KACON H Series Ø25/Ø30 LED Pilot Lamps

KACON H Series LED pilot lamps with BA9S LED for Ø25 and Ø30 panel holes in five lens colours.

Key features

Ø25 (H25) and Ø30 (H30) panel sizes
BA9S + L type LED
Lamp voltage 24VDC, 110VDC, 110VAC or 220VAC
Red, green, blue, yellow, white
IP65

Specifications

Light source	BA9S LED
Lamp voltage	24VDC / 110VDC / 110VAC / 220VAC (specify)
LED current	Approx. 15mA
LED life	Min. 50,000 hrs
Degree of protection	IP65
Ambient temperature	-25 to +70°C (no icing)
Panel cut-out	Ø25.5 (+0.4) / Ø30.5 (+0.5)
Source	KACON H Series Catalog catalogue, p. 2-3

H25-17R		Panel hole: Ø25 \| Colour: Red
H25-17G		Panel hole: Ø25 \| Colour: Green
H25-17B		Panel hole: Ø25 \| Colour: Blue
H25-17Y		Panel hole: Ø25 \| Colour: Yellow
H25-17W		Panel hole: Ø25 \| Colour: White
H30-17R		Panel hole: Ø30 \| Colour: Red
H30-17G		Panel hole: Ø30 \| Colour: Green
H30-17B		Panel hole: Ø30 \| Colour: Blue
H30-17Y		Panel hole: Ø30 \| Colour: Yellow
H30-17W		Panel hole: Ø30 \| Colour: White

Pilot LampsKACON

10 product codes available in this family

Sourced direct from KoreaExport-ready supplyCompetitive pricing

RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

KACON H Series Ø25/Ø30 LED Pilot Lamps

Brand KACON·Pilot Lamps

Available part numbers (10)

H25-17R, H25-17G, H25-17B, H25-17Y, H25-17W, H30-17R, H30-17G, H30-17B, H30-17Y, H30-17W

How to order

Send the KACON part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.
