LK LTHM-490 Chain Hoist (4-Point)

LK LTHM-490 Chain Hoist (4-Point)

The LK LTHM-490 Chain Hoist (4-Point) is a heavy-duty lifting device designed for secure multi-point load handling, sourced direct from Korea.

Key features

  • Four-point chain hoists are commonly used in industrial rigging, construction sites, and manufacturing facilities where balanced lifting of wide or irregularly shaped loads is required

Specifications

Lift Height 4
558-0079 MPN: LTHM-490 | LTHM-490 (0.49T) Three-Phase 220V | Spec: 0.49 | Weight: 78.0 | Number of Strings: 1 | Up/Down Speed: 8 | Min Lateral Speed: 9.23 | Max Lateral Speed: 18.8 | Chain Thickness: 6.3 | Lift Height: 4
558-0088 MPN: LTHM-1S | LTHM-1S (1.0T) Three Phase 220V | Spec: 1.0 | Weight: 79.0 | Number of Strings: 1 | Up/Down Speed: 8.2 | Min Lateral Speed: 9.23 | Max Lateral Speed: 18.8 | Chain Thickness: 7.1 | Lift Height: 4
558-0097 MPN: LTHM-2W | LTHM-2W (2.0T) Three-Phase 220V | Spec: 2.0 | Weight: 92.0 | Number of Strings: 2 | Up/Down Speed: 4.1 | Min Lateral Speed: 9.23 | Max Lateral Speed: 18.8 | Chain Thickness: 7.1 | Lift Height: 4
558-0103 MPN: LDSM-1S | LDSM-1S (1.0T) Three Phase 220V | Spec: 1.0 | Weight: 80.0 | Number of Strings: 1 | Up/Down Speed: 8.2 | Min Lateral Speed: 9.23 | Max Lateral Speed: 18.8 | Chain Thickness: 7.1 | Lift Height: 4
558-0112 MPN: LDSM-2W | LDSM-2W (2.0T) Three Phase 220V | Spec: 2.0 | Weight: 94.0 | Number of Strings: 2 | Up/Down Speed: 4.1 | Min Lateral Speed: 9.23 | Max Lateral Speed: 18.8 | Chain Thickness: 7.1 | Lift Height: 4
558-0121 MPN: LDSM-2.8W | LDSM-2.8W (2.8T) Three Phase 220V | Spec: 2.8 | Weight: 102.0 | Number of Strings: 2 | Up/Down Speed: 3.1 | Min Lateral Speed: 14 | Max Lateral Speed: 20 | Chain Thickness: 8 | Lift Height: 4
558-0680 MPN: LTDM-1S | LTDM-1S (1.0T) Three Phase 220V | Spec: 1.0 | Weight: 84.0 | Number of Strings: 1 | Up/Down Speed: 8.2/2 | Min Lateral Speed: 9.23 | Max Lateral Speed: 18.8 | Chain Thickness: 7.1 | Lift Height: 4
558-0699 MPN: LTDM-2W | LTDM-2W (2.0T) Three Phase 220V | Spec: 2.0 | Weight: 98.0 | Number of Strings: 2 | Up/Down Speed: 8.2/2 | Min Lateral Speed: 9.23 | Max Lateral Speed: 18.8 | Chain Thickness: 7.1 | Lift Height: 4
Hoists & WinchesLK
8 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

LK LTHM-490 Chain Hoist (4-Point)

Brand LK·Hoists & Winches

Available part numbers (8)

558-0079, 558-0088, 558-0097, 558-0103, 558-0112, 558-0121, 558-0680, 558-0699

How to order

Send the LK part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
558-0079MPN: LTHM-490 | LTHM-490 (0.49T) Three-Phase 220V | Spec: 0.49 | Weight: 78.0 | Number of Strings: 1 | Up/Down Speed: 8 | Min Lateral Speed: 9.23 | Max Lateral Speed: 18.8 | Chain Thickness: 6.3 | Lift Height: 4
558-0088MPN: LTHM-1S | LTHM-1S (1.0T) Three Phase 220V | Spec: 1.0 | Weight: 79.0 | Number of Strings: 1 | Up/Down Speed: 8.2 | Min Lateral Speed: 9.23 | Max Lateral Speed: 18.8 | Chain Thickness: 7.1 | Lift Height: 4
558-0097MPN: LTHM-2W | LTHM-2W (2.0T) Three-Phase 220V | Spec: 2.0 | Weight: 92.0 | Number of Strings: 2 | Up/Down Speed: 4.1 | Min Lateral Speed: 9.23 | Max Lateral Speed: 18.8 | Chain Thickness: 7.1 | Lift Height: 4
558-0103MPN: LDSM-1S | LDSM-1S (1.0T) Three Phase 220V | Spec: 1.0 | Weight: 80.0 | Number of Strings: 1 | Up/Down Speed: 8.2 | Min Lateral Speed: 9.23 | Max Lateral Speed: 18.8 | Chain Thickness: 7.1 | Lift Height: 4
558-0112MPN: LDSM-2W | LDSM-2W (2.0T) Three Phase 220V | Spec: 2.0 | Weight: 94.0 | Number of Strings: 2 | Up/Down Speed: 4.1 | Min Lateral Speed: 9.23 | Max Lateral Speed: 18.8 | Chain Thickness: 7.1 | Lift Height: 4
558-0121MPN: LDSM-2.8W | LDSM-2.8W (2.8T) Three Phase 220V | Spec: 2.8 | Weight: 102.0 | Number of Strings: 2 | Up/Down Speed: 3.1 | Min Lateral Speed: 14 | Max Lateral Speed: 20 | Chain Thickness: 8 | Lift Height: 4
558-0680MPN: LTDM-1S | LTDM-1S (1.0T) Three Phase 220V | Spec: 1.0 | Weight: 84.0 | Number of Strings: 1 | Up/Down Speed: 8.2/2 | Min Lateral Speed: 9.23 | Max Lateral Speed: 18.8 | Chain Thickness: 7.1 | Lift Height: 4
558-0699MPN: LTDM-2W | LTDM-2W (2.0T) Three Phase 220V | Spec: 2.0 | Weight: 98.0 | Number of Strings: 2 | Up/Down Speed: 8.2/2 | Min Lateral Speed: 9.23 | Max Lateral Speed: 18.8 | Chain Thickness: 7.1 | Lift Height: 4

Need a different model, or a part not listed here? Send us your parts list →
