KCC MITONE SKY Suspended Acoustic Ceiling/Wall Panel (30-50 mm)

KCC MITONE SKY Suspended Acoustic Ceiling/Wall Panel (30-50 mm)

KCC MITONE SKY is a free-hanging acoustic panel made from mineral wool with a Cloudia face. It hangs from exposed slabs or gypsum ceilings on wires or fixing profiles, and a round-frame version mounts on walls to reduce reverberation.

Key features

  • Mineral wool sound-absorbing panels cut reverberation from exposed concrete or gypsum ceilings
  • Wire, profile and wall installation types; square, rectangular, vertical and circular shapes
  • Supplied as a package with fixings (wire set, anchors, profiles) for easy installation
  • Aluminium-frame types can take fabric facings in a custom colour palette
  • Independent seismic-safe ceiling system verified by KDS seismic testing

Specifications

Material Mineral wool board, Cloudia (glass tissue) face
Thickness 30 mm non-frame / 40 mm frame / 50 mm vertical
Frame Aluminium (frame and round types)
Installation Wire, profile (ceiling) or wall profile
Wire set Rope D1.2 x 1,000 mm, top/bottom hooks
Acoustic result RT cut about 0.7 s (KCC lab test)
Use Exposed ceilings, offices, cafes, lobbies, gyms
Source KCC MITONE SKY catalogue (2026.08)
MITONE SKY MKNWWAA00A00 30T 1000x1000 Type: Non-frame | Install: Wire | Weight: 8.0 kg +/-0.3
MITONE SKY MKNPWAA00A00 30T 1000x1000 Type: Non-frame | Install: Profile | Weight: 8.2 kg +/-0.3
MITONE SKY MKWWWBA00A00 40T 1000x1000 Type: Al frame | Install: Wire | Weight: 6.0 kg +/-0.3
MITONE SKY MKWPWBA00A00 40T 1000x1000 Type: Al frame | Install: Profile | Weight: 6.2 kg +/-0.3
MITONE SKY MKWWWB600600 40T 600x600 Type: Al frame | Install: Wire | Weight: 2.9 kg +/-0.3
MITONE SKY MKWWWB600A00 40T 600x1000 Type: Al frame | Install: Wire | Weight: 4.35 kg +/-0.3
MITONE SKY MKWPWB600600 40T 600x600 Type: Al frame | Install: Profile | Weight: 3.0 kg +/-0.3
MITONE SKY MKWPWB600A00 40T 600x1000 Type: Al frame | Install: Profile | Weight: 4.45 kg +/-0.3
MITONE SKY MKWVWD300A00 50T 300x1000 Type: Al frame, vertical | Install: Wire | Weight: 3.4 kg +/-0.3
MITONE SKY MKWWWBA00 40T D1000 Type: Round Al frame | Install: Wire | Weight: 5.2 kg +/-0.3
MITONE SKY MKWWWBB80B80 40T D800 Type: Round Al frame | Install: Wire | Weight: 4.5 kg +/-0.3
MITONE SKY MKWWWBB60B60 40T D600 Type: Round Al frame | Install: Wire | Weight: 3.9 kg +/-0.3
MITONE SKY MKRPWBA00A00 40T 1000x1000 Type: Wall, round-corner frame | Install: Wall profile | Weight: 6.2 kg +/-0.3
MITONE SKY MKRPWB600A00 40T 600x1000 Type: Wall, round-corner frame | Install: Wall profile | Weight: 4.35 kg +/-0.3
MITONE SKY MKRPWB600600 40T 600x600 Type: Wall, round-corner frame | Install: Wall profile | Weight: 2.9 kg +/-0.3
Acoustic PanelsKCC Corporation
15 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

KCC MITONE SKY Suspended Acoustic Ceiling/Wall Panel (30-50 mm)

Brand KCC Corporation·Acoustic Panels

Available part numbers (15)

MITONE SKY MKNWWAA00A00 30T 1000x1000, MITONE SKY MKNPWAA00A00 30T 1000x1000, MITONE SKY MKWWWBA00A00 40T 1000x1000, MITONE SKY MKWPWBA00A00 40T 1000x1000, MITONE SKY MKWWWB600600 40T 600x600, MITONE SKY MKWWWB600A00 40T 600x1000, MITONE SKY MKWPWB600600 40T 600x600, MITONE SKY MKWPWB600A00 40T 600x1000, MITONE SKY MKWVWD300A00 50T 300x1000, MITONE SKY MKWWWBA00 40T D1000 + 5 more — see full table ↓

How to order

Send the KCC Corporation part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
MITONE SKY MKNWWAA00A00 30T 1000x1000Type: Non-frame | Install: Wire | Weight: 8.0 kg +/-0.3
MITONE SKY MKNPWAA00A00 30T 1000x1000Type: Non-frame | Install: Profile | Weight: 8.2 kg +/-0.3
MITONE SKY MKWWWBA00A00 40T 1000x1000Type: Al frame | Install: Wire | Weight: 6.0 kg +/-0.3
MITONE SKY MKWPWBA00A00 40T 1000x1000Type: Al frame | Install: Profile | Weight: 6.2 kg +/-0.3
MITONE SKY MKWWWB600600 40T 600x600Type: Al frame | Install: Wire | Weight: 2.9 kg +/-0.3
MITONE SKY MKWWWB600A00 40T 600x1000Type: Al frame | Install: Wire | Weight: 4.35 kg +/-0.3
MITONE SKY MKWPWB600600 40T 600x600Type: Al frame | Install: Profile | Weight: 3.0 kg +/-0.3
MITONE SKY MKWPWB600A00 40T 600x1000Type: Al frame | Install: Profile | Weight: 4.45 kg +/-0.3
MITONE SKY MKWVWD300A00 50T 300x1000Type: Al frame, vertical | Install: Wire | Weight: 3.4 kg +/-0.3
MITONE SKY MKWWWBA00 40T D1000Type: Round Al frame | Install: Wire | Weight: 5.2 kg +/-0.3
MITONE SKY MKWWWBB80B80 40T D800Type: Round Al frame | Install: Wire | Weight: 4.5 kg +/-0.3
MITONE SKY MKWWWBB60B60 40T D600Type: Round Al frame | Install: Wire | Weight: 3.9 kg +/-0.3
MITONE SKY MKRPWBA00A00 40T 1000x1000Type: Wall, round-corner frame | Install: Wall profile | Weight: 6.2 kg +/-0.3
MITONE SKY MKRPWB600A00 40T 600x1000Type: Wall, round-corner frame | Install: Wall profile | Weight: 4.35 kg +/-0.3
MITONE SKY MKRPWB600600 40T 600x600Type: Wall, round-corner frame | Install: Wall profile | Weight: 2.9 kg +/-0.3
