    LS Electric iRU Regenerative Unit 400V 7.5-280 kW (Discontinued)

    LS Electric iRU Regenerative Unit 400V 7.5-280 kW (Discontinued)

    The LS Electric Starvert iRU regenerative braking unit (400 V class, 7.5-280 kW, 25% ED), which returns AC drive braking energy to the mains instead of a braking resistor, is discontinued; these codes are offered as replacement spares.

    Key features

    • Replaces braking unit and resistor; regenerates energy to the 380-480 VAC supply
    • Typical use: elevators, hoists and other regenerative loads
    • Braking torque 150% 1 s, 100% 100 s, 35% continuous; 25% ED rating
    • RUNF / RUNS / EST / RST inputs, fault relay and 24 VDC status output
    • Overcurrent, overload and DC overvoltage (approx. 850 VDC) protection
    • "F" models (up to 22 kW) with built-in EMC filter

    Specifications

    Series Starvert iRU
    Status Discontinued (spares)
    Voltage class 400 V
    DC input voltage 400-800 VDC
    AC supply 380-480 VAC 50/60 Hz
    Voltage tolerance -10% to +10%
    Frequency tolerance +/-3 Hz / 300 ms
    Duty 25% ED
    Braking torque 150% 1 s, 100% 100 s, 35% continuous
    Source LS Electric iRU catalog (2016-11), p. 8-9
    iRU-0075-4-25 Drive rating: 7.5 kW | DC input: 12.3 A avg | AC output: 13.5 A rms | EMC filter: None
    iRU-0075-4-25F Drive rating: 7.5 kW | DC input: 12.3 A avg | AC output: 13.5 A rms | EMC filter: Built-in
    iRU-0150-4-25 Drive rating: 15 kW | DC input: 25.5 A avg | AC output: 27.5 A rms | EMC filter: None
    iRU-0150-4-25F Drive rating: 15 kW | DC input: 25.5 A avg | AC output: 27.5 A rms | EMC filter: Built-in
    iRU-0220-4-25 Drive rating: 22 kW | DC input: 36.0 A avg | AC output: 39.2 A rms | EMC filter: None
    iRU-0220-4-25F Drive rating: 22 kW | DC input: 36.0 A avg | AC output: 39.2 A rms | EMC filter: Built-in
    iRU-0370-4-25 Drive rating: 37 kW | DC input: 60.2 A avg | AC output: 64.6 A rms | EMC filter: None
    iRU-0450-4-25 Drive rating: 45 kW | DC input: 72.7 A avg | AC output: 77.9 A rms | EMC filter: None
    iRU-0550-4-25 Drive rating: 55 kW | DC input: 88.6 A avg | AC output: 94.7 A rms | EMC filter: None
    iRU-0750-4-25 Drive rating: 75 kW | DC input: 121 A avg | AC output: 125.5 A rms | EMC filter: None
    iRU-0900-4-25 Drive rating: 90 kW | DC input: 147 A avg | AC output: 151 A rms | EMC filter: None
    iRU-1100-4-25 Drive rating: 110 kW | DC input: 188.6 A avg | AC output: 187.5 A rms | EMC filter: None
    iRU-1320-4-25 Drive rating: 132 kW | DC input: 214.8 A avg | AC output: 208.8 A rms | EMC filter: None
    iRU-1600-4-25 Drive rating: 160 kW | DC input: 259.7 A avg | AC output: 250 A rms | EMC filter: None
    iRU-2200-4-25 Drive rating: 220 kW | DC input: 352 A avg | AC output: 328 A rms | EMC filter: None
    iRU-2800-4-25 Drive rating: 280 kW | DC input: 415.2 A avg | AC output: 401.4 A rms | EMC filter: None
    Drive OptionsLS Electric
    16 product codes available in this family
    Sourced direct from KoreaExport-ready supplyCompetitive pricing
    RFQ List 0 Email about this

    Need a different model, or a part not listed here? Send us your parts list →

    LS Electric iRU Regenerative Unit 400V 7.5-280 kW (Discontinued)

    Brand LS Electric·Drive Options

    Available part numbers (16)

    iRU-0075-4-25, iRU-0075-4-25F, iRU-0150-4-25, iRU-0150-4-25F, iRU-0220-4-25, iRU-0220-4-25F, iRU-0370-4-25, iRU-0450-4-25, iRU-0550-4-25, iRU-0750-4-25 + 6 more — see full table ↓
