KCC Mineral Wool Wired Blanket (60-140 kg/m3, Wire Mesh Faced)

KCC Mineral Wool Wired Blanket (60-140 kg/m3, Wire Mesh Faced)

KCC Mineral Wool Wired Blanket is a vibration-resistant, wire-mesh-faced mineral wool blanket for insulating high-temperature equipment of complex shape such as large pipes, tanks, ducts and vessels.

Key features

  • Superb thermal insulation at high temperatures
  • Single-sided wire mesh facing, resistant to vibration
  • Flexible for complex equipment configurations
  • Sound absorption for noise-generating thermal facilities
  • Thermal shrinkage temperature over 600C

Specifications

Material Mineral wool blanket with single-sided wire mesh
Density 60, 80, 100, 120, 140 kg/m3
Thickness 50/75/100 mm (60-100K); 25/50/75 mm (120-140K)
Width 1000 mm
Length 1-10 m
Thermal conductivity 0.035 W/mK (20C); 0.042-0.043 W/mK (70C)
Thermal shrinkage temp. Over 600C
Related standards KS L 9102, JIS A 9504, ASTM C592
Source KCC Mineral Wool catalogue (2025.03)
MINERAL WOOL WIRED BLANKET 60K 50T Type: Type 1a | Density: 60 kg/m3 | Thickness: 50 mm | Width: 1000 mm | Length: 1-10 m
MINERAL WOOL WIRED BLANKET 60K 75T Type: Type 1a | Density: 60 kg/m3 | Thickness: 75 mm | Width: 1000 mm | Length: 1-10 m
MINERAL WOOL WIRED BLANKET 60K 100T Type: Type 1a | Density: 60 kg/m3 | Thickness: 100 mm | Width: 1000 mm | Length: 1-10 m
MINERAL WOOL WIRED BLANKET 80K 50T Type: Type 1b | Density: 80 kg/m3 | Thickness: 50 mm | Width: 1000 mm | Length: 1-10 m
MINERAL WOOL WIRED BLANKET 80K 75T Type: Type 1b | Density: 80 kg/m3 | Thickness: 75 mm | Width: 1000 mm | Length: 1-10 m
MINERAL WOOL WIRED BLANKET 80K 100T Type: Type 1b | Density: 80 kg/m3 | Thickness: 100 mm | Width: 1000 mm | Length: 1-10 m
MINERAL WOOL WIRED BLANKET 100K 50T Type: Type 1b | Density: 100 kg/m3 | Thickness: 50 mm | Width: 1000 mm | Length: 1-10 m
MINERAL WOOL WIRED BLANKET 100K 75T Type: Type 1b | Density: 100 kg/m3 | Thickness: 75 mm | Width: 1000 mm | Length: 1-10 m
MINERAL WOOL WIRED BLANKET 100K 100T Type: Type 1b | Density: 100 kg/m3 | Thickness: 100 mm | Width: 1000 mm | Length: 1-10 m
MINERAL WOOL WIRED BLANKET 120K 25T Type: Type 2 | Density: 120 kg/m3 | Thickness: 25 mm | Width: 1000 mm | Length: 1-10 m
MINERAL WOOL WIRED BLANKET 120K 50T Type: Type 2 | Density: 120 kg/m3 | Thickness: 50 mm | Width: 1000 mm | Length: 1-10 m
MINERAL WOOL WIRED BLANKET 120K 75T Type: Type 2 | Density: 120 kg/m3 | Thickness: 75 mm | Width: 1000 mm | Length: 1-10 m
MINERAL WOOL WIRED BLANKET 140K 25T Type: Type 2 | Density: 140 kg/m3 | Thickness: 25 mm | Width: 1000 mm | Length: 1-10 m
MINERAL WOOL WIRED BLANKET 140K 50T Type: Type 2 | Density: 140 kg/m3 | Thickness: 50 mm | Width: 1000 mm | Length: 1-10 m
MINERAL WOOL WIRED BLANKET 140K 75T Type: Type 2 | Density: 140 kg/m3 | Thickness: 75 mm | Width: 1000 mm | Length: 1-10 m
Mineral Wool InsulationKCC Corporation
15 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

KCC Mineral Wool Wired Blanket (60-140 kg/m3, Wire Mesh Faced)

Brand KCC Corporation·Mineral Wool Insulation

Available part numbers (15)

MINERAL WOOL WIRED BLANKET 60K 50T, MINERAL WOOL WIRED BLANKET 60K 75T, MINERAL WOOL WIRED BLANKET 60K 100T, MINERAL WOOL WIRED BLANKET 80K 50T, MINERAL WOOL WIRED BLANKET 80K 75T, MINERAL WOOL WIRED BLANKET 80K 100T, MINERAL WOOL WIRED BLANKET 100K 50T, MINERAL WOOL WIRED BLANKET 100K 75T, MINERAL WOOL WIRED BLANKET 100K 100T, MINERAL WOOL WIRED BLANKET 120K 25T + 5 more — see full table ↓
