ENGONE 4-Side Folded Steel Panel (Boltless Type, Digital Print)

Coated steel panel folded on all four sides with tongue-and-groove side joints for a boltless facade. Supplied plain, with gypsum backing or with perforated patterns.

Key features

Tongue-and-groove side joints; no exposed bolts
Joint options: with reveal gap or without gap
Optional 12.5 mm gypsum board or non-woven backing for flatness or sound absorption
Perforated type with custom patterns
Digital-print, polyester and PVDF faces

Specifications

Face material	Coated GI 0.5-1.2 mm (PE or PVDF)
Face standard	Pre-painted per KS D 3520 (GI base) / KS D 3862 (GL base)
Panel width	300-1,000 mm (standard 500 mm)
Panel length	500-3,000 mm
Corner panels	W 300-1,000 mm; L1+L2 up to 2,500 mm
Joint	Tongue and groove, boltless; gap or no gap
Backing	Optional gypsum board 12.5 mm (KS F 3504) or non-woven
Coating build-up	Epoxy primer 3-5 µm + PE/PVDF top 15-20 µm; back epoxy 3-5 µm
Digital print colours	Wood W-14-LBR, W-04-LBR, W-14-RBR, W-04-DBR; Marble & Stone M-06-IV, ST-05-MG, JWOD8A, ST-07-DB; Artcon CON-05-LG, CON-07-MG, CON-07-DG, CON-11-LG; Rusty RST-02-DG, RST-02-VBR, RST-02-LG; Stripe DLINE-PINK, DLINE-RED, DLINE-BLUE; ArtMeta-01 to ArtMeta-04
Source	ENGONE product data sheet

4SIDE BL 0.8T W500		Face: digital print \| t: 0.8 \| W: 500
4SIDE BL 1.0T W500		Face: digital print \| t: 1.0 \| W: 500
4SIDE BL 1.2T W500		Face: digital print \| t: 1.2 \| W: 500
4SIDE PERFORATED		Type: perf. \| W: 300-1000 \| L: 500-3000

Metal Facade PanelsENGONE

4 product codes available in this family

Sourced direct from KoreaExport-ready supplyCompetitive pricing

RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

ENGONE 4-Side Folded Steel Panel (Boltless Type, Digital Print)

Brand ENGONE·Metal Facade Panels

Available part numbers (4)

4SIDE BL 0.8T W500, 4SIDE BL 1.0T W500, 4SIDE BL 1.2T W500, 4SIDE PERFORATED

How to order

Send the ENGONE part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →

Colours & finishes

View full details

Product codes & specifications

0 selected

RFQ List (0)

	Product code	Spec
	4SIDE BL 0.8T W500	Face: digital print \| t: 0.8 \| W: 500
	4SIDE BL 1.0T W500	Face: digital print \| t: 1.0 \| W: 500
	4SIDE BL 1.2T W500	Face: digital print \| t: 1.2 \| W: 500
	4SIDE PERFORATED	Type: perf. \| W: 300-1000 \| L: 500-3000
