DeckDyne HH-200 Honeycomb Raised Floor Panel (Naval / Military)

DeckDyne HH-200 Honeycomb Raised Floor Panel (Naval / Military)

DeckDyne HH-200 is a lightweight floating floor with a non-conductive finish developed for patrol vessels and naval ships, part of Hongseong Industrial's DeckDyne raised floor range for ships and offshore units. Panels lift out easily for emergency access to equipment below.

Key features

  • Non-conductive aluminium honeycomb floor for naval CIC and central control rooms
  • Designed and installed to IMO and US MIL specifications
  • Panels remove quickly for emergency maintenance beneath the floor
  • Aluminium or steel skins on steel pedestal structure
  • Supplied for Korean Navy destroyers, frigates and other naval programmes

Specifications

Panel thickness 10 to 25 mm (other sizes available)
Panel weight 7.6 kg/m2 (12 mm base)
Skin material Aluminium or steel
Standard dimension 600 x 600 or 700 x 700 mm or custom
Core Aluminium honeycomb
Pedestal Steel structure
Standards IMO, MIL
Manufacturer Hongseong Industrial Co., Ltd. (Korea)
Source architecks.com m02_02_01
HH-200 Type: Alu honeycomb, military | Thickness: 10-25 mm | Panel: 600x600 or 700x700 mm | Weight: 7.6 kg/m2 (12 mm)
Raised Floor SystemsHongseong Industrial
1 product code available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

DeckDyne HH-200 Honeycomb Raised Floor Panel (Naval / Military)

Brand Hongseong Industrial·Raised Floor Systems

Available part numbers (1)

HH-200

How to order

Send the Hongseong Industrial part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
HH-200Type: Alu honeycomb, military | Thickness: 10-25 mm | Panel: 600x600 or 700x700 mm | Weight: 7.6 kg/m2 (12 mm)
