LS Electric APMC-F Servo Motors 200V (40-80 mm, 0.05-1 kW)

LS Electric APMC-F Servo Motors 200V (40-80 mm, 0.05-1 kW)

LS Electric Xmotion APMC-F 200V flat servo motors in 40, 60 and 80 mm flanges (FAL/FBL/FCL, 50 W to 1 kW) with 18/19-bit serial or 17-bit magnetic encoders.

Key features

  • Compact flat F series motors (FAL 40 mm, FBL 60 mm, FCL 80 mm), made in China (APMC)
  • Encoder M (19-bit, 16-bit multi-turn), M8 (18-bit, FAL only) or Y (17-bit magnetic single-turn)
  • Full order code e.g. APMC-FBL04AMK2 (brake) or APMC-FCL08AYK (magnetic encoder)
  • Shaft K (round key, standard) or N (straight); FAL 40 mm: brake only, no oil seal; FAL015A: no brake
  • Matched to iX7NH, iX7M, L7 series and L7C drives (magnetic encoder versions for L7C)

Specifications

Motor series APMC-F (Xmotion F series, made in China)
Voltage 200 VAC class
Protection Totally enclosed, IP67 (shaft through-hole excluded)
Time rating Continuous
Allowable load inertia 30x (40 mm), 20x (60 mm), 15x (80 mm)
Holding brake DC 24 V, 0.32 / 1.47 / 3.23 N.m (FAL/FBL/FCL)
Ambient 0 to 40 C, 80% RH max, non-condensing
Vibration 49 m/s2 (5G)
Note Magnetic Y with L7C: multi-turn function not available
Source LS Electric Xmotion Servo System catalog (KR, 2024.09), p. 98-99, 114-118
APMC-FALR5A Flange: 40 mm | Rating: 0.05 kW / 0.16 N.m | Rated speed: 3,000 rpm | Encoder: Base model (specify) | Shaft: Specify | Option: Specify
APMC-FALR5AM8K Flange: 40 mm | Rating: 0.05 kW / 0.16 N.m | Rated speed: 3,000 rpm | Encoder: M8: 18-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: None
APMC-FALR5AM8K2 Flange: 40 mm | Rating: 0.05 kW / 0.16 N.m | Rated speed: 3,000 rpm | Encoder: M8: 18-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Brake
APMC-FALR5AM8N Flange: 40 mm | Rating: 0.05 kW / 0.16 N.m | Rated speed: 3,000 rpm | Encoder: M8: 18-bit abs, 16-bit multi-turn | Shaft: Straight | Option: None
APMC-FALR5AM8N2 Flange: 40 mm | Rating: 0.05 kW / 0.16 N.m | Rated speed: 3,000 rpm | Encoder: M8: 18-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Brake
APMC-FALR5AYK Flange: 40 mm | Rating: 0.05 kW / 0.16 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: None
APMC-FALR5AYK2 Flange: 40 mm | Rating: 0.05 kW / 0.16 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Brake
APMC-FALR5AYN Flange: 40 mm | Rating: 0.05 kW / 0.16 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: None
APMC-FALR5AYN2 Flange: 40 mm | Rating: 0.05 kW / 0.16 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Brake
APMC-FAL01A Flange: 40 mm | Rating: 0.1 kW / 0.32 N.m | Rated speed: 3,000 rpm | Encoder: Base model (specify) | Shaft: Specify | Option: Specify
APMC-FAL01AM8K Flange: 40 mm | Rating: 0.1 kW / 0.32 N.m | Rated speed: 3,000 rpm | Encoder: M8: 18-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: None
APMC-FAL01AM8K2 Flange: 40 mm | Rating: 0.1 kW / 0.32 N.m | Rated speed: 3,000 rpm | Encoder: M8: 18-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Brake
APMC-FAL01AM8N Flange: 40 mm | Rating: 0.1 kW / 0.32 N.m | Rated speed: 3,000 rpm | Encoder: M8: 18-bit abs, 16-bit multi-turn | Shaft: Straight | Option: None
APMC-FAL01AM8N2 Flange: 40 mm | Rating: 0.1 kW / 0.32 N.m | Rated speed: 3,000 rpm | Encoder: M8: 18-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Brake
APMC-FAL01AYK Flange: 40 mm | Rating: 0.1 kW / 0.32 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: None
APMC-FAL01AYK2 Flange: 40 mm | Rating: 0.1 kW / 0.32 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Brake
APMC-FAL01AYN Flange: 40 mm | Rating: 0.1 kW / 0.32 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: None
APMC-FAL01AYN2 Flange: 40 mm | Rating: 0.1 kW / 0.32 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Brake
APMC-FAL015A Flange: 40 mm | Rating: 0.15 kW / 0.48 N.m | Rated speed: 3,000 rpm | Encoder: Base model (specify) | Shaft: Specify | Option: Specify
APMC-FAL015AM8K Flange: 40 mm | Rating: 0.15 kW / 0.48 N.m | Rated speed: 3,000 rpm | Encoder: M8: 18-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: None
APMC-FAL015AM8N Flange: 40 mm | Rating: 0.15 kW / 0.48 N.m | Rated speed: 3,000 rpm | Encoder: M8: 18-bit abs, 16-bit multi-turn | Shaft: Straight | Option: None
APMC-FAL015AYK Flange: 40 mm | Rating: 0.15 kW / 0.48 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: None
APMC-FAL015AYN Flange: 40 mm | Rating: 0.15 kW / 0.48 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: None
APMC-FBL01A Flange: 60 mm | Rating: 0.1 kW / 0.32 N.m | Rated speed: 3,000 rpm | Encoder: Base model (specify) | Shaft: Specify | Option: Specify
APMC-FBL01AMK Flange: 60 mm | Rating: 0.1 kW / 0.32 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: None
APMC-FBL01AMK1 Flange: 60 mm | Rating: 0.1 kW / 0.32 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Oil seal
APMC-FBL01AMK2 Flange: 60 mm | Rating: 0.1 kW / 0.32 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Brake
APMC-FBL01AMK3 Flange: 60 mm | Rating: 0.1 kW / 0.32 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Oil seal + brake
APMC-FBL01AMN Flange: 60 mm | Rating: 0.1 kW / 0.32 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: None
APMC-FBL01AMN1 Flange: 60 mm | Rating: 0.1 kW / 0.32 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Oil seal
APMC-FBL01AMN2 Flange: 60 mm | Rating: 0.1 kW / 0.32 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Brake
APMC-FBL01AMN3 Flange: 60 mm | Rating: 0.1 kW / 0.32 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Oil seal + brake
APMC-FBL01AYK Flange: 60 mm | Rating: 0.1 kW / 0.32 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: None
APMC-FBL01AYK1 Flange: 60 mm | Rating: 0.1 kW / 0.32 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Oil seal
APMC-FBL01AYK2 Flange: 60 mm | Rating: 0.1 kW / 0.32 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Brake
APMC-FBL01AYK3 Flange: 60 mm | Rating: 0.1 kW / 0.32 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Oil seal + brake
APMC-FBL01AYN Flange: 60 mm | Rating: 0.1 kW / 0.32 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: None
APMC-FBL01AYN1 Flange: 60 mm | Rating: 0.1 kW / 0.32 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Oil seal
APMC-FBL01AYN2 Flange: 60 mm | Rating: 0.1 kW / 0.32 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Brake
APMC-FBL01AYN3 Flange: 60 mm | Rating: 0.1 kW / 0.32 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Oil seal + brake
APMC-FBL02A Flange: 60 mm | Rating: 0.2 kW / 0.64 N.m | Rated speed: 3,000 rpm | Encoder: Base model (specify) | Shaft: Specify | Option: Specify
APMC-FBL02AMK Flange: 60 mm | Rating: 0.2 kW / 0.64 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: None
APMC-FBL02AMK1 Flange: 60 mm | Rating: 0.2 kW / 0.64 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Oil seal
APMC-FBL02AMK2 Flange: 60 mm | Rating: 0.2 kW / 0.64 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Brake
APMC-FBL02AMK3 Flange: 60 mm | Rating: 0.2 kW / 0.64 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Oil seal + brake
APMC-FBL02AMN Flange: 60 mm | Rating: 0.2 kW / 0.64 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: None
APMC-FBL02AMN1 Flange: 60 mm | Rating: 0.2 kW / 0.64 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Oil seal
APMC-FBL02AMN2 Flange: 60 mm | Rating: 0.2 kW / 0.64 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Brake
APMC-FBL02AMN3 Flange: 60 mm | Rating: 0.2 kW / 0.64 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Oil seal + brake
APMC-FBL02AYK Flange: 60 mm | Rating: 0.2 kW / 0.64 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: None
APMC-FBL02AYK1 Flange: 60 mm | Rating: 0.2 kW / 0.64 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Oil seal
APMC-FBL02AYK2 Flange: 60 mm | Rating: 0.2 kW / 0.64 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Brake
APMC-FBL02AYK3 Flange: 60 mm | Rating: 0.2 kW / 0.64 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Oil seal + brake
APMC-FBL02AYN Flange: 60 mm | Rating: 0.2 kW / 0.64 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: None
APMC-FBL02AYN1 Flange: 60 mm | Rating: 0.2 kW / 0.64 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Oil seal
APMC-FBL02AYN2 Flange: 60 mm | Rating: 0.2 kW / 0.64 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Brake
APMC-FBL02AYN3 Flange: 60 mm | Rating: 0.2 kW / 0.64 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Oil seal + brake
APMC-FBL04A Flange: 60 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: Base model (specify) | Shaft: Specify | Option: Specify
APMC-FBL04AMK Flange: 60 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: None
APMC-FBL04AMK1 Flange: 60 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Oil seal
APMC-FBL04AMK2 Flange: 60 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Brake
APMC-FBL04AMK3 Flange: 60 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Oil seal + brake
APMC-FBL04AMN Flange: 60 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: None
APMC-FBL04AMN1 Flange: 60 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Oil seal
APMC-FBL04AMN2 Flange: 60 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Brake
APMC-FBL04AMN3 Flange: 60 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Oil seal + brake
APMC-FBL04AYK Flange: 60 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: None
APMC-FBL04AYK1 Flange: 60 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Oil seal
APMC-FBL04AYK2 Flange: 60 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Brake
APMC-FBL04AYK3 Flange: 60 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Oil seal + brake
APMC-FBL04AYN Flange: 60 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: None
APMC-FBL04AYN1 Flange: 60 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Oil seal
APMC-FBL04AYN2 Flange: 60 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Brake
APMC-FBL04AYN3 Flange: 60 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Oil seal + brake
APMC-FCL04A Flange: 80 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: Base model (specify) | Shaft: Specify | Option: Specify
APMC-FCL04AMK Flange: 80 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: None
APMC-FCL04AMK1 Flange: 80 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Oil seal
APMC-FCL04AMK2 Flange: 80 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Brake
APMC-FCL04AMK3 Flange: 80 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Oil seal + brake
APMC-FCL04AMN Flange: 80 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: None
APMC-FCL04AMN1 Flange: 80 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Oil seal
APMC-FCL04AMN2 Flange: 80 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Brake
APMC-FCL04AMN3 Flange: 80 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Oil seal + brake
APMC-FCL04AYK Flange: 80 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: None
APMC-FCL04AYK1 Flange: 80 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Oil seal
APMC-FCL04AYK2 Flange: 80 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Brake
APMC-FCL04AYK3 Flange: 80 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Oil seal + brake
APMC-FCL04AYN Flange: 80 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: None
APMC-FCL04AYN1 Flange: 80 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Oil seal
APMC-FCL04AYN2 Flange: 80 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Brake
APMC-FCL04AYN3 Flange: 80 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Oil seal + brake
APMC-FCL06A Flange: 80 mm | Rating: 0.6 kW / 1.91 N.m | Rated speed: 3,000 rpm | Encoder: Base model (specify) | Shaft: Specify | Option: Specify
APMC-FCL06AMK Flange: 80 mm | Rating: 0.6 kW / 1.91 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: None
APMC-FCL06AMK1 Flange: 80 mm | Rating: 0.6 kW / 1.91 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Oil seal
APMC-FCL06AMK2 Flange: 80 mm | Rating: 0.6 kW / 1.91 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Brake
APMC-FCL06AMK3 Flange: 80 mm | Rating: 0.6 kW / 1.91 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Oil seal + brake
APMC-FCL06AMN Flange: 80 mm | Rating: 0.6 kW / 1.91 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: None
APMC-FCL06AMN1 Flange: 80 mm | Rating: 0.6 kW / 1.91 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Oil seal
APMC-FCL06AMN2 Flange: 80 mm | Rating: 0.6 kW / 1.91 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Brake
APMC-FCL06AMN3 Flange: 80 mm | Rating: 0.6 kW / 1.91 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Oil seal + brake
APMC-FCL06AYK Flange: 80 mm | Rating: 0.6 kW / 1.91 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: None
APMC-FCL06AYK1 Flange: 80 mm | Rating: 0.6 kW / 1.91 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Oil seal
APMC-FCL06AYK2 Flange: 80 mm | Rating: 0.6 kW / 1.91 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Brake
APMC-FCL06AYK3 Flange: 80 mm | Rating: 0.6 kW / 1.91 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Oil seal + brake
APMC-FCL06AYN Flange: 80 mm | Rating: 0.6 kW / 1.91 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: None
APMC-FCL06AYN1 Flange: 80 mm | Rating: 0.6 kW / 1.91 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Oil seal
APMC-FCL06AYN2 Flange: 80 mm | Rating: 0.6 kW / 1.91 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Brake
APMC-FCL06AYN3 Flange: 80 mm | Rating: 0.6 kW / 1.91 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Oil seal + brake
APMC-FCL08A Flange: 80 mm | Rating: 0.75 kW / 2.39 N.m | Rated speed: 3,000 rpm | Encoder: Base model (specify) | Shaft: Specify | Option: Specify
APMC-FCL08AMK Flange: 80 mm | Rating: 0.75 kW / 2.39 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: None
APMC-FCL08AMK1 Flange: 80 mm | Rating: 0.75 kW / 2.39 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Oil seal
APMC-FCL08AMK2 Flange: 80 mm | Rating: 0.75 kW / 2.39 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Brake
APMC-FCL08AMK3 Flange: 80 mm | Rating: 0.75 kW / 2.39 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Oil seal + brake
APMC-FCL08AMN Flange: 80 mm | Rating: 0.75 kW / 2.39 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: None
APMC-FCL08AMN1 Flange: 80 mm | Rating: 0.75 kW / 2.39 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Oil seal
APMC-FCL08AMN2 Flange: 80 mm | Rating: 0.75 kW / 2.39 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Brake
APMC-FCL08AMN3 Flange: 80 mm | Rating: 0.75 kW / 2.39 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Oil seal + brake
APMC-FCL08AYK Flange: 80 mm | Rating: 0.75 kW / 2.39 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: None
APMC-FCL08AYK1 Flange: 80 mm | Rating: 0.75 kW / 2.39 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Oil seal
APMC-FCL08AYK2 Flange: 80 mm | Rating: 0.75 kW / 2.39 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Brake
APMC-FCL08AYK3 Flange: 80 mm | Rating: 0.75 kW / 2.39 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Oil seal + brake
APMC-FCL08AYN Flange: 80 mm | Rating: 0.75 kW / 2.39 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: None
APMC-FCL08AYN1 Flange: 80 mm | Rating: 0.75 kW / 2.39 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Oil seal
APMC-FCL08AYN2 Flange: 80 mm | Rating: 0.75 kW / 2.39 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Brake
APMC-FCL08AYN3 Flange: 80 mm | Rating: 0.75 kW / 2.39 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Oil seal + brake
APMC-FCL10A Flange: 80 mm | Rating: 1 kW / 3.18 N.m | Rated speed: 3,000 rpm | Encoder: Base model (specify) | Shaft: Specify | Option: Specify
APMC-FCL10AMK Flange: 80 mm | Rating: 1 kW / 3.18 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: None
APMC-FCL10AMK1 Flange: 80 mm | Rating: 1 kW / 3.18 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Oil seal
APMC-FCL10AMK2 Flange: 80 mm | Rating: 1 kW / 3.18 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Brake
APMC-FCL10AMK3 Flange: 80 mm | Rating: 1 kW / 3.18 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Oil seal + brake
APMC-FCL10AMN Flange: 80 mm | Rating: 1 kW / 3.18 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: None
APMC-FCL10AMN1 Flange: 80 mm | Rating: 1 kW / 3.18 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Oil seal
APMC-FCL10AMN2 Flange: 80 mm | Rating: 1 kW / 3.18 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Brake
APMC-FCL10AMN3 Flange: 80 mm | Rating: 1 kW / 3.18 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Oil seal + brake
APMC-FCL10AYK Flange: 80 mm | Rating: 1 kW / 3.18 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: None
APMC-FCL10AYK1 Flange: 80 mm | Rating: 1 kW / 3.18 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Oil seal
APMC-FCL10AYK2 Flange: 80 mm | Rating: 1 kW / 3.18 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Brake
APMC-FCL10AYK3 Flange: 80 mm | Rating: 1 kW / 3.18 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Oil seal + brake
APMC-FCL10AYN Flange: 80 mm | Rating: 1 kW / 3.18 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: None
APMC-FCL10AYN1 Flange: 80 mm | Rating: 1 kW / 3.18 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Oil seal
APMC-FCL10AYN2 Flange: 80 mm | Rating: 1 kW / 3.18 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Brake
APMC-FCL10AYN3 Flange: 80 mm | Rating: 1 kW / 3.18 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Oil seal + brake
APMC-FCL03D Flange: 80 mm | Rating: 0.3 kW / 1.43 N.m | Rated speed: 2,000 rpm | Encoder: Base model (specify) | Shaft: Specify | Option: Specify
APMC-FCL03DMK Flange: 80 mm | Rating: 0.3 kW / 1.43 N.m | Rated speed: 2,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: None
APMC-FCL03DMK1 Flange: 80 mm | Rating: 0.3 kW / 1.43 N.m | Rated speed: 2,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Oil seal
APMC-FCL03DMK2 Flange: 80 mm | Rating: 0.3 kW / 1.43 N.m | Rated speed: 2,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Brake
APMC-FCL03DMK3 Flange: 80 mm | Rating: 0.3 kW / 1.43 N.m | Rated speed: 2,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Oil seal + brake
APMC-FCL03DMN Flange: 80 mm | Rating: 0.3 kW / 1.43 N.m | Rated speed: 2,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: None
APMC-FCL03DMN1 Flange: 80 mm | Rating: 0.3 kW / 1.43 N.m | Rated speed: 2,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Oil seal
APMC-FCL03DMN2 Flange: 80 mm | Rating: 0.3 kW / 1.43 N.m | Rated speed: 2,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Brake
APMC-FCL03DMN3 Flange: 80 mm | Rating: 0.3 kW / 1.43 N.m | Rated speed: 2,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Oil seal + brake
APMC-FCL03DYK Flange: 80 mm | Rating: 0.3 kW / 1.43 N.m | Rated speed: 2,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: None
APMC-FCL03DYK1 Flange: 80 mm | Rating: 0.3 kW / 1.43 N.m | Rated speed: 2,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Oil seal
APMC-FCL03DYK2 Flange: 80 mm | Rating: 0.3 kW / 1.43 N.m | Rated speed: 2,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Brake
APMC-FCL03DYK3 Flange: 80 mm | Rating: 0.3 kW / 1.43 N.m | Rated speed: 2,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Oil seal + brake
APMC-FCL03DYN Flange: 80 mm | Rating: 0.3 kW / 1.43 N.m | Rated speed: 2,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: None
APMC-FCL03DYN1 Flange: 80 mm | Rating: 0.3 kW / 1.43 N.m | Rated speed: 2,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Oil seal
APMC-FCL03DYN2 Flange: 80 mm | Rating: 0.3 kW / 1.43 N.m | Rated speed: 2,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Brake
APMC-FCL03DYN3 Flange: 80 mm | Rating: 0.3 kW / 1.43 N.m | Rated speed: 2,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Oil seal + brake
APMC-FCL05D Flange: 80 mm | Rating: 0.45 kW / 2.15 N.m | Rated speed: 2,000 rpm | Encoder: Base model (specify) | Shaft: Specify | Option: Specify
APMC-FCL05DMK Flange: 80 mm | Rating: 0.45 kW / 2.15 N.m | Rated speed: 2,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: None
APMC-FCL05DMK1 Flange: 80 mm | Rating: 0.45 kW / 2.15 N.m | Rated speed: 2,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Oil seal
APMC-FCL05DMK2 Flange: 80 mm | Rating: 0.45 kW / 2.15 N.m | Rated speed: 2,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Brake
APMC-FCL05DMK3 Flange: 80 mm | Rating: 0.45 kW / 2.15 N.m | Rated speed: 2,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Oil seal + brake
APMC-FCL05DMN Flange: 80 mm | Rating: 0.45 kW / 2.15 N.m | Rated speed: 2,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: None
APMC-FCL05DMN1 Flange: 80 mm | Rating: 0.45 kW / 2.15 N.m | Rated speed: 2,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Oil seal
APMC-FCL05DMN2 Flange: 80 mm | Rating: 0.45 kW / 2.15 N.m | Rated speed: 2,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Brake
APMC-FCL05DMN3 Flange: 80 mm | Rating: 0.45 kW / 2.15 N.m | Rated speed: 2,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Oil seal + brake
APMC-FCL05DYK Flange: 80 mm | Rating: 0.45 kW / 2.15 N.m | Rated speed: 2,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: None
APMC-FCL05DYK1 Flange: 80 mm | Rating: 0.45 kW / 2.15 N.m | Rated speed: 2,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Oil seal
APMC-FCL05DYK2 Flange: 80 mm | Rating: 0.45 kW / 2.15 N.m | Rated speed: 2,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Brake
APMC-FCL05DYK3 Flange: 80 mm | Rating: 0.45 kW / 2.15 N.m | Rated speed: 2,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Oil seal + brake
APMC-FCL05DYN Flange: 80 mm | Rating: 0.45 kW / 2.15 N.m | Rated speed: 2,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: None
APMC-FCL05DYN1 Flange: 80 mm | Rating: 0.45 kW / 2.15 N.m | Rated speed: 2,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Oil seal
APMC-FCL05DYN2 Flange: 80 mm | Rating: 0.45 kW / 2.15 N.m | Rated speed: 2,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Brake
APMC-FCL05DYN3 Flange: 80 mm | Rating: 0.45 kW / 2.15 N.m | Rated speed: 2,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Oil seal + brake
APMC-FCL06D Flange: 80 mm | Rating: 0.55 kW / 2.63 N.m | Rated speed: 2,000 rpm | Encoder: Base model (specify) | Shaft: Specify | Option: Specify
APMC-FCL06DMK Flange: 80 mm | Rating: 0.55 kW / 2.63 N.m | Rated speed: 2,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: None
APMC-FCL06DMK1 Flange: 80 mm | Rating: 0.55 kW / 2.63 N.m | Rated speed: 2,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Oil seal
APMC-FCL06DMK2 Flange: 80 mm | Rating: 0.55 kW / 2.63 N.m | Rated speed: 2,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Brake
APMC-FCL06DMK3 Flange: 80 mm | Rating: 0.55 kW / 2.63 N.m | Rated speed: 2,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Oil seal + brake
APMC-FCL06DMN Flange: 80 mm | Rating: 0.55 kW / 2.63 N.m | Rated speed: 2,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: None
APMC-FCL06DMN1 Flange: 80 mm | Rating: 0.55 kW / 2.63 N.m | Rated speed: 2,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Oil seal
APMC-FCL06DMN2 Flange: 80 mm | Rating: 0.55 kW / 2.63 N.m | Rated speed: 2,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Brake
APMC-FCL06DMN3 Flange: 80 mm | Rating: 0.55 kW / 2.63 N.m | Rated speed: 2,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Oil seal + brake
APMC-FCL06DYK Flange: 80 mm | Rating: 0.55 kW / 2.63 N.m | Rated speed: 2,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: None
APMC-FCL06DYK1 Flange: 80 mm | Rating: 0.55 kW / 2.63 N.m | Rated speed: 2,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Oil seal
APMC-FCL06DYK2 Flange: 80 mm | Rating: 0.55 kW / 2.63 N.m | Rated speed: 2,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Brake
APMC-FCL06DYK3 Flange: 80 mm | Rating: 0.55 kW / 2.63 N.m | Rated speed: 2,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Oil seal + brake
APMC-FCL06DYN Flange: 80 mm | Rating: 0.55 kW / 2.63 N.m | Rated speed: 2,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: None
APMC-FCL06DYN1 Flange: 80 mm | Rating: 0.55 kW / 2.63 N.m | Rated speed: 2,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Oil seal
APMC-FCL06DYN2 Flange: 80 mm | Rating: 0.55 kW / 2.63 N.m | Rated speed: 2,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Brake
APMC-FCL06DYN3 Flange: 80 mm | Rating: 0.55 kW / 2.63 N.m | Rated speed: 2,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Oil seal + brake
APMC-FCL07D Flange: 80 mm | Rating: 0.65 kW / 3.1 N.m | Rated speed: 2,000 rpm | Encoder: Base model (specify) | Shaft: Specify | Option: Specify
APMC-FCL07DMK Flange: 80 mm | Rating: 0.65 kW / 3.1 N.m | Rated speed: 2,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: None
APMC-FCL07DMK1 Flange: 80 mm | Rating: 0.65 kW / 3.1 N.m | Rated speed: 2,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Oil seal
APMC-FCL07DMK2 Flange: 80 mm | Rating: 0.65 kW / 3.1 N.m | Rated speed: 2,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Brake
APMC-FCL07DMK3 Flange: 80 mm | Rating: 0.65 kW / 3.1 N.m | Rated speed: 2,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Oil seal + brake
APMC-FCL07DMN Flange: 80 mm | Rating: 0.65 kW / 3.1 N.m | Rated speed: 2,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: None
APMC-FCL07DMN1 Flange: 80 mm | Rating: 0.65 kW / 3.1 N.m | Rated speed: 2,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Oil seal
APMC-FCL07DMN2 Flange: 80 mm | Rating: 0.65 kW / 3.1 N.m | Rated speed: 2,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Brake
APMC-FCL07DMN3 Flange: 80 mm | Rating: 0.65 kW / 3.1 N.m | Rated speed: 2,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Oil seal + brake
APMC-FCL07DYK Flange: 80 mm | Rating: 0.65 kW / 3.1 N.m | Rated speed: 2,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: None
APMC-FCL07DYK1 Flange: 80 mm | Rating: 0.65 kW / 3.1 N.m | Rated speed: 2,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Oil seal
APMC-FCL07DYK2 Flange: 80 mm | Rating: 0.65 kW / 3.1 N.m | Rated speed: 2,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Brake
APMC-FCL07DYK3 Flange: 80 mm | Rating: 0.65 kW / 3.1 N.m | Rated speed: 2,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Oil seal + brake
APMC-FCL07DYN Flange: 80 mm | Rating: 0.65 kW / 3.1 N.m | Rated speed: 2,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: None
APMC-FCL07DYN1 Flange: 80 mm | Rating: 0.65 kW / 3.1 N.m | Rated speed: 2,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Oil seal
APMC-FCL07DYN2 Flange: 80 mm | Rating: 0.65 kW / 3.1 N.m | Rated speed: 2,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Brake
APMC-FCL07DYN3 Flange: 80 mm | Rating: 0.65 kW / 3.1 N.m | Rated speed: 2,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Oil seal + brake
Servo MotorsLS Electric
210 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

LS Electric APMC-F Servo Motors 200V (40-80 mm, 0.05-1 kW)

Brand LS Electric·Servo Motors

Available part numbers (210)

APMC-FALR5A, APMC-FALR5AM8K, APMC-FALR5AM8K2, APMC-FALR5AM8N, APMC-FALR5AM8N2, APMC-FALR5AYK, APMC-FALR5AYK2, APMC-FALR5AYN, APMC-FALR5AYN2, APMC-FAL01A + 200 more — see full table ↓

How to order

Send the LS Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
APMC-FALR5AFlange: 40 mm | Rating: 0.05 kW / 0.16 N.m | Rated speed: 3,000 rpm | Encoder: Base model (specify) | Shaft: Specify | Option: Specify
APMC-FALR5AM8KFlange: 40 mm | Rating: 0.05 kW / 0.16 N.m | Rated speed: 3,000 rpm | Encoder: M8: 18-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: None
APMC-FALR5AM8K2Flange: 40 mm | Rating: 0.05 kW / 0.16 N.m | Rated speed: 3,000 rpm | Encoder: M8: 18-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Brake
APMC-FALR5AM8NFlange: 40 mm | Rating: 0.05 kW / 0.16 N.m | Rated speed: 3,000 rpm | Encoder: M8: 18-bit abs, 16-bit multi-turn | Shaft: Straight | Option: None
APMC-FALR5AM8N2Flange: 40 mm | Rating: 0.05 kW / 0.16 N.m | Rated speed: 3,000 rpm | Encoder: M8: 18-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Brake
APMC-FALR5AYKFlange: 40 mm | Rating: 0.05 kW / 0.16 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: None
APMC-FALR5AYK2Flange: 40 mm | Rating: 0.05 kW / 0.16 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Brake
APMC-FALR5AYNFlange: 40 mm | Rating: 0.05 kW / 0.16 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: None
APMC-FALR5AYN2Flange: 40 mm | Rating: 0.05 kW / 0.16 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Brake
APMC-FAL01AFlange: 40 mm | Rating: 0.1 kW / 0.32 N.m | Rated speed: 3,000 rpm | Encoder: Base model (specify) | Shaft: Specify | Option: Specify
APMC-FAL01AM8KFlange: 40 mm | Rating: 0.1 kW / 0.32 N.m | Rated speed: 3,000 rpm | Encoder: M8: 18-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: None
APMC-FAL01AM8K2Flange: 40 mm | Rating: 0.1 kW / 0.32 N.m | Rated speed: 3,000 rpm | Encoder: M8: 18-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Brake
APMC-FAL01AM8NFlange: 40 mm | Rating: 0.1 kW / 0.32 N.m | Rated speed: 3,000 rpm | Encoder: M8: 18-bit abs, 16-bit multi-turn | Shaft: Straight | Option: None
APMC-FAL01AM8N2Flange: 40 mm | Rating: 0.1 kW / 0.32 N.m | Rated speed: 3,000 rpm | Encoder: M8: 18-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Brake
APMC-FAL01AYKFlange: 40 mm | Rating: 0.1 kW / 0.32 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: None
APMC-FAL01AYK2Flange: 40 mm | Rating: 0.1 kW / 0.32 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Brake
APMC-FAL01AYNFlange: 40 mm | Rating: 0.1 kW / 0.32 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: None
APMC-FAL01AYN2Flange: 40 mm | Rating: 0.1 kW / 0.32 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Brake
APMC-FAL015AFlange: 40 mm | Rating: 0.15 kW / 0.48 N.m | Rated speed: 3,000 rpm | Encoder: Base model (specify) | Shaft: Specify | Option: Specify
APMC-FAL015AM8KFlange: 40 mm | Rating: 0.15 kW / 0.48 N.m | Rated speed: 3,000 rpm | Encoder: M8: 18-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: None
APMC-FAL015AM8NFlange: 40 mm | Rating: 0.15 kW / 0.48 N.m | Rated speed: 3,000 rpm | Encoder: M8: 18-bit abs, 16-bit multi-turn | Shaft: Straight | Option: None
APMC-FAL015AYKFlange: 40 mm | Rating: 0.15 kW / 0.48 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: None
APMC-FAL015AYNFlange: 40 mm | Rating: 0.15 kW / 0.48 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: None
APMC-FBL01AFlange: 60 mm | Rating: 0.1 kW / 0.32 N.m | Rated speed: 3,000 rpm | Encoder: Base model (specify) | Shaft: Specify | Option: Specify
APMC-FBL01AMKFlange: 60 mm | Rating: 0.1 kW / 0.32 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: None
APMC-FBL01AMK1Flange: 60 mm | Rating: 0.1 kW / 0.32 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Oil seal
APMC-FBL01AMK2Flange: 60 mm | Rating: 0.1 kW / 0.32 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Brake
APMC-FBL01AMK3Flange: 60 mm | Rating: 0.1 kW / 0.32 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Oil seal + brake
APMC-FBL01AMNFlange: 60 mm | Rating: 0.1 kW / 0.32 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: None
APMC-FBL01AMN1Flange: 60 mm | Rating: 0.1 kW / 0.32 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Oil seal
APMC-FBL01AMN2Flange: 60 mm | Rating: 0.1 kW / 0.32 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Brake
APMC-FBL01AMN3Flange: 60 mm | Rating: 0.1 kW / 0.32 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Oil seal + brake
APMC-FBL01AYKFlange: 60 mm | Rating: 0.1 kW / 0.32 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: None
APMC-FBL01AYK1Flange: 60 mm | Rating: 0.1 kW / 0.32 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Oil seal
APMC-FBL01AYK2Flange: 60 mm | Rating: 0.1 kW / 0.32 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Brake
APMC-FBL01AYK3Flange: 60 mm | Rating: 0.1 kW / 0.32 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Oil seal + brake
APMC-FBL01AYNFlange: 60 mm | Rating: 0.1 kW / 0.32 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: None
APMC-FBL01AYN1Flange: 60 mm | Rating: 0.1 kW / 0.32 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Oil seal
APMC-FBL01AYN2Flange: 60 mm | Rating: 0.1 kW / 0.32 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Brake
APMC-FBL01AYN3Flange: 60 mm | Rating: 0.1 kW / 0.32 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Oil seal + brake
APMC-FBL02AFlange: 60 mm | Rating: 0.2 kW / 0.64 N.m | Rated speed: 3,000 rpm | Encoder: Base model (specify) | Shaft: Specify | Option: Specify
APMC-FBL02AMKFlange: 60 mm | Rating: 0.2 kW / 0.64 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: None
APMC-FBL02AMK1Flange: 60 mm | Rating: 0.2 kW / 0.64 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Oil seal
APMC-FBL02AMK2Flange: 60 mm | Rating: 0.2 kW / 0.64 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Brake
APMC-FBL02AMK3Flange: 60 mm | Rating: 0.2 kW / 0.64 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Oil seal + brake
APMC-FBL02AMNFlange: 60 mm | Rating: 0.2 kW / 0.64 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: None
APMC-FBL02AMN1Flange: 60 mm | Rating: 0.2 kW / 0.64 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Oil seal
APMC-FBL02AMN2Flange: 60 mm | Rating: 0.2 kW / 0.64 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Brake
APMC-FBL02AMN3Flange: 60 mm | Rating: 0.2 kW / 0.64 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Oil seal + brake
APMC-FBL02AYKFlange: 60 mm | Rating: 0.2 kW / 0.64 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: None
APMC-FBL02AYK1Flange: 60 mm | Rating: 0.2 kW / 0.64 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Oil seal
APMC-FBL02AYK2Flange: 60 mm | Rating: 0.2 kW / 0.64 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Brake
APMC-FBL02AYK3Flange: 60 mm | Rating: 0.2 kW / 0.64 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Oil seal + brake
APMC-FBL02AYNFlange: 60 mm | Rating: 0.2 kW / 0.64 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: None
APMC-FBL02AYN1Flange: 60 mm | Rating: 0.2 kW / 0.64 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Oil seal
APMC-FBL02AYN2Flange: 60 mm | Rating: 0.2 kW / 0.64 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Brake
APMC-FBL02AYN3Flange: 60 mm | Rating: 0.2 kW / 0.64 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Oil seal + brake
APMC-FBL04AFlange: 60 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: Base model (specify) | Shaft: Specify | Option: Specify
APMC-FBL04AMKFlange: 60 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: None
APMC-FBL04AMK1Flange: 60 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Oil seal
APMC-FBL04AMK2Flange: 60 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Brake
APMC-FBL04AMK3Flange: 60 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Oil seal + brake
APMC-FBL04AMNFlange: 60 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: None
APMC-FBL04AMN1Flange: 60 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Oil seal
APMC-FBL04AMN2Flange: 60 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Brake
APMC-FBL04AMN3Flange: 60 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Oil seal + brake
APMC-FBL04AYKFlange: 60 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: None
APMC-FBL04AYK1Flange: 60 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Oil seal
APMC-FBL04AYK2Flange: 60 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Brake
APMC-FBL04AYK3Flange: 60 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Oil seal + brake
APMC-FBL04AYNFlange: 60 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: None
APMC-FBL04AYN1Flange: 60 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Oil seal
APMC-FBL04AYN2Flange: 60 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Brake
APMC-FBL04AYN3Flange: 60 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Oil seal + brake
APMC-FCL04AFlange: 80 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: Base model (specify) | Shaft: Specify | Option: Specify
APMC-FCL04AMKFlange: 80 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: None
APMC-FCL04AMK1Flange: 80 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Oil seal
APMC-FCL04AMK2Flange: 80 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Brake
APMC-FCL04AMK3Flange: 80 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Oil seal + brake
APMC-FCL04AMNFlange: 80 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: None
APMC-FCL04AMN1Flange: 80 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Oil seal
APMC-FCL04AMN2Flange: 80 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Brake
APMC-FCL04AMN3Flange: 80 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Oil seal + brake
APMC-FCL04AYKFlange: 80 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: None
APMC-FCL04AYK1Flange: 80 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Oil seal
APMC-FCL04AYK2Flange: 80 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Brake
APMC-FCL04AYK3Flange: 80 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Oil seal + brake
APMC-FCL04AYNFlange: 80 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: None
APMC-FCL04AYN1Flange: 80 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Oil seal
APMC-FCL04AYN2Flange: 80 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Brake
APMC-FCL04AYN3Flange: 80 mm | Rating: 0.4 kW / 1.27 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Oil seal + brake
APMC-FCL06AFlange: 80 mm | Rating: 0.6 kW / 1.91 N.m | Rated speed: 3,000 rpm | Encoder: Base model (specify) | Shaft: Specify | Option: Specify
APMC-FCL06AMKFlange: 80 mm | Rating: 0.6 kW / 1.91 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: None
APMC-FCL06AMK1Flange: 80 mm | Rating: 0.6 kW / 1.91 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Oil seal
APMC-FCL06AMK2Flange: 80 mm | Rating: 0.6 kW / 1.91 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Brake
APMC-FCL06AMK3Flange: 80 mm | Rating: 0.6 kW / 1.91 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Oil seal + brake
APMC-FCL06AMNFlange: 80 mm | Rating: 0.6 kW / 1.91 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: None
APMC-FCL06AMN1Flange: 80 mm | Rating: 0.6 kW / 1.91 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Oil seal
APMC-FCL06AMN2Flange: 80 mm | Rating: 0.6 kW / 1.91 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Brake
APMC-FCL06AMN3Flange: 80 mm | Rating: 0.6 kW / 1.91 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Oil seal + brake
APMC-FCL06AYKFlange: 80 mm | Rating: 0.6 kW / 1.91 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: None
APMC-FCL06AYK1Flange: 80 mm | Rating: 0.6 kW / 1.91 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Oil seal
APMC-FCL06AYK2Flange: 80 mm | Rating: 0.6 kW / 1.91 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Brake
APMC-FCL06AYK3Flange: 80 mm | Rating: 0.6 kW / 1.91 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Oil seal + brake
APMC-FCL06AYNFlange: 80 mm | Rating: 0.6 kW / 1.91 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: None
APMC-FCL06AYN1Flange: 80 mm | Rating: 0.6 kW / 1.91 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Oil seal
APMC-FCL06AYN2Flange: 80 mm | Rating: 0.6 kW / 1.91 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Brake
APMC-FCL06AYN3Flange: 80 mm | Rating: 0.6 kW / 1.91 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Oil seal + brake
APMC-FCL08AFlange: 80 mm | Rating: 0.75 kW / 2.39 N.m | Rated speed: 3,000 rpm | Encoder: Base model (specify) | Shaft: Specify | Option: Specify
APMC-FCL08AMKFlange: 80 mm | Rating: 0.75 kW / 2.39 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: None
APMC-FCL08AMK1Flange: 80 mm | Rating: 0.75 kW / 2.39 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Oil seal
APMC-FCL08AMK2Flange: 80 mm | Rating: 0.75 kW / 2.39 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Brake
APMC-FCL08AMK3Flange: 80 mm | Rating: 0.75 kW / 2.39 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Oil seal + brake
APMC-FCL08AMNFlange: 80 mm | Rating: 0.75 kW / 2.39 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: None
APMC-FCL08AMN1Flange: 80 mm | Rating: 0.75 kW / 2.39 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Oil seal
APMC-FCL08AMN2Flange: 80 mm | Rating: 0.75 kW / 2.39 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Brake
APMC-FCL08AMN3Flange: 80 mm | Rating: 0.75 kW / 2.39 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Oil seal + brake
APMC-FCL08AYKFlange: 80 mm | Rating: 0.75 kW / 2.39 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: None
APMC-FCL08AYK1Flange: 80 mm | Rating: 0.75 kW / 2.39 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Oil seal
APMC-FCL08AYK2Flange: 80 mm | Rating: 0.75 kW / 2.39 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Brake
APMC-FCL08AYK3Flange: 80 mm | Rating: 0.75 kW / 2.39 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Oil seal + brake
APMC-FCL08AYNFlange: 80 mm | Rating: 0.75 kW / 2.39 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: None
APMC-FCL08AYN1Flange: 80 mm | Rating: 0.75 kW / 2.39 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Oil seal
APMC-FCL08AYN2Flange: 80 mm | Rating: 0.75 kW / 2.39 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Brake
APMC-FCL08AYN3Flange: 80 mm | Rating: 0.75 kW / 2.39 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Oil seal + brake
APMC-FCL10AFlange: 80 mm | Rating: 1 kW / 3.18 N.m | Rated speed: 3,000 rpm | Encoder: Base model (specify) | Shaft: Specify | Option: Specify
APMC-FCL10AMKFlange: 80 mm | Rating: 1 kW / 3.18 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: None
APMC-FCL10AMK1Flange: 80 mm | Rating: 1 kW / 3.18 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Oil seal
APMC-FCL10AMK2Flange: 80 mm | Rating: 1 kW / 3.18 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Brake
APMC-FCL10AMK3Flange: 80 mm | Rating: 1 kW / 3.18 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Oil seal + brake
APMC-FCL10AMNFlange: 80 mm | Rating: 1 kW / 3.18 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: None
APMC-FCL10AMN1Flange: 80 mm | Rating: 1 kW / 3.18 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Oil seal
APMC-FCL10AMN2Flange: 80 mm | Rating: 1 kW / 3.18 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Brake
APMC-FCL10AMN3Flange: 80 mm | Rating: 1 kW / 3.18 N.m | Rated speed: 3,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Oil seal + brake
APMC-FCL10AYKFlange: 80 mm | Rating: 1 kW / 3.18 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: None
APMC-FCL10AYK1Flange: 80 mm | Rating: 1 kW / 3.18 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Oil seal
APMC-FCL10AYK2Flange: 80 mm | Rating: 1 kW / 3.18 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Brake
APMC-FCL10AYK3Flange: 80 mm | Rating: 1 kW / 3.18 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Oil seal + brake
APMC-FCL10AYNFlange: 80 mm | Rating: 1 kW / 3.18 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: None
APMC-FCL10AYN1Flange: 80 mm | Rating: 1 kW / 3.18 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Oil seal
APMC-FCL10AYN2Flange: 80 mm | Rating: 1 kW / 3.18 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Brake
APMC-FCL10AYN3Flange: 80 mm | Rating: 1 kW / 3.18 N.m | Rated speed: 3,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Oil seal + brake
APMC-FCL03DFlange: 80 mm | Rating: 0.3 kW / 1.43 N.m | Rated speed: 2,000 rpm | Encoder: Base model (specify) | Shaft: Specify | Option: Specify
APMC-FCL03DMKFlange: 80 mm | Rating: 0.3 kW / 1.43 N.m | Rated speed: 2,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: None
APMC-FCL03DMK1Flange: 80 mm | Rating: 0.3 kW / 1.43 N.m | Rated speed: 2,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Oil seal
APMC-FCL03DMK2Flange: 80 mm | Rating: 0.3 kW / 1.43 N.m | Rated speed: 2,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Brake
APMC-FCL03DMK3Flange: 80 mm | Rating: 0.3 kW / 1.43 N.m | Rated speed: 2,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Oil seal + brake
APMC-FCL03DMNFlange: 80 mm | Rating: 0.3 kW / 1.43 N.m | Rated speed: 2,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: None
APMC-FCL03DMN1Flange: 80 mm | Rating: 0.3 kW / 1.43 N.m | Rated speed: 2,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Oil seal
APMC-FCL03DMN2Flange: 80 mm | Rating: 0.3 kW / 1.43 N.m | Rated speed: 2,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Brake
APMC-FCL03DMN3Flange: 80 mm | Rating: 0.3 kW / 1.43 N.m | Rated speed: 2,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Oil seal + brake
APMC-FCL03DYKFlange: 80 mm | Rating: 0.3 kW / 1.43 N.m | Rated speed: 2,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: None
APMC-FCL03DYK1Flange: 80 mm | Rating: 0.3 kW / 1.43 N.m | Rated speed: 2,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Oil seal
APMC-FCL03DYK2Flange: 80 mm | Rating: 0.3 kW / 1.43 N.m | Rated speed: 2,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Brake
APMC-FCL03DYK3Flange: 80 mm | Rating: 0.3 kW / 1.43 N.m | Rated speed: 2,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Oil seal + brake
APMC-FCL03DYNFlange: 80 mm | Rating: 0.3 kW / 1.43 N.m | Rated speed: 2,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: None
APMC-FCL03DYN1Flange: 80 mm | Rating: 0.3 kW / 1.43 N.m | Rated speed: 2,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Oil seal
APMC-FCL03DYN2Flange: 80 mm | Rating: 0.3 kW / 1.43 N.m | Rated speed: 2,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Brake
APMC-FCL03DYN3Flange: 80 mm | Rating: 0.3 kW / 1.43 N.m | Rated speed: 2,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Oil seal + brake
APMC-FCL05DFlange: 80 mm | Rating: 0.45 kW / 2.15 N.m | Rated speed: 2,000 rpm | Encoder: Base model (specify) | Shaft: Specify | Option: Specify
APMC-FCL05DMKFlange: 80 mm | Rating: 0.45 kW / 2.15 N.m | Rated speed: 2,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: None
APMC-FCL05DMK1Flange: 80 mm | Rating: 0.45 kW / 2.15 N.m | Rated speed: 2,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Oil seal
APMC-FCL05DMK2Flange: 80 mm | Rating: 0.45 kW / 2.15 N.m | Rated speed: 2,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Brake
APMC-FCL05DMK3Flange: 80 mm | Rating: 0.45 kW / 2.15 N.m | Rated speed: 2,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Oil seal + brake
APMC-FCL05DMNFlange: 80 mm | Rating: 0.45 kW / 2.15 N.m | Rated speed: 2,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: None
APMC-FCL05DMN1Flange: 80 mm | Rating: 0.45 kW / 2.15 N.m | Rated speed: 2,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Oil seal
APMC-FCL05DMN2Flange: 80 mm | Rating: 0.45 kW / 2.15 N.m | Rated speed: 2,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Brake
APMC-FCL05DMN3Flange: 80 mm | Rating: 0.45 kW / 2.15 N.m | Rated speed: 2,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Oil seal + brake
APMC-FCL05DYKFlange: 80 mm | Rating: 0.45 kW / 2.15 N.m | Rated speed: 2,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: None
APMC-FCL05DYK1Flange: 80 mm | Rating: 0.45 kW / 2.15 N.m | Rated speed: 2,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Oil seal
APMC-FCL05DYK2Flange: 80 mm | Rating: 0.45 kW / 2.15 N.m | Rated speed: 2,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Brake
APMC-FCL05DYK3Flange: 80 mm | Rating: 0.45 kW / 2.15 N.m | Rated speed: 2,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Oil seal + brake
APMC-FCL05DYNFlange: 80 mm | Rating: 0.45 kW / 2.15 N.m | Rated speed: 2,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: None
APMC-FCL05DYN1Flange: 80 mm | Rating: 0.45 kW / 2.15 N.m | Rated speed: 2,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Oil seal
APMC-FCL05DYN2Flange: 80 mm | Rating: 0.45 kW / 2.15 N.m | Rated speed: 2,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Brake
APMC-FCL05DYN3Flange: 80 mm | Rating: 0.45 kW / 2.15 N.m | Rated speed: 2,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Oil seal + brake
APMC-FCL06DFlange: 80 mm | Rating: 0.55 kW / 2.63 N.m | Rated speed: 2,000 rpm | Encoder: Base model (specify) | Shaft: Specify | Option: Specify
APMC-FCL06DMKFlange: 80 mm | Rating: 0.55 kW / 2.63 N.m | Rated speed: 2,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: None
APMC-FCL06DMK1Flange: 80 mm | Rating: 0.55 kW / 2.63 N.m | Rated speed: 2,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Oil seal
APMC-FCL06DMK2Flange: 80 mm | Rating: 0.55 kW / 2.63 N.m | Rated speed: 2,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Brake
APMC-FCL06DMK3Flange: 80 mm | Rating: 0.55 kW / 2.63 N.m | Rated speed: 2,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Oil seal + brake
APMC-FCL06DMNFlange: 80 mm | Rating: 0.55 kW / 2.63 N.m | Rated speed: 2,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: None
APMC-FCL06DMN1Flange: 80 mm | Rating: 0.55 kW / 2.63 N.m | Rated speed: 2,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Oil seal
APMC-FCL06DMN2Flange: 80 mm | Rating: 0.55 kW / 2.63 N.m | Rated speed: 2,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Brake
APMC-FCL06DMN3Flange: 80 mm | Rating: 0.55 kW / 2.63 N.m | Rated speed: 2,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Oil seal + brake
APMC-FCL06DYKFlange: 80 mm | Rating: 0.55 kW / 2.63 N.m | Rated speed: 2,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: None
APMC-FCL06DYK1Flange: 80 mm | Rating: 0.55 kW / 2.63 N.m | Rated speed: 2,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Oil seal
APMC-FCL06DYK2Flange: 80 mm | Rating: 0.55 kW / 2.63 N.m | Rated speed: 2,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Brake
APMC-FCL06DYK3Flange: 80 mm | Rating: 0.55 kW / 2.63 N.m | Rated speed: 2,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Oil seal + brake
APMC-FCL06DYNFlange: 80 mm | Rating: 0.55 kW / 2.63 N.m | Rated speed: 2,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: None
APMC-FCL06DYN1Flange: 80 mm | Rating: 0.55 kW / 2.63 N.m | Rated speed: 2,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Oil seal
APMC-FCL06DYN2Flange: 80 mm | Rating: 0.55 kW / 2.63 N.m | Rated speed: 2,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Brake
APMC-FCL06DYN3Flange: 80 mm | Rating: 0.55 kW / 2.63 N.m | Rated speed: 2,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Oil seal + brake
APMC-FCL07DFlange: 80 mm | Rating: 0.65 kW / 3.1 N.m | Rated speed: 2,000 rpm | Encoder: Base model (specify) | Shaft: Specify | Option: Specify
APMC-FCL07DMKFlange: 80 mm | Rating: 0.65 kW / 3.1 N.m | Rated speed: 2,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: None
APMC-FCL07DMK1Flange: 80 mm | Rating: 0.65 kW / 3.1 N.m | Rated speed: 2,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Oil seal
APMC-FCL07DMK2Flange: 80 mm | Rating: 0.65 kW / 3.1 N.m | Rated speed: 2,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Brake
APMC-FCL07DMK3Flange: 80 mm | Rating: 0.65 kW / 3.1 N.m | Rated speed: 2,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Key, one end round (std) | Option: Oil seal + brake
APMC-FCL07DMNFlange: 80 mm | Rating: 0.65 kW / 3.1 N.m | Rated speed: 2,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: None
APMC-FCL07DMN1Flange: 80 mm | Rating: 0.65 kW / 3.1 N.m | Rated speed: 2,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Oil seal
APMC-FCL07DMN2Flange: 80 mm | Rating: 0.65 kW / 3.1 N.m | Rated speed: 2,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Brake
APMC-FCL07DMN3Flange: 80 mm | Rating: 0.65 kW / 3.1 N.m | Rated speed: 2,000 rpm | Encoder: M: 19-bit abs, 16-bit multi-turn | Shaft: Straight | Option: Oil seal + brake
APMC-FCL07DYKFlange: 80 mm | Rating: 0.65 kW / 3.1 N.m | Rated speed: 2,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: None
APMC-FCL07DYK1Flange: 80 mm | Rating: 0.65 kW / 3.1 N.m | Rated speed: 2,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Oil seal
APMC-FCL07DYK2Flange: 80 mm | Rating: 0.65 kW / 3.1 N.m | Rated speed: 2,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Brake
APMC-FCL07DYK3Flange: 80 mm | Rating: 0.65 kW / 3.1 N.m | Rated speed: 2,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Key, one end round (std) | Option: Oil seal + brake
APMC-FCL07DYNFlange: 80 mm | Rating: 0.65 kW / 3.1 N.m | Rated speed: 2,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: None
APMC-FCL07DYN1Flange: 80 mm | Rating: 0.65 kW / 3.1 N.m | Rated speed: 2,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Oil seal
APMC-FCL07DYN2Flange: 80 mm | Rating: 0.65 kW / 3.1 N.m | Rated speed: 2,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Brake
APMC-FCL07DYN3Flange: 80 mm | Rating: 0.65 kW / 3.1 N.m | Rated speed: 2,000 rpm | Encoder: Y: 17-bit magnetic single-turn | Shaft: Straight | Option: Oil seal + brake

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Motors & Gearheads →
