KITZ 175 psi Stainless Steel Threaded Butterfly Valve (UV)

KITZ 175 psi Stainless Steel Threaded Butterfly Valve (UV)

KITZ Fig. UV: Threaded compact butterfly valve (KITZ BUTTER series) with W-NBR seat and balancing stop lever. 175 psi, BS21 (JIS B0203) ends, sizes 1/2 in to 2 in.

Key features

  • Threaded ends (JIS B0203) for small-size piping
  • Approx. 1/4 the weight of an equivalent ball valve
  • W-NBR seat with self-cleaning sealing section
  • Balancing stop handle for flow volume control
  • Body CF8; disc 304SS + W-NBR; stem 304SS

Specifications

Pressure class 175 psi
End connection BS21 (JIS B0203)
Body CF8
Stem/Bottom Stem 304SS
Disc 304SS + W-NBR
Packing/O ring NBR
Handle 430SS
Service conditions W.O.G. Non-shock 1.21MPa(175psi) (DO NOT USE against Flammable (Gas or Toxic Gas.)
Remarks Balancing Stop Handle Lever
Dimension key L face-to-face, H height, D handwheel/lever; B gear (per catalogue drawing)
Source KITZ General Catalog E-020=26 (KITZ_general.pdf), p. 125
UV 15A Size: 1/2 in (15A) | Dimensions (mm): L 43, H 45, D 85
UV 20A Size: 3/4 in (20A) | Dimensions (mm): L 47, H 47, D 85
UV 25A Size: 1 in (25A) | Dimensions (mm): L 56, H 50, D 85
UV 32A Size: 1-1/4 in (32A) | Dimensions (mm): L 63, H 60, D 110
UV 40A Size: 1-1/2 in (40A) | Dimensions (mm): L 69, H 64, D 110
UV 50A Size: 2 in (50A) | Dimensions (mm): L 77, H 70, D 110
Butterfly ValvesKITZ
6 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

KITZ 175 psi Stainless Steel Threaded Butterfly Valve (UV)

Brand KITZ·Butterfly Valves

Available part numbers (6)

UV 15A, UV 20A, UV 25A, UV 32A, UV 40A, UV 50A
