DKM FX3000 Torque Controller for AC Torque Motors

DKM FX3000 Torque Controller for AC Torque Motors

Compact panel-mount phase-control controller that sets the speed and torque of DKM AC torque motors (3-60 W) with a front dial and digital display.

Key features

  • Speed and torque of the motor are controlled simply by connecting motor and controller and applying AC power
  • Screwless connector for easy wiring and maintenance
  • Speed and torque set with the front-panel dial
  • Digital display of current speed (r/min) and torque (%)
  • Parameters for acceleration time, rotation direction, gear ratio, control mode and P/I gain

Specifications

Rated voltage 1ø AC 220-240 V 50/60 Hz ±10%
Allowable current Below 6 A
Control function Speed control, torque control
Control system Phase control
Speed setting range 50 Hz: 90-1400 r/min; 60 Hz: 90-1700 r/min
Torque control range 0-100%
Speed setting Front volume (dial)
Speed variation 5% (standard value)
Ambient temperature -10 to +55 °C
Ambient humidity 35-85% RH (no condensation)
Insulation resistance 100 MΩ min. at 500 VDC (power supply to external terminals)
Dielectric strength 1500 VAC for 1 minute (power supply to external terminals)
FX3000-003T Motor output: 3 W | Combined motor: 3 W torque motor (6TD series) | Control type: T (torque control motor)
FX3000-006T Motor output: 6 W | Combined motor: 6 W torque motor (7TD series) | Control type: T (torque control motor)
FX3000-010T Motor output: 10 W | Combined motor: 10 W torque motor (8TD series) | Control type: T (torque control motor)
FX3000-020T Motor output: 20 W | Combined motor: 20 W torque motor (9TD-20F2 series) | Control type: T (torque control motor)
FX3000-030T Motor output: 30 W | Combined motor: 30 W torque motor (9TD-30F2 series) | Control type: T (torque control motor)
FX3000-040T Motor output: 40 W | Combined motor: 40 W torque motor (9TD-40F2 series) | Control type: T (torque control motor)
FX3000-060T Motor output: 60 W | Combined motor: 60 W torque motor (9TD-60F2 series) | Control type: T (torque control motor)
Motor ControllersDKM
7 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

DKM FX3000 Torque Controller for AC Torque Motors

Brand DKM·Motor Controllers

Available part numbers (7)

FX3000-003T, FX3000-006T, FX3000-010T, FX3000-020T, FX3000-030T, FX3000-040T, FX3000-060T

How to order

Send the DKM part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
FX3000-003TMotor output: 3 W | Combined motor: 3 W torque motor (6TD series) | Control type: T (torque control motor)
FX3000-006TMotor output: 6 W | Combined motor: 6 W torque motor (7TD series) | Control type: T (torque control motor)
FX3000-010TMotor output: 10 W | Combined motor: 10 W torque motor (8TD series) | Control type: T (torque control motor)
FX3000-020TMotor output: 20 W | Combined motor: 20 W torque motor (9TD-20F2 series) | Control type: T (torque control motor)
FX3000-030TMotor output: 30 W | Combined motor: 30 W torque motor (9TD-30F2 series) | Control type: T (torque control motor)
FX3000-040TMotor output: 40 W | Combined motor: 40 W torque motor (9TD-40F2 series) | Control type: T (torque control motor)
FX3000-060TMotor output: 60 W | Combined motor: 60 W torque motor (9TD-60F2 series) | Control type: T (torque control motor)
