Dongkuk CM EGI Electro-Galvanized Steel Sheet (CS, DS, DDS)

Electro-galvanized (EGI) steel sheet and coil: cold-rolled steel with an even electrolytic zinc coating. Because no heat is involved, the base metal keeps its formability, paintability and weldability.

Key features

Even, spangle-free and pin-hole-free zinc surface ideal for painting
Base metal formability retained (no heat in the coating process)
Highest weldability among coated steels due to the low zinc amount
Chromated, phosphated, AFP and chromium-free AFP treatments
Chromium-free AFP: trivalent-chromium based, Cr(VI)-free and environment-friendly

Specifications

Coating	Electrolytic zinc on cold-rolled steel
Thickness range	0.3 - 2.0 mm
Width range	600 - 1,350 mm
Length (sheet)	400 - 5,000 mm
Coating weight, both sides	6 - 100 g/m2
Coating mass symbols	E08, E16, E24, E32, E40 (10-50 g/m2 per side)
Surface treatment codes	MX, MO, PX, PO, CX, CO, PCX, PCO, PCF, CFA (Cr-free AFP), ICA (conductive AFP)
Standard widths	762, 914, 1,000, 1,219, 1,250 mm
Coil	ID 508 mm, OD 2,040 mm max, 22.5 t max
Applications	Home appliances, furniture, industrial machinery
Source	Dongkuk CM EGI_GI_GL_en.pdf, p. 9-14

EGI CS (Commercial Quality)		Use: Commercial \| Cr-free AFP: 0.3-1.6 mm \| Coating: E08-E40
EGI DS (Drawing Quality)		Use: Drawing \| Cr-free AFP: 0.6-1.6 mm \| Coating: E08-E40
EGI DDS (Deep Drawing Quality)		Use: Deep drawing \| Cr-free AFP: 0.6-1.6 mm \| Coating: E08-E40

Electro-Galvanized Steel SheetDongkuk CM

3 product codes available in this family

Sourced direct from KoreaExport-ready supplyCompetitive pricing

RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Dongkuk CM EGI Electro-Galvanized Steel Sheet (CS, DS, DDS)

Brand Dongkuk CM·Electro-Galvanized Steel Sheet

Available part numbers (3)

EGI CS (Commercial Quality), EGI DS (Drawing Quality), EGI DDS (Deep Drawing Quality)

How to order

Send the Dongkuk CM part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →

View full details

Product codes & specifications

0 selected

RFQ List (0)

	Product code	Spec
	EGI CS (Commercial Quality)	Use: Commercial \| Cr-free AFP: 0.3-1.6 mm \| Coating: E08-E40
	EGI DS (Drawing Quality)	Use: Drawing \| Cr-free AFP: 0.6-1.6 mm \| Coating: E08-E40
	EGI DDS (Deep Drawing Quality)	Use: Deep drawing \| Cr-free AFP: 0.6-1.6 mm \| Coating: E08-E40
