KCC Ceiling Suspension Grid Components (T-Bar / T&H-Bar / M-Bar)

KCC Ceiling Suspension Grid Components (T-Bar / T&H-Bar / M-Bar)

These are the suspension components KCC lists for MITONE ceiling systems: exposed T-Bar grids, semi-concealed T&H-Bar and Module Bar lines, and the M-Bar system. Each item is shown with the section size from KCC's materials schedules.

Key features

  • 25 mm and 20 mm galvanized T-Bars (white plus six colours) for 610/640 mm modules
  • Line T-Bar with two-tone groove, wire-hung for faster installation
  • Aluminium 15 mm, Omega and Module Bar profiles with epoxy powder coating
  • Carrying/minor channels, clips, joints, hangers and bolts for complete suspension
  • Matched to KCC MITONE, MITEX and SUKGOTEX ceiling boards

Specifications

Steel bars Galvanized steel + anti-corrosion coat
Steel standard KS D 3506
Aluminium bars Al extrusion + epoxy powder coat
T-Bar colours White and six other colours (25/20 mm)
Hanger spacing @900-1,200 mm (strong anchors)
Minor channel spacing @2,000-3,000 mm
Source KCC MITONE catalogue (2025.03), systems
MAIN T-BAR 0.4T 38x25 Item: 25 mm T-Bar main | Material: Galvanized steel (KS D 3506) | Use: KCC ceiling systems
CROSS T-BAR 0.4T 25x25 Item: 25 mm T-Bar cross | Material: Galvanized steel (KS D 3506) | Use: KCC ceiling systems
MAIN T-BAR 0.4T 38x20 Item: 20 mm T-Bar main | Material: Galvanized steel (KS D 3506) | Use: KCC ceiling systems
CROSS T-BAR 0.4T 25x20 Item: 20 mm T-Bar cross | Material: Galvanized steel (KS D 3506) | Use: KCC ceiling systems
LINE T-BAR 0.4T 42x16 Item: Line T-Bar main/cross | Material: Galvanized steel (KS D 3506) | Use: KCC ceiling systems
AL T-BAR 1.2T 38x15 Item: 15 mm T-Bar main/cross | Material: Aluminium, epoxy powder coat | Use: KCC ceiling systems
AL OMEGA T-BAR 1.2T 38x25 Item: Omega T-Bar main/cross | Material: Aluminium, epoxy powder coat | Use: KCC ceiling systems
AL OMEGA T-BAR 1.2T 35x66 Item: Omega T-Bar (LP system) | Material: Aluminium, epoxy powder coat | Use: KCC ceiling systems
AL MODULE BAR 1.2T 70x38 Item: Module Bar (T&H/Pyramodule) | Material: Aluminium, epoxy powder coat | Use: KCC ceiling systems
H-BAR 0.45T 20x20 Item: H-Bar (T&H-Bar system) | Material: Steel | Use: KCC ceiling systems
Z-BAR 0.5T 20x50 Item: Z-Bar (LP long-panel) | Material: Steel | Use: KCC ceiling systems
M-BAR 0.5T 50x19 Item: M-Bar (M-Bar system) | Material: Steel | Use: KCC ceiling systems
CARRYING CHANNEL 1.2T 38x12 Item: Carrying channel | Material: Steel | Use: KCC ceiling systems
MINOR CHANNEL 1.2T 19x10 Item: Minor channel | Material: Steel | Use: KCC ceiling systems
CARRYING JOINT 0.5T 100x35x10 Item: Carrying channel joint | Material: Steel | Use: KCC ceiling systems
CHANNEL CLIP 1.2T 38x23x14 Item: Channel clip | Material: Steel | Use: KCC ceiling systems
HOLD DOWN CLIP 0.5T 16x25 Item: Hold-down clip (T-Bar) | Material: Steel | Use: KCC ceiling systems
HANGER AND PIN 2.0T 105x20 Item: Hanger and pin | Material: Steel | Use: KCC ceiling systems
HANGER BOLT D9x1000 Item: Hanger bolt | Material: Steel | Use: KCC ceiling systems
HANGER WIRE D3.5x1000 Item: Hanger wire (Line T-Bar) | Material: Steel wire | Use: KCC ceiling systems
Ceiling SystemsKCC Corporation
20 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

KCC Ceiling Suspension Grid Components (T-Bar / T&H-Bar / M-Bar)

Brand KCC Corporation·Ceiling Systems

Available part numbers (20)

MAIN T-BAR 0.4T 38x25, CROSS T-BAR 0.4T 25x25, MAIN T-BAR 0.4T 38x20, CROSS T-BAR 0.4T 25x20, LINE T-BAR 0.4T 42x16, AL T-BAR 1.2T 38x15, AL OMEGA T-BAR 1.2T 38x25, AL OMEGA T-BAR 1.2T 35x66, AL MODULE BAR 1.2T 70x38, H-BAR 0.45T 20x20 + 10 more — see full table ↓

How to order

Send the KCC Corporation part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
MAIN T-BAR 0.4T 38x25Item: 25 mm T-Bar main | Material: Galvanized steel (KS D 3506) | Use: KCC ceiling systems
CROSS T-BAR 0.4T 25x25Item: 25 mm T-Bar cross | Material: Galvanized steel (KS D 3506) | Use: KCC ceiling systems
MAIN T-BAR 0.4T 38x20Item: 20 mm T-Bar main | Material: Galvanized steel (KS D 3506) | Use: KCC ceiling systems
CROSS T-BAR 0.4T 25x20Item: 20 mm T-Bar cross | Material: Galvanized steel (KS D 3506) | Use: KCC ceiling systems
LINE T-BAR 0.4T 42x16Item: Line T-Bar main/cross | Material: Galvanized steel (KS D 3506) | Use: KCC ceiling systems
AL T-BAR 1.2T 38x15Item: 15 mm T-Bar main/cross | Material: Aluminium, epoxy powder coat | Use: KCC ceiling systems
AL OMEGA T-BAR 1.2T 38x25Item: Omega T-Bar main/cross | Material: Aluminium, epoxy powder coat | Use: KCC ceiling systems
AL OMEGA T-BAR 1.2T 35x66Item: Omega T-Bar (LP system) | Material: Aluminium, epoxy powder coat | Use: KCC ceiling systems
AL MODULE BAR 1.2T 70x38Item: Module Bar (T&H/Pyramodule) | Material: Aluminium, epoxy powder coat | Use: KCC ceiling systems
H-BAR 0.45T 20x20Item: H-Bar (T&H-Bar system) | Material: Steel | Use: KCC ceiling systems
Z-BAR 0.5T 20x50Item: Z-Bar (LP long-panel) | Material: Steel | Use: KCC ceiling systems
M-BAR 0.5T 50x19Item: M-Bar (M-Bar system) | Material: Steel | Use: KCC ceiling systems
CARRYING CHANNEL 1.2T 38x12Item: Carrying channel | Material: Steel | Use: KCC ceiling systems
MINOR CHANNEL 1.2T 19x10Item: Minor channel | Material: Steel | Use: KCC ceiling systems
CARRYING JOINT 0.5T 100x35x10Item: Carrying channel joint | Material: Steel | Use: KCC ceiling systems
CHANNEL CLIP 1.2T 38x23x14Item: Channel clip | Material: Steel | Use: KCC ceiling systems
HOLD DOWN CLIP 0.5T 16x25Item: Hold-down clip (T-Bar) | Material: Steel | Use: KCC ceiling systems
HANGER AND PIN 2.0T 105x20Item: Hanger and pin | Material: Steel | Use: KCC ceiling systems
HANGER BOLT D9x1000Item: Hanger bolt | Material: Steel | Use: KCC ceiling systems
HANGER WIRE D3.5x1000Item: Hanger wire (Line T-Bar) | Material: Steel wire | Use: KCC ceiling systems
