• Jeoneo JHS225 Heat-Shrinkable Tubing 2:1, Clear
1 1

Jeoneo JHS225 Heat-Shrinkable Tubing 2:1, Clear

Jeoneo JHS225 Heat-Shrinkable Tubing 2:1, Clear

Clear polyolefin heat-shrinkable tubing with 2:1 shrink ratio and 125 °C temperature grade, sizes 1 to 100 mm.

Key features

  • Polyolefin, continuous operating temperature -55 to 125 °C
  • Shrink ratio 2:1 (50%)
  • UL listed

Specifications

Material Polyolefin
Shrink ratio 2:1
Operating temperature -55 to 125 °C
Color Clear
JHS225-CL-1.0 Size (mm): 1.0 | Expanded D (mm): 1.4 | Expanded wall T (mm): 0.2 | Recovered d (mm): 0.5 | Recovered wall t (mm): 0.36 | Roll length (m): 200
JHS225-CL-1.5 Size (mm): 1.5 | Expanded D (mm): 2.0 | Expanded wall T (mm): 0.2 | Recovered d (mm): 0.75 | Recovered wall t (mm): 0.44 | Roll length (m): 200
JHS225-CL-2 Size (mm): 2.0 | Expanded D (mm): 2.5 | Expanded wall T (mm): 0.2 | Recovered d (mm): 1.0 | Recovered wall t (mm): 0.44 | Roll length (m): 100
JHS225-CL-2.5 Size (mm): 2.5 | Expanded D (mm): 3.0 | Expanded wall T (mm): 0.25 | Recovered d (mm): 1.25 | Recovered wall t (mm): 0.44 | Roll length (m): 100
JHS225-CL-3 Size (mm): 3.0 | Expanded D (mm): 3.4 | Expanded wall T (mm): 0.25 | Recovered d (mm): 1.5 | Recovered wall t (mm): 0.44 | Roll length (m): 100
JHS225-CL-3.5 Size (mm): 3.5 | Expanded D (mm): 3.9 | Expanded wall T (mm): 0.25 | Recovered d (mm): 1.75 | Recovered wall t (mm): 0.44 | Roll length (m): 100
JHS225-CL-4 Size (mm): 4.0 | Expanded D (mm): 4.3 | Expanded wall T (mm): 0.25 | Recovered d (mm): 2.0 | Recovered wall t (mm): 0.44 | Roll length (m): 100
JHS225-CL-4.5 Size (mm): 4.5 | Expanded D (mm): 5.0 | Expanded wall T (mm): 0.25 | Recovered d (mm): 2.25 | Recovered wall t (mm): 0.56 | Roll length (m): 100
JHS225-CL-5 Size (mm): 5.0 | Expanded D (mm): 5.6 | Expanded wall T (mm): 0.25 | Recovered d (mm): 2.5 | Recovered wall t (mm): 0.56 | Roll length (m): 100
JHS225-CL-6 Size (mm): 6.0 | Expanded D (mm): 6.5 | Expanded wall T (mm): 0.25 | Recovered d (mm): 3.0 | Recovered wall t (mm): 0.56 | Roll length (m): 100
JHS225-CL-7 Size (mm): 7.0 | Expanded D (mm): 7.7 | Expanded wall T (mm): 0.25 | Recovered d (mm): 3.5 | Recovered wall t (mm): 0.56 | Roll length (m): 100
JHS225-CL-8 Size (mm): 8.0 | Expanded D (mm): 8.6 | Expanded wall T (mm): 0.25 | Recovered d (mm): 4.0 | Recovered wall t (mm): 0.56 | Roll length (m): 100
JHS225-CL-9 Size (mm): 9.0 | Expanded D (mm): 9.8 | Expanded wall T (mm): 0.25 | Recovered d (mm): 4.5 | Recovered wall t (mm): 0.56 | Roll length (m): 100
JHS225-CL-10 Size (mm): 10.0 | Expanded D (mm): 10.4 | Expanded wall T (mm): 0.25 | Recovered d (mm): 5.0 | Recovered wall t (mm): 0.56 | Roll length (m): 100
JHS225-CL-11 Size (mm): 11.0 | Expanded D (mm): 11.4 | Expanded wall T (mm): 0.25 | Recovered d (mm): 5.5 | Recovered wall t (mm): 0.56 | Roll length (m): 100
JHS225-CL-12 Size (mm): 12.0 | Expanded D (mm): 12.5 | Expanded wall T (mm): 0.25 | Recovered d (mm): 6.0 | Recovered wall t (mm): 0.56 | Roll length (m): 100
JHS225-CL-13 Size (mm): 13.0 | Expanded D (mm): 13.7 | Expanded wall T (mm): 0.30 | Recovered d (mm): 6.5 | Recovered wall t (mm): 0.69 | Roll length (m): 100
JHS225-CL-14 Size (mm): 14.0 | Expanded D (mm): 14.4 | Expanded wall T (mm): 0.30 | Recovered d (mm): 7.0 | Recovered wall t (mm): 0.69 | Roll length (m): 100
JHS225-CL-15 Size (mm): 15.0 | Expanded D (mm): 15.6 | Expanded wall T (mm): 0.30 | Recovered d (mm): 7.5 | Recovered wall t (mm): 0.69 | Roll length (m): 100
JHS225-CL-16 Size (mm): 16.0 | Expanded D (mm): 16.7 | Expanded wall T (mm): 0.30 | Recovered d (mm): 8.0 | Recovered wall t (mm): 0.69 | Roll length (m): 100
JHS225-CL-18 Size (mm): 18.0 | Expanded D (mm): 19.3 | Expanded wall T (mm): 0.35 | Recovered d (mm): 9.0 | Recovered wall t (mm): 0.77 | Roll length (m): 50
JHS225-CL-20 Size (mm): 20.0 | Expanded D (mm): 21.7 | Expanded wall T (mm): 0.40 | Recovered d (mm): 10.0 | Recovered wall t (mm): 0.77 | Roll length (m): 50
JHS225-CL-22 Size (mm): 22.0 | Expanded D (mm): 23.4 | Expanded wall T (mm): 0.40 | Recovered d (mm): 11.0 | Recovered wall t (mm): 0.77 | Roll length (m): 50
JHS225-CL-25 Size (mm): 25.0 | Expanded D (mm): 25.5 | Expanded wall T (mm): 0.45 | Recovered d (mm): 12.5 | Recovered wall t (mm): 0.87 | Roll length (m): 50
JHS225-CL-28 Size (mm): 28.0 | Expanded D (mm): 29.0 | Expanded wall T (mm): 0.45 | Recovered d (mm): 14.0 | Recovered wall t (mm): 0.87 | Roll length (m): 50
JHS225-CL-30 Size (mm): 30.0 | Expanded D (mm): 31.0 | Expanded wall T (mm): 0.45 | Recovered d (mm): 15.0 | Recovered wall t (mm): 0.87 | Roll length (m): 50
JHS225-CL-38 Size (mm): 38.0 | Expanded D (mm): 39.0 | Expanded wall T (mm): 0.45 | Recovered d (mm): 19.0 | Recovered wall t (mm): 0.97 | Roll length (m): 50
JHS225-CL-50 Size (mm): 50.0 | Expanded D (mm): 51.0 | Expanded wall T (mm): 0.45 | Recovered d (mm): 25.0 | Recovered wall t (mm): 0.97 | Roll length (m): 50
JHS225-CL-60 Size (mm): 60.0 | Expanded D (mm): 63.5 | Expanded wall T (mm): 0.55 | Recovered d (mm): 31.75 | Recovered wall t (mm): 1.1 | Roll length (m): 25
JHS225-CL-75 Size (mm): 75.0 | Expanded D (mm): 76.2 | Expanded wall T (mm): 0.6 | Recovered d (mm): 38.1 | Recovered wall t (mm): 1.17 | Roll length (m): 25
JHS225-CL-100 Size (mm): 100.0 | Expanded D (mm): 101.6 | Expanded wall T (mm): 0.7 | Recovered d (mm): 50.8 | Recovered wall t (mm): 1.17 | Roll length (m): 20
Heat Shrink TubingJeoneo
31 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Jeoneo JHS225 Heat-Shrinkable Tubing 2:1, Clear

Brand Jeoneo·Heat Shrink Tubing

Available part numbers (31)

JHS225-CL-1.0, JHS225-CL-1.5, JHS225-CL-2, JHS225-CL-2.5, JHS225-CL-3, JHS225-CL-3.5, JHS225-CL-4, JHS225-CL-4.5, JHS225-CL-5, JHS225-CL-6 + 21 more — see full table ↓

How to order

Send the Jeoneo part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
JHS225-CL-1.0Size (mm): 1.0 | Expanded D (mm): 1.4 | Expanded wall T (mm): 0.2 | Recovered d (mm): 0.5 | Recovered wall t (mm): 0.36 | Roll length (m): 200
JHS225-CL-1.5Size (mm): 1.5 | Expanded D (mm): 2.0 | Expanded wall T (mm): 0.2 | Recovered d (mm): 0.75 | Recovered wall t (mm): 0.44 | Roll length (m): 200
JHS225-CL-2Size (mm): 2.0 | Expanded D (mm): 2.5 | Expanded wall T (mm): 0.2 | Recovered d (mm): 1.0 | Recovered wall t (mm): 0.44 | Roll length (m): 100
JHS225-CL-2.5Size (mm): 2.5 | Expanded D (mm): 3.0 | Expanded wall T (mm): 0.25 | Recovered d (mm): 1.25 | Recovered wall t (mm): 0.44 | Roll length (m): 100
JHS225-CL-3Size (mm): 3.0 | Expanded D (mm): 3.4 | Expanded wall T (mm): 0.25 | Recovered d (mm): 1.5 | Recovered wall t (mm): 0.44 | Roll length (m): 100
JHS225-CL-3.5Size (mm): 3.5 | Expanded D (mm): 3.9 | Expanded wall T (mm): 0.25 | Recovered d (mm): 1.75 | Recovered wall t (mm): 0.44 | Roll length (m): 100
JHS225-CL-4Size (mm): 4.0 | Expanded D (mm): 4.3 | Expanded wall T (mm): 0.25 | Recovered d (mm): 2.0 | Recovered wall t (mm): 0.44 | Roll length (m): 100
JHS225-CL-4.5Size (mm): 4.5 | Expanded D (mm): 5.0 | Expanded wall T (mm): 0.25 | Recovered d (mm): 2.25 | Recovered wall t (mm): 0.56 | Roll length (m): 100
JHS225-CL-5Size (mm): 5.0 | Expanded D (mm): 5.6 | Expanded wall T (mm): 0.25 | Recovered d (mm): 2.5 | Recovered wall t (mm): 0.56 | Roll length (m): 100
JHS225-CL-6Size (mm): 6.0 | Expanded D (mm): 6.5 | Expanded wall T (mm): 0.25 | Recovered d (mm): 3.0 | Recovered wall t (mm): 0.56 | Roll length (m): 100
JHS225-CL-7Size (mm): 7.0 | Expanded D (mm): 7.7 | Expanded wall T (mm): 0.25 | Recovered d (mm): 3.5 | Recovered wall t (mm): 0.56 | Roll length (m): 100
JHS225-CL-8Size (mm): 8.0 | Expanded D (mm): 8.6 | Expanded wall T (mm): 0.25 | Recovered d (mm): 4.0 | Recovered wall t (mm): 0.56 | Roll length (m): 100
JHS225-CL-9Size (mm): 9.0 | Expanded D (mm): 9.8 | Expanded wall T (mm): 0.25 | Recovered d (mm): 4.5 | Recovered wall t (mm): 0.56 | Roll length (m): 100
JHS225-CL-10Size (mm): 10.0 | Expanded D (mm): 10.4 | Expanded wall T (mm): 0.25 | Recovered d (mm): 5.0 | Recovered wall t (mm): 0.56 | Roll length (m): 100
JHS225-CL-11Size (mm): 11.0 | Expanded D (mm): 11.4 | Expanded wall T (mm): 0.25 | Recovered d (mm): 5.5 | Recovered wall t (mm): 0.56 | Roll length (m): 100
JHS225-CL-12Size (mm): 12.0 | Expanded D (mm): 12.5 | Expanded wall T (mm): 0.25 | Recovered d (mm): 6.0 | Recovered wall t (mm): 0.56 | Roll length (m): 100
JHS225-CL-13Size (mm): 13.0 | Expanded D (mm): 13.7 | Expanded wall T (mm): 0.30 | Recovered d (mm): 6.5 | Recovered wall t (mm): 0.69 | Roll length (m): 100
JHS225-CL-14Size (mm): 14.0 | Expanded D (mm): 14.4 | Expanded wall T (mm): 0.30 | Recovered d (mm): 7.0 | Recovered wall t (mm): 0.69 | Roll length (m): 100
JHS225-CL-15Size (mm): 15.0 | Expanded D (mm): 15.6 | Expanded wall T (mm): 0.30 | Recovered d (mm): 7.5 | Recovered wall t (mm): 0.69 | Roll length (m): 100
JHS225-CL-16Size (mm): 16.0 | Expanded D (mm): 16.7 | Expanded wall T (mm): 0.30 | Recovered d (mm): 8.0 | Recovered wall t (mm): 0.69 | Roll length (m): 100
JHS225-CL-18Size (mm): 18.0 | Expanded D (mm): 19.3 | Expanded wall T (mm): 0.35 | Recovered d (mm): 9.0 | Recovered wall t (mm): 0.77 | Roll length (m): 50
JHS225-CL-20Size (mm): 20.0 | Expanded D (mm): 21.7 | Expanded wall T (mm): 0.40 | Recovered d (mm): 10.0 | Recovered wall t (mm): 0.77 | Roll length (m): 50
JHS225-CL-22Size (mm): 22.0 | Expanded D (mm): 23.4 | Expanded wall T (mm): 0.40 | Recovered d (mm): 11.0 | Recovered wall t (mm): 0.77 | Roll length (m): 50
JHS225-CL-25Size (mm): 25.0 | Expanded D (mm): 25.5 | Expanded wall T (mm): 0.45 | Recovered d (mm): 12.5 | Recovered wall t (mm): 0.87 | Roll length (m): 50
JHS225-CL-28Size (mm): 28.0 | Expanded D (mm): 29.0 | Expanded wall T (mm): 0.45 | Recovered d (mm): 14.0 | Recovered wall t (mm): 0.87 | Roll length (m): 50
JHS225-CL-30Size (mm): 30.0 | Expanded D (mm): 31.0 | Expanded wall T (mm): 0.45 | Recovered d (mm): 15.0 | Recovered wall t (mm): 0.87 | Roll length (m): 50
JHS225-CL-38Size (mm): 38.0 | Expanded D (mm): 39.0 | Expanded wall T (mm): 0.45 | Recovered d (mm): 19.0 | Recovered wall t (mm): 0.97 | Roll length (m): 50
JHS225-CL-50Size (mm): 50.0 | Expanded D (mm): 51.0 | Expanded wall T (mm): 0.45 | Recovered d (mm): 25.0 | Recovered wall t (mm): 0.97 | Roll length (m): 50
JHS225-CL-60Size (mm): 60.0 | Expanded D (mm): 63.5 | Expanded wall T (mm): 0.55 | Recovered d (mm): 31.75 | Recovered wall t (mm): 1.1 | Roll length (m): 25
JHS225-CL-75Size (mm): 75.0 | Expanded D (mm): 76.2 | Expanded wall T (mm): 0.6 | Recovered d (mm): 38.1 | Recovered wall t (mm): 1.17 | Roll length (m): 25
JHS225-CL-100Size (mm): 100.0 | Expanded D (mm): 101.6 | Expanded wall T (mm): 0.7 | Recovered d (mm): 50.8 | Recovered wall t (mm): 1.17 | Roll length (m): 20

Need a different model, or a part not listed here? Send us your parts list →
