• GEMÜ 651 Diaphragm Valve (Pneumatic, fieldbus, DN 4-25)
1 1

GEMÜ 651 Diaphragm Valve (Pneumatic, fieldbus, DN 4-25)

GEMÜ 651 Diaphragm Valve (Pneumatic, fieldbus, DN 4-25)

GEMÜ 651: pneumatically operated diaphragm valve for hygienic pharmaceutical, biotech and food processes. Available with pneumatic, fieldbus actuation and nominal sizes DN 4-25.

Key features

  • Pneumatic, fieldbus actuation
  • Connections: Clamp; Flange; Spigot; Threaded
  • Body materials: 1.4408, 1.4435, 1.4539
  • Nominal sizes DN 4-25
  • Up to 10 bar operating pressure; media temperature up to 100 °C
  • Sterilisable, max. 150 °C

Specifications

Type GEMÜ 651
Actuator Pneumatic Fieldbus
Connection Clamp; Flange; Spigot; Threaded connection
Body material 1.4408, investment casting material; 1.4435 (316L), forged material; 1.4435 (BN2), forged material; 1.4435, investment casting material; 1.4539 (904L), forged material
Nominal sizes DN 4; DN 6; DN 8 (1/4"); DN 10 (3/8"); DN 15 (1/2"); DN 20 (3/4"); DN 25 (1")
Max. operating pressure 10 bar
Max. media temperature 100 °C
Min. media temperature -10 °C
Sterilisation temperature max. 150 °C
Product group Sanitary diaphragm valves
Source GEMÜ product overview: Sanitary diaphragm valves
GEMÜ 651 Actuator: Pneumatic, fieldbus | Size: DN 4-25 | Body: 1.4408/1.4435/1.4539 | Pmax: 10 bar | Tmax: 100 °C
Diaphragm ValveGEMÜ
1 product code available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

GEMÜ 651 Diaphragm Valve (Pneumatic, fieldbus, DN 4-25)

Brand GEMÜ·Diaphragm Valve

Available part numbers (1)

GEMÜ 651

How to order

Send the GEMÜ part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
GEMÜ 651Actuator: Pneumatic, fieldbus | Size: DN 4-25 | Body: 1.4408/1.4435/1.4539 | Pmax: 10 bar | Tmax: 100 °C
