HIGEN RNM VX/VY Vector Inverter Duty Motors (Flange Mount)

HIGEN RNM VX/VY Vector Inverter Duty Motors (Flange Mount)

HIGEN RNM VX and VY series vector-inverter-duty induction motors with forced cooling fan and encoder, vertical flange-mount FF215 to FF500, 0.75 to 160 kW.

Key features

  • VX model: 150% 1-minute short-time torque; VY model: wide constant-power range and 200% 1-minute torque
  • Insulation system meets NEMA MG-1 Part 31 voltage-spike requirements for IGBT inverters
  • Forced cooling fan, speed encoder and NTC overheat sensor fitted as standard
  • Wide variable speed range with constant power at high speed and full torque at low speed
  • Harmonics-reduction core for low noise; precision machining for low vibration (V15)

Specifications

Type Vector inverter duty induction motor
Base speed 1800 rpm (4P) / 1200 rpm (6P)
Maximum speed 3600 rpm (4P) / 2400 rpm (6P)
Overload VX 150% 1 min / VY 200% 1 min
Vibration / noise V15 / 75 dB(A) or less
Standard parts Cooling fan, encoder, NTC sensor
Insulation Inverter-duty, NEMA MG-1 Part 31
Installation Indoor, 1000 m max, -20 to +40 °C
Mounting Vertical, flange (FF215-FF500)
Source HIGEN RNM Low Voltage Motor catalog, p. 24-25, 27
VX FF215 112S 4P 0.75kW Model: VX | Output: 0.75 kW | Poles: 4 | Shaft: Ø28j6 | Weight: 42 kg
VX FF215 112S 4P 1.5kW Model: VX | Output: 1.5 kW | Poles: 4 | Shaft: Ø28j6 | Weight: 42 kg
VX FF215 112S 4P 2.2kW Model: VX | Output: 2.2 kW | Poles: 4 | Shaft: Ø28j6 | Weight: 42 kg
VX FF215 112S 6P 0.75kW Model: VX | Output: 0.75 kW | Poles: 6 | Shaft: Ø28j6 | Weight: 42 kg
VX FF215 112S 6P 1.5kW Model: VX | Output: 1.5 kW | Poles: 6 | Shaft: Ø28j6 | Weight: 42 kg
VY FF215 112S 4P 0.75kW Model: VY | Output: 0.75 kW | Poles: 4 | Shaft: Ø28j6 | Weight: 42 kg
VY FF215 112S 4P 1.5kW Model: VY | Output: 1.5 kW | Poles: 4 | Shaft: Ø28j6 | Weight: 42 kg
VY FF215 112S 6P 0.75kW Model: VY | Output: 0.75 kW | Poles: 6 | Shaft: Ø28j6 | Weight: 42 kg
VX FF215 112M 4P 3.7kW Model: VX | Output: 3.7 kW | Poles: 4 | Shaft: Ø28j6 | Weight: 52 kg
VX FF215 112M 6P 2.2kW Model: VX | Output: 2.2 kW | Poles: 6 | Shaft: Ø28j6 | Weight: 52 kg
VY FF215 112M 4P 2.2kW Model: VY | Output: 2.2 kW | Poles: 4 | Shaft: Ø28j6 | Weight: 52 kg
VY FF215 112M 6P 1.5kW Model: VY | Output: 1.5 kW | Poles: 6 | Shaft: Ø28j6 | Weight: 52 kg
VX FF265 132S 4P 5.5kW Model: VX | Output: 5.5 kW | Poles: 4 | Shaft: Ø38k6 | Weight: 78 kg
VX FF265 132S 6P 3.7kW Model: VX | Output: 3.7 kW | Poles: 6 | Shaft: Ø38k6 | Weight: 78 kg
VY FF265 132S 4P 3.7kW Model: VY | Output: 3.7 kW | Poles: 4 | Shaft: Ø38k6 | Weight: 72 kg
VY FF265 132S 6P 2.2kW Model: VY | Output: 2.2 kW | Poles: 6 | Shaft: Ø38k6 | Weight: 80 kg
VX FF265 132M 4P 7.5kW Model: VX | Output: 7.5 kW | Poles: 4 | Shaft: Ø38k6 | Weight: 92 kg
VX FF265 132M 6P 5.5kW Model: VX | Output: 5.5 kW | Poles: 6 | Shaft: Ø38k6 | Weight: 92 kg
VY FF265 132M 6P 3.7kW Model: VY | Output: 3.7 kW | Poles: 6 | Shaft: Ø38k6 | Weight: 94 kg
VX FF300 160M 4P 11kW Model: VX | Output: 11 kW | Poles: 4 | Shaft: Ø42k6 | Weight: 125 kg
VX FF300 160M 6P 7.5kW Model: VX | Output: 7.5 kW | Poles: 6 | Shaft: Ø42k6 | Weight: 135 kg
VY FF300 160M 4P 5.5kW Model: VY | Output: 5.5 kW | Poles: 4 | Shaft: Ø42k6 | Weight: 110 kg
VY FF300 160M 6P 5.5kW Model: VY | Output: 5.5 kW | Poles: 6 | Shaft: Ø42k6 | Weight: 135 kg
VX FF300 160L 4P 15kW Model: VX | Output: 15 kW | Poles: 4 | Shaft: Ø42k6 | Weight: 150 kg
VX FF300 160L 6P 11kW Model: VX | Output: 11 kW | Poles: 6 | Shaft: Ø42k6 | Weight: 155 kg
VY FF300 160L 4P 7.5kW Model: VY | Output: 7.5 kW | Poles: 4 | Shaft: Ø42k6 | Weight: 130 kg
VY FF300 160L 4P 11kW Model: VY | Output: 11 kW | Poles: 4 | Shaft: Ø42k6 | Weight: 150 kg
VY FF300 160L 4P 15kW Model: VY | Output: 15 kW | Poles: 4 | Shaft: Ø42k6 | Weight: 160 kg
VY FF300 160L 6P 7.5kW Model: VY | Output: 7.5 kW | Poles: 6 | Shaft: Ø42k6 | Weight: 155 kg
VX FF350 180M 4P 18.5kW Model: VX | Output: 18.5 kW | Poles: 4 | Shaft: Ø48k6 | Weight: 205 kg
VX FF350 180M 6P 15kW Model: VX | Output: 15 kW | Poles: 6 | Shaft: Ø48k6 | Weight: 215 kg
VY FF350 180M 4P 18.5kW Model: VY | Output: 18.5 kW | Poles: 4 | Shaft: Ø48k6 | Weight: 205 kg
VY FF350 180M 6P 11kW Model: VY | Output: 11 kW | Poles: 6 | Shaft: Ø48k6 | Weight: 215 kg
VX FF350 180L 4P 22kW Model: VX | Output: 22 kW | Poles: 4 | Shaft: Ø55m6 | Weight: 240 kg
VX FF350 180L 6P 18.5kW Model: VX | Output: 18.5 kW | Poles: 6 | Shaft: Ø55m6 | Weight: 245 kg
VY FF350 180L 4P 22kW Model: VY | Output: 22 kW | Poles: 4 | Shaft: Ø55m6 | Weight: 255 kg
VY FF350 180L 6P 15kW Model: VY | Output: 15 kW | Poles: 6 | Shaft: Ø55m6 | Weight: 255 kg
VX FF400 200L 4P 30kW Model: VX | Output: 30 kW | Poles: 4 | Shaft: Ø60m6 | Weight: 300 kg
VX FF400 200L 4P 37kW Model: VX | Output: 37 kW | Poles: 4 | Shaft: Ø60m6 | Weight: 325 kg
VX FF400 200L 6P 22kW Model: VX | Output: 22 kW | Poles: 6 | Shaft: Ø60m6 | Weight: 300-310 kg
VY FF400 200L 4P 30kW Model: VY | Output: 30 kW | Poles: 4 | Shaft: Ø60m6 | Weight: 325 kg
VY FF400 200L 4P 37kW Model: VY | Output: 37 kW | Poles: 4 | Shaft: Ø60m6 | Weight: 345 kg
VY FF400 200L 6P 18.5kW Model: VY | Output: 18.5 kW | Poles: 6 | Shaft: Ø60m6 | Weight: 310 kg
VY FF400 200L 6P 22kW Model: VY | Output: 22 kW | Poles: 6 | Shaft: Ø60m6 | Weight: 345 kg
VX FF400 225M 4P 45kW Model: VX | Output: 45 kW | Poles: 4 | Shaft: Ø65m6 | Weight: 385 kg
VX FF400 225M 4P 55kW Model: VX | Output: 55 kW | Poles: 4 | Shaft: Ø65m6 | Weight: 455 kg
VX FF400 225M 6P 30kW Model: VX | Output: 30 kW | Poles: 6 | Shaft: Ø65m6 | Weight: 385 kg
VX FF400 225M 6P 37kW Model: VX | Output: 37 kW | Poles: 6 | Shaft: Ø65m6 | Weight: 455 kg
VY FF400 225M 4P 45kW Model: VY | Output: 45 kW | Poles: 4 | Shaft: Ø65m6 | Weight: 455 kg
VY FF400 225M 4P 55kW Model: VY | Output: 55 kW | Poles: 4 | Shaft: Ø65m6 | Weight: 480 kg
VY FF400 225M 6P 30kW Model: VY | Output: 30 kW | Poles: 6 | Shaft: Ø65m6 | Weight: 455 kg
VY FF400 225M 6P 37kW Model: VY | Output: 37 kW | Poles: 6 | Shaft: Ø65m6 | Weight: 480 kg
VX FF500 250M 4P 75kW Model: VX | Output: 75 kW | Poles: 4 | Shaft: Ø75m6 | Weight: 535 kg
VX FF500 250M 6P 45kW Model: VX | Output: 45 kW | Poles: 6 | Shaft: Ø75m6 | Weight: 555 kg
VX FF500 250M 6P 55kW Model: VX | Output: 55 kW | Poles: 6 | Shaft: Ø75m6 | Weight: 605 kg
VY FF500 250M 4P 75kW Model: VY | Output: 75 kW | Poles: 4 | Shaft: Ø75m6 | Weight: 585 kg
VY FF500 250M 6P 45kW Model: VY | Output: 45 kW | Poles: 6 | Shaft: Ø75m6 | Weight: 555 kg
VY FF500 250M 6P 55kW Model: VY | Output: 55 kW | Poles: 6 | Shaft: Ø75m6 | Weight: 605 kg
VX FF500 280M 4P 90kW Model: VX | Output: 90 kW | Poles: 4 | Shaft: Ø85m6 | Weight: 720 kg
VX FF500 280M 6P 75kW Model: VX | Output: 75 kW | Poles: 6 | Shaft: Ø85m6 | Weight: 750 kg
VX FF500 280L 4P 110kW Model: VX | Output: 110 kW | Poles: 4 | Shaft: Ø85m6 | Weight: 750 kg
VX FF500 280L 4P 132kW Model: VX | Output: 132 kW | Poles: 4 | Shaft: Ø85m6 | Weight: 800 kg
VX FF500 280L 4P 160kW Model: VX | Output: 160 kW | Poles: 4 | Shaft: Ø85m6 | Weight: 860 kg
VX FF500 280L 6P 95kW Model: VX | Output: 95 kW | Poles: 6 | Shaft: Ø85m6 | Weight: 780 kg
VX FF500 280L 6P 110kW Model: VX | Output: 110 kW | Poles: 6 | Shaft: Ø85m6 | Weight: 820 kg
AC MotorsHIGEN RNM
65 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

HIGEN RNM VX/VY Vector Inverter Duty Motors (Flange Mount)

Brand HIGEN RNM·AC Motors

Available part numbers (65)

VX FF215 112S 4P 0.75kW, VX FF215 112S 4P 1.5kW, VX FF215 112S 4P 2.2kW, VX FF215 112S 6P 0.75kW, VX FF215 112S 6P 1.5kW, VY FF215 112S 4P 0.75kW, VY FF215 112S 4P 1.5kW, VY FF215 112S 6P 0.75kW, VX FF215 112M 4P 3.7kW, VX FF215 112M 6P 2.2kW + 55 more — see full table ↓

How to order

Send the HIGEN RNM part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.
