEB Hole Width (E): 87 mm | FEB Width (F): 125 mm | GC Hole Width (G): 87 mm | Chain Outer Width (I): 107 mm | Guide Channel: GC300 (L300, hole A226) / GC500 (L500, hole A426) | Bracket: G (Horizontal GC End Bracket) / GT (Tie Wrap) | Length & Divider: made-to-order | Material: CPS-Amide (PA6+G.F) | Speed: 6-10 m/s | Acceleration: 15-20 m/s2 | Temperature: -30 to +130C | Certificate: CE, ATEX(Ex), RoHs2
ST072E.85/G Unity System ST072E (Shift Chain Enclosed (E)), inside width 85mm, Guide Channel supported | Type: Shift Chain Enclosed (E), Guide Channel supported | Inside Width (C): 85 mm | Frame (D): 100 mm | FEB Hole Width (E): 112 mm | FEB Width (F): 150 mm | GC Hole Width (G): 112 mm | Chain Outer Width (I): 132 mm | Guide Channel: GC300 (L300, hole A226) / GC500 (L500, hole A426) | Bracket: G (Horizontal GC End Bracket) / GT (Tie Wrap) | Length & Divider: made-to-order | Material: CPS-Amide (PA6+G.F) | Speed: 6-10 m/s | Acceleration: 15-20 m/s2 | Temperature: -30 to +130C | Certificate: CE, ATEX(Ex), RoHs2
ST072E.110/G Unity System ST072E (Shift Chain Enclosed (E)), inside width 110mm, Guide Channel supported | Type: Shift Chain Enclosed (E), Guide Channel supported | Inside Width (C): 110 mm | Frame (D): 125 mm | FEB Hole Width (E): 137 mm | FEB Width (F): 175 mm | GC Hole Width (G): 137 mm | Chain Outer Width (I): 157 mm | Guide Channel: GC300 (L300, hole A226) / GC500 (L500, hole A426) | Bracket: G (Horizontal GC End Bracket) / GT (Tie Wrap) | Length & Divider: made-to-order | Material: CPS-Amide (PA6+G.F) | Speed: 6-10 m/s | Acceleration: 15-20 m/s2 | Temperature: -30 to +130C | Certificate: CE, ATEX(Ex), RoHs2
ST072E.135/G Unity System ST072E (Shift Chain Enclosed (E)), inside width 135mm, Guide Channel supported | Type: Shift Chain Enclosed (E), Guide Channel supported | Inside Width (C): 135 mm | Frame (D): 150 mm | FEB Hole Width (E): 162 mm | FEB Width (F): 200 mm | GC Hole Width (G): 162 mm | Chain Outer Width (I): 182 mm | Guide Channel: GC300 (L300, hole A226) / GC500 (L500, hole A426) | Bracket: G (Horizontal GC End Bracket) / GT (Tie Wrap) | Length & Divider: made-to-order | Material: CPS-Amide (PA6+G.F) | Speed: 6-10 m/s | Acceleration: 15-20 m/s2 | Temperature: -30 to +130C | Certificate: CE, ATEX(Ex), RoHs2
Cable CarriersCP System
5 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

CP System Unity System ST072E (Shift Chain Enclosed (E), Guide Channel Supported)

Brand CP System·Cable Carriers

Available part numbers (5)

ST072E.35/G, ST072E.60/G, ST072E.85/G, ST072E.110/G, ST072E.135/G

How to order

Send the CP System part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
ST072E.35/GUnity System ST072E (Shift Chain Enclosed (E)), inside width 35mm, Guide Channel supported | Type: Shift Chain Enclosed (E), Guide Channel supported | Inside Width (C): 35 mm | Frame (D): 50 mm | FEB Hole Width (E): 62 mm | FEB Width (F): 100 mm | GC Hole Width (G): 62 mm | Chain Outer Width (I): 82 mm | Guide Channel: GC300 (L300, hole A226) / GC500 (L500, hole A426) | Bracket: G (Horizontal GC End Bracket) / GT (Tie Wrap) | Length & Divider: made-to-order | Material: CPS-Amide (PA6+G.F) | Speed: 6-10 m/s | Acceleration: 15-20 m/s2 | Temperature: -30 to +130C | Certificate: CE, ATEX(Ex), RoHs2
ST072E.60/GUnity System ST072E (Shift Chain Enclosed (E)), inside width 60mm, Guide Channel supported | Type: Shift Chain Enclosed (E), Guide Channel supported | Inside Width (C): 60 mm | Frame (D): 75 mm | FEB Hole Width (E): 87 mm | FEB Width (F): 125 mm | GC Hole Width (G): 87 mm | Chain Outer Width (I): 107 mm | Guide Channel: GC300 (L300, hole A226) / GC500 (L500, hole A426) | Bracket: G (Horizontal GC End Bracket) / GT (Tie Wrap) | Length & Divider: made-to-order | Material: CPS-Amide (PA6+G.F) | Speed: 6-10 m/s | Acceleration: 15-20 m/s2 | Temperature: -30 to +130C | Certificate: CE, ATEX(Ex), RoHs2
ST072E.85/GUnity System ST072E (Shift Chain Enclosed (E)), inside width 85mm, Guide Channel supported | Type: Shift Chain Enclosed (E), Guide Channel supported | Inside Width (C): 85 mm | Frame (D): 100 mm | FEB Hole Width (E): 112 mm | FEB Width (F): 150 mm | GC Hole Width (G): 112 mm | Chain Outer Width (I): 132 mm | Guide Channel: GC300 (L300, hole A226) / GC500 (L500, hole A426) | Bracket: G (Horizontal GC End Bracket) / GT (Tie Wrap) | Length & Divider: made-to-order | Material: CPS-Amide (PA6+G.F) | Speed: 6-10 m/s | Acceleration: 15-20 m/s2 | Temperature: -30 to +130C | Certificate: CE, ATEX(Ex), RoHs2
ST072E.110/GUnity System ST072E (Shift Chain Enclosed (E)), inside width 110mm, Guide Channel supported | Type: Shift Chain Enclosed (E), Guide Channel supported | Inside Width (C): 110 mm | Frame (D): 125 mm | FEB Hole Width (E): 137 mm | FEB Width (F): 175 mm | GC Hole Width (G): 137 mm | Chain Outer Width (I): 157 mm | Guide Channel: GC300 (L300, hole A226) / GC500 (L500, hole A426) | Bracket: G (Horizontal GC End Bracket) / GT (Tie Wrap) | Length & Divider: made-to-order | Material: CPS-Amide (PA6+G.F) | Speed: 6-10 m/s | Acceleration: 15-20 m/s2 | Temperature: -30 to +130C | Certificate: CE, ATEX(Ex), RoHs2
ST072E.135/GUnity System ST072E (Shift Chain Enclosed (E)), inside width 135mm, Guide Channel supported | Type: Shift Chain Enclosed (E), Guide Channel supported | Inside Width (C): 135 mm | Frame (D): 150 mm | FEB Hole Width (E): 162 mm | FEB Width (F): 200 mm | GC Hole Width (G): 162 mm | Chain Outer Width (I): 182 mm | Guide Channel: GC300 (L300, hole A226) / GC500 (L500, hole A426) | Bracket: G (Horizontal GC End Bracket) / GT (Tie Wrap) | Length & Divider: made-to-order | Material: CPS-Amide (PA6+G.F) | Speed: 6-10 m/s | Acceleration: 15-20 m/s2 | Temperature: -30 to +130C | Certificate: CE, ATEX(Ex), RoHs2

Need a different model, or a part not listed here? Send us your parts list →
