KACON J2 Series Ø40 Emergency Stop Switches

KACON J2 Ø40 red mushroom emergency stop switches with positive-opening 1NC contact, non-illuminated or LED-illuminated.

Key features

Ø40 red mushroom head for Ø22/Ø25 holes
Standard 1NC (J2-01) positive-opening contact (IEC 60947-5-1)
Illuminated version with LED options D6 to A2
Compatible with KEG guards and HP119 name plates
Min. 50mm hole spacing

Specifications

Colour	Red
Head	Ø40 mushroom
Standard contact	1NC (J2-01)
Lamp voltage (illuminated)	D6 / D12 / D4 / A1 / A2 (specify)
Panel cut-out	Ø22 / Ø25 (ring compatible)
Contact rating	10A 240VAC AC-12 / 3A 240VAC AC-15
Rated insulation voltage	600V
Terminal	M3.5 screw, 14-16AWG
Ambient temperature	-20 to +55°C
Source	KACON J2 Catalog catalogue, p. 1-2, 6

J2-8701		Illumination: Illuminated LED \| Max. contact blocks: 2
J2-9101		Illumination: Non-illuminated \| Max. contact blocks: 3

Emergency Stop SwitchesKACON

2 product codes available in this family

Sourced direct from KoreaExport-ready supplyCompetitive pricing

RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

KACON J2 Series Ø40 Emergency Stop Switches

Brand KACON·Emergency Stop Switches

Available part numbers (2)

J2-8701, J2-9101

How to order

Send the KACON part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.
